Pentair silentflo User manual

OWNER’S MANUAL
Should the installer or owner be unfamiliar with the correct
installation or operation of this type of equipment you should contact
the distributor/manufacturer for the correct advice before proceeding
For the Installation, Operation and Service of
SilentFlo
Pool Pump
The pump must be supplied from a circuit
with the installation or operation of this product.
protected by a residual current device (RCD) with
a maximum rated residual current of 30mA
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

Table of Contents
Page
Model Data 2
Installation 3
Pressure Testing 4
Pump Mount 5
Tef on Taping Instructions 6
Fittings 6
Pool Outlets 6
Entrapment Protection 7
Testing and Certif cation 7
Outlets per Pump 7
Water Velocity 7
Electrical 8
Operation 9
Priming Pump 10
Service and Maintenance 11
Troubleshooting 12
Parts Breakdown 14
1
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

Model Data
2
Part Output Power Max Total Head
Number (m)
(W) (hp)
SF550100 550 3/4 18
SF750103 750 1 17
SF1100100 1100 1.5 15
SF1500100 1500 2 12
Technical Information
Inlet (Suction):
ABS Barrel Union to suit 50mm I.D PVC pipe
to AS/NZS 1477
Outlet (Discharge): ABS Barrel Un ion to suit 50mm I.D PVC pipe
to AS/NZS 1477
Max Working Pressure: 260 kPa
Water Temperature Range: 5°C – 38°C
IP Rating: IPX5
Electrical Rating: 230-240V 50Hz single phase
Motor: Built in auto reset overload protection.
Flexible power supply cord 10Amp.
Recommended pH Range: 7.2 - 7.8 (Guide Only)
Maximum Ambient temperature: 55°C
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

3
Incorrectly installed or tested equipment may fail, causing severe injury
or property damage.
Read the following instructions in this owner’s manual
when installing and operating equipment. Have a trained
pool professional perform all pressure tests.
1. Do not connect system to high pressure or mains
water system.
2. Use equipment only in a swimming pool or spa pool
installation.
3. Install pump with at least 2 hydraulically balanced
main drains equipped with correctly installed, screw -
fastened, antientrapment certified covers according
to local regulations.
4. Trapped air in system can cause explosion.
Ensure all air is out of the system before operating or
testing equipment.
Silentflo is electrically connected. Ensure that it is isolated
from electrical supply during installation and any subsequent
service work.
The pump should be installed and serviced by a suitably
qualified person in order to avoid hazard.
These instructions are a guide only. Should you the installer or
owner of the product be unfamiliar with the correct installation
or operation of this product you should contact a suitably
qualified person for advice.
Freezing conditions will damage the unit, as water expands as
it freezes. Ensure that Silentflo is located so that it is not prone
to freezing, or ensure that the product is disconnected and
dried of water during cold conditions.
Installation
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

4
(Have a trained pool professional perform all pressure tests).
Before pressure testing, make the following safety checks:
1. Check all clamps, bolts, lids, and system accessories prior to testing.
2. Release all air in system before testing.
3. Tighten trap lid to 4.1kg-m torque for testing.
4. Water pressure for test must be less than 170kPa (25 PSI)
5. Water tempertaure for test must be less than 38°C
6. Limit test to 24 hours. After test, visually check system to be sure it is ready
for operation. Remove trap lid and retighten hand tight only.
Fire and burn hazard. Modern motors run at high temperatures. To reduce
risk of fire, do not allow leaves, debris, or foreign matter to collect around the
pump motor. To avoid burns when handling the motor, let it cool for at least
20 minutes before trying to work on it. A thermal overload switch protects the
motor from heat damage during operation.
Only qualifi ed, licensed personnel should install pump. The electrical
installation shall be in accordance with the national wiring rules (AS/NZS 3000)
for class I, IP55 rated products. Refer to page 10 for Electrical Installation.
Pressure Testing
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

