Pepperl+Fuchs Bebco EPS 6100 Series User manual

MANUAL
6100 Series
Bebco EPS®6100 Series
Ex pxb Purge and Pressurization System

2
6100 Series Manual
With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published by the
Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie
(ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of
proprietorship."
World Headquarters
Pepperl+Fuchs AG
Lilienthalstr. 200
68307 Mannheim
Germany
Phone: [phone] - 0
Email: [e-mail]
North American Headquarters
Pepperl+Fuchs Inc.
1600 Enterprise Parkway
Twinsburg, Ohio 44087
USA
Phone: [phone]
Email: [email protected].com
Asia Headquarters
Pepperl+Fuchs Pte. Ltd.
P+F Building
18 Ayer Rajah Crescent
Singapore 139942
Phone: [phone]
Email: [email protected]

3
6100 Series Manual
1. Preface........................................................................................... 5
1.1 Information on This Manual ......................................................................... 5
1.2 Responsibility of the Operator and/or Installer ......................................... 5
2. Safety............................................................................................. 6
2.1 Introduction................................................................................................... 6
2.1.1 Contents................................................................................................................................6
2.1.2 Target Group, Personnel........................................................................................................6
2.1.3 Symbols Used.......................................................................................................................7
2.1.4 Pertinent Laws, Standards, Directives, and Further Documentation......................................7
2.1.5 Declaration of Conformity......................................................................................................7
2.2 Warning Labels ............................................................................................. 8
2.3 Conditions of Safe Use................................................................................. 8
2.4 General Information on Pressurized Enclosures ...................................... 9
3. Product Description ................................................................... 10
3.1 Overview ......................................................................................................10
3.2 System Components .................................................................................. 11
3.2.1 6100-MP-EX-* Control Unit .................................................................................................11
3.2.2 6100-MP-LPP-* Pressure Sensor........................................................................................12
3.2.3 EPV-6100-MP-* Enclosure Protection Vent .........................................................................12
3.2.4 Temperature Monitoring/Control Accessories .....................................................................12
3.3 Technical Data............................................................................................. 13
3.3.1 6100-MP-EX-* Control Unit .................................................................................................13
3.3.2 6100-MP-LPP-* Pressure Sensor........................................................................................15
3.3.3 EPV-6100-MP-* Enclosure Protection Vent .........................................................................17
3.4 Dimensions.................................................................................................. 18
3.4.1 6100-MP-EX-* Control Unit .................................................................................................18
3.4.2 EVP-6100-MP-* Enclosure Protection Vent .........................................................................19
3.4.3 6100-MP-LPP-* Pressure Sensor........................................................................................20
3.4.4 6000-TEMP-01 Temperature Hub........................................................................................21
3.4.5 6000-TSEN-01 Temperature Sensor....................................................................................21
3.5 Labels and Markings .................................................................................. 22
4. Electrical Installation ................................................................. 22
4.1 General Wiring Notes ................................................................................. 22
4.2 Power and Intrinsically Safe Wiring .......................................................... 23
4.3 Wiring Parameters ...................................................................................... 24
5. Pneumatic Requirements .......................................................... 25
5.1 Protective Gas Supply................................................................................ 25
5.2 Pneumatic Connections............................................................................. 25
5.3 Pressurization Adjustment ........................................................................ 25
5.4 Purging Adjustment.................................................................................... 25
Contents

4
6100 Series Manual
6. Operation .................................................................................... 26
6.1 Turning on Power to the Enclosure........................................................... 26
6.2 Turning o Power to the Enclosure........................................................... 27
6.3 6100 Series Components........................................................................... 28
6.4 Setup Procedures ....................................................................................... 33
6.5 Operation in Gas-Hazardous Locations ................................................... 34
6.6 Programming............................................................................................... 34
6.6.1 User Interface......................................................................................................................34
6.6.2 Programming Menu.............................................................................................................35
6.6.3 Purge Settings.....................................................................................................................36
6.6.4 Units....................................................................................................................................36
6.6.5 Inputs ..................................................................................................................................37
6.6.6 Outputs ...............................................................................................................................40
6.6.7 Password.............................................................................................................................41
6.6.8 Language............................................................................................................................41
6.6.9 Bypass Control....................................................................................................................41
6.6.10 Restore Defaults..................................................................................................................41
6.6.11 Stats....................................................................................................................................42
6.6.12 Statistics..............................................................................................................................43
6.6.13 Alarm...................................................................................................................................45
6.6.14 Fault ....................................................................................................................................46
6.6.15 Clear Statistics ....................................................................................................................47
6.6.16 Clear Fault...........................................................................................................................47
6.6.17 Operation Screen................................................................................................................47
7. Maintenance and Repair............................................................ 48
8. Alarm and Fault Conditions....................................................... 49
9. Dismantling and Decommissioning ......................................... 50
10. Appendix ..................................................................................... 51
10.1 Programming Worksheet ........................................................................... 51
10.2 Type Codes .................................................................................................. 58
Contents

