Pentair SAND DOLLAR User manual

IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
INSTALLATION AND
USER’S GUIDE
SAND DOLLAR
®
AND CRISTAL-FLO
™
II
TOP MOUNT SAND FILTER
ENGLISH FRANÇAIS ESPAÑOL

SAND DOLLAR® and CRISTAL-FLO™II Top Mount Sand Filter Installation and User’s Guide
Important Warning and Safety Instructions ..............
Filter Overview ............................................................
Installation ...................................................................
Operation and Maintenance .......................................
Initial Start-Up
General Maintenance
Cleaning
Filter and Control Valve Functions
Filter Backwash Procedure
Chemical Cleaning
Winterizing the System
Troubleshooting ..........................................................
Replacement Parts ......................................................
Filter Replacement Parts
1.5” Valve Replacement Parts
2” Valve Replacement Parts
ii
1
2
5
5
6
7
7
8
9
10
11
13
13
14
15
TABLE OF CONTENTS
If you have questions about ordering Pentair Aquatic Systems replacement parts,
and pool products, please contact:
TECHNICAL SUPPORT
Technical Support, USA
Sanford, North Carolina (8 A.M. to 4:30 P.M. ET)
Moorpark, California (8 A.M. to 4:30 P.M. PT)
Phone: [phone]
Fax: [phone]
Web site
Visit www.pentairpool.com or www.staritepool.com for information about Pentair
products.
P/N 152006 Rev. C 12/14/15
i

SAND DOLLAR® and CRISTAL-FLO™II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
Water temperature in excess of 100° F (37.7° C) may be hazardous to
your health. Prolonged immersion in hot water may induce hyperthermia.
Hyperthermia occurs when the internal temperature of the body reaches a
level several degrees above normal body temperature of 98.6° F. (37° C.).
Effects of hyperthermia include: (1) Unawareness of impending danger. (2)
Failure to perceive heat. (3) Failure to recognize the need to leave the spa.
(4) Physical inability to exit the spa. (5) Fetal damage in pregnant women. (6)
Unconsciousness resulting in danger of drowning. The use of alcohol, drugs, or medication can
greatly increase the risk of fatal hyperthermia in hot tubs and spas.
Do not permit children to use or operate this sand filter.
When setting up pool water turnovers or flow rates the operator must consider
local codes governing turnover as well as disinfectant feed ratios.
DO NOT increase pump size; this will increase the flow rate through the
system and may exceed the maximum flow rate stated on the drain cover.
For filters intended for use in other than single-family dwellings, a clearly
labeled emergency switch shall be provided as part of the installation. The
switch shall be readily accessible to the occupants and shall be installed at least 5 feet (1.52 m)
away, adjacent to, and within sight of, the filter.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS
SERIOUS BODILY INJURY OR DEATH CAN RESULT IF THIS SAND
FILTER IS NOT INSTALLED AND USED CORRECTLY.
INSTALLERS, POOL OPERATORS AND POOL OWNERS MUST READ
THESE WARNINGS AND ALL INSTRUCTIONS BEFORE USING THIS
SAND FILTER.
Before installing this product, read and follow all warning notices
and instructions in this Guide. Failure to follow warnings and instructions
can result in severe injury, death, or property damage. Call [phone] for additional free
copies of these instructions. Please refer to www.pentair.com for more information related to
this product.
Most states and local codes regulate the construction, installation, and
operation of public pools and spas, and the construction of residential
pools and spas. It is important to comply with these codes, many of which directly regulate
the installation and use of this product. Consult your local building and health codes for more
information.
This sand filter is intended for use in swimming pool applications.
IMPORTANT NOTICE - Attention Installer: This Installation and User’s Guide
(“Guide”) contains important information about the installation, operation and safe
use of this sand filter. This Guide should be given to the owner and/or operator of
this equipment.
ii

