PCE Instruments PCE-MMT E User manual

PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: [phone]
Fax: [phone]
[e-mail]
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: [phone]
Fax: [phone]
[e-mail]
www.pce-instruments.com/english
www.pce-instruments.com
Manual
Tensile and Compressive Force Meter PCE-MMT E
Version 1.0
Date of creation: 09.03.2016
Date of last change: 08.12.2016

Contents
1Introduction......................................................................................................................................... 3
2Safety notes......................................................................................................................................... 3
3Specification........................................................................................................................................ 3
3.1 Delivery....................................................................................................................................... 4
4System description............................................................................................................................. 4
4.1 Key functions.............................................................................................................................. 4
4.2 Operating system ....................................................................................................................... 6
5Main menu........................................................................................................................................... 6
5.1 User............................................................................................................................................ 6
5.2 Save............................................................................................................................................ 6
5.2.1 Function ......................................................................................................................................... 6
5.2.2 “Limit values”.................................................................................................................................. 8
5.2.3 Display ........................................................................................................................................... 9
5.2.4 TEDs (automatic sensor recognition)............................................................................................. 9
5.2.5 Calibration No. (selection of a characteristic).............................................................................. 11
5.2.6 System......................................................................................................................................... 11
5.3 Settings..................................................................................................................................... 12
5.3.1 “Auto-0-”....................................................................................................................................... 12
5.3.2 Measuring frequency ................................................................................................................... 12
5.3.3 Digital filter ................................................................................................................................... 13
5.4 Factory setup............................................................................................................................ 13
6Save and transfer the measurement data ...................................................................................... 13
6.1 Peak values.............................................................................................................................. 13
6.2 Curve........................................................................................................................................ 14
6.3 Termination of dara saving....................................................................................................... 14
6.4 Data transfer in mass storage mode........................................................................................ 14
6.5 Data transfer in a data streaming mode (DSI transmission).................................................... 14
6.6 Transmission of measurement data to an existing terminal program:..................................... 15
7Calibration......................................................................................................................................... 16
8Battery life and charging.................................................................................................................. 16
9SD memory card ............................................................................................................................... 16
10 In- and outputs.................................................................................................................................. 16
10.1 Mini-USB interface.................................................................................................................... 16
10.2 Output....................................................................................................................................... 16
10.3 USB charger............................................................................................................................. 17
11 Incremental encoder (optional)....................................................................................................... 17
12 Error messages................................................................................................................................. 17
13 Reset function................................................................................................................................... 17
14 Menu overview.................................................................................................................................. 17
15 Disposal............................................................................................................................................. 18
16 Contact............................................................................................................................................... 19
16.1 PCE Instruments UK ................................................................................................................ 19

Manual
3
16.2 PCE Americas .......................................................................................................................... 19
1 Introduction
Thank you for purchasing a Tensile and Compressive Force Meter PCE-MMT E from PCE Instruments.
This manual is published by PCE Instruments without any warranty. Our equipment complies with all the
relevant safety regulations and carries the CE symbol. The CE Declaration of Conformity can be found as
an attachment. We point explicitly to our general warranty conditions, which can also be found on this
disk (CD) are and ask for attention. The warranty period of 24 months as described herein does not apply
to batteries. For this a statutory warranty period is 6 months from the date of delivery.
The warrant expires in case of damage:
•an intervention by the buyer, the user or unauthorized third party in the device or its software;
•improper handling; especially if the mechanical overloading of the built-in sensor is caused;
•improper operation, storage, force majeure or other external influences occurs.
Improvements and changes to this manual necessitated by typographical errors and inaccuracies can be
made by the PCE Germany GmbH at any time without notice.
The PCE Germany GmbH reserves the right to make technical modifications and changes to the device,
its accessories and software at any time and without notice. Any changes will be reflected in the then
published user manuals.
2 Safety notes
Please read this manual carefully and completely before you use the device for the first time. The device
may only be used by qualified personnel and repaired by PCE Instruments personnel. There is no
warranty of damages or injuries caused by non-observance of the manual.
- The device may only be used in approved temperature range
- The opening of the instrument should only be done by qualified personnel of the PCE Instruments
- The instrument should never be placed face down on the user interface (e.g., keyboard side on a table)
- You should not make technical changes to the device
- The appliance should only be cleaned with a damp cloth / use only pH-neutral cleaner
This user's handbook is published from PCE Instruments without any guarantee.
We expressly point to our general guarantee terms, they can be found in our general terms of business.
With the present measuring instrument, tensile and compressive forces can be determined up to the
specified maximum measuring range. Improper use may cause damage to the sensor.
If you have any questions please contact PCE Instruments.
3 Specification
Measuring accuracy ≤0.05% v.E
Max. measurement frequency 2000 Hz
Resolution ± 50.000 digits
Power supply 3 AA NiMh batteries
Memory 2 GB SD memory card
Visualization Display of measurement curves
Dimensions 75 x 35 x 170 mm

