Pepperl+Fuchs IUH-F190-V1 Series User manual

IUH-F190-V1-*
Read / Write Head for IDENTControl
FACTORY AUTOMATION
MANUAL

With regard to the supply of products, the current issue of the following document is ap-
plicable: The General Terms of Delivery for Products and Services of the Electrical Indus-
try, published by the Central Association of the Electrical Industry (Zentralverband
Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the
supplementary clause: "Expanded reservation of proprietorship"
IUH-F190-V1-*

IUH-F190-V1-*
3
1 Introduction................................................................................. 6
2 Certificates and approvals......................................................... 7
2.1 Declaration of Conformity (R&TTE Directive 1995/5/EC)................. 7
2.2 FCC Information ................................................................................... 7
2.3 IC Information....................................................................................... 8
2.4 UL Information...................................................................................... 8
2.5 Additional country-specific approvals............................................... 8
3 Safety ........................................................................................... 9
3.1 Symbols relevant to safety.................................................................. 9
3.2 Intended Use ........................................................................................ 9
3.3 General notes on safety..................................................................... 10
4 Product Description ................................................................. 11
4.1 RFID Frequency Bands...................................................................... 11
4.2 UHF general........................................................................................ 11
4.2.1 Advantages of UHF.......................................................................... 11
4.2.2 Applications for UHF systems .......................................................... 11
4.2.3 Memory Structure of a Tag / EPC Gen 2 (ISO/IEC 18000-63)........... 12
4.2.4 Electronic Product Code (EPC)........................................................ 14
4.2.5 Influence of various materials on the sensing range......................... 14
4.2.6 Dense Reader Mode (DRM) ............................................................ 15
4.2.7 Frequency Hopping Spread Spectrum............................................. 16
4.2.8 Relevant Standards for UHF............................................................. 16

4
IUH-F190-V1-*
4.3 Countries of Use.................................................................................17
4.3.1 European Union ............................................................................... 17
4.3.2 Argentina.......................................................................................... 17
4.3.3 Australia ........................................................................................... 17
4.3.4 Brazil ................................................................................................ 18
4.3.5 Canada ............................................................................................ 18
4.3.6 China................................................................................................ 18
4.3.7 Hong Kong ....................................................................................... 18
4.3.8 India ................................................................................................. 19
4.3.9 Japan ............................................................................................... 19
4.3.10 Colombia.......................................................................................... 19
4.3.11 Malaysia ........................................................................................... 19
4.3.12 Mexico.............................................................................................. 20
4.3.13 New Zealand .................................................................................... 20
4.3.14 Russia .............................................................................................. 20
4.3.15 Singapore......................................................................................... 20
4.3.16 South Korea ..................................................................................... 21
4.3.17 Thailand ........................................................................................... 21
4.3.18 United States of America .................................................................. 22
4.3.19 Vietnam............................................................................................ 22
4.4 General Functions and Features .......................................................23
4.5 Indicators and Operating Controls ...................................................24
4.6 Connection..........................................................................................24
4.7 Scope of Delivery ...............................................................................25
4.8 Accessories ........................................................................................25
4.8.1 IDENTControl................................................................................... 25
4.8.2 Read/Write Tags............................................................................... 26
4.8.3 Connection cable for R/W heads and trigger sensors ...................... 26
4.8.4 Cable connectors for the power supply ............................................ 27
4.8.5 Mounting set..................................................................................... 27
5 Installation................................................................................. 28
5.1 Storage and transport ........................................................................28
5.2 Unpacking ...........................................................................................28

IUH-F190-V1-*
5
5.3 Mounting ............................................................................................. 28
5.3.1 Room Orientation............................................................................. 29
5.3.2 Minimum Distances ......................................................................... 30
5.3.3 Polarization ...................................................................................... 30
5.4 Connection ......................................................................................... 31
5.5 EMC Concept...................................................................................... 31
6 Commissioning......................................................................... 32
6.1 Definitions........................................................................................... 32
6.1.1 Display............................................................................................. 32
6.1.2 Legend............................................................................................. 32
6.2 Initial Commissioning........................................................................ 33
6.3 Device Settings .................................................................................. 34
6.4 Operation via the Command Interface ............................................. 34
7 Operation................................................................................... 38
7.1 General ................................................................................................ 38
7.2 Basic Command Process .................................................................. 38
7.3 Command Overview .......................................................................... 39
7.4 Read/Write Commands...................................................................... 40
7.5 Filter Commands................................................................................ 44
7.6 Configuration Commands ................................................................. 47
7.6.1 ChangeTag Command..................................................................... 47
7.6.2 Read and Write Parameters ............................................................. 48
7.6.3 Parameters ...................................................................................... 50
7.7 Error/Status Messages ...................................................................... 58
8 Service and Maintenance ........................................................ 59
9 Troubleshooting........................................................................ 60
10 Appendix ................................................................................... 61
10.1 Dimensions......................................................................................... 61
10.2 ASCII table .......................................................................................... 61
10.3 Detection Range................................................................................. 62