SAND DOLLAR® and CRISTAL-FLO™II Top Mount Sand Filter Installation and User’s Guide
A pool or spa pump must be installed by a qualified pool and spa service
professional in accordance with the National Electrical Code and all applicable
local codes and ordinances. Improper installation may create an electrical hazard which could
result in death or serious injury to pool users, installers, or others due to electrical shock, and may
also cause damage to property.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS
Pumps are not a substitute for properly installed and secured pool drain
covers. An ANSI/ASME A112.19.8 approved anti-entrapment drain cover
must be used for each drain. Pools and spas should utilize a minimum of two drains per pump.
If a drain cover becomes loose, broken or is missing, close the pool or spa immediately and
shut off the pump until an approved anti-entrapment drain cover is properly installed with the
manufacturer’s supplied screws.
High Pressure from the Sand Filter can cause severe injury or major
property damage due to tank separation.
Release all pressure and read instructions before working on the
sand filter.
If the filter clamp is adjusted under pressure, the tank can separate,
causing serious injury or major property damage.
For information about the Virginia Graeme Baker Pool and Spa Safety
Act, contact the Consumer Product Safety Commission at [phone]
or visit www.cpsc.gov.
Important Note: Always turn off all power to the pool pump before
installing the cover or working on any suction outlet.
BEFORE WORKING ON FILTER!
(1) Stop pump.
(2) Open air release valve.
(3) Release all pressure from system.
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION:
PUMPS REQUIRE HIGH VOLTAGE WHICH CAN SHOCK, BURN, OR
CAUSE DEATH.
BEFORE WORKING ON PUMP!
Always disconnect power to the pool pump at the circuit breaker
from the pump before servicing the pump. Failure to do so could
result in death or serious injury to service person, pool users or
others due to electric shock.
iii

1
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
FILTER OVERVIEW
Your high rate sand filter is designed to produce clear, sparkling water and
operate for years with a minimum of maintenance when installed, operated
and maintained in accordance with these instructions.Your filter uses
special filter sand to remove dirt particles from the water. Dirt is collected
in the filter by the sand bed as water flows through the filter. Water enters
the filter through the valve on top of the filter and is distributed evenly
downward across the sand bed. The dirt is removed by the sand and the
clean water flows through the piping (laterals) at the bottom of the filter,
up through the stand pipe, back to the valve on top of the filter, where the
clean water is returned to the pool through the piping or hoses.
After a period of time, dirt will accumulate in the filter causing a
resistance to the flow of water through the filter. This resistance results
in a diminished flow of water and a rise in the pressure of the filter.
Eventually the filter sand will have removed so much dirt and the
filter pressure risen to such a point that it will be necessary to clean
(backwash) your filter.
This filter operates under high pressure. When any part of the
circulating system (e.g., clamp, pump, filter, valves, etc.) is serviced,
air can enter the system and become pressurized. Pressurized air can cause the lid or
control valve to separate which may result in serious injury, death, or property damage. To
avoid this potential hazard, follow these instructions.
1. Before repositioning valves and before beginning the assembly, disassembly, or
adjustment of the clamp or any other service of the circulating system:
(a) Turn the pump off and shut off any automatic controls to ensure the
system is not inadvertently started during the servicing;
(b) Open manual air relief valve;
(c) Wait until all pressure is relieved, pressure gauge must read zero (0).
2. Whenever installing the filter clamp, follow the filter valve and clamp installation
instructions exactly.
3. Once service on the circulating system is complete, follow system restart
instructions exactly.
4. Maintain circulation system properly. Replace worn or damaged parts immediately
(e.g., clamp, pressure gauge, relief valve, o-rings, etc.).
5. Be sure that the filter is properly mounted and positioned according to instructions
provided.
Tank
Diameter
Filter Area
Sq. Ft.
Lbs. of Sand
Required
Max Working
Pressure (PSI)
Vrtl. Clearance
Required
Design Flow
Rate GPM
Max Water
Temp
16” 1.40 100 30 45” 35 95°F
19” 1.92 150 35 49” 40 95°F
22” 2.64 250 40 55” 60 95°F
24” 3.15 300 50 58” 70 95°F
26” 3.69 350 50 60” 75 95°F

SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
2
By setting the valve on top of the filter to the “Backwash” position, the
flow of water is automatically reversed through the filter so that the
flow of water is directed to the bottom of the filter, up through the sand
bed, flushing the dirt and debris out through the waste line. Once the
backwash procedure is complete, the valve is manually returned to
its “Filter” position to resume normal filtration. The filter’s function is
to remove suspended matter from the water. It does not sanitize the
water. For sparkling clear water, the water must be sanitized as well as
balanced. Pool chemistry is a specialized area, and you should consult
your local pool service specialist for specific details. In general, proper
pool sanitation requires a free chlorine level of 1 to 2 PPM and a pH
range of 7.2 to 7.6.Your filtration system should be designed to meet
your local health codes. As a minimum, you must be sure that your
system will turnover the total volume of water in your pool at least twice
in a twenty-four hour period.
INSTALLATION
1. Read and understand all instructions before attempting to
install, operate or maintain your pump and sand filter system.
2. Provide space and lighting for routine maintenance access.
Locate the system close to the pool. Install electrical controls
(e.g., on/off switches, timers, control systems, etc.) at least five (5)
feet from the filter. This will allow you enough room to stand clear
of the filter during system start up.
3. Remove all individual components from carton and inspect for any
visible damage. If carton or parts are damaged contact seller or
freight company.
Failure to operate your filter system or inadequate filtration can cause
poor water clarity obstructing visibility in your pool. Poor water clarity may
obscure objects in the water which while swimming and diving could cause serious personal
injury or death. Never swim in a pool with poor water clarity.
Blockage of suction fittings can cause serious or fatal injury due to
drowning. To reduce the risk of injury, do not permit children to use
this product.
Never work on the pump while it is running or power is still
connected. High voltage can cause serious or fatal injury. A suitable
ground fault interrupter (GFCI) should always be installed at the power supply source of
this unit. Be sure to ground the motor before connecting to electrical AC power supply.
Failure to ground the motor can cause serious or fatal electrical shock hazard. DO NOT
ground to a gas supply pipe line.

3
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
4. The filter is ready to be moved into its final position. The system
must be placed on level solid earth. When the filter is filled with
sand and water it can weigh several hundred pounds.
5. Be certain to install the precise amount of filter sand listed on
your filter name plate. You must use only No. 20 standard silica
sand having a uniformity coefficient of 1.75 or less. No. 20 silica
sand has a particle size of .018-.022 inches (.45 to .55 mm).
Before pouring the sand into the filter, look inside and check the
lower under drain for broken or loose laterals (or fingers), which
may have been accidentally damaged by rough handling during
shipment. Replace any broken parts if necessary.
6. Install the sand guide in the top of the filter and fill the tank about
half full of water. Pour the sand into the top of the filter at a slow
rate so that the weight of the sand does not damage the laterals.
After the required amount of sand has been installed, remove and
discard the sand guide. Wash away all sand around the opening at
the top of the tank.
7. Be sure top of filter is free of any sand or debris and valve o-ring
is in place on valve body. Install valve so that the port locations
are in the desired final position. Valve ports are labeled with the
location of where they should be connected i.e. pump port must
go to pump discharge, waste port must go to the waste line and
return port must go to
the pool return.
8. Insure that the valve is
firmly pushed into the
top of the tank and that
the flange of the tank
and the flange of the
valve are contacting
each other. See
Figure 1.
9. The plastic clamp can now be installed.
Place the clamp half over the valve
flange and the tank flange as shown
in Figure 1. Insert the clamp screws
and nuts into the clamp making sure
that the nuts are located in the special
hexagonal retainer slots on the clamps.
See Figure 2.Figure 2
Figure 1

SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
4
10. Tighten clamp screws firmly and visually check the valve tank and
clamp assembly to insure that the joint is correctly assembled.
11. The filter unit has a maximum operating pressure listed on the
filter name plate. DO NOT OPERATE this unit above the maximum
operating pressure of the valve or the filter. Never connect the
filter and valve unit to a pump which can generate a pressure that
exceeds the operating pressure of the filter or valve.
12. Use sealant on all tapered male connections of pipes and fittings.
Use only sealant compounds suited for plastic pipe. Support
pipe to prevent strains on filter, pump or valve. DO NOT USE
PETROLEUM BASED PRODUCTS. NOTICE: All valve internal
threads are tapered except the air bleeder connection. Do not over
tighten tapered thread connections.
13. Install pressure gauge in 1/4”NPT port directly across from the
pump port of the valve.
14. Never store pool chemicals within ten (10) feet of your pool filter,
pump or valve. Pool chemicals should always be stored in a cool,
dry, well ventilated area.
High Pressure:
Improper tank valve assembly could cause the valve to separate
and cause serious injury and/or major property damage.
Chemical fumes and/or spills can cause serious corrosion to the filter and
pump structural components. Structurally weakened components can cause
filter, pump or valve attachments to separate and could cause serious bodily injury or property
damage.
The system’s centrifugal pump operates with electrical voltage, and can
generate both vacuum and pressure in the water system. When properly
wired and plumbed, this pump will operate in a safe manner.
High voltage can cause serious or fatal injury. Always install a suitable
GFCI at the power source of this unit as an added safety precaution. Article
681-31 of the NEC requires that a GFCI be used if this pump is used with a storable pool.
15. Avoid over tightening the pipe threads when connecting fittings
to the pump or valve. Proper procedure is to apply a pipe sealant
to the thread and then install hand tight plus one turn. DO NOT
OVER TIGHTEN.

5
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
Initial Start-Up
1. Be sure the correct amount of silica filter sand is in the tank and
that all connections have been made and are secure.
2. Verify that the backwash is open so that water is free to flow
from the pool and out the backwash line. Set the control valve to
“Backwash” position.
3. Check the valve clamp on the filter for proper installation. For
valve clamp installation instructions, see “Installation” on
page 2.
4. Open the manual air bleeder.
(See Figure 3 for air bleeder
location). STAND CLEAR OF
THE FILTER. Prime and start
the pump according to the
pump instructions allowing
the filter tank to fill with water.
Close the air bleeder on the
filter when a steady stream of
water emerges.
5. Once the water flow is steady
out the waste line, run the
pump for at least two minutes.
This initial backwashing of
the filter is recommended to remove any impurities of fine sand
particles in the silica sand media.
6. Turn the pump off and set valve to “Rinse” position. Ensure that
all pool suction and return lines are open so that the water is free
to flow from the pool to waste. STAND CLEAR OF FILTER and
start the pump.
7. Run the pump for at least two minutes.
OPERATION AND MAINTENANCE
Always turn pump off before changing valve positions. Changing valve
positions while the pump is running can damage the control valve, which
may cause serious injury or property damage.
This filter operates under pressure. With the valve clamped properly
and operated without air in the system, this filter will operate in a safe
manner. Air entering the filter and the valve not clamped correctly can
cause the valve to separate, which could cause serious personal injury
and/or property damage.
Figure 3
Manual
air bleeder

SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
6
8. Turn the pump off and set valve to “Filter” position. Be sure that
all pool suction and return lines are open so that water is free to
flow from and to the pool.
9. Open the manual air bleeder on the filter. STAND CLEAR OF
FILTER and start the pump.
10. Close the air bleeder on the filter when a steady stream of water
emerges.
11. The filter has now started its filtering cycle. Verify that water is
returning to the pool and take note of the operating pressure. The
original starting pressure is ___________ psi with the filter clean.
12. Check the system for water leaks. If a leak is found, shut the
pump off before correcting the leak.
13. As the filter removes dirt and impurities from the pool water, the
accumulation will cause the filter pressure to rise and flow to
diminish. When the pressure gauge reading is 10 psi higher than
the clean filter reading noted above, it is time to backwash the
filter.
General Maintenance
Proper care and maintenance of the pump and sand filter system will
add many years of enjoyment to the pool. Follow these suggestions
for long trouble free operation.
1. To clean the exterior of the pump and sand filter system of dust
and dirt, wash with mild detergent and water and then hose off.
Do not use solvents.
2. If internal filter maintenance is required, sand may be removed by
removing the entire drain spigot from the bottom of the filter and
flushing with a garden hose.
3. The filter is a pressure vessel and should never be serviced
while under pressure. Always relieve tank pressure and open air
bleeder on filter before attempting to service the filter.
4. When restarting the filter always open the manual air bleeder on
the filter and STAND CLEAR OF FILTER.
5. The strainer basket in the pump should be inspected and cleaned
twice each week. Remove the clear lid and the basket, and clean
debris from basket. Inspect the lid o-ring; if damaged, replace.
The pump seal requires no lubrication. The pump motor should
only be serviced by a motor service center.