5
6100 Series Manual
1 Preface
We are pleased that you have chosen a quality product from Pepperl+Fuchs.
This manual will help you meet the safety and protection requirements for installing, commissioning, and
using the 6100 purge and pressurization system and its components.
We reserve the right to make technical changes.
Publisher with responsibility for content:
Pepperl+Fuchs AG
Lilienthalstraße 200
68307 Mannheim, Germany
1.1 Information on This Manual
Knowledge of the basic safety regulations and additional training and experience in the area of explosion
protection are essential for the safe handling and failure-free operation of the 6100 series purge and
pressurization system.
These operating instructions contain important data and information to ensure the safe use of the
6100 system in hazardous areas and to meet the requirements of Directive 2014/34/EU. This manual,
particularly the safety information, must be followed by all personnel who work on the system.
1.2 Responsibility of the Operator and/or Installer
The operator and/or installer undertake to ensure that only specialist, trained personnel work on the 6100
series purge and pressurization system and that they
are familiar with the occupational safety and accident prevention regulations and have been briefed
regarding handling of the unit.
have the additional knowledge of explosion protection that is required for work on explosion protected
components.
are familiar with the relevant rules and regulations for the installation, operation, and maintenance of
explosion-protected systems.
have read the safety section and warnings in this manual.
Preface

6
6100 Series Manual
2 Safety
2.1 Introduction
2.1.1 Contents
This document contains information that you need to use your product throughout the applicable stages of
the product life cycle.These can include the following:
Product identification
Delivery, transport, and storage
Mounting and installation
Commissioning and operation
Maintenance and repair
Troubleshooting
Dismounting and disposal
Warning!
Failure to follow these instructions may impair the safety protection and function of the equipment.
Note!
For complete information on the product, refer to the instruction manual and further documentation at
www.pepperl-fuchs.com.
The documentation consists of the following parts:
Present document
Instruction manual
Datasheet
Additionally, the following parts may belong to the documentation, if applicable:
EU declaration of conformity
Certificates
Control drawings
Additional documents
2.1.2 Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance, and dismounting lies with
the plant operator. In accordance with but not limited to IEC/EN 60079-14, only appropriately trained and
qualified personnel may carry out mounting, installation, commissioning, operation, maintenance, and
dismounting of the product. National laws and regulations must be observed and take precedence over
any aspects of IEC/EN 60079-14. The personnel must have read and understood the instruction manual
and any further documentation.
Safety

7
6100 Series Manual
Safety
2.1.3 Symbols Used
This document contains symbols for the identification of warning messages and of informative messages.
Warning Messages
You will find warning messages in instances where danger may arise from your actions.You must observe
these warning messages for your personal safety and to avoid property damage. Depending on the risk
level, the warning messages are displayed in descending order as follows:
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure
Informative Symbols
Note!
This symbol brings important information to your attention.
Action
This symbol indicates a paragraph with instructions.You are prompted to perform an action or
a sequence of actions.
2.1.4 Pertinent Laws, Standards, Directives, and Further Documentation
NEC, CEC, and other national and local laws, standards, or Directives that are applicable to the intended
use and installation location must be observed. In relation to hazardous areas, Directive 2014/34/EC must
be observed.
The corresponding datasheets, EU Declaration of Conformity, EU Type Examination Certificates, NEC/
NFPA and CEC certificates, and control drawings, if applicable (see datasheet), are an integral part of this
document.You can find this information at www.pepperl-fuchs.com.
Due to constant revisions, documentation is always subject to change. Please refer only to the most up-to-
date version, which can be found at www.pepperl-fuchs.com.
2.1.5 Declaration of Conformity
All products were developed and manufactured under observance of the applicable European standards
and guidelines.
Note!
A declaration of conformity is included with these instructions and can be requested from the manufacturer
or obtained online at www.pepperl-fuchs.com.