Manual
4
3.1 Delivery
1 X PCE-MMT E tensile and compressive force meter
1 X carrying case
1 X factory calibration certificate
1 X CE certificate
1 X 2 GD SD memory card
1 X USB power adapter
1 X USB cable
1 X PC software
4 System description
4.1 Key functions
4
5 6
7
1 2
3
1
Power button
To turn the device on, please, press the
button for 2-3 seconds. Then the device
starts and displays the connected TEDs
measuring cells (Notes on TEDs in chapter
4.5). After confirming the measuring cell
and the choice of the memory, the device
shows the last selected measuring mode.
If no new / other measuring cell should be
connected and the previous user settings,
such as unit and limit value, should be

Manual
5
retained, please, press the CLR button. The
reading of the TED data will be cancelled.
2
Mode „measure with peak value“ : delete peak
values
Upper and lower peak value will be deleted.
Undeleted peak values remain obtained
and will be displayed again when the peak
mode is activated again.
Mode „Menu“
Exit the menu-mode and browser window.
The mode „Measure“ is active. Settings are
saved.
3
Access to the mode „Menu“
In the menu: confirmation of the entries made
e.g. when entering the limit values or also
for confirmation of the TEDs measuring
cells
4
Mode „Measure with peak values“
Save peak value
Acceptance of the current peak values in
the open file of the data logger till the
number of the readings set in the menu is
not reached.
Mode “Menu“
Scroll through the menu to the top.
Input of the numerical values: increase of
the displayed value
Mode “Data transfer“ / “Save the curve“
Starting the data transfer in a continuous
data transfer mode or the curve recording
in a mass storage mode.
5
Mode “Measure without peak value”
Zeroing of the indicated force
Mode “Menu”
One menu level higher from the submenu.
Input of the numerical value: move the
cursor to the left.
6
Mode “Measure with peak value”
Switching: peak values above
peak values below
Current reading
Indicator in the lower part of the display.
Indicator in the lower part of the display.
Note: when the peak measurement is
active, the current measurement is, in
addition, displayed in the lower field of the
display.
No indicator in the lower field of the display.
Mode “Menu”
One menu level further from the main menu
Input of the numerical values: move the
cursor to the right
7
Mode “Measure with peak values”
Close file in a data logger
Immediate termination of the recording of
the readings, regardless of whether the
preset number of the readings has been
reached.
Mode “Menu”
Scroll down through the menu.
Input of the numerical value: decrease of
the displayed value.
Mode “data transfer” / „save the curve“
Termination of the data transfer in a
continuous data transfer mode or the curve
recording in a mass storage mode.

Manual
6
4.2 Operating system
The hand dynamometer has its own processor and operates with a real time operating system of the
latest generation. This system processes the raw data of the measurements and indicates them
accordingly. In case of a switched memory functions MS Excel-compatible CSV files can be stored in the
integrated data logger. On delivery, the device has a SD memory card with 2GB capacity.
5 Main menu
Press to enter the menu selection. You can now find the menu items "User", "Settings" and "Factory
Setup".
With you can switch between the displayed menu items and select the desired menu item with
the help of
the menu item "user" includes the mode you need for measurement. In the menu item "Settings" you can
carry out the expanded settings. The menu item "Factory Setup" makes it possible to restore the factory
default settings or to enter the calibration mode. This area, however, is password protected and can be
reached only through our service.
5.1 User
Here you are in the user mode. The menu is structured as follows:
- Save
- Limits
- Display
- Units
- TEDs
- Calibration No.
- System
With the help of you can switch between the displayed menu items and select the desired menu
item with the help of
5.2 Save
Here you can configure, delete or view the memory. The menu is structured as follows:
- Function
- Select the quantity
- Time curve
- Delete
- Browse
With you can switch between the displayed menu items and select the desired menu item
with the help of .
5.2.1 Function
The menu is divided as follows:
- No saving

