Parker PSD1 User manual

192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface
192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface 09.09.15 07:29 1 (6)
192-011005N1
2015-09
PSD1: Parker Servo Drive
PSD1 Softmotion / Drive-Interface
Installation Guide

192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface
192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface 09.09.15 07:29 2 (6)
Windows NT®, Windows 2000™, Windows XP™, Windows Vista, Windows 7 are trademarks of Microsoft
Corporation.
EtherCAT® is a registered trademark and a patented technology of Beckhoff Automation GmbH,
Germany.
CoDeSys® is a registered trademark of 3S-Smart Software Solutions GmbH.
PROFINET is a registered trademark of Profibus and PROFINET International.
Ethernet/IP is a trademark of Open DeviceNet Vendor Association.
Non-warranty clause
We checked the contents of this publication for compliance with the associated
hard and software. We can, however, not exclude discrepancies and do therefore
not accept any liability for the exact compliance. The information in this publication
is regularly checked, necessary corrections will be part of the subsequent
publications.
German Master created.
Production site:
Germany
Parker Hannifin Manufacturing Germany GmbH & Co. KG
Electromechanical Automation Europe [EME]
Robert-Bosch-Strasse 22
77656 Offenburg (Germany)
Tel.: + 49 (0781) 509-0
Fax: + 49 (0781) 509-98176
Internet:
www.parker.com/eme
http://www.parker.com/eme
E-mail:
[e-mail]
mailto:[e-mail]
Parker Hannifin GmbH - registered office: Bielefeld HRB 35489
Management Board: Ellen Raahede Secher, Dr.-Ing. Hans-Jürgen Haas, Günter Schrank, Kees Veraart - Chairman of the board: Hansgeorg
Greuner
Italy:
Parker Hannifin Manufacturing Srl
Electromechanical Automation Europe [EME]
Via C. Gounod, 1
20092 Cinisello Balsamo (Milano), Italy
Tel.: + 39 (0)2 361081
Fax: + 39 (0)2 36108400
Internet:
www.parker.com/eme
http://www.parker.com/eme
E-mail:
[e-mail]
mailto:[e-mail]
Location USA:
Parker Hannifin Corporation • Electromechanical Automation
5500 Business Park Drive • Rohnert Park, CA 94928
Phone #: [phone] • FAX #: [phone]
E-mail:
[e-mail]
mailto:[e-mail]
• Internet:
www.parker.com/emn
http://www.parker.com/emn

192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface
09.09.15 07:29 3 (6)
PSD1 Softmotion/Drive-Interface Installation Guide
Please download the files form the PSD Download page:
http://solutions.parker.com/psd_support
and open the zip file
1. Copy all files to local folder
2. Run CoDeSys
3. Select: <Tools> <Library Repository>
4. Click “Install…”, select “SM3_Drive_ETC_Parker_PSD.library” in the used folder and
click “Open” (“Öffnen”)

192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface
09.09.15 07:29 4 (6)
5. Wait till ready, then close this window
6. Select: <Tools> <Device Repository>

192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface
09.09.15 07:29 5 (6)
7. Click “Install…”
8. Click “Install…” and pre-select “Device description files”

192-011005N1 2015-09 PSD1 Softmotion / Drive-Interface
09.09.15 07:29 6 (6)
9. Select all remaining files and click “Open” (“Öffnen”)
10. Wait till ready, then close this window
