Pepperl+Fuchs VBA-2E-G11-I/U/PT100-F User manual

A
D
Spec 2.1
VBA-2E-G11-I/U/PT100-F
VBA-2E-G11-I/U/PT100-V1
AS-Interface Analog Module
FACTORY AUTOMATION
MANUAL

With regard to the supply of products, the current issue of the following document is ap-
plicable: The General Terms of Delivery for Products and Services of the Electrical Indus-
try, published by the Central Association of the Electrical Industry (Zentralverband
Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the
supplementary clause: "Expanded reservation of proprietorship"
VBA-2E-G11-I/U/PT100-*

VBA-2E-G11-I/U/PT100-*
3
1 Introduction................................................................................. 4
2 Declaration of Conformity.......................................................... 5
3 Safety ........................................................................................... 6
3.1 Symbols relevant to safety.................................................................. 6
3.2 Intended Use ........................................................................................ 6
3.3 General Safety Instructions................................................................. 6
4 Product Description ................................................................... 7
4.1 Displays and Controls ......................................................................... 7
4.2 Connections ......................................................................................... 8
4.3 Automatic Detection of the Sensor Type ........................................... 9
4.4 Pt100 temperature sensor................................................................. 10
5 Installation................................................................................. 11
5.1 Storage and transport........................................................................ 11
5.2 Unpacking........................................................................................... 11
5.3 Mounting............................................................................................. 11
5.4 Connecting the AS-Interface............................................................. 11
5.5 Connecting the Sensors.................................................................... 13
6 Commissioning......................................................................... 14
6.1 Assigning an Address to the Module............................................... 14
6.2 Slave Profile........................................................................................ 14
6.3 Parameterization ................................................................................ 14
7 Troubleshooting........................................................................ 16
7.1 Causes and Elimination of Peripheral Faults .................................. 16
7.2 Cause and elimination of a channel fault ........................................ 16
8 Appendix A................................................................................ 17
8.1 Dimensions......................................................................................... 17
8.2 Technical Data .................................................................................... 17
9 Appendix B................................................................................ 20
9.1 Analog Input Module Measurement Ranges ................................... 20
9.2 Delay Times ........................................................................................ 21

2014-02
4
VBA-2E-G11-I/U/PT100-*
Introduction
1Introduction
Congratulations
You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs develops,
produces and distributes electronic sensors and interface modules for the market of
automation technology on a worldwide scale.
Before you install this device and put it into operation, please read the operating instructions
thoroughly. The instructions and notes contained in this operating manual will guide you step-
by-step through the installation and commissioning procedures to ensure trouble-free use of
this product. By doing so, you:
■ guarantee safe operation of the device
■ can utilize the entire range of device functions
■ avoid faulty operation and associated errors
■ reduce costs from downtimes and incidental repairs
■ increase the effectiveness and operating efficiency of your plant.
Store this operating manual somewhere safe in order to have it available for future work on the
device.
After opening the packaging, please ensure that the device is intact and that the package is
complete.
Symbols used
The following symbols are used in this manual:
Handling instructions
You will find handling instructions beside this symbol
Contact
If you have any questions about the device, its functions, or accessories, please contact us at:
Pepperl+Fuchs GmbH
Lilienthalstraße 200
68307 Mannheim
Telephone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Note!
This symbol draws your attention to important information.

VBA-2E-G11-I/U/PT100-*
Declaration of Conformity
2014-02
5
2 Declaration of Conformity
All products were developed and manufactured under observance of the applicable European
standards and guidelines.
The product manufacturer, Pepperl+Fuchs GmbH, 68307 Mannheim, has a certified quality
assurance system that conforms to ISO 9001.
Note!
A Declaration of Conformity can be requested from the manufacturer.
ISO9001