2014-11
6
IUH-F190-V1-*
Introduction
1Introduction
Congratulations
You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs develops,
produces and distributes electronic sensors and interface modules for the market of
automation technology on a worldwide scale.
Before you install this device and put it into operation, please read the operating instructions
thoroughly. The instructions and notes contained in this operating manual will guide you step-
by-step through the installation and commissioning procedures to ensure trouble-free use of
this product. By doing so, you:
■guarantee safe operation of the device
■can utilize the entire range of device functions
■avoid faulty operation and the associated errors
■reduce costs from downtimes and incidental repairs
■increase the effectiveness and operating efficiency of your plant.
Store this operating manual somewhere safe in order to have it available for future work on the
device.
After opening the packaging, please ensure that the device is intact and that the package is
complete.
Symbols used
The following symbols are used in this manual:
Handling instructions
You will find handling instructions beside this symbol
Contact
If you have any questions about the device, its functions, or accessories, please contact us at:
Pepperl+Fuchs GmbH
Lilienthalstraße 200
68307 Mannheim
Telephone: [phone]
Fax: [phone]
E-Mail: fa[email protected]
Note!
This symbol draws your attention to important information.
IUH-F190-V1-*

IUH-F190-V1-*
Certificates and approvals
2014-11
7
2 Certificates and approvals
2.1 Declaration of Conformity (R&TTE Directive 1995/5/EC)
This product was developed and manufactured under observance of the applicable European
standards and guidelines.
The product manufacturer, Pepperl+Fuchs GmbH, 68307 Mannheim, has a certified quality
assurance system that conforms to ISO 9001.
2.2 FCC Information
Note:
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his own expense.
FCC Notice
To comply with FCC part 15 rules in the United States, the system must be professionally
installed to ensure compliance with the Part 15 certification. It is the responsibility of the
operator and professional installer to ensure that only certified systems are deployed in the
United States. The use of the system in any other combination (such as co-located antennas
transmitting the same information) is expressly forbidden.
FCC Exposure Information
To comply with FCC RF exposure compliance requirements, the antennas used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons
and must not be co-located or operated in conjunction with any other antenna or transmitter.
Note!
A Declaration of Conformity can be requested from the manufacturer or downloaded from
www.pepperl-fuchs.com.
ISO9001
FCC ID: IREIUH-F190-V1
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause
undesired operation.
Attention:
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
IUH-F190-V1-*

2014-11
8
IUH-F190-V1-*
Certificates and approvals
2.3 IC Information
2.4 UL Information
Technical Data and Environmental Conditions
This device is for indoor use only.
This device may be operated in altitudes up to 2000 m.
The ambient temperature range is from -25 °C to +50 °C for continuous transmission mode, or
-25 °C to +70 °C for operation with non-transmission periods.
The maximum relative humidity is 80 % for temperatures up to 31 °C decreasing linearly to 50
% relative humidity at 40 °C.
Nominal power supply voltage is 24 VDC . For the intended use this read/write head has
to be connected to Pepperl+Fuchs IDENTControl control interfaces using a shielded
connection cable. The IDENTControl supplies the read/write head with 20 ... 30 VDC, Protective
Extra Low Voltage (PELV).
Protection class IP67 is not included in the UL approval. The protection class is tested by
Pepperl + Fuchs GmbH.
2.5 Additional country-specific approvals
For all current approvals see the data sheet of your read / write head under www.pepperl-
fuchs.com.
This device complies with Industry Canada licence-exempt RSS standard(s) and with part 15
of the FCC Rules. Operation is subject to the following two conditions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouil-
lage est susceptible d'en compromettre le fonctionnement.

