Pelican HeadsUp Lite 2690 LED User manual

PART # REV ECR # RELEASE DATE START DATE VERSION
2693-319-002 A 5-36103 NO 21 10-13-21 1
DESIGNER MARKETING COPY TECHNICAL COPY TRANSLATION COPY PRODUCT MANAGER
Tyler Bennett Elissa Teitelman Jon French Estefania Fenoy Justin Nishiki
11-1-21 11-3-21 11-1-21 N/A N/A
APPROVED FOR PRINT - MUST BE APPROVED BY ALL TEAM MEMBERS
BLACK SIDES PAPER THICKNESS FLAT SIZE NUMBER OF FOLDS FOLDED SIZE
2 Sided 14.00”w x 6.8”h 4 half folds 3.40”h x 1.75”w
2690 LED Cat. # 2690
EN
INSTRUCTIONS
Battery Installation
1. Remove the two screws on the battery cover with a Phillips #1
screwdriver.
2. Install three (3) AAA batteries as per the polarity icons on the
battery compartment.
3. Replace the battery cover and screws.
WARNING: Substitution of components may impair intrinsic safety.
WARNING: Use only Duracell™ MN2400 LR03, Energizer™ E92 LR03,
Philips™ PN LR 03 (Powerlife) or Panasonic™ PN LR03 (Xtreme
Power) AAA size alkaline batteries. To reduce the risk of explosion, do
not mix old batteries with new batteries, or mix batteries from different
manufacturers. To reduce the risk of explosion, batteries must only be
changed in an area known to be non-hazardous.
Operation
1. Rotate the shroud-lens clockwise toward the headlamp body to turn
the light ON.
2. Rotate the shroud-lens counter-clockwise approximately a half
turn to turn the light OFF.
Headband Adjustment
The headband can be adjusted to suit by sliding the adjusters to tighten
or loosen the strap.
Model Type: HeadsUp Lite™2690
Certication# IECEx TRC 11.0010X
Standards IEC60079-0: 2007-10, IEC60079-11: 2006,
IEC60079-26: 2006, IEC61241-0:2004,
IEC61241-11: 2005
Code: Ex ia I Ma
Ex ia IIC T4 Ga
Ex ia IIIC T65˚C Da IP65
BATTERY SAFETY
BATTERY SAFETY – YOU MUST READ THESE WARNINGS
AND INSTRUCTIONS BEFORE USING OR CHARGING YOUR
BATTERIES!
WARNING: HANDLE AND STORE BATTERIES PROPERLY TO
AVOID INJURY OR DAMAGE
BATTERIES CAN BE DANGEROUS!
IMPROPER HANDLING OF BATTERIES CAN LEAD TO LEAKING,
FIRE OR EXPLOSION WHICH CAN CAUSE SERIOUS INJURY OR
PROPERTY DAMAGE.
Alkaline Batteries
» For those products with Hazardous Location Safety Approvals for
explosive environments, please be advised that the safety approval
is only valid for the specied battery type and manufacturers and,
where applicable, brand names that are displayed on the equipment
and/or instructions sheets that are supplied with the ashlight.
The use of other battery types may reduce the performance of the
equipment, expose the user or others to serious injury, and will
invalidate the safety approval.
» Always read the battery manufacturer’s recommendations for the
appropriate useage of the battery type/brand prior to using.
» When replacing the batteries, replace all the batteries at the same
time. DO NOT mix battery brands. DO NOT mix old and new
batteries. Always insert batteries correctly with regard to polarity
(+ and -) marked on the battery and equipment.
» DO NOT change batteries in a hazardous location.
» DO NOT use batteries beyond their expiration date.
» Remove batteries from equipment if it is not to be used for an
extended period of time.
Battery Recycling
ALWAYS dispose of batteries properly at an approved battery recycling
center. Failure to do so may be a crime and can lead to the release of
harmful toxic materials. Pelican has partnered with Call 2 Recycle in the
US and Canada to dispose of recyclable batteries. Please call
1-800-822-8837 to nd a battery recycling center near you.
ES
INSTRUCCIONES
Colocación De Las Pilas
1. Quite los dos tornillos de la tapa del compartimento de las
pilas con el destornillador Phillips #1.