Manual
7
- Peak value up / down
- Save the curve
With you can switch between the displayed menu items and select the desired menu item with the
help of .
Turn off the storage ("no saving")
When this button is pressed, no measurement values are stored.
Storing the upper and lower peak values ("peak value up / down")
If you press here, the memory function of the peak values is activated.
First, the upper peak value is displayed. Indicator appears at the bottom of the display. With the
help of the display of the stored value is switched. Then the lower peak value follows, and
appears on display. The current measurement value is displayed in this operating mode additionally in the
lower section of the display (in a smaller representation).
With the display is switched again. Then only the current measurement value is displayed again.
Note: The stored peak values are retained until the Clear key (CLR, button 2) is pressed. Undeleted peak
values are retained and displayed again when the peak measurement is enabled. They will be only
overwritten with higher values.
Curve storage (“Curve")
Clicking activates the function “curve storage”.
5.2.1.1 Define the number of peak values (“select the quantity”)
This function makes it possible to determine the number of peak values that will be stored in the same
file. Pressing (key 6) opens a window in which the number of to be stored peak values can be set.
The factory default setting is 10.
5.2.1.2 Curve recording duration (”time curve”)
If you press the function "time curve" is activated. This function allows setting the recording time (1 to
600 s) of a curve. After pressing the window "seconds” opens, in which the time must be entered.
Note:The maximum duration of the recording is limited by the size of the measuring frequency.
5.2.1.3 “Delete”
In the menu levels “delete peak value”, “delete curve” and “delete all” the saved files can be deleted.
Pressing (key 6) on the desired function opens the selection window. The options are “OK” and “Exit”.
Selection of the desired option is carried out with the help of . Confirm your choice with

Manual
8
5.2.1.4 Display of the stored files (“Browse”)
By pressing a new window is opened. In this window, the curves and peak value files stored on the
meter are displayed in a tabular form. That name is presented which the file shows. To navigate is
possible with the help of
By pressing on one of the selected files you get a possibility to see the file information, such as time
of saving and size, displayed. Besides, it is possible to delete the selected files individually.
To exit this window, press .
5.2.2 “Limit values”
In this item, positive and negative limit values can be set. When these values are reached, there is a
potential pending signal at the output jack. With this, for example, a relay can be switched. If you operate
the device with the test stands PCE-TF 3, PCE-TF 4, offered by us, the machines can be stopped in such
a way. The limit values may show positive, negative or both a positive and negative numerical value. With
activated distance measurement (optional) an upper and a lower distance limit value can be set in
addition.
Note: The data transfer and storage is automatically stopped when a limit value is exceeded.
Two symbols (“<", ">") on the display above the power indicator show the current limit value status. The
"<" symbol indicates that the measurement value is below the limit value. If the current measurement
value reaches and exceeds the set limit, the ">" symbol is displayed.
5.2.2.1 “Upper limit” and “lower limit”
After pressing you can choose between the input of the limit value as a numerical value, the
operating mode of the output limit value and the selection of the sign mode. Navigation is carried out with
the help of
"Set point"
Pressing makes the input of the value for the limit value active. The cursor is moved to the desired
digit with the help of . With the desired value of the digit can be decreased or increased.
The key confirms the input of the value.
"Mode Output"
Pressing activates the selection operating mode of the limit output. With you may choose
between closing and opening function of the limit value output. Confirm with .
"Sign"
Clicking activates the selection of type of the limit value. With you select between signed and
absolute value. Confirm with .