Pump mount must:
1. Be located away from corrosive or flammable chemicals. Have enough ventilation to
maintain air tempertaure at less than the maximum ambient temperture rating. If this
pump is installed in an enclosure/pump house, the enclosure must have adequate
ventilation (200sq.cm min, inlet & outlet) and air circulation to keep the temperature
in the enclosure at or below the motor’s rated ambient temperature whenever the
pump is running. Keep rear of motor clear (150mm).
2. Be solid, level, rigid and ribration free. (To reduce vibration and pipe stress, bolt pump
to mount). Fixing holes accept 12mm fasteners.
3. Allow pump suction inlet height to be as far below water level as possible.
4. Allow use of short, direct suction pipe (to reduce friction losses).
5. Allow for shut-off valves in suction and discharge piping.
6. Have adequate floor drainage to prevent fl ooding.
7. Be protected from excess moisture
8. Allow adequate access for servicing pump and piping.
We recommend mounting the pump on a concrete platform for quietest performance.
Use Tefl on tape for making all threaded connections to the
pump. DO NOT use pipe dope (glue) as this will cause stress
fractures in the pump.
Pump suction and discharge connections have moulded in
thread stops. DO NOT screw pipe in beyond these stops.
DO NOT use sealants which are incompatible with pipe fi ttings.
Pump Mount
5
Equipotential
Bonding Terminal
Fixing Holes
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

 Use only new or clean PVC pipe fi
6
ttings.
 Wrap male pipe threads with a sufficient number of layers of Tefl on tape.
Cover entire thread portion.
 Do not overtighten or tighten past thread stop in pump port.
 If leaks occur, remove pipe, clean off old tape, wrap as previously with one
to two additional layers of tape and remake the connection.
Piping
Support all piping connected to the pump.
 Use at least 2” (50mm) PVC pipe. Increase size if a long run is needed.
 To avoid stress on the pump, support both suction and discharge pipes
independently.
 Place these supports as close to the pump as possible.
 To avoid a strain left by a gap at the last connection, start all piping at the pump
and run pipe away from the pump.
 Never use a suction pipe smaller than pump suction connections (2”/50mm).
 To avoid airlocking, slope suction pipe slightly upward toward the pump.
 Do not use an elbow near the suction port of the pump. Use a straight length of
pipe into the suction port.
To prevent flooding when removing pump for service, all fl ooded suction
systems must have shut-off valves in suction and discharge pipes.
Fittings
Teflon Taping Instructions
Fittings restrict flow; for best efficiency use fewest possible fittings. Avoid
fittings which could cause an air trap.
Pool Outlets
Use only non-entrapping suction fitting or double suction conforming with
the AS1926.3 standard.
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

7
Pump suctions are hazardous and can trap and drown or disembowel bathers.
Do not use or operate pump, pool or spa if a suction outlet cover is missing,
broken, or loose. Follow the guidelines below for a pump installation which
minimises risk to users or pools and spas.
Entrapment Protection
The pump suction system must provide protection against hazard of suction
entrapment or hair entrapment/entanglement.
Testing and Certif
ication
Suction outlet covers must have been tested by a nationally recognised
testing laboratory and found to comply with the latest AS1926.3 standard or
ASME/ANSI specification for Suction Fittings For Use in Swimming Pools,
Spas, Hot Tubs, and Whirlpool Bathtub Applications.
Outlets Per Pump
Provide at least two hydraulically balanced main drains, with covers, for each
swimming pool pump suction line. The centres of the main drains (suction
fittings) must be at least 800mm apart.
The system must be built so that it cannot operate with the pump drawing
water from only one main drain (that is, there must be at least two main drains
connected to the pump whenever it is running). However, if two main drains
run into a single suction line, the single suction line may be equipped with a
valve which will shut off both main drains from the pump.
More than one pump can be connected to a single suction line as long as the
requirements above are met.
Water Velocity
The maximum water velocity through any suction outlet must comply with
the latest AS1926.3 Standard or ASME/ANSI Specification for Suction
Fittings For Use in Swimming Pools, Spas, Hot Tubs, and Whirlpool Bathtub
Applications.
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