2. Coloque tres (3) pilas AAA según indican los iconos de polaridad
del compartimento de las pilas.
3. Vuelva a colocar la tapa y los tornillos.
Advertencia: La sustitución de componentes puede afectar a la
seguridad intrínseca.
Advertencia: Utilice únicamente pilas alcalinas de tamaño “AAA”
Duracel™l MN2400 LR03, Energizer™ E92 LR03, Philips™ PN LR03
(Powerlife) o Panasonic™ PN LR03 (Xtreme Power). Para reducir el
riesgo de explosión, evite mezclar pilas nuevas y antiguas, así como
pilas de diferentes fabricantes. Para reducir el riesgo de explosión,
cambie las pilas sólo en una zona en donde no exista riesgo.
GARANTÍA LIMITADA DE POR VIDA DE PELICAN
Pelican Products, Inc. («Pelican») garantiza sus linternas y linternas frontales de por
vida frente a roturas o defectos de fabricación. Esta garantía no cubre la bombilla ni
las pilas/batería.
EN LA MEDIDA EN QUE LA LEY LO PERMITA: (A) ESTA GARANTÍA REEMPLAZA
CUALQUIER OTRA GARANTÍA, EXPRESA O IMPLÍCITA, INCLUIDAS, ENTRE
OTRAS, LAS GARANTÍAS IMPLÍCITAS DE COMERCIABILIDAD E IDONEIDAD
PARA UN FIN PARTICULAR; (B) QUEDAN ANULADAS Y EXCLUIDAS LAS
DEMÁS GARANTÍAS IMPLÍCITAS Y CUALQUIER OTRA RESPONSABILIDAD QUE
NO SE HAYA CONTRAÍDO EN VIRTUD DE ESTE CONTRATO; Y (C) EN NINGÚN
CASO PELI SERÁ RESPONSABLE DE NINGÚN DAÑO INDIRECTO, PUNITIVO,
INCIDENTAL, CONSECUENTE O ESPECIAL, INDEPENDIENTEMENTE DE SI
LA RECLAMACIÓN POR TALES DAÑOS SE FUNDAMENTA EN LA GARANTÍA,
CONTRATO, NEGLIGENCIA O CUALQUIER OTRO MEDIO, ni la responsabilidad
de Pelican para con el comprador en relación con los daños excederá el precio de
compra del producto objeto de la reclamación.
Pelican reparará o sustituirá los productos defectuosos a su entera discreción.
Algunos productos están disponibles durante un tiempo limitado. En el caso de las
reclamaciones relacionadas con dichos productos, Pelican se reserva el derecho a
substituir el producto roto o defectuoso por un producto Pelican estándar de tamaño
y calidad similares si en el momento de la reclamación no se dispone de ningún
producto de edición limitada similar. EN LA MEDIDA EN QUE LA LEY LO PERMITA,
ÉSTE CONSTITUIRÁ EL ÚNICO Y EXCLUSIVO RECURSO DEL COMPRADOR.
Para formular una reclamación de garantía, el comprador debe rellenar el formulario
de reclamación de garantía de pelican.com/claim. El comprador debe presentar la
reclamación de garantía lo antes posible. El comprador debe solicitar al servicio de
atención al cliente de Pelican un número de autorización de devolución antes de
devolver cualquier producto, y se hará cargo de todos los gastos de transporte en
garantía. En el caso de que Pelican determine que un producto devuelto no está
defectuoso, en virtud de lo estipulado en esta garantía, el comprador debe abonar
a Pelican todos los costes correspondientes a la manipulación, el transporte y las
reparaciones, según las tarifas vigentes de Pelican.
Si el producto presenta alteraciones, daños o modicaciones físicas de cualquier
tipo, o bien se ha hecho un mal uso, un uso abusivo, o ha sido objeto de
negligencias o accidentes, la garantía quedará anulada.
La exclusión o limitación anterior puede no ser aplicable en su caso, ya que algunos
países y estados no contemplan limitaciones en la duración de las garantías
implícitas ni exclusiones o limitaciones en los daños consecuentes o incidentales. La
presente garantía le conere derechos legales especícos, pero puede tener otros
derechos, que variarán según el Estado o el país.
La garantía de por vida no cubre los productos de la sistema de iluminación de área
remota. Visite www.pelican.com/warranty para obtener todos los detalles.
GARANTIE À VIE LIMITÉE DE PELICAN