2014-02
6
VBA-2E-G11-I/U/PT100-*
Safety
3Safety
3.1 Symbols relevant to safety
3.2 Intended Use
The VBA-2E-G11-I/U/PT100-* is an analog module for connecting 0 V ... 10 V or 0/4 mA ... 20
mA measurement sensors and Pt100 sensors to the AS-Interface network. Measured values
are converted and data transmitted asynchronously as defined by AS-Interface profile 7.3. The
measured values are converted internally at a resolution of 16 bits. The analog module features
two analog inputs which can be current input, voltage input, or resistance therm ometer input.
The measurement sensors are powered either by the AS-Interface or by the auxiliary power
source.
Read through these instructions thoroughly. Familiarize yourself with the device before
installing, mounting, or operating.
Always operate the device as described in these instructions to ensure that the device and
connected systems function correctly. The protection of operating personnel and plant is only
guaranteed if the device is operated in accordance with its intended use.
3.3 General Safety Instructions
Only instructed specialist staff may operate the device in accordance with the operating
manual.
User modification and or repair are dangerous and will void the warranty and exclude the
manufacturer from any liability. If serious faults occur, stop using the device. Secure the device
against inadvertent operation. In the event of repairs, return the device to your local
Pepperl+Fuchs representative or sales office.
The connection of the device and maintenance work when live may only be carried out by a
qualified electrical specialist.
The operating company bears responsibility for observing locally applicable safety regulations.
Store the not used device in the original packaging. This offers the device optimal protection
against impact and moisture.
Ensure that the ambient conditions comply with regulations.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt devices and any connected facilities or systems, or result in
their complete failure.
Note!
Disposal
Electronic waste is hazardous waste. When disposing of the equipment, observe the current
statutory requirements in the respective country of use, as well as local regulations.

VBA-2E-G11-I/U/PT100-*
Product Description
2014-02
7
4ProductDescription
4.1 Displays and Controls
Figure 4.1 Display and control elements
The VBA-2E-G11-I/U/PT100-* analog module is equipped with the following displays and
controls:
LED Indicator
Switch
In order to reach the switch, remove the blind plug
AS-i/FAULT LED Status indication; multicolor LED
Green: normal mode
Red: communication error
Flashing yellow/red: address 0
Flashing green/red: peripheral fault
PT1 LED
PT2 LED
Status of input signal; yellow LED
Off: not active
On: signal within measurement range
Flashing: signal outside measurement range
I1 LED
I2 LED
U1 LED
U2 LED
AUX LED Ext. auxiliary power source (U
AUX
); dual LED (green/red)
Green: voltage OK
Red: voltage reversed
INT/EXT LED Status indication, input supply; green LED
Green: internal input supply
Off: external input supply
INT/EXT switch Set to INT: sensors powered via the AS-Interface (max. 140 mA)
Set to EXT: sensors powered via an auxiliary power source (max. 600 mA)
2
T
P
VBA-2E-G11-I/U/PT100
AUX
AS-i
FAU LT
R
D
D
A
1
T
P
I
1
I
2
U
2
U
1
INT
EXT
1
3
2
4
6
5
7
2
1
3
5
4
6
7
7

2014-02
8
VBA-2E-G11-I/U/PT100-*
Product Description
4.2 Connections
VBA-2E-G11-I/U/PT100-F
Figure 4.2 Connections VBA-2E-G11-I/U/PT100-F
The VBA-2E-G11-I/U/PT100-F analog module is equipped with the following connections:
VBA-2E-G11-I/U/PT100-V1
Figure 4.3 Connections VBA-2E-G11-I/U/PT100-V1
The VBA-2E-G11-I/U/PT100-V1 analog module is equipped with the following connections:
Pt100 inputs
: functional ground
M12 round plug connector
Current inputs
Voltage inputs
Addressing socket Low voltage switch socket, 1.3 mm
Pt100 inputs
: functional ground
M12 round plug connector
Current inputs
Voltage inputs
AS-Interface/U
AUX
1: AS-Interface +
2: AUX -
3: AS-Interface -
4: AUX +
M12 round plug connector
2
T
P
VBA-2E-G11-I/U/PT100
AUX
AS-i
FAU LT
R
D
D
A
1
T
P
I
1
I
2
U
2
U
1
INT
EXT
4
3
1
2
1
43
12
5
2
3
4
2
T
P
VBA-2E-G11-I/U/PT100
AUX
AS-i
FAU LT
I
-
S
A
1
T
P
I
1
I
2
U
2
U
1
INT
EXT
X
U
A
4
3
1
2
1
43
12
5
2
3
4
1
34
2