8
6100 Series Manual
2.2 Warning Labels
WARNING—FOR PRESSURIZED ENCLOSURES IN HAZARDOUS GAS ENVIRONMENTS
This pressurized enclosure shall not be opened unless the area is known to be free of flammable
materials or unless all devices have been de-energized. Power must not be restored after the
pressurized enclosure has been opened until the pressurized enclosure is completely purged of all
hazardous gas and the enclosure re-pressurized.
2.3 Conditions of Safe Use
Control Unit
1. When the purge control unit is mounted to an enclosure, the complete unit shall be evaluated to the
current revision of IEC/EN 60079-2 or NFPA 496 as applicable. See certificates and/or Declaration of
Conformity for reference to relevant editions of these standards.
2. The purge control unit has an operating temperature class of 135 °C (T4 temperature class).This
temperature shall be considered when mounted to an enclosure.
3. Intrinsically safe cables extending from the enclosure must be provided with at least 0.25 mm insulation
thickness per conductive core to maintain segregation between intrinsically safe circuits.
4. The cable entries may be used only in places where they are protected against the influence of
mechanical danger.
5. The non-metallic membrane touchpad and display is a potential electrostatic discharge hazard. Use
only water damp cloth and allow to air dry for cleaning device. Do not use or install in high charge
areas. See IEC 60079-32-1 for further information.
6. For all applications, the 6000-TEMP-XX I.S. temperature hub must be mounted in an enclosure that is a
minimum IP54. Maintain separation of I.S. to non-I.S. wiring as required by local codes.
7. Caution must be used when handling or cleaning products so there is no static charge buildup. Do
not wipe off the 6000-TSEN-xx sensor with dry cloth or use in the presence of high charge generating
processes such as ionizers or electrostatic equipment. See IEC 60079-32-1 for further information.
8. The 6100 systems may also be provided with previously certified items (operators, cable glands,
terminal box, etc.) as specified in the test reports.
9. The equipment shall only be fitted with suitably certified cable entry devices and/or blanking plugs
appropriate to the application.
10. When the purge control unit is mounted to an enclosure or motor, the complete unit shall be evaluated
to IEC/EN 60079-2:2014 (Ed. 6).
11. The control unit must be mounted via the mounting tabs that are shown in chapter 3.4.1.
I.S. Termination Board, DIN Mounted: 6000-ISB-xx
1. Only connect to the 6000 EPCU I.S. termination connection.
2. All wiring to and from this board is for intrinsically safe connections and must be properly routed and
managed per international, NEC, local codes, and applicable standards.
Note!
The SRM module is a simple apparatus and does not require third-party certification.
Safety

9
6100 Series Manual
EPV-6100 Enclosure Protection Vent
1. The EPV has an operating temperature class of 135 °C (T4 temperature class).This temperature shall
be considered when mounted to an enclosure.
2. Cables use to connect the EPV must be provided with at least 0.25 mm insulation thickness per
conductive core to maintain segregation between intrinsically safe circuits.
3. Only EPV-6100 vents can be connected to any certified 6100 series control system.
4. The EPV must be mounted via the mounting holes that are shown in chapter 3.4.2.
2.4 General Information on Pressurized Enclosures
The pressurized enclosure is one of the most multifunctional applicable types of protection. It
is based on a first flush operation which removes potential ignitable gas mixtures of the local
environment from the enclosure. After the flush, the overpressure will be maintained by adding as
much pressurized air as necessary to compensate for the leaks of the enclosure or components. This
constant overpressure status protects against the diffusion of potentially explosive atmospheres.
During the flush, the internal pressure will be up to 3 ... 5 mbar. In the operation phase, it is reduced
to 1 ... 2.5 mbar. Hot spots at single components inside the enclosure are monitored by temperature
sensors (optional) and if required turned off. This assures that no unacceptable surface temperature
will occur. For this reason, the pressurized enclosure is especially suited for the use of non-Ex
certified equipment in Ex areas.
Enclosure has to be prepared specially for the use of Ex p:
All walls have to be additionally armed
The doors have to be specially constructed
Tested for mechanical stability
Tested for overpressure resistance
Danger!
When using an inert gas like nitrogen, an asphyxiation hazard can exist.
Safety