Pelican Products, Inc. (« Pelican ») garantit à vie ses lampes torches et torches
frontales contre la casse et les défauts de fabrication. Cette garantie ne couvre pas
l’ampoule ni les piles.
DANS LES LIMITES PERMISES PAR LA LOI : (A) LA PRÉSENTE GARANTIE
REMPLACE TOUTES LES GARANTIES, EXPLICITES OU TACITES,
COMPRENANT, MAIS SANS S’Y LIMITER, LES GARANTIES TACITES DE
QUALITÉ MARCHANDE ET D’ADAPTATION À UNE FIN PARTICULIÈRE ; (B)
TOUTES LES AUTRES GARANTIES TACITES ET TOUTE RESPONSABILITÉ NON
CONTRACTUELLE SONT PAR CONSÉQUENT ICI DÉCLINÉES ET EXCLUES ,
ET (C) EN AUCUN CAS PELICAN NE SERA TENU POUR RESPONSABLE D’UN
QUELCONQUE DOMMAGE IMMATÉRIEL, PUNITIF, ACCESSOIRE OU INDIRECT,
NI D’UN QUELCONQUE DOMMAGE PARTICULIER, QU’UNE RÉCLAMATION
POUR DE TELS DOMMAGES SOIT BASÉE OU NON SUR UNE GARANTIE,
UN CONTRAT, UNE NÉGLIGENCE OU AUTRE. EN CAS DE DOMMAGES, LA
RESPONSABILITÉ DE PELICAN ENVERS L’ACHETEUR NE DÉPASSERA PAS
NON PLUS LE PRIX D’ACHAT DU PRODUIT POUR LEQUEL DES DOMMAGES
FONT L’OBJET D’UNE RÉCLAMATION.
Pelican réparera ou remplacera tout produit défectueux, à sa seule discrétion.
Certains produits sont disponibles pour une période limitée uniquement. Si une
réclamation concerne l’un de ces produits, Pelican se réserve le droit de remplacer
un produit cassé ou défectueux par un produit Pelican standard de taille et de
qualité comparables si aucun produit en édition limitée comparable n’est disponible
au moment de la réclamation. DANS LES LIMITES PERMISES PAR LA LOI, LE
RECOURS MENTIONNÉ ICI CONSTITUE LE SEUL ET UNIQUE RECOURS DE
L’ACHETEUR.
Pour déposer une demande de prise en charge sous garantie, l’acheteur doit remplir
le formulaire de demande de garantie sur la page pelican.com/claim. Toute demande
de prise en charge sous garantie doit être déposée par l’acheteur dès que possible.
Avant de retourner un produit, l’acheteur doit obtenir un numéro d’autorisation
de retour auprès du service après-vente de Pelican, et prendre à sa charge tous
les frais de transport. Dans le cas où Pelican considérerait qu’un produit retourné
n’est pas défectueux, selon les conditions de la présente garantie, l’acheteur devra
rembourser Pelican de tous les frais de manipulation, de transport et de réparation,
aux tarifs de Pelican en vigueur.
Toute demande de prise en charge sous garantie, de quelque nature qu’elle soit,
sera refusée si le produit a été modié, endommagé, s’il a subi des transformations
physiques quelles qu’elles soient, s’il a été sujet à un traitement abusif, une
mauvaise utilisation, une négligence ou un accident.
Certains états et pays n’autorisent pas les limitations de durée des garanties
implicites ni l’exclusion ou la limitation des dommages accessoires ou indirects,
de telle sorte que la limitation ou l’exclusion mentionnée ci-dessus peut ne
pas s’appliquer dans votre cas. La présente garantie octroie des droits légaux
spéciques, mais vous pouvez également bénécier d’autres droits, variables d’un
état ou d’un pays à l’autre.
La garantie à vie ne couvre pas le Système d’éclairage pour zones d’accès difcile.
Visitez www.pelican.com/warranty pour plus de détails.
PELICAN PRODUCTS, INC.
23215 Early Avenue • Torrance, CA 90505 USA
Tel (310) 326-4700 • FAX (310) 326-3311 • www.pelican.com
PELICAN PRODUCTS ULC
10221-184th Street • Edmonton, Alberta T5S 2J4
Tel (780) 481-6076 • FAX (780) 481-9586 • www.pelican.ca
2693-319-003 5-36103 Rev A NO/21
© 2021 Pelican Products, Inc.
Panasonic is a trademark and/or registered trademark of Panasonic
Corporation or afliates. Duracell is a trademark and/or registered
trademark of Duracell Batteries BVBA or afliates. Energizer is a