Manual
9
Example: -> upper limit -> set point = -200 N
Sign = absolute value
In both cases, when + 200 N as well as -200 N is exceeded the upper limit is active.
-> upper limit -> set point = -200 N
Sign = to be signed
Only when -200 N is exceeded, the upper limit is active. +
5.2.2.2 Time limit for data transfer
In the menu item "DSI time limit activation" you can activate a time limit for stopping the data
transmission.
The menu item "DSI time limit (sec)" allows you to enter certain time that represents how long the data
will transferred via USB interface. The input is made in seconds (0 ... 9999 s). If the time is set to 0, this
function is disabled.
Note:The limit value outputs of the device are switched when the overruns of the time limit happen. A
connected test stand is thereby stopped. To reset the outputs, press either or start a new data
transfer.
If the function "Save the curve" is activated, this setting is not effective. Instead, the time limit is
considered from "curve duration".
5.2.3 Display
You can adjust display as follows according to your needs:
"Rotate display "
After pressing you can rotate the display by 180 ° with the help of . Confirm with ..
"Background"
After pressing you can select between Normal and Inverted display with the help of ..Confirm
with
"Backlight"
After pressing the backlight can be controlled with smoothly. Confirm the selection with ..
"Contrast"
After pressing the contrast can be controlled with .smoothly. Confirm the selection with
5.2.4 TEDs (automatic sensor recognition)
Information: what is TEDs? TEDs (transducer electronic data sheet) is an international standard for
sensors. Each TEDs measuring cell has a memory chip integrated in the sensor or plug, on which the
basic information on the measuring cell is stored. These are, for example, serial number, measurement
range or calibration.
When a TEDs measuring cell is connected to the meter, you can view the information stored on the
memory chip in this menu.
"Reading ID"
By pressing a new window is opened, which contains the basic TEDs information. Navigate here with

Manual
10
the help of .
"Reading Sensor"
By pressing a new window is opened, which contains the physical information of the cell (for
example, the measuring range). Navigate here with the help of ..
"Reading Calibration"
By pressing a new window is opened, which contains the calibration information of the measuring
cell. Navigate here with the help of .
5.2.4.1 Connection of a TEDs measuring cell
Once a cell with TEDs memory chip is connected to a switched on measuring instrument, as well as when
the device is switched on, the detected measurement cell information is displayed.
A new window open which displays the main information of the measurement cell (manufacturer, model
and measuring range.
By pressing , you acknowledge that the calibration stored on the TEDs memory chip is loaded into the
meter. Pressing results in stopping the downloading and previously set user settings such as limit
values and units remain retained.
In the next window you can select one of eight memory locations on the meter. Here, the calibration is
loaded to the connected measuring cell. Confirm your choice with .

Manual
11
5.2.5 Calibration No. (Selection of a characteristic)
The manual selection of a characteristic is only necessary if you have no TEDs measuring cells available
and use several sensors without TEDs.
Connect the desired cell with the instrument and select the required curve with the help of .
Confirm the selection by pressing .
Pressing brings you back to the measurement mode. The measuring cell should be ready to use now.
5.2.6 System
5.2.6.1 Date / Time
Here you can set the date and time. It is necessary only in case of battery pack change, as the date and
time are set at the factory.
With you can set the time and date. The input is activated after the initial pressing of any of both
keys.
Confirm with
5.2.6.2 Language
The following languages can be set for the display:
- German
- English
- Spanish
- French
- Italian
Choose with the help of the desired language and confirm with . The language changes
immediately after pressing .
5.2.6.3 Auto off function
You can choose different possibilities:
- Off (auto power off is disabled)
- 1 (auto power off after 1 minute)
- 2 (auto power off after 2 minutes)
- 5 (auto power off after 5 minutes, factory setting)
- 10 (auto power off after 10 minutes)
With you can choose one option. Confirm with .

