Pepperl+Fuchs DAD10-8P Series User manual

MANUAL
FACTORY AU TOMATION
DAD10-8P
OPTICAL DATA COUPLER

Date of issue 2010-04 Part No. 226387
With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central
Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.)
in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"

DAD10-8P Optical data coupler
Date of issue 2010-04 Part No. 226387
3
1 Introduction ...............................................................................4
1.1 Warranty ........................................................................................... 4
2 Declaration of Conformity ........................................................5
3 Safety .........................................................................................6
3.1 Symbols used ................................................................................... 6
3.2 General safety instructions ............................................................... 6
4 Product description ..................................................................7
4.1 Technical Description ....................................................................... 7
4.2 Action on light beam interruption: ..................................................... 7
4.3 Switching off the transmitter: ............................................................ 7
4.4 In- and Outputs, receiving signals: ................................................... 7
5 Appendix ....................................................................................8
5.1 Technical data .................................................................................. 8
5.2 Sample of input wiring/ switchings ................................................... 9
5.3 Functional indications ..................................................................... 10
5.4 Diagrams ........................................................................................ 10
5.5 Dimensions .................................................................................... 11
5.6 Connection diagram ....................................................................... 13
5.7 Article description and Article numbers to ease your order ............ 14

DAD10-8P Optical data coupler
Introduction
Date of issue 2010-04 Part No. 226387
4
1 Introduction
Congratulations!
You have chosen a device from Pepperl+Fuchs. Pepperl+Fuchs develops, produces,
and markets electronic sensors and interface components for the automation technology
market worldwide.
Contact
If you have questions about the device, accessories, or other functions, please contact:
Pepperl+Fuchs GmbH
Lilienthalstraße 200
68307 Mannheim
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
1.1. Warranty
Pepperl+Fuchs manufactures its hardware products according to recognized industrial
standards. Pepperl+Fuchs guarantees its products to be free of defects in material and
workmanship provided the products are used under the normal operating conditions
specified by the manufacturer. The warranty applies only to the original owner and is not
transferable. All accompanying exclusionsofliability,restrictions, and other conditions of
this section apply to this warranty.
Exclusions of liability
No warranty obtained or granted hereby shall apply to products that:
• have been repaired, modified, or tampered with unless explicitly performed or ap-
proved by Pepperl+Fuchs
• have not been serviced in accordance with the Operating and Handling Instructions
provided by Pepperl+Fuchs
• have been exposed to unusual physical or electrical loads, immersed in liquids, or ex-
posed to any one of the following circumstances:
• breakdown
•crushing
• improper use
•misuse
• low current
• unsuitable power supply
• reverse polarity
• negligence or accident
• has been used for any purpose other than what is described in the Operating and Han-
dling Instructions
Preventive maintenance is the customer's responsibility and is not covered by this war-
ranty.

DAD10-8P Optical data coupler
Declaration of Conformity
Date of issue 2010-04 Part No. 226387
5
General
With the exception of the warranties noted above, Pepperl+Fuchs offers no warranties
for products delivered below in any form whatsoever, whether explicit or implicit, includ-
ing, but not limited to implicit defect warranty services and guarantee of suitability for a
specific purpose, and absence of injury. The explicit warranties noted above shall satisfy
all obligations and liabilities of Pepperl+Fuchs for damages, including but not limited to
concrete damages, indirect damages or consequential damages in connection with the
use or design of the product. The seller's liability to the buyer and other persons (regard-
less of the origin of liability, whether it be based on contract, warranty, impermissible han-
dling, misuse, and/or other origin) in connection with the use of a product shall in no case
exceed the original purchase price of the product. Pepperl+Fuchs shall in no event be
liable for consequential damages, concrete and indirect damages, secondary damages
or penalties, or lost profits, sales, or loss of data, even if Pepperl+Fuchs had been made
aware of this possibility.
2 Declaration of Conformity
We, Pepperl+Fuchs GmbH, hereby declare on our sole responsibility that the
DAD10-8P Optical data coupler
and all models of this product to which this declaration refers are in conformity with the
following standards and other regulatory documents
EN 60947-5-2
Product family standard: Electromagnetic Compatibility (EMC for light industry and in-
dustry)
Pepperl+Fuchs GmbH in D-68301 Mannheim has a certified quality assurance system in
conformity with ISO 9001.
A corresponding Declaration of Conformity may be requested from the
manufacturer.
ISO9001