Hazardous voltage.
Can shock, burn or
cause death.
8
WARNING
Electrical
Electrical installation shall be in accordance with the national wiring rules (AS/NZS
3000) taking into account its ratings (Class I, IPX5). The pump is supplied with a
standard Australian 10 amp plug and 2 metres of cord. Select the correct Pool Zone
for installation.
Using the tapped hole terminal and tin plated copper lug connect the equipotential
bonding conductor to the pump if required. The terminal is on the motor side of the
fl ange. Remove paint from the terminal surface and use M5x12 zinc plated screw with
lock washer or similar to secure the termination.
An RCD with maximum rated residual current of 30mA is required for the power supply
to the pump. Additionally, if a suitable socket outlet is not available a weatherproof
socket must be installed by an electrician in a suitable location. RCD tripping indicates
an electrical problem. If RCD trips and will not reset have a qualifi ed electrician inspect
and repair electrical system.
Do not use extension leads as they are unsafe in and around the Pool Zone.
Incorrect voltage can cause fire or seriously damage pump and voids warranty.
Voltage at pump must not be more than 6% above or
10% below motor nameplate rated voltage or pump
may overheat, causing overload tripping and reduced
component life. If voltage is less than 90% or more than
106% of rated voltage when pump is running at full load,
consult the power company.
To avoid dangerous or fatal electrical shock, turn OFF
power to pump and remove plug from outlet before
working on electrical connections.
The power supply cord has a type ‘Y’ attachment and if
service is required to the power cord, it must be replaced
with the specialised power cord assembly by Pentair
Water service agent or similarly qualifi ed personnel in
order to avoid a hazard. Warranty is void if unauthorised
modifications are made to any component.
No valves between Tee
and Main Drains
Valves OK between
pump and Tee
Suction Outlet
(Main Drain)
Suction Outlet
(Main Drain)
Certified Anti-entrapment
Cover or Suction Fitting,
screw fastened to Main
Drain Sump
Certified Anti-entrapment
Cover or Suction Fitting,
screw fastened to Main
Drain Sump
Pump
800mm
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

The pump operator or owner must be provided with this owner’s
9
manual. This must be read before operation, and followed during
operation.
The pump is not intended for use by young children or infi rm persons
without supervision. Young children should be supervised to ensure
that they do not play with the pump.
NEVER run pump dry. Running pump dry may damage seals, causing
leakage and flooding. Fill pump with water before starting motor.
If pump has been pressure tested, ensure pressure has been released
before removing trap lid. Do not block pump suction. To do so with
body may cause severe or fatal injury.
Small children using pool must ALWAYS have close adult supervision.
Pump suction is hazardous and can trap and drown or disembowel
bathers. Do not use or operate pump, pool/spas if a suction outlet
cover is missing, broken, or loose. Follow the guidelines below for a
pump installation which minimises risk to users of pool and spas.
Fire and burn hazard. Modern motors run at high temperatures. To
reduce the risk of fire, do not allow leaves, debris, or foreign matter
to collect around the pump motor. To avoid burns when handling the
motor, let it cool for at least 20 minutes before trying to work on it.
Before removing trap lid:
1. SWITCH OFF POWER SUPPLY to pump and unplug from outlet
before proceeding.
2. CLOSE SHUT-OFF VALVES in suction and discharge pipes.
3. RELEASE ALL PRESSURE from pump and piping system.
4. NEVER tighten or loosen trap lid while pump is operating.
Operation
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

10
An automatic internal thermal overload switch protects the
motor from heat damage during operation and if operated
can restart without notice.
Maximum ambient temperature for motor operation must not
exceed maximum ambient temperature range (See page 4).
Switch the pump off at the controller or power point while
ambient temperature exceeds maximum.
Priming Pump
Release all air from fi
flooded suction system (water source higher than pump), pump will prime itself when
suction and discharge valves are opened.
If pump is not in a flooded suction system, disconnect power supply to pump follow
above instructions for removing trap lid; fill trap and pump with water.
Do not lubricate the trap lid o-ring. The original equipment O’ring contains a permanent
internal lubricant.
If the o-ring needs replacement insist on genuine Onga service parts. Clean and
inspect o-ring; reinstall on trap. Replace trap lid turn clockwise to tighten by hand only
- no wrenches!
Pump should prime now. Priming time will depend on vertical height of suction lift
and horizontal length of suction piping. The self-priming time range is 1 to 3 minutes
for a height difference of 2 to 3 metres, under normal installation conditions. Normal
conditions are understood to be: with suction having an internal diameter of DN 50mm,
water temperature at 20°C, and 50Hz mains power supply.
Should the pump not prime, ensure that all valves are open, lint trap is clear of debris
and suctions and suction pipe end is submersed in water, and that there are no leaks in
suction pipe. See troubleshooting guide.
lter, pump and piping system: refer filter owner’s manual. In a
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