VBA-2E-G11-I/U/PT100-*
Product Description
2014-02
9
4.3 Automatic Detection of the Sensor Type
The VBA-2E-G11-I/U/PT100-* analog input module automatically detects which sensor type is
connected. The types of sensors that can be connected are: 0 V ... 10 V measurement
sensors, 0/4 mA ... 20 mA-measurement sensors, or Pt100 temperature sensors. The sensor
type is automatically detected once switched on. Once the module has detected the sensor
type, the corresponding module configuration is activated.
All input LEDs are illuminated during the first few seconds after switching on. During this time,
the module evaluates the connected sensor type on the basis of various measured values. The
signal values that ensure unambiguous detection of the type of sensor connected are:
■ Voltage: 1 V ... 11.5 V
■ Current: 1 mA ... 23 mA
■ Pt100: -219 °C ... 884 °C
If the module cannot clearly establish which sensor type is connected, the last detected sensor
type is provisionally activated. For example, the module may not detect which sensor type is
connected if the signal values are not within the specified thresholds or if two different sensor
types are simultaneously applied to one channel.
A specific sensor type is finally activated when the signal values measured are within the
specified thresholds.
Note!
Switching Off the Second Channel
Figure 4.4 Input PT2 bridge
Two bridges are plugged in at the PT100 input PT2 by default; these bridges are designed to
switch off channel 2. Remove the bridges to use channels 1 and 2.
The bridges must be plugged in and disconnected only when the module is de-energized!
1
2
3
4
Note!
The Pt100 Input Is an Exception:
The Pt100 sensor type is only activated if a Pt100 temperature sensor is connected to the
PT100 inputs before switching on. The Pt100 sensor type cannot be activated during operation
or activated provisionally.
Note!
If you connect two different sensor types to one channel simultaneously, fault-free operation is
not guaranteed. The module will not be damaged by this.

2014-02
10
VBA-2E-G11-I/U/PT100-*
Product Description
4.4 Pt100 temperature sensor
Pt100 temperature sensors are platinum resistance thermometers complying with standard
IEC 751 / DIN EN 60751. In this standard, various values of the temperature sensor are
defined. The nominal resistance of the Pt100 is 100 , measured at 0 °C. Furthermore, as well
as other values, the mean temperature coefficient of 0°C to 100 °C is also defined. The mean
temperature coefficient defines the mean change in resistance relative to the nominal
resistance. The analog module calculates the corresponding temperature based on the
measured resistance of the temperature sensor.
Figure 4.5 Curve Pt100
50
100
150
200
250
300
350
400
Resistance [Ω]
Temperature [°C]
Pt100
Curve Resistance Thermometer Pt100
0 100 200 300 400 500 600 700 800 900

VBA-2E-G11-I/U/PT100-*
Installation
2014-02
11
5 Installation
5.1 Storage and transport
For storage and transport purposes, package the unit using shockproof packaging material
and protect it against moisture. The best method of protection is to package the unit using the
original packaging. Furthermore, ensure that the ambient conditions are within allowable range.
5.2 Unpacking
Check the product for damage while unpacking. In the event of damage to the product, inform
the post office or parcel service and notify the supplier.
Retain the original packaging in case the device must be stored or shipped again at a later
date.
Should you have any questions, please direct them to Pepperl+Fuchs.
5.3 Mounting
Align the device as required and secure to a flat mounting surface by screwing it in place with
two M4 mounting screws. When the central screw is tightened, the functional ground of the
M12 round plug connector connects with the metal insert in the mounting base. Ensure that this
metal insert is connected with the protective ground via the mounting screws. The mounting
screws are not included.
Figure 5.1
Screw a blind plug onto unused connections to ensure the relevant degree of protection. The
recommended tightening torque for securing blind plugs is 0.4 Nm.
5.4 Connecting the AS-Interface
VBA-2E-G11-I/U/PT100-F
The VBA-2E-G11-I/U/PT100-F is connected with the AS-Interface network via the yellow flat
cable. The external auxiliary power source U
AUX
is connected to the module via the black flat
cable where required.
Connecting to the AS-Interface
1. Open the module by unscrewing the central screw.
2. Place the yellow flat cable in the channel labeled AS-i.
4.8
50
60
Ø 85.8
metal insert