DAD10-8P Optical data coupler
Safety
Date of issue 2010-04 Part No. 226387
6
3Safety
3.1. Symbols used
Safety-related symbols
3.2. General safety instructions
The following basic instructions must be observed in all cases:
• The device must not be placed in service until the manual has been read and under-
stood
• The power device for generating the power supply voltage must be reliably insulated
electrically by means of double insulation and a safety transformer according to DIN
VDE 0551 (corresponds to IEC 742).
• The device must not be used outside the specification without suitable protective mea-
sures
• No unauthorized tampering with the device is permitted
• Do not point the device directly at the sun or measure into the sun
• Do not remove the warning instructions or rating plates
The radiation emitted by a Class 1 laser is harmless. This type of laser instrument can
be operated by anyone.
The system operator is responsible for planning, assembly, commissioning, operation,
and maintenance of the system.
Installation and commissioning of all devices must only be performed by personnel spe-
cially trained for that purpose.
The protection of the system and operating personnel is not ensured if the module is not
used according to its intended purpose.
Observe the applicable laws and regulations for use and for the intended purpose. The
devices are only approved for proper use in accordance with intended purpose. Any oth-
er use voids all warrantee claims and manufacturer's responsibility.
Use only recommended original accessories.
If you are unable to eliminate malfunctions, take the device out of operation. Secure the
device against accidental operation. Return the device to Pepperl+Fuchs for repair. Own
interventions and modifications are potentially hazardous, and any guarantee and man-
ufacturer's liability shall become void.
Dispose of the useless device in keeping with the applicable national legal regulations.
For example, you can take the sensor to the designated collection point for electronic
scrap.
Danger!
This symbol identifies an immediate and present danger.
Failure to observe this warning may result in personal injury or even
death.
In applications with shelf distances and moving carriages, care must
always be taken to observe the applicable safety regulations. Failure to
do so will result in grave danger to life and limb!

DAD10-8P Optical data coupler
Product description
Date of issue 2010-04 Part No. 226387
7
4 Product description
Features
• Supply Voltage: 10-60 VDC
• Range: 0 - 1,5 m.
• Sensitivity control
• Half Duplex Data transmission
• Baud Rate: 2400
• 10 optocoupler inputs
• 10 PNP-outputs.
• Action of outputs by interrupting the beams is selectable
• Optical signals for receiving, data inputs and data outputs
• Programmable Operating mode - Master/Slave.
• External transmitter switch off
4.1 Technical Description
The DAD 10-8P unit allows for bidirectional data transmission of 8 bit data words. A pair
of units is required to create the transmission path. One of the units is set upas the MAS-
TER(High-level atinputMaster/ Slave)and thesecond asthe SLAVE(Low-level atinput
Master / Slave).
All parallel binary control signals connected to the inputs D1 to D8 are converted into an
8 bit serial sequence. This serial data is transmitted by light beam to the receiver where
it is converted back to parallel data available at the outputs D1 to D8. Frequency shift
keying is used to provide secure transmission of the binary data. The total response time
is 3ms during which both 8 bit words are transmitted, one in each direction, in timed mul-
tiplex mode.
This provides a transmission speed of 2400 baud. A feature of the timed multiplex mode
is that the last data message is always stored at the output until the next message is
transmitted.
4.2 Action on light beam interruption:
The action required in case the light beam is interrupted can be controlled by a switch.
Switch position 1: data outputs are switched off, when the light beam is interrupted.
Switch position 2: The data received last is still available at the outputs, when the light
beam is interrupted.
4.3 Switching off the transmitter:
For operating the DAD10-8P a High-level is necessary at the ENABLE input. If the EN-
ABLE-input is at low level, the transmitter is switched off.
If the transmitter is switched off at the MASTER, the SLAVE -transmitter is also switched
off automatically. If the SLAVE is switched off, the MASTER still transmits data, that the
SLAVE receives.