To avoid dangerous or fatal electrical shock hazard, turn OFF
power to motor and remove plug from power outlet before
working on pump or motor.
Routine Maintenance requires regular checking of the pump to ensure no water is
leaking from joints whilst pump is operating and inspection/cleaning of trap basket.
Debris or trash that collects in basket will choke off water fl ow through the pump.
Do not operate pump with trap basket missing or damaged.
Follow instructions below to clean trap:
1. Switch off power to pump, close valves in suction and discharge, and release all
pressure from system before proceeding.
2. Remove trap cover (turn clockwise). If necessary, tap handles gently with a rubber
mallet or use a board as a lever.
3. Remove strainer basket and clean. Ensure all holes in basket are clear, fl ush basket
with water and replace in trap with large opening at pipe connection port (between
ribs provided). If basket is replaced backwards, the cover will not fit on trap body.
To clean tranparent cover, use water and neutral soap only. Do not use solvents.
4. Clean and inspect lid o-ring; reinstall on trap.
5. Clean O’ring groove on trap body and replace cover. To help keep cover from
sticking, tighten hand tight only.
6. Prime pump (refer priming instructions).
Pump Service
Pump should only be serviced by qualifi
genuine Onga service parts. Be sure to prime pump before starting.
Before removing clamp or trap cover:
1. SWITCH OFF POWER to pump before proceeding.
2. CLOSE SHUT-OFF VALVES in suction and discharge pipes.
3. RELEASE ALL PRESSURE from pump and piping system.
4. NEVER tighten or loosen covers, valves, nuts or bolts while pump is
operating!
11
Service & Maintenance
ed personel. For best results, use only
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

12
No lubrication or regular maintenance is needed beyond reasonable care and periodic
cleaning of strainer basket. When pump is not in use and there is a risk of frost, empty
it completely through the drain plug. If shaft seal is worn or damaged consult your
Pentair Water authorised service agent.
Symptom Cause Remedy
Low water pressure, low f ow
from pump.
Suction leaks / lost prime. Pump must be primed; make sure
that the pump casing and strainer
are full of water. Refer priming
instructions.
Make sure there are no leaks in
suction piping.
Make sure suctions pipe inlet
is well below the water level to
prevent pump from sucking air.
Suction lift of 3 to 6 metres will
reduce performance. Suction lift
of more than 6 metres will prevent
pumping and cause pump to lose
prime. In either instance, move the
pump closer (vertically) to water
source. Ensure that the suction
pipe diameter is large enough.
Low voltage. Check voltage at motor terminals
and at meter while pump is
running - this check should
be performed by a qualif ed
electrician only. If voltage is low
check for loose connections or
consult your power company.
Clogged pipe / strainer /
impeller / f ilter system.
Ensure trap is not clogged with
debris; clean basket and/or f ilter.
Make sure that the impeller is not
clogged. This should be checked
by qualif ied personnel only.
Pump may be trying to push too
high a column of water. If so, a
Trouble Shooting
higher pressure pump is required.
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