7
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
Cleaning
1. The filter on a new pool should be backwashed, and cleaned after
the first 48 hours of operation to clean out construction debris.
There are three different ways to identify when the filter needs
backwashing:
a) The most accurate indicator on pool systems with a flow
meter is to backwash when the flow decreases 30% from
original (clean filter) flow. For example, if the original flow
was 60 GPM, the filter should be backwashed when the flow
is reduced by about 20 GPM (or 30%) to 40 GPM.
b) A more subjective and less accurate indicator is to observe
the amount of water flowing from the flow directionals located
in the wall of the pool. The filter should be backwashed once
it is detected that the flow has been reduced.
c) The most commonly used, but least accurate indicator is
to backwash when the filter gauge reading increases 10
psi over the initial (clean filter) reading.
2. It is important not to backwash the filter solely on a timed basis
such as every three (3) days. It is also important to note that
backwashing too frequently actually causes poor filtration. Factors
like weather conditions, heavy rains, dust or pollen, and water
temperatures all affect the frequency of backwashing. As you use
your pool, you will become aware of these influences.
Filter and Control Valve Functions
FILTER: From pump, through valve, downward through filter sand bed,
up through center pipe to valve return port, and back to the pool for
normal filter action and vacuuming pool through filter.
BACKWASH: From pump, through valve, down through center pipe, up
through filter sand to valve, and out waste port. This position is used for
cleaning filter by reversing flow.
RINSE: From pump, through valve, downward through filter sand, up
through center pipe to valve and out waste port. This position is used
for start up cleaning and resettling filter bed after backwashing.
WASTE: From pump, through valve, bypasses filter and goes to waste
port. This position is for vacuuming directly to waste, lowering pool
level, or draining pool.
CLOSED: NO FLOW IN THIS POSITION - DO NOT USE THIS
SETTING WHILE PUMP IS OPERATING.
RECIRCULATE: From pump, through valve, bypasses filter and goes
to return port and back to pool. This position is for circulating water
without going through filter.
WINTERIZING: Valve position for a winterized filter, see page 10.

SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
8
1. Stop pump.
2. Ensure that the suction and backwash lines are open so that water
is free to come from the pool and flow out the backwash line. Set
control valve to “Backwash” position.
3. STAND CLEAR OF FILTER and start pump.
4. Backwash filter for approximately three (3) minutes or until
backwash water is clean.
5. Stop pump and set valve to “Rinse” position.
6. STAND CLEAR OF FILTER and start pump..
7. Rinse filter for approximately 30 seconds.
8. Stop pump and set valve to “Filter” position.
9. Ensure the pool return line is open so that water may flow freely
from the filter back to the pool.
10. Open manual air bleeder on filter. STAND CLEAR OF FILTER and
start pump.
11. Close manual air bleeder on filter when a steady stream of water
emerges from the bleeder.
12. The filter has now started its filtering cycle. Verify the water is
returning to the pool and take note of the filter pressure.
13. The filter pressure in Step 12 above should not exceed the
pressure originally observed on the filter when it was initially
started. If after backwashing, the pressure is 4 to 6 psi above the
start condition it will be necessary to chemically clean the sand
bed.
Filter Backwash Procedure
Failure to operate your filter system or inadequate filtration can cause
poor water clarity obstructing visibility in your pool. Poor water clarity may
obscure objects in the water which while swimming and diving could cause serious injury or
death. Never swim in a pool with poor water clarity.
To prevent equipment damage and possible injury, always turn
pump off before changing valve position.