trademark and/or registered trademark of Energizer Brands, LLC
or afliates. Philips is a trademark and/or registered trademark of
Koninklijke Philips N.V. All other trademarks are registered and/or
unregistered trademarks of Pelican Products, Inc., its subsidiaries
and/or afliates.
PART # REV ECR # RELEASE DATE START DATE VERSION
2693-319-002 A 5-36103 NO 21 10-13-21 1
DESIGNER MARKETING COPY TECHNICAL COPY TRANSLATION COPY PRODUCT MANAGER
Tyler Bennett Elissa Teitelman Jon French Estefania Fenoy Justin Nishiki
11-1-21 11-3-21 11-1-21 N/A N/A
APPROVED FOR PRINT - MUST BE APPROVED BY ALL TEAM MEMBERS
BLACK SIDES PAPER THICKNESS FLAT SIZE NUMBER OF FOLDS FOLDED SIZE
2 Sided 14.00”w x 6.8”h 4 half folds 3.40”h x 1.75”w
Funcionamiento
1. Gire el recubrimiento-lente en el sentido de las agujas del reloj
hacia el cuerpo de la linterna para encenderla.
2. Gire el recubrimiento-lente en el sentido contrario al de las agujas
del relojaproximadamente media vuelta para apagar la linterna.
Ajuste De La Cinta Para La Cabeza
La cinta para la cabeza puede ajustarse deslizando los ajustadores
para apretar o aojar la cinta.
Tipo de modelo: HeadsUp Lite™2690
Núm. de certicación IECEx TRC 11.0010X
Normas IEC60079-0: 2007-10, IEC60079-11: 2006,
IEC60079-26: 2006, IEC61241-0:2004,
IEC61241-11: 2005
Código Ex ia I Ma
Ex ia IIC T4 Ga
Ex ia IIIC T65˚C Da IP65
SEGURIDAD SOBRE BATERÍAS
SEGURIDAD DE LAS BATERÍAS: ¡USTED DEBE LEER ESTAS
ADVERTENCIAS E INSTRUCCIONES ANTES DE USAR O CARGAR
SUS BATERÍAS!
ADVERTENCIA: MANEJE Y ALMACENE LAS BATERÍAS
ADECUADAMENTE PARA EVITAR LESIONES O DAÑOS
¡LAS BATERÍAS PUEDEN SER PELIGROSAS!
EL MANEJO INADECUADO DE LAS BATERÍAS PUEDE
OCASIONAR FUGAS, INCENDIOS O EXPLOSIONES, LO QUE
PUEDE CAUSAR LESIONES GRAVES O DAÑOS MATERIALES.
Baterías Alcalinas
» Para aquellos productos con aprobaciones de seguridad para
ubicaciones peligrosas en entornos explosivos, tenga en cuenta
que la aprobación de seguridad sólo es válida para los tipos
de baterías y fabricantes especicados y, cuando corresponda,
para las marcas que se muestran en el equipo o en las hojas de
instrucciones provistas con la linterna. Usar otros tipos de baterías
puede reducir el rendimiento del equipo, exponer al usuario u otras
personas a lesiones graves e invalidar la aprobación de seguridad.
» Siempre lea las recomendaciones del fabricante de la batería sobre
el uso apropiado del tipo o marca de la batería antes de usarla.
» Cuando reemplace baterías, reemplácelas todas al mismo tiempo.
NO MEZCLE marcas de baterías. NO MEZCLE baterías nuevas y
viejas. Inserte siempre las baterías correctamente con respecto a la
polaridad (+ y -) marcada en la batería y el equipo.
» NO CAMBIE las baterías en un lugar peligroso.
» NO USE las baterías después de su fecha de vencimiento.
» Si no usará el equipo durante un período de tiempo prolongado,
quítele las baterías.
Reciclaje De Baterías
SIEMPRE deseche las baterías correctamente en un centro de reciclaje
de baterías aprobado. No hacerlo puede ser un delito y puede provocar
la liberación de materiales tóxicos nocivos. Pelican se asoció con Call
2 Recycle en los EE. UU. y Canadá para desechar baterías reciclables.
Llame al 1-800-822-8837 para encontrar un centro de reciclaje de
baterías cerca de usted.
FR
INSTRUCTIONS
Mise En Place Des Piles
1. Retirer les deux vis du couvercle des piles à l’aide du tournevis
Phillips #1.
2. Installer trois (3) piles AAA conformément aux icônes de polarité
indiqués sur le compartiment des piles.
3. Remettre le couvercle des piles et les vis.
Avertissement: Le remplacement des composants peut nuire
aux conditions intrinsèques de sécurité.