10
6100 Series Manual
3 Product Description
3.1 Overview
The purpose of the Pepperl+Fuchs Bebco EPS 6100 series Ex pxb, Zone 1 large enclosure / motor purge
and pressurization system is to allow general purpose or non-rated electrical equipment located in a general
purpose enclosure to operate in Zone 1 locations. Other purposes of the 6100 series system include heat,
moisture, and dust contamination prevention.
The 6100 series system operates by controlling and monitoring compressed instrument air or inert gas

system consists of the following parts:
The 6100-MP-EX-* control unit houses the controller and the pneumatics for purging/pressurization and
monitors these actions.
The 6100-MP-LPP-01 pressure sensor is usually mounted at the lowest pressure section of the motor
and feeds back the pressure to the controller. This pressure will determine if the enclosure is operating
at a safe pressure and will indicate the enclosure/motor pressure through the controller's user-interface
controller (UIC).
The EPV-6100-MP-* enclosure protection vent purges and maintains pressure within the enclosure/


The optional 6000-TEMP-01 temperature hub and 6000-TSEN-01 temperature sensor are used to
monitor temperatures within the enclosure/motor. This signal runs back to the controller and can be used
to start the purging valve for cooling or take action through various means.
The controller's UIC allows programming of up to 2 switch inputs, temperature modules, enclosure power


are easily programmed for a fully automated system. Additional features allow inputs for system bypass,



The 6100 system uses many components of the Pepperl+Fuchs Bebco EPS 6000 series purge and
pressurization system and can provide a complete system for purging and pressurizing enclosure/motors for
hazardous location operation.
Note!
One operations copy of this manual must be studied and retained by the system operator in addition to one

start-up.
Product Description, Overview

11
6100 Series Manual
3.2 System Components
3.2.1 6100-MP-EX-* Control Unit
1User-interface controller (UIC)
2Inlet for purge gas supply—1 1/4" FNPT
3Outlet for purge gas supply into enclosure—
1 1/4" FNPT
4Intrinsically safe pilot valve supply port 1/4" tube
 
5Manual gate valve for pressurization
6Angle valve for purging
7Enclosure protection control unit (EPCU)
8Intrinsically safe pilot valve for actuation of
purging valve
9Intrinsically safe termination board
10 Power terminals
11 Gland plate for cable glands
12 6100-MP-EX-* control unit
Product Description, System Components
1
23
5
6
9
7
8
4
11
12
10

12
6100 Series Manual
3.2.2 6100-MP-LPP-* Pressure Sensor
3.2.3 EPV-6100-MP-* Enclosure Protection Vent
3.2.4 Temperature Monitoring/Control Accessories
Intrinsically safe temperature hub Intrinsically safe temperature sensor
Product Description, System Components

13
6100 Series Manual
3.3 Technical Data
3.3.1 6100-MP-EX-* Control Unit
General specifications
Operating mode manual, semi-automatic, or fully automatic - programmable
Series 6100
Number of volume exchanges 4 to 19
Hazardous environment gas
Supply
Rated voltage Ur100 ... 250 V AC, 48 ... 62 Hz / 0.2 A
20 ... 30 V DC / 0.6 A
Electrical specications
Connection
Power Ex e terminal blocks
Connection 6000-ISB DIN mounted terminal
Input*
Input I Inputs 1, 2: contact input, 5 V DC at 2 mA
Input type discrete input, intrinsically safe
Input II temperature hub, temperature inputs
Input type intrinsically safe
Sensor type 6000-TEMP-01
Input III low pressure sensor
Input type intrinsically safe
Sensor type EPV-6100-LPP
Input IV User interface module
Connection M8 connector, 4-pin (provided)
Input type intrinsically safe
Output
Output I AUX 1
Output type Dry contacts, SPDT
Inrush current 5 A
Contact loading 2 A at 240 V AC resistive load
2 A at 24 V DC
Output II AUX 2
Output type Dry contacts, SPDT
Inrush current 5 A
Contact loading 2 A at 240 V AC resistive load
8 A at 24 V DC
Output III enclosure 1 and 2
Output type Dry contacts (2) SPST, NO
Inrush current 72 A
Contact loading 8 A at 240 V AC / 120 V AC resistive load
8 A at 24 V DC
Indicators/settings
LED indication Safe pressure: Blue - safe pressure is achieved