9
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
Chemical Cleaning
1. It is recommended that a specialty filter cleaning solution be used.
These cleaners will remove oils, scale and rust from the sand bed
in one cleaning operation.
2. Mix the solution following the manufacturer’s instructions on the
label.
3. Backwash the filter with the valve as described above.
4. If the filter is below pool level, switch pump off and close the
appropriate valves to prevent draining the pool.
5. Switch off pump, open filter drain and allow filter to empty. Place
valve in “Backwash” position.
6. After the filter has drained, close the filter drain and remove the
pump strainer pot lid.
7. Be sure the backwash lines are open.
8. Switch the pump on and slowly pour the cleaning solution into the
pump strainer with the pump running. If filter is below pool, open
shut off valve slightly to allow pump to run.
9. Continue adding solution until the sand bed is saturated with
cleaning solution.
10. Switch off the pump and leave filter in “Backwash” position. Allow
the filter to stand overnight (12 hours).
11. Replace the pump lid and follow backwash procedure as
described above.
12. Do not allow cleaning solution to get into the pool.

SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
10
1. In areas that have freezing winter temperatures, the pool
equipment must be winterized to protect it from damage.
2. Backwash the filter. Switch off the pump and set the control valve
to the “Winterize” position.
3. Remove the drain port cap at the bottom of the filter.
IMPORTANT NOTE: Remove drain port cap only for draining
water from filter. Removing the entire fitting will allow sand to
drain also. The filter will drain slowly. Leave the drain port cap
off and store it during the time the system is shut down.
Winterizing the System
Allowing water to freeze in the system will damage the system
and cause potential water damage/flooding and potential property
damage.
The Multiport Valve should be left in the “Winterize” position during
the shutdown season so that the rubber seal of the valve diverter has
no pressure on it. Failure to do so can damage the valve diverter seal which can cause
property damage from leaking water.
4. Drain all appropriate system piping.
5. It is recommended that the pump and filter be covered with a
tarpaulin or plastic sheet to inhibit deterioration from the weather.
DO NOT wrap the pump motor with plastic.
6. In installations where the pump cannot be drained a 40%
Propylene Glycol 60% water solution will protect to -50° F
(-45.5° C)
Note: Do not use anti-freeze solutions except Propylene
Glycol; as other anti-freeze are highly toxic and will damage
the pump.

11
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
TROUBLESHOOTING
Problem Cause Action
Pool water not sufficiently clean.
1. Pool chemistry not adequate to inhibit
algae growth.
2. Too frequent a backwash cycle. 3. Improper amount or wrong sand size. 4. Inadequate turnover rate.
Maintain pool chemistry or consult service technician. Allow pressure to build to 10PSI above clean filter condition before backwashing. Check sand bed depth and sand size or consult pool service technician. Run system for longer time or consult dealer or pool service technician.
Higher filter pressure.
1. Insufficient backwashing. 2. Sand bed plugging with mineral
deposits.
3. Partially closed valve or restriction.
Backwash until effluent runs clear. Chemically clean filter. Open valve or remove obstruction in return line.
Short filter cycles.
1. Improper backwashing. 2. Pool chemistry not adequate to inhabit
algae growth.
3. Plugged sand bed. 4. Flow rate too high.
Backwash until effluent runs clear. Maintain pool chemistry or consult pool service technician. Manually remove top 1” surface of sand bed and chemically clean as required. Restrict flow to capacity of filter.

SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
12
Return flow to pool diminished, low filter pressure.
1. Obstruction in the pump hair and lint
pot.
2. Obstruction in pump. 3. Obstruction in suction line to pump.
Clean basket in strainer. Disassemble and clean pump. Clean skimmer basket. Remove obstruction in lines. Open valves in suction line.
Sand returning to pool.
1. Broken underdrain lateral. 2. Backwash rate too high.
Replace broken or damaged laterals. Reduce backwash flow rate.
Troubleshooting (Cont.)