Avertissement: Utiliser exclusivement des piles alcalines AAA
Duracell™ MN2400 LR03, Energizer™ E92 LR03, Philips™, PN LR 03
(Powerlife) ou Panasonic™, PN LR03 (Xtreme Power). Pour réduire les
risques d’explosion, ne pas mélanger piles usées et piles neuves ou
des piles de différents fabricants. Pour réduire les risques d’explosion,
les piles ne peuvent être changées que dans les espaces que l’on sait
privés de tout danger.
Mode D’emploi
1. Faire tourner le revêtement de la lentille dans le sens des aiguilles
d’une montre vers le corps de la lampe an d’allumer la torche.
2. Faire tourner le revêtement de la lentille dans le sens contraire des
aiguilles d’une montre d’environ un demi tour pour éteindre.
Réglage Du Bandeau Frontal
Le bandeau frontal peut être réglé an de s’adapter à la tête en faisant
glisser les ajusteurs pour resserrer ou desserrer la bande.
Type de modèle: HeadsUp Lite™2690
Certication# IECEx TRC 11.0010X
Normes IEC60079-0: 2007-10, IEC60079-11: 2006,
IEC60079-26: 2006, IEC61241-0:2004,
IEC61241-11: 2005
Code Ex ia I Ma
Ex ia IIC T4 Ga
Ex ia IIIC T65˚C Da IP65
SÉCURITÉ DES PILES
SÉCURITÉ DES PILES - VOUS DEVEZ LIRE CES AVERTISSEMENTS
ET INSTRUCTIONS AVANT D’UTILISER OU DE CHARGER VOS
PILES!
AVERTISSEMENT : MANIPULEZ ET STOCKEZ LES PILES
CORRECTEMENT POUR ÉVITER TOUT RISQUE DE BLESSURE
OU DE DOMMAGE
LES PILES PEUVENT ÊTRE DANGEREUSES!
UNE MAUVAISE MANIPULATION DES PILES PEUT ENTRAINER
UNE FUITE, UN INCENDIE OU UNE EXPLOSION POUVANT CAUSER
DES BLESSURES GRAVES OU DES DOMMAGES MATÉRIELS.
Piles Alcalines
» Pour ces produits soumis aux Approbations de sécurité des
emplacements dangereux pour les environnements explosifs,
veuillez noter que l’approbation de sécurité est valide uniquement
pour le type de pile et les fabricants spéciés, et le cas échéant,
les noms de marque afchés sur l’équipement et/ou les ches
d’instructions fournies avec la lampe torche. L’utilisation d’autres
types de piles peut réduire les performances de l’équipement,
exposer l’utilisateur ou d’autres personnes à des blessures graves
et invalidera l’approbation de sécurité.
» Lisez toujours les recommandations du fabricant de la pile pour
connaître l’utilisation appropriée du type/de la marque de la pile
avant utilisation.
» Lors du remplacement des piles, remplacez toutes les piles au
même moment. ÉVITEZ de mélanger différentes marques de piles.
ÉVITEZ de mélanger d’anciennes piles avec des piles neuves.
Insérez toujours les piles correctement en observant la polarité
(+ et -) indiquée sur la pile et l’équipement.
» ÉVITEZ de changer les piles dans un emplacement dangereux.
» ÉVITEZ d’utiliser les piles au-delà de leur date d’expiration.
» Retirez les piles de l’équipement en cas de non-utilisation pendant
une période prolongée.
Recyclage Des Piles
Éliminez TOUJOURS les piles correctement dans un centre de
recyclage de piles approuvés. Le non-respect de cette instruction peut
constituer un crime est entrainer la libération de matières toxiques
nocives. Pelican a formé un partenariat avec Call 2 Recycle aux États-
Unis et au Canada pour l’élimination des piles recyclables. Appelez le
1-800-822-8837 pour trouver le centre de recyclage de piles le plus
proche de chez vous.
PELICAN LIMITED LIFETIME
GUARANTEE OF EXCELLENCE
Pelican Products, Inc. (“Pelican”) guarantees its ashlights and headlamps for a
lifetime against breakage or defects in workmanship. This guarantee does not cover
the lamp or batteries.
TO THE EXTENT PERMITTED BY LAW: (A) THIS WARRANTY IS IN LIEU OF
ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE; (B) ALL OTHER IMPLIED WARRANTIES AND