DAD10-8P Optical data coupler
Appendix
Date of issue 2010-04 Part No. 226387
8
4.4 In- and Outputs, receiving signals:
The inputs of the DAD10-8P are isolated by optocoupler from the other switches. The
status of data in- and output is displayed by various LEDs. A high level at the input is in-
dicated by a red LED. A green LED indicates an active output.
A yellow or green LED and the output EMPF.-ANZEIGE (receiver display) gives a suffi-
cient optical signal of receiving.
(yellow LED==> standard function reserve;
green LED ==> triple function reserve)
The SYNC-output marks at the MASTER device the times, when data input is received
(rising edge) or when the output data are valid (falling edge).
5Appendix
5.1 Technical data
General specifications
Effective detection range 0 ... 1500 mm
Threshold detection range 3000 mm
Light source IRED
Light type modulated infrared light
Approvals CE
Alignment aid LED green (sufficient stability control)
Transmission mode FSK (214.3 kHZ, 250.0 kHz)
Diameter of the light spot approx. 1250 mm at 1.5 m
Angle of divergence ± 20 °
Ambient light limit 5000 Lux
Cycle time 3
Indicators/operating means
Data flow display Inputs: 8 LEDs red
Outputs: 8 LEDs green:
Function display - green LED for power on
- yellow LED illuminates, when receiving data (standard function reserve)
- green LED illuminated, when receiving (greater than triple function
reserve)
Controls sensitivity adjustment
Controls coding switch: behavior when light beam is interrupted
Electrical specifications
Operating voltage UB10 ... 60 V DC
No-load supply current I0160 mA
Data sampling blanking Enable input emitter deactivation
Data rate 2400 Bit/s
Operation frequency 232 kHz
Interface

DAD10-8P Optical data coupler
Appendix
Date of issue 2010-04 Part No. 226387
9
Table 5.1: Technical data
5.2 Sample of input wiring/ switchings
Interface type 8 bit parallel, bidirectional
inputs: 8 optocoupler
Outputs: 8 PNP, not short-circuit proof
Output
Output of the pre-fault indication 1 PNP (switches if there is sufficient stability control)
Switching voltage max. 60 V DC
Switching current max. 100 mA per channel , total 600 mA
Standard conformity
Standards EN50081-1 : 1992
EN50082-2 : 1994
CISPR 22 Class B
IEC 1000-4-2
IEC 801-3
IEC1000-4-4
IEC 801-6
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Storage temperature -20 ... 75 °C (-4 ... 167 °F)
Mechanical specifications
Protection degree - Connector with PG9- sealing glands:
IP67 to DIN 40050
- Connector with 25-pin Sub-D-socket (optional):
IP42 to DIN 40050
Connection -Screwless spring clamp for
conductor diameters of 0.08 mm ... 0.5 mm
-25-pin Sub-D-plug socket (optional) or connector
Material
Housing Terluran, black
Optical face glass
Mass 170 g
PNP Input
0VInput
DAD10-8P
Control unit
Limitation of input current
8-40 VDC

DAD10-8P Optical data coupler
Appendix
Date of issue 2010-04 Part No. 226387
10
5.3 Functional indications
5.4 Diagrams
8 4 8 4
5 1 5 1
x
y
DAD10-P
OffsetY [mm]
Distance X [m]
Characteristic response curve
0
100
200
300
400
500
600
700
800
00.5 11.5 22.5
x
DAD10-P
Distance X [m]
Stability control
Relative received light strength
1
10
100
1000
00.5 11.5 22.5 33.5
3