2014-02
12
VBA-2E-G11-I/U/PT100-*
Installation
3. If the module is to be powered via an external auxiliary power source U
AUX
, place the black
flat cable in the channel labeled AUX. Set the INT/EXT switch to EXT.
If the module is to be powered solely by the AS-Interface, place the flat cable seal (VAZ-FK-
S-BK-SEAL) in the channel labeled AUX. The flat cable seal ensures compliance with the
protection class.
1. AS-i channel (yellow flat cable)
2. AUX channel (black flat cable)
3. Ensure the flat cable is positioned correctly.
4. Reattach the upper part of the module.
5. Tighten the central screw. The recom mended tightening torque for this screw is 1.8 Nm.
The AUX LED and the AS-i/FAULT LED illuminate in green when the module is
connected to the AS-Interface and the external auxiliary power source U
AUX
.
VBA-2E-G11-I/U/PT100-V1
The VBA-2E-G11-I/U/PT100-V1 is connected to the AS-Interface network and the external
auxiliary power source U
AUX
via the M12 connector. see chapter 4.2.
1
2

VBA-2E-G11-I/U/PT100-*
Installation
2014-02
13
5.5 Connecting the Sensors
Figure 5.2
2-wire, 3-wire, and 4-wire sensors can be connected to the VBA-2E-G11-I/U/PT100-* module.
Suitable for various connection scenarios see Figure 5.2 on page 13. In order to obtain a
sound measurement result, the difference in voltage between pins 3 and 4 on a 4-wire
measurement (2 V) must not be exceeded.
Connection examples:
Pt100
2-wire
Pt100
4-wire
Current input
Voltage input
Pt100 input
Inputs:
3-wire 4-wire
24 V
U+
U-
0 V
+
Sig
-
+
Sig+
Sig-
-
1
2
4
3
ϑ
ϑ
I1/I2
U1/U2
PT1/PT2
2-wire 3-wire 4-wire
24 V
I+
I-
0 V
+
-
+
Sig
-
+
Sig+
Sig-
-
1
2
4
3
43
12
5
43
12
5
43
12
5
+
PT+
PT-
-
1
2
4
3
Note!
Connection Instructions
Use shielded cables to connect the sensors.
Note!
Pin 5 of the M12 round plug connector is the functional ground. When the central screw is
tightened, pin 5 connects with the metal insert in the mounting base. see chapter 5.3. This
metal insert then makes contact with the mounting surface via the mounting screws.

2014-02
14
VBA-2E-G11-I/U/PT100-*
Commissioning
6 Commissioning
6.1 Assigning an Address to the Module
To operate the VBA-2E-G11-I/U/PT100-* in an AS-Interface network, you must assign a
suitable address to the AS-Interface slave. The AS-Interface VBP-HH1-V3.0 handheld device
by Pepperl+Fuchs or an AS-Interface master can be used to assign addresses.
The VBA-2E-G11-I/U/PT100-* module is a standard slave as defined by specification 2.1.
These modules can be assigned addresses 1 to 31. The default address on delivery is 0.
6.2 Slave Profile
The VBA-2E-G11-I/U/PT100-* has the profile
S-7.3.D
The data value is transmitted as defined by AS-Interface profile 7.3.
6.3 Parameterization
The following parameters can be set for the VBA-2E-G11-I/U/PT100-*. Program the
parameters using an AS-Interface master, with the VAZ-SW-ACT32 AS-i Control Tool from
Pepperl+Fuchs or with the VBP-HH1-V3.0 handheld device.
Parameter P0: 50/60 Hz Filter
Default value P0=1, active
With parameter P0, you activate the filter for 50/60 Hz power frequencies. With an activated
filter, power frequency interference is suppressed. In this case, the conversion time is extended
(see chapter 9.2).
Parameter P1: Second Channel
Default value P1=1, active
Parameter P1 is used to switch the second measuring channel on or off. If the second channel
is switched off, this can considerably reduce the conversion time in the module. (see chapter
9.2)
Alternatively, it is possible to control the second channel via the bridges on input PT2. (see
chapter 4.2)
I/O = 7
ID = 3
ID1 = F (programmable)
ID2 = D
Note!
The bridges on input PT2 override parameter P1.

