peerless-AV ACC-DSV449-P Guide

ISSUED: 06-04-10 SHEET #: 120-9080-1
Installation and Assembly:
Universal Tilt Adapter Brackets for LCD and Plasma 32" - 56"
(81 - 142 cm) Flat Panel Screens
Features:
•Universal screen mounting brackets hook onto the wall plate for
quick, easy, and safe installation
•Adjustable up to 15° of forward tilt and up to -5° backward tilt
•One-touch tilt for effortless adjustment
•Pre-tensioned universal tilt bracket allows for tilt angle adjustment
in one easy motion.
•Easy grip handle locks the screens position into place
• 
15° increments
Accessories:
 
cable management accessory (optional)
 
 
 
 
 
Models:
NOTE: Read entire instruction sheet before you start installation and assembly.
 
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
 
construction, and fully understands these instructions.
 
hardware and components.
 
 
 
power.
 
injury.
WARNING
Maximum Load Capacity: 175 lb (79 kg)

2 of 7 ISSUED: 06-04-10 SHEET #: 120-9080-2 05-14-12
AA BB CC
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
Parts List ACC-DSV449 ACC-DSV449-P
Qty. Part Number Part Number
AA left tilt bracket 1  
BB right tilt bracket 1  
CC 4 mm allen wrench 1  
Description

3 of 7 ISSUED: 06-04-10 SHEET #: 120-9080-2 05-14-12
Security Tilt Bracket Fasteners

 
(520-1064)

(520-1122)

(520-1050)

(520-1211)

(520-1068)

(520-1152)
multi-washer (6)


(520-9554)



(520-1101)

(510-1082)
Non-Security Tilt Bracket Fasteners







(510-9109)

(520-1128)

(520-1208)

(520-9402)
multi-washer (6)


(504-1015)









(540-1059)



(540-1059)

4 of 7 ISSUED: 06-04-10 SHEET #: 120-9080-2 05-14-12

screen face side down. If screen has knobs on the back, remove them to allow the adapter brackets to be attached.
Place adapter brackets (AA or BB) on back of screen, align to holes, and center on back of screen as shown
below. Attach the adapter brackets to the back of the screen using the appropriate combination of screws, multi-

NOTE: For at back screens proceed to step 1-1. For bump-out or recessed back screen skip to step 1-2.
NOTE:



X
X


1
Notes:
 
depending upon the type of screen.
 
be used, depending upon the type of
screen.
 
washer that matches your screw size as
shown.




Installing Tilt Brackets
NOTE: Top and bottom mounting holes on screen must be used for attaching brackets.
NOTE:
aligned, and then tighten screws using a phillips screwdriver.
 
can cause stress damage to screws, greatly reducing their holding power and possibly causing screw heads to
become detached. 
 
secured, damage may occur to screen or product may fail.
WARNING
AA
BB

5 of 7 ISSUED: 06-04-10 SHEET #: 120-9080-2 05-14-12
If you have any questions, please call Peerless customer care at 1-800-865-2112.
If you have any questions, please call Peerless customer care at 1-800-865-2112.



fastener pack. Repeat for remaining mounting holes, level brackets and tighten screws.
NOTE: Spacers may not be used, depending upon the type of screen.


Do not over tighten. If screw cannot make three full turns into the screen, select a longer length screw from the

For Flat Back Screen
For Bump-out or Recessed Back Screen
1-1
1-2

(AA or BB)

g. 1.1






(AA or BB)
g. 1.2


6 of 7 ISSUED: 06-04-10 SHEET #: 120-9080-2 05-14-12



CROSS SECTION
DETAIL 1
AA
&
BB
AA
&
BB
g 2.1


Tension Adjustment of Ratchet Handle: Adjust
tension in tilt brackets (AA & BB) by rotating ratchet
handle. NOTE: If obstruction prevents ratchet
handle from rotating, pull handle out while turning
will allow handle to reposition without tightening.
Release and turn handle to tighten or loosen.
Mounting Screen: Ratchet handle must be in
the up or down position or interference will occur
while hooking tilt brackets to wall plate. Slowly
hook tilt brackets (AA & BB) onto wall plate and

hooks must fully engage wall plate as shown in
detail 1. Using security allen wrench (CC), turn
AA & BB)
clockwise till screw tip securely contacts wall plate
as shown in cross section.
2
Mounting and Removing Flat Panel Screen
 

 
Overtightening can cause damage to mount. Tighten

 
the bottom.
WARNING

PLATE

PLATE
Installing Multiple Wall Plates and Screens







brackets can be used to create multiple screen
displays.



7 of 7 ISSUED: 06-04-10 SHEET #: 120-9080-2 05-14-12
DETAIL 2
g 3.1
IncreLok™
TILT

 
HOLE


TILT

HOLES
For preset tilt angles use Increlok™ and for
custom tilt angle use ratchet handle.
INCRELOK™: The screen can be locked into a
pre-set tilt position of -5°, 0°, 5°, 10° or 15°. Use

to align holes. Tighten IncreLok™ tilt locking
screws on both tilt brackets to lock tilt as shown in
detail 2.
Ratchet Handle: Loosen ratchet handle (refer
Push
or pull from top or bottom of screen to adjust tilt


Adjusting the Tilt Angle of the Flat Panel
Screen
3
g 2.2


Screen Adjustment:AA & BB)
4 mm allen
wrench (CC) till screw tip securely contacts wall plate as shown in cross section.
Removing Screen: To remove screen from mount, loosen safety screws, swing screen away from mount, and lift screen
off of mount.