DAD10-8P Optical data coupler
Appendix
Date of issue 2010-04 Part No. 226387
11
5.5 Dimensions
DAD 10-8P series (PG-screwings at the housing bottom
DAD10-8P-SD (with 25-pin Sub-D-socket or connector)
Sensitivity adjuster
11.7
5.8
4.2
20.1
5.5
4.3
40.2
4.3
5.5 65
45
76
56 24
2
51
34
Pg 9

DAD10-8P Optical data coupler
Appendix
Date of issue 2010-04 Part No. 226387
12
DAD10-8P-R (PG-screwings at the housing rear)
Fixing angle for DAD10-8P; DAD10-8P-R; DAD10-8P-SD

DAD10-8P Optical data coupler
Appendix
Date of issue 2010-04 Part No. 226387
13
5.6 Connection diagram
Connector with clamps:
Connector with 25pin Sub-D-socket or connector
Version DAD10-8P(/35) and ...-HD...
*) Reference potential for data inputs
Reception indicator
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
0 V
+UB
SYNC
D8OUT
D7OUT
D6OUT
D5OUT
D4OUT
D3OUT
D2OUT
D1OUT
n. c.
0VIN *)
D8IN
D7IN
D6IN
D5IN
D4IN
D3IN
D2IN
D1IN
IN Master/Slave
IN Enable
Version ...-SDS...and ...-SDB...
Reception indicator
*) Reference potential for data inputs
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
D7IN
D6IN
D5IN
D3IN
D2IN
D1IN
0VIN *)
D1OUT
D3OUT
D5OUT
D6OUT
D7OUT
D8OUT
D8 IN
IN Master/Slave
D4IN
+UB
+UB
0 V
0 V
D2OUT
D4OUT
IN Enable
SYNC

DAD10-8P Optical data coupler
Appendix
Date of issue 2010-04 Part No. 226387
14
5.7 Article description and Article numbers to ease your order
Table 5.2: Model Number
Article Description Article-
Number
Complete Device (Electronics + Cable Adapter)
DAD10-8P 418610
DAD10-8P-SDB (with 25-pin Sub-D-Socket) 418611
DAD10-8P-R-2388
(with 2 PG9-sealing glands at the housing rear and fixing angle) 418612
DAD10-8P-HD (for DIN rail mounting plus 25-pin Sub-D-Socket) 418613
DAD10-8P-R (with 2 PG9-sealing glands at the housing rear) 418614
DAD10-8P-SDS (with 25-pin Sub-D-Connector) 418616
Complete Device
(Electronics + Cable Adapter) Opt. 35 Scanning Range=3m
DAD10-8P/35 418623
DAD10-8P-SDB/35 (with 25-pin Sub-D-Socket) 418624
DAD10-8P-SDS/35 (with 25-pin Sub-D-Connector) 418625
Electronics
DAD10-8P-E 418617
Cable Adapter
DAD10-8P-A 418618
DAD10-8P-AHS (for DIN rail mounting) 418619
DAD10-8P-ASD (with 25-pin Sub-D-Socket) 418620
DAD10-8P-AR (with 2 PG9-sealing glands at the housing rear) 418621
DAD10-8P-AHD (for DIN rail mounting plus 25-pin Sub-D-Sokket) 418622
Accessories
Fixing angle 406978

Date of issue 2010-04 Part No. 226387
With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central
Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.)
in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"

Subject to modifications
Copyright PEPPERL+FUCHS • Printed in Germany
www.pepperl-fuchs.com
Worldwide Headquarters
Pepperl+Fuchs GmbH
68307 Mannheim · Germany
Tel. [phone]
E-mail: [email protected]
USA Headquarters
Pepperl+Fuchs Inc.
Twinsburg, Ohio 44087 · USA
Tel. [phone]
E-mail: [email protected]
Asia Pacific Headquarters
Pepperl+Fuchs Pte Ltd.
Company Registration No. 199003130E
Singapore 139942
Tel. [phone]
E-mail: [email protected]
FACTORY AUTOMATION –
SENSING YOUR NEEDS
226387 DOCT-2081
04/2010