IUH-F190-V1-*
Safety
2014-11
9
3Safety
3.1 Symbols relevant to safety
3.2 Intended Use
The IUH-F190-V1-* is a read/write head for passive read-only and read/write tags.
Always operate the device as described in these instructions to ensure that the device and
connected systems function correctly. The protection of operating personnel and plant is only
guaranteed if the device is operated in accordance with its intended use.
Read through these instructions thoroughly. Familiarize yourself with the device before
installing, mounting, or operating.
Pepperl+Fuchs GmbH provides no guarantee that the information contained in this document
does not contain third-party industrial property rights. Pepperl+Fuchs GmbH does not issue
any licenses to its own or third-party patents or other industrial property rights in this document.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt devices and any connected systems and plants, or result in
their complete failure.
Note!
The installation recommendations made in this document are based on favorable conditions.
Pepperl+Fuchs GmbH provides no guarantee of correct function in environments belonging to
other systems.
Warning!
Malfunctions with Pacemakers
This device does not exceed the permissible limits for electromagnetic fields. Maintain a
minimum distance of 25 cm between the device and your pacemaker.
Inadequate distance from the read/write head can result in inhibitions, reprogramming, or
incorrect stimulation pulses.
IUH-F190-V1-*

2014-11
10
IUH-F190-V1-*
Safety
3.3 General notes on safety
Only instructed specialist staff may operate the device in accordance with the operating
manual.
User modification and or repair are dangerous and will void the warranty and exclude the
manufacturer from any liability. If serious faults occur, stop using the device. Secure the device
against inadvertent operation. In the event of repairs, return the device to your local
Pepperl+Fuchs representative or sales office.
The connection of the device and maintenance work when live may only be carried out by a
qualified electrical specialist.
The operating company bears responsibility for observing locally applicable safety regulations.
Store the not used device in the original packaging. This offers the device optimal protection
against impact and moisture.
Ensure that the ambient conditions comply with regulations.
Note!
Disposal
Electronic waste is hazardous waste. When disposing of the equipment, observe the current
statutory requirements in the respective country of use, as well as local regulations.

IUH-F190-V1-*
Product Description
2014-11
11
4ProductDescription
4.1 RFID Frequency Bands
The following diagram shows the position of the different frequency bands used for RFID. The
IUH-F190-V1-* read/write heads described in this manual operate in the frequency range from
865 MHz ... 868 MHz and from 902 MHz ... 928 MHz, highlighted in color.
■100 kHz ... 135 kHz: Low frequency LF
■13.56 MHz: High frequency HF
■865 MHz ... 868 MHz (Europe), 902 MHz ... 928 MHz (USA), 920 MHz ... 925 MHz
(China): ultra-high frequency UHF
■2.45 GHz and 5.8 GHz: Microwave MW
4.2 UHF general
4.2.1 Advantages of UHF
■Long detection range
■UHF tags are available as cheap and space-saving adhesive labels
■High transfer rates
■Tag is available with a large working memory (user memory)
■Bulk detection
4.2.2 Applications for UHF systems
■Identification in galvanic coating or painting systems used in automotive production,
■Identification feasible over greater distances than with LF and HF systems,
■Identification of automotive superstructures in automotive production,
■Pallet identification and measurement of goods movements in the logistics sector, and
■Access control at unloading stations with HGV identification.
Frequency
[MhZ]
125 kHz
2,45 GHz
13,56 MHz
5,8 GHz
868/915 MHz
0,1
LF
110
HF
100 1000
UHF
10000
MW
IUH-F190-V1-*

2014-11
12
IUH-F190-V1-*
Product Description
4.2.3 Memory Structure of a Tag in Accordance with EPC Gen 2 (ISO/IEC
18000-63)
Figure 4.1
The memory module of an EPC Gen 2 (ISO/IEC 18000-63) tag is split into four segments. The
main contents of these segments are:
Segment Function Length
Bank 00
(00bin = 0dec)
Password
management
Depending on the tag type, see table "Tag Types, UHF"
on page 48/column "Bank 00"
Bank 01
(01bin = 1dec)
Unique Item Identifier
(UII)
Electronic Product
Code (EPC)
Depending on the tag type, see table "Tag Types, UHF"
on page 48/column "UII/EPC"
Bank 10
(10bin = 2dec)
Tag ID (TID) 4 bytes (MDID, TMN) + 0, 4, or 8 bytes
Bank 11
(11bin = 3dec)
User memory Depending on the tag type, see table "Tag Types, UHF"
on page 48/column "User Data"
USER
TID
UII/EPC
RESERVED
RFU [7:0]
10
h1Fh
.
.
.
MSB LSB
DSFID [7:0]
00
h0Fh
TID [15:0]
10
h1Fh
.
.
.
MSB LSB
TID [31:16]
00
h0Fh
UII/EPC [N:N-15]
20
h
210h
2Fh
.
.
.
MSB LSB
PC [15:0]
10
h1Fh
UII/EPC [15:0]
CRC-16 [15:0]
00
h0Fh
Access Password [15:0]
30
h3Fh
.
.
.
MSB LSB
Access Password [31:16]
20
h2Fh
Kill Password [15:0]
10
h1Fh
Kill Password [31:16]
00
h0Fh
Bank 11
Bank 10
Bank 01
Bank 00
SR/ER
SW/EW
SS/ES
SP/EP
SF/EF
.
.
.
Optional XPC_W2 [15:0]
Optional XPC_W2 [15:0]
.
.
.
220
h
21Fh
22Fh
Memory module
Commands
Read / write head