13
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
REPLACEMENT PARTS
Filter Replacement Parts
6
5
7
8
9
3
2
1
10
4
Item
#Description
Sand
Dollar
Part #
Cristal-Flo
Part #
1
Valve, 1.5” (See page 14
for Valve Breakdown) 262506
Valve, 2” (See page 15
for valve breakdown) 263085
2 O-Ring, Valve Body 272541
3Clamp Assembly 152165
4
Piping Asy. - SD/CFII 35 152229
Piping Asy. - SD/CFII 40 152228
Piping Asy. - SD/CFII 60 152227
Piping Asy. - SD/CFII 70 152000
Piping Asy. - SD/CFII/
ClearPro 80 152226
Piping Asy. - SD/CFII 80
w/Hybrid 2” Valve 152238
5
Lateral - SD/CFII 35, 40
(Qty. 6) 150084
Lateral - SD/CFII 60, 70,
80 (Qty. 6) 150085
Lateral - ClearPro
(Qty. 6) 150088
6
Tank Asy. - SD/CFII 35 145339 145364
Tank Asy. - SD/CFII 40 145341 145365
Tank Asy. - SD/CFII 60 145343 145366
Tank Asy. - SD/CFII 70 145368 145369
Tank Asy. - SD/CFII/
ClearPro 80 145334 145370
7 Sand Drain 154711
8 Gasket, Sand Drain 154715
9 Drain Cap 154712
10 Foot - SD/CFII 35, 40 154926
Foot - SD/CFII 60, 70, 80 154520
* Pressure Gauge 190059
* Flex Hose Kit, 6’ 155151
* Flex Hose Kit, 12’ 155005
(*) - Not Shown

SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
14
Item # Part # Description
1 272520 Handle
2 272405 Screw, Handle
3 272505 Washer, Plastic (2 Req.)
4 272599 Valve Position Label
5 272511 O-Ring, Diverter Shaft
6 272535 Spring, 100lb,1-3/8 O.D.
7 354053 O-Ring Top
8 272512 Diverter w/Gasket
9272530 Valve Body & Diffuser
10 273512 Air Bleeder w/O-Ring
11 152165 Clamp Asy1
12 152166 Clamp Half (2 Req.)
13 152168 Clamp Screw (2 Req.)
14 152167 Clamp Nut (2 Req.)
15 354541 Screw #10-24 SS (6 req.)
16 272555 Washer 9/16 SS (6 req.)
17 272554 Nut Serrated SS (6 req.)
18 272531 Valve Top Assembly2
19 190059 Pressure Gauge
20 272550 Sight Glass
21 271106 Gasket, Sight Glass
22 272518 Diffuser
23 272541 Valve Body O-Ring
* 272517 Valve Manual
Note:
(*) Not Shown
(1) Clamp Assembly consists of items 12 thru 14.
(2) Valve Top Assembly consists of items 1 thru 8 and Valve Manual P/N 272517.
1
2
3
15
16
5
3
68
7
19
9
23
12
14
13
17
10
18
11
22
21
20
4
1.5” Valve Replacement Parts

15
SAND DOLLAR® and CRISTAL-FLO™ II Top Mount Sand Filter Installation and User’s Guide
ENGLISH
2” Valve Replacement Parts
Item # Part # Description
1 190059 Pressure Gauge
2 270210Z Valve Body
3 272541 Diffuser
4 272556Z Sight Glass
5 272557Z Drain Plug
6 272558Z Handle
7 272567Z Gasket, Sight Glass
8 272568Z Valve Top Assembly1
9272573Z Drain O-Ring
10 272576Z Valve Position Label
11 272590Z Union Kit
12 274402Z Valve Body O-Ring
Note:
(1) Valve Top Assembly consists of
items 6 and 10.
6
10
1
5
9
74 3
12
2
8
11

1620 HAWKINS AVE., SANFORD, NC 27330 • [phone]
10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • [phone]
WWW.PENTAIRPOOL.COM
All Pentair trademarks and logos are owned by Pentair or one of its global affiliates. Pentair
Aquatic Systems®, Sta-Rite®, Sand Dollar®and Cristal-Flo™are trademarks and/or registered
trademarks of Pentair Water Pool and Spa, Inc. and/or its affiliated companies in the United
States and/ or other countries. Unless expressly noted, names and brands of third parties that
may be used in this document are not used to indicate an affiliation or endorsement between
the owners of these names and brands and Pentair Water Pool and Spa, Inc. Those names
and brands may be the trademarks or registered trademarks of those third parties. Because
we are continuously improving our products and services, Pentair reserves the right to change
specifications without prior notice. Pentair is an equal opportunity employer.
© 2015 Pentair Water Pool and Spa, Inc. All rights reserved. This document is subject to
change without notice.
P/N 152006 REV. C 12/14/15
*152006*