Rapid exchange: Blue - purging is running
System bypass:Yellow - bypass is activated
Alarm fault: Red (blinking) - any alarm input detected; Red (solid) - fault
Product Description, Technical Data
* Warning: Inputs 1, 2, 3, and 4 must be used with the SRM-6000 for tested EMC immunity.

14
6100 Series Manual
Pneumatic parameters
Protective gas supply 
Pressure requirement regulated side: 20 ... 120 psig (1.4 ... 8.3 bar)
unregulated side: 60 ... 120 psig (4.1 ... 8.3 bar)
Safe pressure 0.25 in wc (6.4 mm wc) (0.625 mbar) minimum for 6100-MP-LPP-*
-
sure rate
2000 l/m ... 14000 l/m

 pressurization valve: manual gate valve
purging valve: pilot drive angle seat valve
pilot valve: intrinsically safe solenoid valve
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013
RoHS
Directive 2011/65/EU (RoHS) EN 50581:2012
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Storage temperature -30 ... 80 °C (-22 ... 176 °F)
Relative humidity 5 ... 95 %, noncondensing
Vibration resistance EN 60068-2-6
Impact resistance EN 60068-2-27
Mechanical specications
Connection type Terminals
Cable entry 3 x M16 holes, plugs that are included are not hazardous-location rated
4 x M20 holes, plugs that are included are not hazardous-location rated
Degree of protection IP66
Material inlet and outlet: 1 1/4 inch NPTF, 316 stainless steel
internal piping: brass

gate valve: bronze, Grafoil seals
purging valve: 316 stainless steel, PTFE seals
pilot valve: 1/4 inch NPTF, 316 stainless steel
solenoid valve: aluminum
housing: 303, 304 L stainless steel
Mass 40 kg (88 lbs)
Dimensions 558 mm x 762 mm x 213 mm (22 in x 30 in x 8.4 in)
Data for application in connec-
tion with hazardous areas
 CML 19 ATEX 1425X
Marking II2G Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb
Directive conformity
Directive 2014/34/EU EN IEC 60079-0:2018
EN 60079-1:2014
EN 60079-2:2014
EN 60079-7:2015
EN 60079-11:2012
International approvals
IECEx approval IECEx CML 19.0156X
Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb
Product Description, Technical Data

15
6100 Series Manual
General information
Supplementary information 
Conformity, Attestation of Conformity and instructions have to be ob-
served where applicable. For information see www.pepperl- fuchs.com.
Supplemental Standards : EN 61010-1:2010
3.3.2 6100-MP-LPP-* Pressure Sensor
General specifications
Series 6100
Hazardous environment gas
Electrical specications
Connection
Power Intrinsically safe back to the 6100 control unit
Signal BUS back to 6100 control unit
Connection M12 connector, 4-pin, max length 30 m
Indicators/settings
LED indication power: green
Pneumatic parameters
Maximum pressure 0 ... 25 mbar (0 ... 10 in wc) pressure range
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013
RoHS
Directive 2011/65/EU (RoHS) EN 50581:2012
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Storage temperature -30 ... 80 °C (-22 ... 176 °F)
Relative humidity 5 ... 95 %, noncondensing
Vibration resistance 10 ... 150 Hz, 1g, 12 m², all axes
Impact resistance 30 g, 11 ms, all axes
Mechanical specications
Material 5052 anodized aluminum, 6061T6 anodized aluminum
Installation - any orientation to enclosure
- not gravity dependent
Mass approx. 1.4 kg (3.1 lb)
Dimensions 127.5 x 146 x 82.5 mm (5.05 x 5.75 x 3.25 inch)
Mounting 1 1/2" NPT knockout (50.8 mm (2") hole)
with sealed nut
Data for application in connection
with hazardous areas
 CML 19 ATEX 1425X
Marking II2G Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb
Directive conformity
Directive 2014/34/EU EN IEC 60079-0:2018
EN 60079-1:2014
EN 60079-2:2014
EN 60079-7:2015
EN 60079-11:2012
Product Description, Technical Data