13
Trouble Shooting
Symptom Cause Remedy
No water coming from pump
(Pump is working).
Air ingress to system. Prime the pump. Check that there
are no air leaks in the suction
piping or f ittings. Ensure the
strainer lid is airtight and f itted
securely.
Pump does not work.. Motor termal overload
tripped.
Check for required ventilation and
cooling. If temperature is above
the pump’s maximum ambient,
turn off pump until it cools down.
No power at outlet. Use another electricial appliance
that is known to work to check
power outlet.
Blown fuse / Circuit breaker. Check and call electrician if
necessary.
Motor burnt out due to
voltage spike or f ooded by
water.
The motor may need replacing.
Pump running too slow. Motor capacitor may be
damaged.
Check line voltage; if less that
90% or more that 106% of
rated voltage consult a licensed
electrician.
Water leaking from between the
casing and motor.
Casing bolts are not
tightened suff iciently; worn
mechanical seal requires
replacing.
Switch off the power to the pump.
Tighten the casing bolts or replace
the mechanical seal as required.
Should problems persist, contact your nearest Pentair Water Service Agent.
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:22 PM

14
Parts Breakdown
No. Description Qty Part Number
2SLINGER
3SCREW 3/8"UNC x 1" HEX SS
MOTOR FASTENERS KIT (INCLUDES ITEM 3x4)
4SEAL PLATE
5 MECHANICAL SEAL
MECHANICAL SEAL (25 PACK)
6O-RING PUMP CASING
7 IMPELLER
8DIFFUSER
9 O-RING DIFFUSER
10 SCREW 8/32" x 22mm SS PHILLIPS HEAD
DIFFUSER & O-RING KIT (INCLUDES ITEM 8, 9 & 10x7)
11 LID
12 O-RING LID
13 BASKET
14 DRAIN PLUG & O-RING
15 NUT 3/8" SS
16
17
WASHER SPRING M10 SS
WASHER 3/8" x 3/4" x 184 SS
PUMP FASTENERS KIT
18 PUMP CASING
PUMP CASING ASSEMBLY
19 BARREL UNION KIT (INCLUDES 19a, 19b & 19c) x2
19a COLLAR UNION 2" SLIP
19b COLLAR UNION 2"
19c ORING-Collar Union
20 BASE
21 SCREW 5/16-14" x 1"
22 MOTOR PAD
BASE KIT (INCLUDES 19, 20 & 21)
1 MOTOR
SF550100
1
4
1
1
1
1
1
1
1
1
7
1
1
1
1
2
6
6
10
1
1
1
2
2
2
1
2
1
1
(405691)
801418
See Motor
See Motor Fasteners Kit
801279
C3-184P
801428
800900
1660500
801424 801425 801426 801427
801280
See Pump Casing Assembly
C176-71P
801245
801281
See Barrel Union Kit
See Pump Base Kit
17307-0111
35505-1440
C8-58P
U178-920P
See Pump Fasteners Kit
See Pump Fasteners Kit
See Motor Fasteners Kit
See Diffuser and O-Ring Kit
SF750103 SF1100100 SF1500100
(405692) (405693)
801419 801420
801421 801422 801423 801423
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:23 PM

IMPORTANT
Please attach your sales invoice/docket here as proof of purchase should
warranty service be required.
Please do not return Warranty Form to Pentair Australia -
please retain for your records.
Purchased From ...................................................................................................................
Purchase Date..................................... Serial No.............................. Model No........................
© Information contained here-in remains the property of Pentair Water Pty Ltd. Any reproduction,
display, publication, modif ication or distribution is strictly prohibited without the prior written
permission of Pentair Water Pty Ltd.
Disclaimer: Every endeavour has been made to publish the correct details in this data sheet.
No responsibility will be taken for errors, omissions or changes in product specif ications.
Pentair Water reserves the right to change specif ications
Head Office
Pentair AU/NZ: 1-21 Monash Drive,
Dandenong South, Vic 3175
Australia
National Customer Service: Phone: [phone]
Fax: [phone]
National Dealer Locator: Phone: [phone]
Ema il: [e-mail]
We b: www.pentair.com.au
New Zealand
National Customer Service: Phone: [phone]
Fax: [phone]
National Dealer Locator: Phone: [phone]
Ema il: [e-mail]
Web: www.pentair.co.nz
International Australia/New Zealand
Phone: [phone]
Fax: [phone]
L300216 1212
L300216_SilentFlo_OM_2012
Monday, 17 December 2012 1:32:23 PM