ANY LIABILITY NOT BASED UPON CONTRACT ARE HEREBY DISCLAIMED
AND EXCLUDED; AND (C) IN NO EVENT SHALL PELICAN BE LIABLE FOR
ANY INDIRECT, PUNITIVE, INCIDENTAL OR CONSEQUENTIAL DAMAGES,
OR SPECIAL DAMAGES, REGARDLESS OF WHETHER A CLAIM FOR SUCH
DAMAGES IS BASED ON WARRANTY, CONTRACT, NEGLIGENCE OR
OTHERWISE, nor shall Pelican’s liability to the purchaser for damages exceed the
purchase price of the product in respect of which damages are claimed.
Pelican will either repair or replace any defective product, at our sole option. Certain
products are available for a limited time only. If a claim is made involving one of
these products, Pelican reserves the right to replace a broken or defective product
with a standard Pelican product of comparable size and quality if no comparable
limited edition product is available at the time of a claim. TO THE EXTENT
PERMITTED BY LAW, THIS SHALL BE THE SOLE AND EXCLUSIVE REMEDY OF
THE PURCHASER.
To make a warranty claim, the purchaser must complete the warranty claim form at
pelican.com/claim. Any warranty claims shall be made by the purchaser as soon as
practicable. The purchaser must obtain a return authorization number from Pelican
Customer Service prior to returning any product, and is responsible for paying for
all warranty freight costs. If Pelican determines that any returned product is not
defective, within the terms of this warranty, the purchaser shall pay Pelican all costs
of handling, return freight and repairs at Pelican’s prevailing rates.
All warranty claims of any nature are barred if the product has been altered,
damaged or in any way physically changed, or subjected to abuse, misuse,
negligence or accident.
Some states and countries do not allow limitations on how long an implied warranty
lasts or the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specic
legal rights, and you may have other rights which vary from state to state and
country to country.
In Australia: The benets provided to you under this warranty are in addition to
your rights and remedies as a consumer under the Australian Consumer Law as
contained in the Competition and Consumer Act 2010 (Cth) (“the Act”). Nothing in
this warranty limits the rights or obligations of a party under the Act in relation to
the supply to consumers of goods which cannot be limited, modied or excluded.
If applicable, our goods come with guarantees that cannot be excluded under the
Act. Consumers are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. Consumers
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure. If you are not
a consumer under the Act, then your rights may be limited. To make a warranty
claim, the purchaser may contact Pelican Products Australia, Suite 2.33, West Wing,
Platinum Bldg., Erina NSW 2250, Tel: +612 4367 7022, or email: info.australia@
pelican.com. Any claims should be made as soon as practicable. To expedite claims,
the purchaser should obtain a return authorization number from Pelican Customer
Service prior to returning any product. The purchaser is responsible for paying for
all freight costs. If Pelican determines that any returned product is not defective,
within the terms of this warranty or the Act, the purchaser may pay Pelican all costs
of handling, return freight and repairs at Pelican’s prevailing rates. In the event that
Pelican determines that any returned product is defective, within the terms of this
warranty or the Act, Pelican shall pay the purchaser all reasonable costs of the
purchaser in making a claim under this warranty.
Lifetime warranty does not cover Remote Area Lighting System products.
Visit www.pelican.com/warranty for full details.

