Parkside PAA 20-Li B2 User manual

CORDLESS BATTERY ADAPTOR PAA 20-Li B2
CORDLESS BATTERY ADAPTOR
Translation of the original instructions
АКУМУЛАТОРЕН АДАПТЕР
Превод на оригиналното ръководство за
експлоатация
ΑΝΤΑΠΤΟΡΑΣ
ΕΠΑΝΑΦΟΡΤΙΖΟΜΕΝΟ
Μετάφραση των αυθεντικών οδηγιών
λειτουργίας
AKKU ADAPTER
Originalbetriebsanleitung
AKU ADAPTER
Prevod originalnog uputstva za upotrebu
IAN 326369_1904

GB/CY Translation of the original instructions Page 1
RS Prevod originalnog uputstva za upotrebu Strana 15
BG Превод на оригиналното ръководство за
експлоатация Cтраница 29
GR/CY Μετάφραση των αυθεντικών οδηγιών
λειτουργίας Σελίδα 45
DE/AT/CH Originalbetriebsanleitung Seite 59
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Pre čitanja rasklopite obe strane sa slikama te se upoznajte sa svim funkcija-
ma uređaja.
Преди да прочетете отворете страницата с фигурите и след това се
запознайте с всички функции на уреда.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειω-
θείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

B
C
A

Charging
times
Charging
currents
2 Ah
Battery pack
PAP 20 A1
3 Ah
Battery pack
PAP 20 A2
4 Ah
Battery pack
PAP 20 A3
max. 2.4 A
Charger
PLG 20 A1
60 min
2.4 A
90 min
2.4 A
120 min
2.4 A
max. 3.5 A
Charger
PLG 20 A2
60 min
2.4 A
60 min
3.5 A
80 min
3.5 A
max. 4.5 A
Charger
PLG 20 A3
45 min
3.5 A
45 min
4.5 A
60 min
4.5 A

All Parkside tools and the chargers PLG 20 A1 / PLG 20 A2 /
PLG 20 A3 of the X20V Team series are compatible with the PAP 20 A1 /
PAP20A2 / PAP 20 A3 battery pack.
20V max.
18V

PAA 20-Li B2 GB│CY │ 1 ■
Contents
Introduction...................................2
Intended use..........................................2
Features .............................................3
Package contents ......................................3
Technical specifications .................................3
Safety information .............................4
Personal safety ........................................4
Use (see fig. A) ................................5
LED light (see fig. B) ....................................5
Charging/operating a USB device (see fig. C) ...............6
Maintenance and cleaning.......................6
Storage ......................................7
Disposal......................................7
Kompernass Handels GmbH warranty ............8
Service ......................................11
Importer ....................................11
Translation of the original Conformity Declaration ..12

PAA 20-Li B2
■ 2 │ GB│CY
BATTERY ADAPTER PAA 20-Li B2
Introduction
Congratulations on the purchase of your new appliance. You have
chosen a high-quality product. The operating instructions are part of
this product. They contain important information about safety, usage
and disposal. Before using the product, please familiarise yourself
with all of the operating and safety instructions. Use the product only
as described and for the range of applications specified. Please also
pass these operating instructions on to any future owner.
Intended use
The battery adapter can be used as a charging station or power
source via the two USB ports (only in conjunction with a battery
from the Parkside X 20 V Team series). The cordless LED working
light is not suitable for lighting rooms in houses. Any other usage or
modification of the appliance is deemed to be improper and carries
a significant risk of accidents. The manufacturer accepts no responsi-
bility for damage(s) resulting from improper usage. This appliance is
intended for domestic use only.
Symbols on the appliance:
Read the operating instructions before use.
The cordless LED working light is not suitable for
lighting rooms in houses.
Protection class III/ (protection by extra-low
voltage)
CAUTION! Do not stare at operating lamp. Possibly
dangerous optical radiation emitted from this product.