IUH-F190-V1-*
Product Description
2014-11
13
Bank 00: Password Management
The segment Bank 00 contains the password management information, comprising the
access password and the kill password. The read/write head manages the kill password with
the standard read/write commands SW and SR. The access password is not supported. See
"Single Read Words SR" on page 42, see "Single Write Words SW" on page 43, and see
"Memory Module for Tag Accesses to the "Memory Bank" MB" on page 52.
Bank 01: UII/EPC
In addition to the Unique Item Identifier (UII), the segment Bank 01 contains a calculated
checksum CRC (Cyclic Redundancy Check) for verifying data on the tag and the protocol
control (PC) area. The PC area contains:
■The length of the UII
■The Application Family Identifier (AFI) box
■A bit switch that shows whether the UII contains an EPC sequence of numbers in
accordance with ISO (see chapter 4.2.4)
■A bit switch that shows whether data is stored in segment bank 11 (if present)
The data is addressed via the following commands: single read special read-only code (SS),
single write special read-only code (SP), and enhanced read special read-only code (ES). See
"Single Read Special Read-Only Code SS" on page 40, see "Single Write Special Read-Only
Code SP" on page 41, and see "Enhanced Read Special Read-Only Code ES" on page 41.
Bank 10: TID
The segment Bank 10 contains the tag identifier (TID), consisting of the part number and
optional serial number of the tag. This data is permanently stored without being changed. The
first byte denotes the class of the tag with E0hex, E2hex, or E3hex. The rest of the TID depends
on the class, and can be derived from standard ISO/IEC 18000-63.
Example:
All tags with the class EPC Gen 2 (ISO/IEC 18000-63) are marked with E2hex. The TID is
comprised as follows:
■4 bytes: part number of the tag
• 1 byte: identifier
• 12 bits: tag mask designer identifier (MDID)
• 12 bits: tag model number (TMN), defined by the manufacturer:
■4 or 8 bytes: serial number of the tag
Depending on the manufacturer, the serial numbers do not have to be unique or may even
be omitted.
The data in segment Bank 10 can be output via the single read read-only code (SF) and
enhanced read read-only code (EF) commands. (see "Single Read Read-Only Code SF" on
page 40 and see "Enhanced Read Read-Only Code EF" on page 40)
Bank 11: User Memory
Segment Bank 11 contains an area to which the user has free access. This size of this area
depends on the chip type, or the area may not be present.
The data in segment Bank 11 is addressed via the single read words (SR), single write words
(SW), enhanced read words (ER), and enhanced write words (EW) commands. (see "Single
Read Words SR" on page 42, see "Single Write Words SW" on page 43, see "Enhanced Read
Words ER" on page 42, and see "Enhanced Write Words EW" on page 43)