Manual
12
5.2.6.4 USB
In this menu the type of data transmission is selected. The choices are:
- Mass storage (default setting)PCE-MMT I as a mass storage
- Contin. PCE-MMT I transmits continuously
Press to select the desired transmission type. Confirm the selection with .
5.3 Settings
“Auto-0-” factory default settings -> On
“Measuring frequency” factory default settings -> 100Hz
“AD/DA filter” factory default settings - >Off
With you can select the desired submenu. Confirm the selection with
5.3.1 “Auto-0-”
With you enter the function for the automatic zeroing when switching. By pressing you confirm
the selection.
When this function is active, the display is set to zero at switching automatically, regardless of the existing
load.
5.3.2 Measuring frequency
The following setting options are available:
- 2000 Hz (maximum value)
- 1000 Hz
- 500 Hz
- 400 Hz
- 250 Hz
- 200 Hz
- 160 Hz
- 100 Hz (factory default setting)
- 50 Hz
With you can set the sampling rate of the analog / digital converter. Confirm with
The following setting options are available:
- OFF (no filter; factory default setting)
- F 1 (the smallest filter level)
- F 2
- F 3 (middle filter level)
- F 4
- F 5 (the highest filter level)
With you can select the desired filter. Confirm the selection with .

Manual
13
5.3.3 Digital filter
The following setting options are available:
- OFF (no filter; factory default setting)
- F 1 (the smallest filter level)
- F 2
- F 3 (middle filter level)
- F 4
- F 5 (the highest filter level)
With you can select the desired filter. Confirm the selection with .
Technical note to the filter function:
FIR (Finite Impulse Response) are feedback-free, phase linear digital filters with finite impulse response
the filtered values y (n) of which are calculated from a certain, just distant past of the input signal x. With
the FIR filter, the calculation of the y-value refers to the finite past.
The function of an FIR filter can be compared, for example, with the formation of a sliding mean value.
Then, the sum of "n" successive values is formed and divided by "n". After that, the group of “n” values is
shifted continuously each by one clock, and every time the mean value is formed again. The maximum
number of the past values which are considered during the calculation is then defined as an order. The
higher the order is, the better the properties of the filter are, though the computational complexity is also
higher then. For the display device it means, that the higher the order of the selected filter, the more
values are taken into account in the averaging.
5.4 Factory setup
Note: this menu is password protected and can only be used by our service technicians. It is used for
configuration and calibration of the measuring instrument.
6 Save and transfer the measurement data
6.1 Peak values
If the peak values function is activated, the device saves the pre-set number of peaks in EXCEL
compatible file with the extension * .csv. The format is called "Microsoft Office Excel Comma Separated
Values File".
If the number of the peak values, which was defined in the menu item "number / quantity" is reached, the
file closes automatically. The file name for peak values files is Peakxyz.csv where xyz stands for a
consecutive number starting with 001.
The detected peak value appears on the display. In square brackets the remaining capacity of memory of
the current file is displayed.
The peak value is stored by pressing .
Note: in this case the file closes itself when the pre-set number of peaks is not reached yet!
Saving is stopped if you select the menu item "no saving" or if the space on the SD memory card is full.

Manual
14
6.2 Curve
This function allows the storage of the measurement values in a file. The duration of recording is
adjustable and is limited by the size of measuring frequency (see chapter 3.2.2).
Selected measuring frequency (Hz)
Max. recording time (s)
2000
40
1000
80
500
150
400
200
250
300
200
400
160
500
100
600
50
600
Pressing starts the recording of the data in the * .csv file on the memory card or in case of activated
data streaming the transmission of the data to the connected computer.
Recording is ended in case of pressing or if it exceeds a pre-set limit value (see 3.1.2).
When the pre-set time is over, the recording will stop automatically. The file is closed and a new one
opens, or the transmission to the computer is stopped, when data streaming is enabled.
The file name for the stored on the SD memory card curves is Curvexyz.csv, where xyz stands for a serial
number beginning with 001, stands and is an Excel compatible file with the extension * .csv.
6.3 Termination of data saving
Saving is over when you choose the menu item “no saving” (see chapter ) or when the memory on
the SD card is completely full. The measurement data transfer through the data streaming remains active.
6.4 Data transfer in mass storage mode
Data transfer is carried out via the USB interface. The factory setting of the device makes it possible to
use it as a mass storage. It means that after the first connection to the computer a mass storage driver is
installed automatically, similar to the USB stick. Then the saved measurement data can be copied via
Windows-Explorer. Alternatively, the files can be opened directly via Excel and processed further.
In chapter it is described how the transfer mode can be changed.
6.5 Data transfer in a data streaming mode (DSI transmission)
When the Data Streaming mode is enabled (see chapter ), the measurement data can be sent to a
computer continuously.
Pressing activates the transmission of data to the connected computer.
The data transmission is terminated when is pressed or when a pre-set limit value is exceeded (see
chapter ).
To use this function on the PC, it is necessary to install the virtual COM port driver from the delivered CD.
To do this, put the CD into the drive and ignore any possible auto-start actions of Windows. Turn the

