Parkside PLGK 12 A3 User manual

BATTERY CHARGER 12V 2.4A
AKKU-LADEGERÄT 12 V 2,4 A
CHARGEUR DE BATTERIE 12 V 2,4 A
PLGK 12 A3
CHARGEUR DE BATTERIE 12 V
2,4 A
Traduction des instructions d’origine
AKKU-LADEGERÄT 12 V 2,4 A
Originalbetriebsanleitung
BATTERY CHARGER 12V 2.4A
Translation of the original instructions
NABÍJEČKA BATERIÍ 12 V 2,4 A
Překlad originálního provozního návodu
BATTERIJ OPLADER 12 V 2,4 A
Vertaling van de originele gebruiksaanwijzing
AKUMULÁTOROVÁ
NABÍJAČKA 12 V 2,4 A
Preklad originálneho návodu na obsluhu
ŁADOWARKA DO
AKUMULATORÓW 12 V 2,4 A
Tłumaczenie oryginalnej instrukcji obsługi
CARGADOR DE BATERÍAS 12 V
2,4 A
Traducción del manual de instrucciones original
BATTERIOPLADER 12 V 2,4 A
Oversættelse af den originale driftsvejledning
CARICABATTERIE 12 V 2,4 A
Traduzione delle istruzioni d’uso originali
AKKUTÖLTŐ 12 V 2,4 A
Az originál használati utasítás fordítása POLNILNIK ZA BATERIJE 12 V
2,4 A
Prevod originalnega navodila za uporabo
IAN 391280_2201

GB/ IE Translation of the original instructions Page 1
DE/AT/CH Originalbetriebsanleitung Seite 17
FR/BE Traduction des instructions d’origine Page 33
NL/BE Vertaling van de originele gebruiksaanwijzing Pagina 53
CZ Překlad originálního provozního návodu Strana 69
PL Tłumaczenie oryginalnej instrukcji obsługi Strona 85
SK Preklad originálneho návodu na obsluhu Strana 101
ES Traducción del manual de instrucciones original Página 117
DK Oversættelse af den originale driftsvejledning Side 133
IT Traduzione delle istruzioni d’uso originali Pagina 149
HU Az originál használati utasítás fordítása Oldal 165
SI Prevod originalnega navodila za uporabo Stran 181

A

High-performance Li-Ion battery
Cell Balancing – longer battery life, increased battery lifespan.
Higher battery resources due to evenly used cells.
Maximises the charge potential.
Leistungsstarker Lithium-Ionen-Akku
Cell Balancing – längere Akku-Laufzeit, erhöhte Akku-Lebensdauer
Höhere Akku-Ressource durch gleichmäßig beanspruchte Zellen
Schöpft das Ladungspotenzial maximal aus
Batterie lithium-ions
Cell Balancing – plus grande autonomie et plus grande longévité
de la batterie · meilleure capacité de la batterie grâce à un équilibrage entre
elles des cellules sollicitées · exploite au maximum le potentiel de charge
All Parkside tools and the chargers
PLGK12A1/A2/A3/B2/PDSLG 12 A1
of the X12V Team series are compatible
with the PAPK12A1/A2/A3/B1/B3/
C1/D1 battery pack.
Alle Parkside Geräte und die Ladegeräte
PLGK12A1/A2/A3/B2/PDSLG12A1
der X12V Team Serie sind mit dem
Akku-Pack PAPK12A1/A2/A3/
B1/B3/C1/D1 kompatibel.
Tous les outils Parkside et les chargeurs
PLGK12A1/A2/A3/B2/PDSLG 12 A1 de
la série X12V Team sont compatibles
avec la batterie PAPK12A1/A2/A3/
B1/B3/C1/D1.
Charging times
Ladezeiten
Temps de charge
Charging currents
Ladeströme
Courants de charge
max. 2,4 A · PLGK 12 A1/A2/A3
Charger · Ladegerät · Chargeur
max. 4,5 A
· PLGK 12 B2
Charger · Ladegerät · Chargeur
max. 4,5 A · PDSLG 12 A1
Charger · Ladegerät · Chargeur