VBA-2E-G11-I/U/PT100-*
Commissioning
2014-02
15
Parameter P2: Peripheral Fault
Default value P2=1, active
Parameter P2 is used to switch notification of a peripheral fault in the event of a measuring
overrange on or off (see chapter 9). If notifications are activated, the AS-i/FAULT LED flashes in
the event of a peripheral fault, and a notification is sent to the master.
A peripheral fault is always reported if:
■ The power supply is overloaded.
■ The external power supply is not available when the INT/EXT switch = EXT.
Parameter P3: Current Input 0 mA ... 20 mA
Default value P3=1, not active
Parameter P3=0 is used to set both input channels to current mode. Wire break detection is
simultaneously deactivated. (see chapter 9.1)

2014-02
16
VBA-2E-G11-I/U/PT100-*
Troubleshooting
7 Troubleshooting
7.1 Causes and Elimination of Peripheral Faults
A peripheral fault (P fault) is indicated by the color and flashing of the AS-i/FAULT LED. There
are various causes of and solutions for correcting peripheral faults.
If none of these potential solutions correct the peripheral fault, please contact Pepperl+Fuchs.
7.2 Cause and elimination of a channel fault
If channel 2 is not transferred and the LED at the connection of the relevant input of channel 2 is
not illuminated, channel 2 is not activated.
Cause Solution
Sensor supply overload ■ Check sensor supply for short circuit
Measured values outside the
measurement range
■ Check the connected measurement sensor/Pt100
temperature sensor for wire break/short circuit
Auxiliary power too low (switch set to
EXT)
■ Check the auxiliary power source
Cause Solution
Jumper plugged at PT100-input PT2 ■ Remove jumper (see chapter 4.2)
Parameter P1=0 ■ Change parameter P1 (see chapter 6.3)

VBA-2E-G11-I/U/PT100-*
Appendix A
2014-02
17
8AppendixA
8.1 Dimensions
8.2 Technical Data
Ge n e r a l D a ta
Display/Controls
Electrical Data
Typ e D H l
c
VBA-2E-G11-I/U/PT100-F 85 mm 35 mm -
VBA-2E-G11-I/U/PT100-V1 85 mm 35 mm 11 mm
D
lc
H
Slave type Standard s lave
AS-Interface specification V3.0
Required master
specification
V2.1
UL file number E87056
AS-i/FAULT LED Status indication; multicolor LED
Green: normal mode
Red: communication error
Flashing yellow/red: address 0
Flashing green/red: peripheral fault
ANALOG LED Status of input signal; yellow LED
Off: not active
On: signal within measurement range
Flashing: signal outside measurement range
AUX LED Ext. auxiliary power source (U
AUX
); dual LED (green/red)
Green: voltage OK
Red: voltage reversed
INT/EXT LED Status indication, input supply; green LED
Green: input supply from AS-Interface
Off: input supply from auxiliary power source
Auxiliary power (output) 20 VDC ... 30 VDC PELV
Rated operational voltage 26.5–31.6 V from AS-Interface
Rated operating current 60 mA (without sensors)/max. 200 mA
Protection class III
Surge protection U
AUX
, U
e
: Overvoltage category III, securely isolated power
supplies (PELV)