Manual
15
meter on, activate the mode Data Streaming and connect the meter to a free USB slot. The Windows
Hardware Wizard will appear. Follow the instructions for the automatic installation. (A detailed driver
installation manual is on the CD)
If the driver is installed, two options open for you:
Transmission of the measurement data to the optionally available data acquisition software:
To use the software, please start the setup.exe file from the optional CD and follow the instructions in the
Wizard. Adetailed user manual is included on the CD.
The software provides the following functions:
Display of the transmitted measurement data as a value and as a measurement diagram
Storing the measured data as an Excel compatible * .csv file
Creation of a PDF test report including diagram, maximum, minimum and average value
Determining the slope / gradient
Integration of a company logo (.jpg or .bmp)
Freely available documentation and notes fields
When using PCE-MMT Eand path encoder, switching between force-time and force-distance curves.
Note: Please, always pay attention, that the device must be turned on first, before it is connected to the
started computer. If the data transfer does not work one time, stop the software! Make sure that all the
cable connections are plugged in correctly. Check that all the test stands or external devices are on and
then turn the device on. Start the software again and the data transfer is prepared again.
6.6 Transmission of measurement data to an existing terminal program:
To transfer data into an application to your preference, please follow the instructions for this software.
The measurement data transmitting is carried out with the following format
Force EOT
If the display of an incremental distance encoder is activated (optional) and the latter is connected, the
data is transmitted using the following format
Force; distance EOT
Force: 7 ASCII characters, from 30h to 39h, the possible decimal point (2Eh). Instead of
non-significant zeros vacancies are transmitted (20h)
Distance: 7 ASCII characters, from 30h to 39h, the possible decimal point (2Eh). Instead of
non-significant zeros vacancies are transmitted (20h)
EOT: 04h

Manual
16
Note: How the data is transferred depends on the measuring frequency set on the device. With the set
measuring frequency of 100 Hz, the data is transferred directly and continuously from the start of the
measurement. If the measured frequency is above 100 Hz, the measurement data is first cached in the
meter due to a limitation of the USB interface and then transferred at the end of the measurement.
7 Calibration
The calibration of the display devices and sensors is done in a certified laboratory using traceable
calibrated weights (up to 1000 N) or traceable calibrated reference-force gauges (1000 N).
It is recommended to carry out and certify recalibration annually.
8 Battery life and charging
In the compartment on the back side of the meter there are three environment friendly AA battery packs
that are fully charged before delivery. To charge the batteries, the USB power adapter supplied should be
used. Please work several times until the complete discharge of the batteries and charge them again only
after that. In case of lasting use, for example, in small tests, disconnect the charger at least once a week
during working hours and wait until the full discharge of the batteries. Please charge the device only after
that again. The normal working hours with a fully charged battery pack is about 10 hours. The necessary
charging time is approximately 3 - 4 hours. The current state of charge of the batteries is shown at any
time in the upper right corner of the display. If the batteries have reached their maximum service life and
no longer have their full power, so standard AA batteries or in case of emergency 1.5V AA batteries can
be used. Please note that the working time with standard batteries is limited. When connecting the
delivered charger you can see the state of charge by the moving battery icon in the upper right corner of
the display. Please note that the new batteries reach their full capacity only after a few charge / discharge
cycles. It is recommended to connect the handheld instrument to the charger after each use or daily.
Note: It makes sense to discharge the batteries after long use as much as possible and to charge them
fully again.
9 SD memory card
A memory card with a capacity of 2 GB is included in the delivery. On it, the meter stores accumulating
peak values and curve files. Alternatively, for data transmission via the USB cable, this card with the help
of a small pressure can be taken out of the slot located on the right side. With the help of a SD card
reader it can be read on any computer. SD memory cards up to 4GB are supported.
10 In- and outputs
10.1 Mini-USB interface
The USB-data cable is included in the delivery.
10.2 Output
The analog output is proportional to the measurement value. This has a max. value of ± 2 V DC,
according to the nominal range of the hand-held meter.
A possible calibration of the analog output at two measuring points is available optionally.
Note: The zero adjustment on the display device is carried out in the unloaded condition of the load cell.