2 Ah
Battery pack
Batterie
Batterie
PAPK 12 A1
2 Ah
Battery pack
Batterie
Batterie
PAPK 12 A2/A3
2,5 Ah
Battery pack
Batterie
Batterie
PAPK 12 C1
4 Ah
Battery pack
Batterie
Batterie
PAPK 12 B1/B3
5 Ah
Battery pack
Batterie
Batterie
PAPK 12 D1
60 min
2,4 A
60 min
2,4 A
80 min
2,4 A
120 min
2,4 A
150 min
2,4 A
60 min
2,4 A
45 min
3,5 A
55 min
3,8 A
60 min
4,5 A
80 min
4,5 A
60 min
2,4 A
45 min
3,5 A
55 min
3,8 A
60 min
4,5 A
80 min
4,5 A

PLGK 12 A3 GB│IE │ 1 ■
Contents
Introduction........................................ 2
Intended use.................................................2
Features ....................................................2
Package contents .............................................3
Technical specifications ........................................3
General safety instructions ........................... 4
Use and handling of the cordless electrical power tool ................4
Extended safety guidelines......................................5
Safety guidelines for battery chargers .............................6
Before use ......................................... 7
Charging the battery pack (see fig. A).............................7
Maintenance and storage ............................ 8
Kompernass Handels GmbH warranty ................. 8
Service...........................................11
Importer .........................................11
Disposal..........................................12
Original declaration of conformity ....................14
Ordering a replacement battery......................16
Telephone ordering ......................................... 16

PLGK 12 A3■ 2 │ GB│IE
Introduction
Congratulations on the purchase of your new appliance. You have chosen a
high-quality product. The operating instructions are part of this product. They
contain important information about safety, usage and disposal. Before using
the product, please familiarise yourself with all of the operating and safety
instructions. Use the product only as described and for the range of applica-
tions specified. Please also pass these operating instructions on to any future
owner.
Intended use
This charger is exclusively intended for charging PARKSIDE batteries of
the PAPK12A1/A2/A3/B1/B3/C1/D1 series.
This rechargeable battery is suitable for:
This rechargeable battery is not intended for commercial use. Any other
usage of or modification to the appliance is deemed to be improper and
carries a significant risk of accidents. The manufacturer accepts no responsi-
bility for damage attributable to misuse.
Features
Battery pack*
Release buttons
Red charge control LED
Green charge control LED
High-speed charger

PLGK 12 A3 GB│IE │ 3 ■
Package contents
1 battery charger 12V 2.4A
1 set of operating instructions
Technical specifications
2Ah 12V Battery PAPK 12 A3*
Type LITHIUM ION
Rated voltage 12 V (DC)
Capacity 2000 mAh/24 Wh
Cells 3
Battery Charger 12V 2.4A PLGK 12 A3
INPUT
Rated voltage 220–240 V ∼ (AC), 50–60 Hz
Rated power consumption 50 W
Fuse (internal) 2 A T2A
OUTPUT
Rated voltage 12 V (DC)
Rated current 2.4 A
Charging time approx. 60 min
Protection class II / (double insulation)
* BATTERY IS NOT INCLUDED

PLGK 12 A3■ 4 │ GB│IE
General safety instructions
WARNING!
■Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future reference.
Use and handling of the cordless electrical power tool
a) Charge a rechargeable battery unit using only the charger recom-
mended by the manufacturer. Chargers are often designed for a particular
type of rechargeable battery unit. There is the danger of fire if other types
of rechargeable battery units are used.
b) Only the rechargeable battery units supplied are to be used with an
electrical power tool. The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store rechargeable battery units away
from paperclips, coins, keys, nails, screws or other small metal objects
that could cause the contacts to be bridged. Short-circuiting the contacts
of a rechargeable battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery units if they are misused.
If this happens, avoid contact with the fluid. If contact occurs, flush the
affected area with water. Seek additional medical help if any of the
fluid gets into your eyes. Escaping battery fluid may cause skin irritation
or burns.

PLGK 12 A3 GB│IE │ 5 ■
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable batteries.
Protect the rechargeable battery from heat;
for example, from continuous exposure to sunlight, fire, water and
moisture. There is a risk of explosion.
Extended safety guidelines
■Do not use a damaged or modified battery. Damaged or modified
batteries may behave unexpectedly and cause fires, explosions or pose
arisk of injury.
■Do not expose a battery to fire or excessively high temperatures. Fire
or temperatures in excess of 130°C (265°F) can cause an explosion.
■Follow all instructions regarding charging and never charge the
battery or the cordless tool outside the temperature range given in
the operating instructions.
Incorrect charging or charging outside of the permissible temperature
range can destroy the battery and increase the risk of fire.
WARNING!
■ Do not use any accessories that are not recommended by PARKSIDE.
Unsuitable accessories can lead to a risk of electric shock or fire.