2014-02
18
VBA-2E-G11-I/U/PT100-*
Appendix A
Input
Programming Instructions
Number/type Two analog inputs
Current: 4 mA ... 20 mA/4 mA ... 20 mA
Voltage: 0 V ... 10 V
Pt100: -200 °C ... 850 °C
Power supply From AS-Interface (switch setting INT, basic setting) or from
auxiliary power source U
AUX
(switch setting EXT)
Current rating 140 mA from AS-Interface; overload and short-circuit proof
600 mA from external auxiliary power source U
AUX
, overload
and short-circuit proof
Input resistance Current input: max. 70 
Voltage input: 100 k
Measurement current For Pt100: approx. 1 mA
Measurement accuracy Voltage/current: 0.1% of end value
Pt100: 0.1% of temperature displayed [°C] + 0.3 °C
Resolution 16 bit/1 µA (current input) or
16 bit/1 mV (voltage input) or
16 bit/0.1 °C (temperature input)
Temperature effect Voltage/current: 20 ppm/K
Pt100: (10 ppm of temperature displayed [°C] + 0.003 °C)/K
Profile S-7.3.D
IO code 7
ID code 3
ID2 code D
Data bit (function via AS-
Interface)
The data value is transmitted as defined by AS-Interface profile
7.3.
Parameter bit
(programmable via AS-i)
Function
P0 50/60 Hz filter
P0=1, activated
P0=0, deactivated
P1 Programming the second channel
P1=1, channel 2 is programmed
P1=0, channel 2 is not programmed
P2 Notification of peripheral fault in the event of a measuring
overrange
P2=1, peripheral fault is reported
P2=0, peripheral fault is not reported
P3 P3=1, normal operation
P3=0, both channels in current mode and without wire break
detection

VBA-2E-G11-I/U/PT100-*
Appendix A
2014-02
19
Compliance with Standards and Directives
Ambient conditions
Mechanical Data
Directive conformity
EMC Directive
2004/108/EC
EN 50295:1999
Standard co nformity
Noise immunity EN 61000-6-2:2005, EN 61326-1:2006, IEC 62026-2:2008
Emitted interference EN 61000-6-4:2007
Input EN 61131-2:2007
Degree of protection EN 60529:2000
Fieldbus standard EN 50295:1999, IEC 62026-2:2008
Ambient temperature -25 °C ... 70 °C (-13 °F ... 158 °F)
Storage temperature -25 °C ... 85 °C (-13 °F ... 185 °F)
Device VBA-2E-G11-I/U/PT100-F VBA-2E-G11-I/U/PT100-V1
Connection AS-Interface/U
AUX
: insulation
piercing technology, yellow flat
cable/black flat cable
Inputs: M12 round plug
connectors
AS-Interface/U
AUX
: M12 round
plug connector
Inputs: M12 round plug
connectors
Degree of protection IP68/IP69K
Material
Housing PBT PC
Mounting screw Stainless steel 1.4305/AISI 303 (V2A)
Mass 200 g
Mounting Mounting base

2014-02
20
VBA-2E-G11-I/U/PT100-*
Appendix B
9 Appendix B
9.1 Analog Input Module Measurement Ranges
Current Input Measurement Ranges
The measurement range of the current input can be set via AS-Interface parameter P3:
■ P3=1, nominal range 4 mA ... 20 mA
■ P3=0, nominal range 0 mA ... 20 mA
Current: 4 mA ... 20 mA
Current: 0 mA ... 20 mA
Voltage Input Measurement Ranges
Voltage: 0 V ... 10 V
Input signal [mA] Display on the master Input LED
> 23 32767 Flashing Above threshold
(peripheral fault)
20.001–23 20001–23000 On Extended range
1)
4 ... 20 4000 ... 20000 On Nominal range
1 ... 3999 1000 ... 3999 On Extended range
1)
< 1 32767 Flashing Below threshold
(peripheral fault)
Table 9.1 Measurement range 1 mA ... 23 mA
1)
: Measurement accuracy corresponds to the nominal range
Input signal [mA] Display on the master Input LED
> 23 32767 Flashing Above threshold
(peripheral fault)
20.001 ... 23 20001 ... 23000 On Extended range
1)
0 ... 20 0000 ... 20000 On Nominal range
< 0 0000 On Below threshold
Table 9.2 Measurement range 0 mA ... 23 mA
1)
: Measurement accuracy corresponds to the nominal range
Caution!
Maximum input current
At input currents > 80 mA, fault-free operation of all inputs is not guaranteed.
Input signal [V] Display on the master Input LED
> 11.5 32767 Flashing Above threshold
(peripheral fault)
10.001 ... 11.5 10001 ... 11500 On Extended range
1)
0 ... 10 0000 ... 10000 On Nominal range
<0 0000 On Below threshold
Table 9.3 Measurement range 0 V ... 11.5 V
1)
: Measurement accuracy corresponds to the nominal range