Manual
17
The installation of a power management device, for example, a wedged clamping device on the power
line thread leads to a preloading and thus to a deviant voltage signal at the analog output.
Option: output cable or mating connector for a socket
1) Out 1 – upper limit value
2) Out 2 – lower limit value
3) GND Out
4) Analog ± 2 V
5) GND analog
6) Encoder A (optional)
7) Encoder B (optional)
10.3 USB charger
The USB charger is also included in the delivery.
11 Incremental encoder (optional)
When using PCE-MIT I in one of our test stands, the machine can be read via an optionally available
incremental encoder input on the 12-pin cable and displayed together with the force.
12 Error messages
In case of incorrect operation, which leads to an overload of the built-in load cell, 2 error messages will be
activated:
- In case of an overload of about 15% a header line "Overload" appears instead of the force display.
A mechanical overload protection happens at about 125% of rated load. If the overload is withdrawn in
time, this indication disappears and the handheld instrument can still be used normally.
- Because of excessive force, for example, when the meter is dropped on the force introduction axis, the
mechanical overload protection can be overcome and the sensor is mechanically deformed. Thus, the
zero point of the sensor is permanently shifted. If this offset is permanently more than 20% of the rated
load, the header line "Overloaded" appears at the bottom of the display in addition.
This line can be reset to default only after carried out repair, possibly sensor exchange.
13 Reset function
In the unlikely case that the device can no longer be operated because of some trouble, the system
software can be reset by pressing the reset button (on the upper right side) with the help of a small round
object (such as a paperclip). All the made settings are retained.
14 Menu overview

Manual
18
1. Level
2. Level
3. Level
4. Level
User
11 Memory
1112 Function
1111 No saving
1112 Peak values +/-
1113 Save the curve
112 Quantity
Peak values
1121 Value Input
113 Time Curve
1131 Value Input
114 Delete
1141 Delete Peak value
1142 Delete Curve
1143 Delete All
115 Browse
12 Limit value 121 Upper 1211 Setpoint->Input
1212 Mode->Sign/
Absolute
122 Lower
1221 Setpoint->Input
1222 Mode->Sign/
Absolute
13 Display
131 Rotate
1311 0° / 180°
132 Invert
1321 Normal/Inverted
133 Backlight
1331 Power Off ... Max.
134 Contrast
1341 Power Off ... Max.
14 Units
141 N
142 kN
143 MN
144 g
145 kg
146 t
147 lb
15 System
151 Date/Time
152 Language
1521 D / GB / Sp / Fr / I
153 Auto Off
1531 Off/1/2/5/10min
154 USB
1541 Mass storage
1542 continuous
Settings
21 Auto-0-
211 On/Off
22 Measuring
frequency
221 Selection
2221
2000/1000/500/400/250/200/160/100/50
Hz
23 AD/DA-Filter
231 Off
232 F1
233 F2
234 F3
235 F4
236 F5
15 Disposal

Manual
19
For the disposal of batteries, the 2006/66/EC directive of the European Parliament applies. Due to the
contained pollutants, batteries must not be disposed of as household waste. They must be given to
collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use them or
give them to a recycling company which disposes of the devices in line with law.
If you have any questions, please contact PCE Instruments.
16 Contact
If you have any questions about our range of products or measuring instruments please contact PCE
Instruments.
16.1 PCE Instruments UK
By post:
PCE Instruments UK Ltd.
Units 12/13 Southpoint Business Park
Ensign Way, Southampton
Hampshire
United Kingdom, SO31 4RF
By phone:
02380 987 035
16.2 PCE Americas
By post:
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
33458 FL
USA
By phone:
561 320 9162