PAA 20-Li B2 GB│CY │ 3 ■
Features
LED light
ON/OFF switch
Belt clip
Control LED
USB port
Battery adapter
Battery (not included)
Release button (not included)
Package contents
1 battery adapter with belt clip
1 set of operating instructions
Technical specifications
Input voltage: 20 V (DC)
Output: 2 x USB 5 V (DC); 2.4 A
Colour value proportions: x = 0,2488 y = 0,2314

PAA 20-Li B2
■ 4 │ GB│CY
Safety information
ATTENTION!
► Observe the safety instructions given in the operating manual
of your Parkside X 20 V Team series battery.
► The operating instructions are an integral part of this appliance.
They contain important information about safety, usage and
disposal. Before using the appliance, please familiarise yourself
with all operating and safety instructions. Use this appliance only
as described and for the areas of applications specified. Keep
the operating instructions in a safe place and hand over all
documents when passing the appliance on to any future owner.
Personal safety
■ Do not aim the light beam of the LED into the eyes of people or
animals.
This could be harmful to the eyes.

PAA 20-Li B2 GB│CY │ 5 ■
Use (see fig. A)
♦ Slide the battery adapter onto a charged battery .
It clicks into place audibly.
LED light (see fig. B)
Switching on
♦ Press the ON/OFF switch to activate the battery adapter .
The control LED flashes four times and then lights up.
♦ Press the On/Off switch a second time to turn on the LED light .
The control LED only lights up for a short time and can only be
activated during this time.
Switching off
♦ Press the ON/OFF switch again.
The control LED goes out after a short time.

PAA 20-Li B2
■ 6 │ GB│CY
Charging/operating a USB device (see fig. C)
♦ Connect your USB device to the USB port of the battery
adapter .
♦ Press the ON/OFF switch to activate the battery adapter .
The control LED flashes four times and then lights up. The con-
trol LED lights up permanently to indicate the power supply.
Your device can now be charged or operated on the battery
adapter .
♦ To turn off the USB port , press the ON/OFF switch again
for around two seconds.
The LED light lights up briefly and the power supply to the
USB device is disconnected.
The control LED goes out after a short time.
♦ If you are no longer using or charging your device, disconnect it
from the battery adapter .
Maintenance and cleaning
WARNING! RISK OF INJURY! Disconnect the
appliance from the battery before cleaning.
Do not spray the appliance or place it in water.
Risk of injury due to electric shock.
■ The appliance is maintenance-free.
■ Use a damp cloth or brush for cleaning.
■ Do not use cleaning agents or solvents.
This could cause irreparable damage to the appliance.
NOTE
► Replacement parts not listed (such as carbon brushes,
switches) can be ordered via our service hotline.

PAA 20-Li B2 GB│CY │ 7 ■
Storage
■ Store the appliance in a frost-free, dry and dust-protected place,
out of the reach of children.
Disposal
The packaging consists of environmentally friendly material.
It can be disposed of in local recycling containers.
Do not dispose of the appliance in the normal
domestic waste!
Your local community or municipal authorities can provide information
on how to dispose of the worn-out appliance.
Dispose of the packaging in an environmentally friendly
manner.
Note the labelling on the packaging and separate
the packaging material components for disposal if
necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following
meanings:
1–7: plastics,
20–22: paper and cardboard,
80–98: composites
Your local community or municipal authorities can
provide information on how to dispose of the worn-out
product.

PAA 20-Li B2
■ 8 │ GB│CY
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of pur-
chase. If this product has any faults, you, the buyer, have certain
statutory rights. Your statutory rights are not restricted in any way by
the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your
receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the
date of purchase of the product, we will either repair or replace the
product for you or refund the purchase price (at our discretion). This
warranty service requires that you present the defective appliance
and the proof of purchase (receipt) within the three-year warranty
period, along with a brief written description of the fault and of
when it occurred.
If the defect is covered by the warranty, your product will either be
repaired or replaced by us. The repair or replacement of a product
does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the
warranty. This also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be re-
ported immediately after unpacking. Repairs carried out after expiry
of the warranty period shall be subject to a fee.