16
6100 Series Manual
International approvals
IECEx approval IECEx CML 19.0156X
Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb
General information
Supplementary information -
ration of Conformity, Attestation of Conformity and instructions have
to be observed where applicable. For information see www.pepperl-
fuchs.com.
Supplemental Standards : EN 61010-1:2010
3.3.3 EPV-6100-MP-* Enclosure Protection Vent
General specifications
Series 6100
Hazardous environment gas
Electrical specications
Connection
Power Intrinsically safe back to the 6100 control unit
Signal 2-wire intrinsically safe pressure switch
Connection 2-wire
Pneumatic parameters
Protective gas supply Clean air or inert gas
Safe pressure 0.25 in wc (0.625 mbar) (6.4 mm wc)
Enclosure pressure 0 ... 9.9 in wc (25 mbar) (250 mm wc)

rate
EPV-6100-MP-020: 2000 l/min at 6.3 mbar (70 cfm at 2.5 in wc)
EPV-6100-MP-050: 5000 l/min at 6.8 mbar (175 cfm at 2.7 in wc)
EPV6100-MP-080: 8000 l/min at 9.0 mbar (280 cfm at 3.6 in wc)
EPV-6100-MP-110: 11000 l/min at 9.0 mbar (380 cfm at 3.6 in wc)
EPV-6100-MP-140: 14000 l/min at 9.0 mbar (490 cfm at 3.6 in wc)
Flow rate for leakage compensation depends on enclosure seal
based on completely sealed enclosure
Breaking pressure approx. 3.0 mbar (1.2 in wc)
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013
RoHS
Directive 2011/65/EU (RoHS) EN 50581:2012
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Storage temperature -30 ... 80 °C (-22 ... 176 °F)
Relative humidity 5 ... 95 %, noncondensing
Vibration resistance EN 60068-2-6
Impact resistance EN 60068-2-27
Mechanical specications
Installation -gravity dependent
-air outlet, screen side must be facing down
Mass 17 kg (37 lb)
Product Description, Technical Data

17
6100 Series Manual
Data for application in connection
with hazardous areas
 CML 19 ATEX 1425X
Marking II2G Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb
Directive conformity
Directive 2014/34/EU EN IEC 60079-0:2018
EN 60079-1:2014
EN 60079-2:2014
EN 60079-7:2015
EN 60079-11:2012
International approvals
IECEx approval IECEx CML 19.0156X
Ex db eb ib [ib Gb][pxb Gb] IIC T4 Gb
General information
Supplementary information -
ration of Conformity, Attestation of Conformity and instructions have
to be observed where applicable. For information see www.pepperl-
fuchs.com.
Supplemental Standards : EN 61010-1:2010
Product Description, Technical Data

18
6100 Series Manual
3.4 Dimensions
3.4.1 6100-MP-EX-* Control Unit
N O T R E L E A S E D
N O T R E L E A S E D
N O T R E L E A S E D
N O T R E L E A S E D
104-5530 Not released EDM checkout 11/01/2019
N O T R E L E A S E D
NOT RELEASED
N O T R E L E A S E D
N O T R E L E A S E D
104-5530 Not released EDM checkout 11/01/2019
Product Description, Dimensions
Note!
The purge controller is
equipped with a stud for
equipotential bonding.

19
6100 Series Manual
3.4.2 EPV-6100-MP-* Vent
N O T R E L E A S E D
NOT RELEASED
N O T R E L E A S E D
N O T R E L E A S E D
104-5528 Not released EDM checkout 11/01/2019
N O T R E L E A S E D
N O T R E L E A S E D
N O T R E L E A S E D
N O T R E L E A S E D
104-5528 Not released EDM checkout 11/01/2019
Product Description, Dimensions

20
6100 Series Manual
3.4.3 6100-MP-LPP-* Pressure Sensor
N O T R E L E A S E D
N O T R E L E A S E D
N O T R E L E A S E D
N O T R E L E A S E D
104-5529 Not released EDM checkout 11/01/2019
Product Description, Dimensions