PLGK 12 A3■ 6 │ GB│IE
Safety guidelines for battery chargers
■ This appliance may be used by children aged 8 years
and above and by persons with limited physical, sensory
or mental capabilities or lack of experience and knowl-
edge, provided that they are under supervision or have
been told how to use the appliance safely and are
aware of the potential risks. Do not allow children to
use the appliance as a toy. Cleaning and user mainte-
nance tasks may not be carried out by children unless
they are supervised.
■ To avoid potential risks, damaged mains cables should
be replaced by the manufacturer, their customer service
department or a similarly qualified person.
The charger is suitable for indoor use only.
WARNING!
■ To avoid potential risks, damaged mains cables should be replaced
by the manufacturer, their customer service department or a similarly
qualified person.
ATTENTION!
♦ This charger can only charge the following batteries: PAPK12A1/
PAPK12A2/PAPK12A3/PAPK12B1/PAPK12B3/PAPK 12C1/
PAPK12D1.
♦ A current list of battery compatibility can be found at www.lidl.de/Akku.

PLGK 12 A3 GB│IE │ 7 ■
Before use
Charging the battery pack (see fig. A)
CAUTION!
► Always unplug the appliance before you remove the battery pack from
or connect the battery pack to the charger.
NOTE
► Never charge the battery pack if the ambient temperature is below
10°C or above 40°C. If a lithium-ion battery is to be stored for an
extended period, the charge level should be checked regularly. The
optimum charge level is between 50% and 80%. The storage climate
should be cool and dry and the ambient temperature should be
between 0°C and 50°C.
♦ Insert the battery pack into the high-speed charger .
♦ Insert the power plug into the socket. The charge control LED
lights up red.
♦ The green charge control LED indicates that charging is complete
and the battery pack is ready for use.
♦ Push the battery pack into the appliance.
♦ Switch the high-speed charger off for at least 15 minutes between
successive charging processes. Also disconnect the power plug from
the mains power socket.

PLGK 12 A3■ 8 │ GB│IE
Maintenance and storage
■ If you do not intend to use the appliance for an extended period, remove
the batteries and store it in a clean, dry place away from direct sunlight.
■ If a lithium-ion battery is to be stored for an extended period, the charge
level should be checked regularly. The optimum charge level is between
50% and 80%. The optimum storage environment is cool and dry.
■Never try to repair damaged batteries.
Maintenance of batteries should only be carried out by the manufacturer
or an approved customer service centre.
■ Clean the charger and the battery with a dry cloth or a brush. Do not use
water or metallic objects.
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this
product has any faults, you, the buyer, have certain statutory rights. Your stat-
utory rights are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt
in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of
purchase of the product, we will either repair or replace the product for you
or refund the purchase price (at our discretion). This warranty service requires
that you present the defective appliance and the proof of purchase (receipt)
within the three-year warranty period, along with a brief written description
of the fault and of when it occurred.

PLGK 12 A3 GB│IE │ 9 ■
If the defect is covered by the warranty, your product will either be repaired
or replaced by us. The repair or replacement of a product does not signify
the beginning of a new warranty period.
X 12 V and X 20 V Team Series battery packs come with a 3-year warranty
valid from the date of purchase.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and
defects present at the time of purchase must be reported immediately after
unpacking. Repairs carried out after expiry of the warranty period shall be
subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality
guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does
not extend to product parts subject to normal wear and tear or to fragile
parts which could be considered as consumable parts such as switches or
parts made of glass.
The warranty does not apply if the product has been damaged, improperly
used or improperly maintained. The directions in the operating instructions for
the product regarding proper use of the product are to be strictly followed.
Uses and actions that are discouraged in the operating instructions or which
are warned against must be avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or improper
handling, use of force and modifications/repairs which have not been
carried out by one of our authorised Service centres.

PLGK 12 A3■ 10 │ GB│IE
The warranty period does not apply to
■ Normal reduction of the battery capacity overtime
■ Commercial use of the product
■ Damage to or alteration of the product by the customer
■ Non-compliance with safety and maintenance instructions,
operating errors
■ Damage caused by natural hazards
Warranty claim procedure
To ensure quick processing of your case, please observe the following
instructions:
■ Please have the till receipt and the item number (IAN)391280_2201
available as proof of purchase.
■ You will find the item number on the type plate on the product, an
engraving on the product, on the front page of the operating instructions
(below left) or on the sticker on the rear or bottom of the product.
■ If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service
address that will be provided to you. Ensure that you enclose the proof of
purchase (till receipt) and information about what the defect is and when
it occurred.
You can download these instructions along with many
other manuals, product videos and installation software at
www.lidl-service.com.
This QR code will take you directly to the Lidl
service page (www.lidl-service.com) where you can open your operating
instructions by entering the item number (IAN) 391280_2201.

