Pentair INTELLICHLOR COMSYS-10 User manual

IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
INTELLICHLOR®SALT CHLORINATOR
COMMERCIAL SYSTEM
COMSYS-10 (P/N 520974)
INSTALLATION GUIDE

1
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
IntelliChlor®Salt Chlorine Generator (SCG) COMSYS-10 Overview
The IntelliChlor COMSYS-10 commercial system consists of four IntelliChlor (SCG) cells and four power
centers (one primary and four secondary).
Each cell can produce up to 2.00 lbs of pure chlorine per 24 hours of operation. These cells can sanitize either a
pool or spa, or combination of both. Acommercial system requires an external ORPpanel and sensor to
produce chlorine upon demand as needed. The ORPsystem is sold separately.
Features
• Each cell draws approximately 220 Watts.
• Dry contact wires on primary power center connect to chlorine controller panel (ORP system).
Closing these wires turns the Comsys system on with an output level of 100%. The system is now
producing chlorine. Opening these wires turns the Comsys system off with an output level of 0%, so
the system is not producing chlorine.
• Each cell produces 2.00 pounds of chlorine per 24 hours.
• Comsys-10 (5-cell - 1 primary and 4 secondary) produces ten pounds of chlorine per day.
• The ORP system (not provided) is a separate device that monitors the available chlorine in the water
and, when needed, calls for chlorine to be produced by closing a dry contact output. An ORP
system consists of a panel, usually with an LCD display, that has the ORP sensor in the water.
Preparing the Site
1. Add salt to the water until it measures 3600 ppm. Use an electronic tester to measure salt, such as
the Extech EC400. DO NOT USE SALT TEST STRIPS AS THEY TEND TO BE INACCURATE.
Allow the salt to mix for 24 hours before using the IntelliChlor system.
2. Locate a clear spot on a wall, within 15 feet of the IntelliChlor manifold.
3. Locate a clear spot on the return line where the IntelliChlor manifold will be mounted. Be sure that
the user can readily see the lights and press buttons if needed.
4. Be sure 110VAC or 220VAC is available and on its own circuit breaker, to power the IntelliChlor
power centers. This separate breaker will make it easier to service the IntelliChlor.
5. Be sure 110VAC or 220VAC is provided to the power center bank in a conduit, for maximum safety
and NEC compliance.

2
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
Installation
Before installing the IntelliChlor CIC60 system, please read all SAFETY PRECAUTIONS below.
Kit Contents
-Five Power Centers(one primary,four secondary)
-One CIC60Pcell
-Four CIC60Scells
-Installation Guide(this manual)
RequiredTools
-Medium phillipsor flathead screwdriver(and tenscrews)
- Electric drill and 1/4" masonry drill bit. (To mount Power Center Bank)
Mount Power Center BanksToWall
1. Locate awall near thepool equipment areawithin 15 feetof the IntelliChlor cells. Positionthe
CPC103 POWER CENTER BANK on the wall at eye level. Mount and secure the power center
bank to the wall using six (6) screws (not provided in kit). See illustration on next page.
2. Position the CPC202 POWER CENTER BANK on the wall at eye level either just below or to
the right of the CPC103.
3. Mount and secure the CPC103 power center bank to the wall using six (6) screws (not provided in
kit).See next page for illustration.
SAFETY PRECAUTIONS - PLEASE READ BEFORE PROCEEDING
IMPORTANT SAFETY PRECAUTIONS. PLEASE READ THE FOLLOWING:
Read all the safety precautions in this manual before attempting any electrical wiring. Be
sure to read and follow all safety Instructions on page ii.Wiring should only be performed
by a qualified professional. When using electrical products, basic precautions should
always be followed, including the following:
RISK OF ELECTRIC SHOCK,WHICH CAN RESULT IN SERIOUS INJURY OR DEATH. Before
attempting installation of service, ensure that all power to the circuit supplying power to the
system is disconnected/switched off at the circuit breaker. The Power Center must be
interconnected with pool pump motor power source.This insures the IntelliChlor chlorinator and
pool pump will switch on and off together.
• Grounding (earth bonding) is required.The unit should be installed by a qualified service
person and grounded.
CAUTION - Install the IntelliChlor cell a minimum of two (2) feet from the heater outlet.
• Allow ample access to the IntelliChlor control panel buttons and the IntelliChlor Power Center.
• Pipe couplings:Schedule 80, maximum pressure 150 psi at 70° F.
• Operate unit with a minimum flow rate of 25 gpm per celll. For high flow applications, use a
bypass loop.