This manual suits for next models

1

Other Pelican Headlamp manuals

Pelican 2765 User manual

Pelican

Pelican 2765 User manual

Pelican 2780R User manual

Pelican

Pelican 2780R User manual

Pelican HeadsUp Lite 2610 User manual

Pelican

Pelican HeadsUp Lite 2610 User manual

Pelican HeadsUp Lite 2610 LED User manual

Pelican

Pelican HeadsUp Lite 2610 LED User manual

Pelican HeadsUp Lite 2690 User manual

Pelican

Pelican HeadsUp Lite 2690 User manual

Pelican 2750 LED User manual

Pelican

Pelican 2750 LED User manual

Pelican HeadsUp Lite 2600 User manual

Pelican

Pelican HeadsUp Lite 2600 User manual

Pelican HeadsUp Lite 2690 LED User manual

Pelican

Pelican HeadsUp Lite 2690 LED User manual

Pelican 2755 LED User manual

Pelican

Pelican 2755 LED User manual

Pelican 2745 LED User manual

Pelican

Pelican 2745 LED User manual

Pelican 2755 LED User manual

Pelican

Pelican 2755 LED User manual

Pelican 2760 LED User manual

Pelican

Pelican 2760 LED User manual

Pelican HeadsUp Lite 2680 User manual

Pelican

Pelican HeadsUp Lite 2680 User manual

Pelican 2765 LED User manual

Pelican

Pelican 2765 LED User manual

Pelican 2755 User manual

Pelican

Pelican 2755 User manual

Pelican 2765 LED User manual

Pelican

Pelican 2765 LED User manual

Pelican 2745 LED User manual

Pelican

Pelican 2745 LED User manual

Pelican 2740 LED User manual

Pelican

Pelican 2740 LED User manual

Pelican 2780 User manual

Pelican

Pelican 2780 User manual

Pelican 2740 LED User manual

Pelican

Pelican 2740 LED User manual

Popular Headlamp manuals by other brands

WolfVision VZ-C3D instructions

WolfVision

WolfVision VZ-C3D instructions

Asaklitt MF-H05 instruction manual

Asaklitt

Asaklitt MF-H05 instruction manual

Petzl TIKKA E43P quick start guide

Petzl

Petzl TIKKA E43P quick start guide

Night Stick XPP-5450GC instruction manual

Night Stick

Night Stick XPP-5450GC instruction manual

ledlenser H7R quick start guide

ledlenser

ledlenser H7R quick start guide

ledlenser SEO 3 manual

ledlenser

ledlenser SEO 3 manual

Petzl DUOBELT LED 5 manual

Petzl

Petzl DUOBELT LED 5 manual

DOTLUX 600137 manual

DOTLUX

DOTLUX 600137 manual

StreamLight PROTAC HL USB user manual

StreamLight

StreamLight PROTAC HL USB user manual

Petzl Tikka Plus 2 manual

Petzl

Petzl Tikka Plus 2 manual

Facom 779.FRT3 Original instructions

Facom

Facom 779.FRT3 Original instructions

Petzl TIKKA quick start guide

Petzl

Petzl TIKKA quick start guide

Lupine NEO user manual

Lupine

Lupine NEO user manual

Stanley HL2S instruction manual

Stanley

Stanley HL2S instruction manual

Princeton Tec Byte Operating and maintenance instructions

Princeton Tec

Princeton Tec Byte Operating and maintenance instructions

Nitecore HA40 user manual

Nitecore

Nitecore HA40 user manual

LumX TCT-640 instruction manual

LumX

LumX TCT-640 instruction manual

Silva TIPI Full version manual

Silva

Silva TIPI Full version manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