PAA 20-Li B2 GB│CY │ 9 ■
Scope of the warranty
This appliance has been manufactured in accordance with strict
quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warran-
ty does not extend to product parts subject to normal wear and tear
or to fragile parts which could be considered as consumable parts
such as switches, batteries or parts made of glass.
The warranty does not apply if the product has been damaged,
improperly used or improperly maintained. The directions in the oper-
ating instructions for the product regarding proper use of the product
are to be strictly followed. Uses and actions that are discouraged
in the operating instructions or which are warned against must be
avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or
improper handling, use of force and modifications/repairs which
have not been carried out by one of our authorised Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity overtime
■ Commercial use of the product
■ Damage to or alteration of the product by the customer
■ Non-compliance with safety and maintenance instructions,
operating errors
■ Damage caused by natural hazards

PAA 20-Li B2
■ 10 │ GB│CY
Warranty claim procedure
To ensure quick processing of your case, please observe the follow-
ing instructions:
■ Please have the till receipt and the item number (e.g.
IAN12345) available as proof of purchase.
■ You will find the item number on the type plate on the product,
an engraving on the product, on the front page of the operating
instructions (below left) or on the sticker on the rear or bottom of
the product.
■ If functional or other defects occur, please contact the service
department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the ser-
vice address that will be provided to you. Ensure that you enclose
the proof of purchase (till receipt) and information about what the
defect is and when it occurred.
You can download these instructions along with many
other manuals, product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to the Lidl service
page (www.lidl-service.com) where you can open your
operating instructions by entering the item number (IAN) 123456.

PAA 20-Li B2 GB│CY │ 11 ■
Service
WARNING!
►Have your appliances repaired by the Service Centre or a
qualified electrician and only using genuine replacement
parts. This will ensure that the safety of the appliance is
maintained.
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: kom[email protected]
IAN 326369_1904
Importer
Please note that the following address is not the service address.
Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PAA 20-Li B2
■ 12 │ GB│CY
Translation of the original Conformity
Declaration
We, KOMPERNASS HANDELS GMBH, document officer:
Mr Semi Uguzlu, BURGSTR. 21, 44867 BOCHUM, GERMANY,
hereby declare that this product complies with the following
standards, normative documents and EC directives:
EMC (electromagnetic compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)*
*The manufacturer bears the full responsibility for compliance with
this conformity declaration.
The object of the declaration described above complies with
the requirements of the Directive 2011/65/EU of the European
Parliament and Council of 8 June 2011 on the limitations of use of
certain dangerous substances in electrical and electronic devices.
ErP 2009/125/EU
ErP (EU) 2015/1428
ErP (EU) No. 1194/2012
Applied harmonised standards:
EN 62368-1:2014+A11:2017
EN 55032:2015
EN 55035:2017
EN 62471:2008
EN 50581:2012

PAA 20-Li B2 GB│CY │ 13 ■
Type designation of the machine: CORDLESS BATTERY ADAPTOR
PAA 20-Li B2
Year of manufacture: 10 - 2019
Serial number: IAN 326369_1904
Bochum, 30/10/2019
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical changes in the context of
further product development.

PAA 20-Li B2
■ 14 │ GB│CY

PAA 20-Li B2 RS │ 15 ■
Sadržaj
Uvod .......................................16
Namenska upotreba ..................................16
Oprema ............................................17
Obim isporuke .......................................17
Tehnički podaci ......................................17
Bezbednosne napomene .......................18
Bezbednost lica ......................................18
Puštanje u rad (vidi sliku A).....................19
LED svetlo (vidi sliku B) .................................19
Punjenje/rukovanje USB uređajem (vidi sliku C) .............20
Održavanje i čišćenje ..........................21
Čuvanje .....................................22
Odlaganje ...................................22
Garancija I Garantni List .......................23
Prevod originalne Izjave o usaglašenosti .........26