3
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
Mount Power Center Banks ToWall (Continued)
4. Remove the cover retaining screw and remove the cover from
upper side left PRIMARY power center and the lower left
side SECONDARY power center.
Connect AC PowerWires and ORP SensorWires
1. Mount a JUNCTION BOX on the left
side of the Power Center Banks.
2. Run a CONDUIT(with 208VAC -
260VAC wires) from theAC
BREAKER to the junction box. Note:
ThisAC power should be on its own
breakerfor futureservicing.
Note: For 110VAC operations, each
power center will need to be re-
configured. A 110VAC wiring
diagram is provided on the inside of
each the power center covers.
3. Run conduitfrom thejunctionbox into
each of the power centers located on
theleft side (PRIMARYand
SECONDARY).A(knock-out) conduit
opening is provided on the bottom of
each of power centers.
Mount power centers to wall using four
(4) screws
Remove cover screw
and cover
Remove cover screw and cover
Mount power centers to
wall using six (6) screws
CPC103
CPC103
CPC202
CPC202

4
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
Connect these
wires to ORP
PRIMARY SECONDARY SECONDARY
Connect these
wires to AC
power source
Connect AC PowerWires and ORP SensorWires (Continued)
4. Splice the incomingAC power wires onto the two wires labeled WIREDFOR 220V. Do not
applyAC power yet.
5. Connect the two (2) twisted wires labeled ORPSENSORto the ORP chlorine controller panel
(AcuTrol, etc., not included in kit). Carefully place the connection inside of power center.
6. Replace the cover on the upper Primary power center and lower Secondary power center.
Secure each cover with the retaining screw.
PRIMARY Secondary Secondary
Secondary Secondary
CPC103
CPC202
CPC103
Splice in junction box
(see STEP 4)
Communication
wires

5
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
7. Remove the cover retaining screw and remove the cover from the SECONDARY power center,
located on the top bank, far right side (CPC103).
8. Route the communication cable from the CPC202 power center through the bottom hole of the
CPC103 Secondary power center.
9. Insert the two wires from the CPC202 into terminal block in same order as the wires already
connected. Be sure to match the wire colors. GREEN to GREEN andYELLOW toYELLOW.
10. Replace the cover on the upper Secondary power center (top far right side). Secure the cover with
theretaining screw.
GREEN and
YELLOW wire
from CPC202
power center
Terminal screw
connector: Match wires
GREEN to GREEN and
YELLOW to YELLOW
CPC103
PRIMARY SECONDARY SECONDARY
CPC103
Insert wires from
CPC202 into hole and
connect into terminal
connector
Communication
wires

6
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
Assemble the Manifold
1. Place an o-ring into groove on union coupling.
2. Place each cell on the manifold and tighten coupling nut securely. Be sure the o-ring stays
in place. Note: Cells labeled PRIMARY and SECONDARY can be placed anywhere in
the manifold, they do not need to be in a specific location.
3. Glue the manifold into the system plumbing at desired location, either horizontal or vertical.
Make sure the cells are readable and the buttons can be pressed if needed.
CAUTION: Do not install upside down!
4. Verify water flow direction See the FLOW arrow located on the IntelliChlor cell near the
input coupling.
IMPORTANT! MANIFOLD ASSEMBLY AND INTELLICHLOR CELL MUST BE
INSTALLED IN THE VERTICAL POSITION, AS SHOWN BELOW.
Gluethemanifold
6. Glue manifold into system plumbing at the desired location. The manifold will sit on the floor. Be sure
the cells are readable and the buttons can be pressed if needed. Do not install upside down!
7. Verifywaterflow direction.
O-ring
Union coupling nut
Coupling
Manifold
Outlet
Inlet
Drain
Stand
Spacer
DO NOT MIX OLD AND
NEW MANIFOLD PARTS.
MANIFOLD
DIMENSIONS MAY NOT
BE BACKWARDS
COMPATIBLE.