PLGK 12 A3 GB│IE │ 11 ■
WARNING!
►Have your appliances repaired by the Service Centre or a trained
electrician, and use only original spare parts. This will ensure that the
safety of the appliance is maintained.
►Always ensure that the power plug or the mains cable is replaced
only by the manufacturer of the appliance or by an approved
customer service provider. This will ensure that the safety of the appli-
ance is maintained.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
Service Ireland
Tel.: [phone]
E-Mail: [email protected]
IAN 391280_2201
Importer
Please note that the following address is not the service address.
Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PLGK 12 A3■ 12 │ GB│IE
Disposal
The product and its packaging are recyclable. They are subject to an
extended manufacturer responsibility and will be collected separately.
Do not dispose of power tools in your normal domestic
waste!
The adjacent symbol of a crossed-out dustbin means that this
appliance is subject to Directive 2012/19/EU. This directive
states that this appliance may not be disposed of in the normal household
waste at the end of its useful life, but must be taken to specially set-up collec-
tion locations, recycling depots or disposal companies.
The disposal is free of charge for the user. Protect the environment
and dispose of this appliance properly.
If it is possible to do so without destroying the old appliance, remove the
old batteries or rechargeable batteries before returning the appliance for
disposal and take them to a separate collection point. In the case of perma-
nently installed rechargeable batteries, you must indicate during disposal that
the appliance contains a battery.

PLGK 12 A3 GB│IE │ 13 ■
Your local community or municipal authorities can provide
information on how to dispose of the worn-out product.
Do not dispose of batteries in your normal household
waste!
Defective or worn-out rechargeable batteries must be recycled
according to Directive 2006/66/EC. Batteries/rechargeable bat-
teries must be treated as hazardous waste and must therefore be disposed
of in an environmentally sound manner by appropriate bodies (dealers,
specialist dealers, public municipal bodies, commercial disposal companies).
Batteries/rechargeable batteries may contain toxic heavy metals.
For this reason, do not dispose of batteries/rechargeable batteries in domes-
tic waste. Take them to a specialist collection point. Only return batteries that
are fully discharged.
The packaging is made from environmentally friendly material
and can be disposed of at your local recycling plant.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging
material components for disposal if necessary. The packaging
material is labelled with abbreviations (a) and numbers (b) with
the following meanings: 1–7: plastics, 20–22: paper and cardboard,
80–98: composites.

PLGK 12 A3■ 14 │ GB│IE
Original declaration of conformity
We, KOMPERNASS HANDELS GMBH, document officer: Mr Semi Uguzlu,
BURGSTR. 21, 44867 BOCHUM, GERMANY, hereby declare that this
product complies with the following standards, normative documents and EC
directives:
EC Low Voltage Directive
(2014/35/EU)
Electromagnetic Compatibility
(2014/30/EU)
RoHS Directive
(2011/65/EU)*
* The manufacturer bears the sole responsibility for compliance with this conformity
declaration. The subject of the declaration described above meets the requirements
of Directive 2011/65/EU of the European Parliament and Council of 8 June 2011
on the restriction of the use of certain hazardous substances in electrical and elec-
tronic equipment.
Applied harmonised standards
EN 60335-2-29:2004/A11:2018
EN 60335-1:2012/A15:2021
EN 62233:2008
EN 55014-1:2017/A11:2020
EN 55014-2:1997/A2:2008
EN IEC 55014-1:2021
EN IEC 55014-2:2021
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 61000-3-3:2013/A1:2019

PLGK 12 A3 GB│IE │ 15 ■
EN IEC 61000-3-2:2019/A1:2021
EN IEC 63000:2018
IEC 62133-2:2017
IEC 62133-2:2017/AMD1:2021
EN 62841-1:2015 Annex K
Type/appliance designation: Battery Charger 12V 2.4A PLGK 12 A3
Year of manufacture: 07–2022
Serial number: IAN 391280_2201
Bochum, 19/04/2022
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical changes in the context of further
product development.