7
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
Connect the IntelliChlor Cells
1. Connect the cell power connector, labeled PRIMARY(CIC60P), into the receptacle on the
bottom of the power center labeled PRIMARY. While holding the connector on the receptacle,
turn it slowly until the plug pins are inserted into the receptacle, then twist it to lock it in
place.
2. Plug the four SECONDARY cell power connectors into each of the power centers labeled
SECONDARY using same method as described in step 1.
PRIMARY SECONDARY SECONDARY
Secondary power
center receptacle
Primary (CIC60P)
power center receptacle
Secondary connector
Primary (CIC60P) connector
SECONDARY SECONDARY
CPC103
CPC202
Communication
wires

8
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
PRIMARY SECONDARY SECONDARY
Terminal Screw
Connector
CPC203
CPC103
SECONDARY SECONDARY
Power Centers
The PRIMARYand SECONDARYpower centers have been pre-wired with communication wires as shown
below.
Power Centers (Front View)
Power Center
communication wire
connection

9
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
Operation
When the ORP system requests chlorine, it closes the dry-contact output that is connected to the ORP
SENSOR wires, and causes each cell to set its output level to 100%. The CELL light will turn on and
chlorine will be produced. If the ORP system is not requesting chlorine (ORP SENSOR wires open),
all lights in the SANITIZER OUTPUT section will be off, no chlorine is produced.
Chlorine will be produced only when:
• SANITIZER OUTPUT 100% light is on
• CELL is green and not flashing
• FLOW light is green
• Salt is FLASHING GOOD, GOOD, or CHECK SALT
Note: Verify each cell has a green FLOW light, to show that adequate water is flowing through the
cell.
• After power up, all cells will scroll the salt lights LOW, CHECK SALT and GOOD for 2 minutes
while waiting to check salt. If FLOW is red, these lights will scroll indefinitely.
• After 2 minutes of green FLOW, the salt will be read and all cells will now display the same salt
color.
• If the CELL light is flashing, the cell has become dirty and requires acid cleaning. Turn off the
circuit breaker to the power centers, disable water flow through the manifold (either an external
valve or turn off the filter pump), and remove the cell. Check the cell and acid clean if necessary.
Power Up the system
1. Switch the AC circuit breaker to ON to apply AC power to the system.
2. After the system is powered up for one minute, if any SECONDARY cell shows a red light,
the communications to that cell is not connected.
Open the power center covers and verify the two green and yellow wires on each terminal
block are connected and in the same order. Verify these connections from each
SECONDARY power center to the PRIMARY power center (see page 6).
3. Apply water flow to the cell manifold. When water flow is present, each cell's FLOW light
will go from red (no flow) to green (flow).
4. The GOOD, CHECK SALT and LOW salt lights on each cell will scroll back and forth for
two minutes before checking the salt level. If water flow is not present, this two minutes
will start over when flow is restored. Note: THE SALT LEVEL CAN NOT BE CHECKED
WHEN THE FLOW LIGHT IS RED.
5. After two minutes, the salt level will be read and displayed on all cells.

10
IntelliChlor Electronic Chlorine Generator COMSYS-10 Installation Guide
Troubleshooting
TheIntelliChlor100% light doesnotcome on whenthechlorinecontroller calls forchlorine
1. Verify the ORP controller is opening and closing the dry-contact output.
2. Remove the ORP SENSOR wires connection from the PRIMARY power center and the ORP
controller. Manually tie the ORP SENSOR wires together. This will turn on the cells at 100%. If
the 100% lights do not come on for each cell or only one cell, verify the communication wires are
connected, shown in POWER UP THE SYSTEM, step 3, page 7.
The IntelliChlor 100% light stays on after the chlorine controller says to stop
1. Verify the communication wires are connected, as shown in section 5, POWER UP THE SYSTEM,
step 3.
2. Verify the ORP SENSOR wires are not shorted together in the power center.
3. Verify the ORP controller dry contact output is opening and closing by using an ohmmeter.
Manually set this output open and closed using the controller menu system.
The CHECK SALT light is on
More salt needs to be added to the water.
1. Add salt to the water and bring up to 3600ppm. Allow it to mix for 24 hours.
2. The salt level will be automatically checked every 8 hours by the primary cell and displayed.
The LOW salt light is on
Not enough salt is in the water to produce chlorine, cell is OFF.
1. Add salt to the water and bring up to 3600ppm. Allow it to mix for 24 hours.
2. The salt level will be checked every 8 hours by the cells and displayed.
Not enough chlorine is produced
1. Ensure the ORP sensor probe on the chlorine controller unit is clean and working.
2. Verify the IntelliChlor cells do not have a flashing CELL light. If so, remove the cell and acid clean.
3. Verify no debris is in the cells. Remove if present.
4. Verify the FLOW light is green, for adequate water flow.
5. Verify the salt level lights are displaying either green GOOD or yellow CHECK SALT. If displaying
yellow CHECK SALT, add salt to the water, and allow to mix for 24 hours.
6. Verify the ORP controller sets the cells to 100% SANITIZER OUTPUT or 0%, by manually
controlling this output relay (done in the ORP controller, not the IntelliChlor) or by disconnecting
the ORP SENSOR wires from the power center and manually opening and closing the wires.
7. Verify the ORP probe is clean.
8. Verify the filter pump is not being turned off by a timer.
The cell is not powered up
1. Check fuse, replace if open. 2. Check if cell connector is plugged and twist-locked all the way in.
Fuse is blown
1. Replace with 12 amp ceramic fuse. DO NOT USE 10AMP glass (a common fuse), it is not reliable and
might fail later. If the fuse blows again, replace the cell.
2. Verify the Power center is not wired for 110VAC and has 220VAC applied to it. THIS IS NOT COVERED
BYTHE WARRANTY.

Salt is an inherently corrosive material. While the levels of salt required for proper operation of the IntelliChlor Salt
Chlorine Generatorr (SCG) are relatively low when compared to sea water and other salt solutions, placing any
amount of salt in your pool increases the likelihood of corrosion or other deterioration of pool equipment and any
surfaces used in and around your pool. Metal parts (including metal pools) and certain natural and man-made
surfaces are particularly susceptible to corrosion and deterioration when used in and around salt water pools.
Pentair Water Pool and Spa, Inc. (“Pentair”) does not represent or otherwise guarantee that the proper use of
the (SCG) will prevent corrosion or other deterioration of pool equipment and any surfaces used in and around
your pool. Consult your experienced pool professional, who should be able to advise you on the proper material
selection, installation techniques for those materials, and the proper use, care and maintenance of those materials
for your specific pool type and location in order to minimize the corrosion and deterioration that is inherent in and
around salt water pools.
PENTAIR WATER POOL AND SPA, INC
1620 HAWKINS AVE., SANFORD, NC 27330 • [phone]
10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • [phone]
WWW.PENTAIRPOOL.COM
TECHNICAL SUPPORT: 800.831.7133
All Pentair trademarks and logos are owned by Pentair or one of its global afilliates. Pentair Aquatic Systems®, IntelliChlor®, EasyTouch®, and
IntelliTouch®, are trademarks and/or registered trademarks of Pentair Water Pool and Spa, Inc. and/or its affiliated companies in the United States
and/ or other countries. Unless expressly noted, names and brands of third parties that may be used in this document are not used to indicate an
affiliation or endorsement between the owners of these names and brands and Pentair Water Pool and Spa, Inc. Those names and brands may be
the trademarks or registered trademarks of those third parties. Because we are continuously improving our products and services, Pentair reserves
the right to change specifications without prior notice. Pentair is an equal opportunity employer.
© 2016 Pentair Water Pool and Spa, Inc. All rights reserved. This document is subject to change without notice.
P/N 520984 REV. B 1/2016
*520984*