2014-11
14
IUH-F190-V1-*
Product Description
4.2.4 Electronic Product Code (EPC)
The electronic product code is a unique identifier in the form of a sequence of numbers. The
number sequence has a set structure and a length of 64 bits, 80 bits, 96 bits, or longer
(depending on the EPC Ident number used). This number sequence is saved to the RFID tag,
offering worldwide unique identification of the tagged object.
The system of Electronic Product Codes (EPC) was defined by GS1/EPCglobal for use in
inventory management. Tags with memory banks for EPC codes must be programmed by the
user. The memory of new tags must not contain any valid EPC codes. The EPC numbers are
managed and assigned by GS1. To obtain EPC numbers, please contact the GS1 branch in
your country (http://www.gs1.com/contact).
The electronic product code is defined by EPCglobal with at present 13 different encryptions.
SGTIN-96 (serialized global trade item number) is given here as an example of a frequently
used encryption. SGTIN-96 has a defined format, and is structured as follows:
1. Header: The header specifies the EPC standard used, and denotes the number se-
quence.
2. Filter value: Denotes the unit of the product, for example, end product, additional pack-
aging, pallet.
3. Partition: Denotes the point at which the following company prefix ends and the object
data begins.
4. Company Prefix: Assigned sequence of numbers that identifies the producer.
5. Object class: Sequence of numbers that describes the object, e.g., item number.
The company prefix and the object class are each of variable length, but together are al-
ways 44 bits long.
6. Serial number: Sequence of numbers that identifies the item, for example, the sequential
serial number of the item.
To work with unique number sequences without having to use sometimes expensive EPC
codes, we recommend using the TID of the tag, which is programmed into the tag chips by the
semiconductor manufacturer.
4.2.5 Influence of various materials on the sensing range
In the UHF range, the nature of the surrounding area and the surface to which the transponder
is secured have a serious influence on the range that the system can attain. The UHF
transponder cannot be mounted on metal without requiring adaptations. Glass has a negative
influence on the sensing range when used as a mounting surface. If a UHF transponder is
mounted on damp material, the sensing range is much poorer than the range of a transponder
mounted on dry material. The mounting surface often affects the read range much more than
the material between the transponder and the read/write head. The graph shows the effect of
different materials on the sensing range.
8 Bit 3 Bit 3 Bit 20 - 40 Bit 4 - 24 Bit 38 Bit
5
dez
0
dez
48
dez
4050143
dez
203886
dez
124
dez
Header Filter value Partition Company Prefix Object class Serial number
Length
Value

IUH-F190-V1-*
Product Description
2014-11
15
4.2.6 Dense Reader Mode (DRM)
Europe
A special operating mode for read/write tags in accordance with the specification EPC Gen 2
(ISO/IEC 18000-63) allows several read/write heads to be operated close to each other
simultaneously without interference.
In accordance with EN 302208, the read/write head uses only channels 4, 7, 10, and 13 in this
mode for transmission (read/write head read/write tag communication path). The
transmission power is a maximum of 2 Werp in accordance with EN 302208.
Figure 4.2
The response from the read/write tag appears via the frequency offset, which is achieved by
the modulation used in this mode on the two adjacent channels. Due to the high level
difference between the transmission channels and the response channels, this technology
offers major benefits for reusing frequencies.
0 %
10 %
20 %
30 %
40 %
50 %
60 %
70 %
80 %
90 %
100 %
Material
underground
Material between transponder and
read / write head
Foam material
Film
Cardboard (dry)
Cardboard (wet)
Wood (dry)
Glass
Metal
Ai
r
Fi
lm
Car
db
oard (dr
y
)
C
ardboard (wet)
Wood (dr
y
)
Foam m
a
teri
a
l
Glas
s
Me
t
a
l
Werp
2.0
865.0 868.0865.7 867.5 MHz
123456789101112131415 Channel
866.9866.3

2014-11
16
IUH-F190-V1-*
Product Description
4.2.7 Frequency Hopping Spread Spectrum
With FHSS (Frequency Hopping Spread Spectrum), the information to be transmitted is
distributed successively through multiple channels. Only one frequency channel is used at any
one time. This results in a larger bandwidth for the entire signal, in spite of the fact that each
channel has a smaller bandwidth. The following sections set out some examples with various
parameters. Different parameterizations apply in other countries.
China
In China, 920 MHz ... 925 MHz is one of the frequency ranges available for UHF-RFID readers.
The range is split into channels, each with a bandwidth of 250 kHz. A maximum of 2 WERP is
permitted on 16 of the available channels. The transmission power is indicated in WERP
. FHSS
is used with a maximum retention time of 2 seconds. The IUH-F190-V1-FR2 uses channel 2 to
17.
Figure 4.3
United States
The ISM band from 902 MHz ... 928 MHz is available in the USA. The band is split into 50
channels, each with a 500 kHz bandwidth. FHSS with a maximum retention time of 0.4
seconds is used. All channels must be used. Channel restriction is not permitted.
In contrast to the read/write heads for Europe and China, the transmission power is indicated in
Weirp. A maximum of 4 Weirp is permitted on all channels.
Figure 4.4
4.2.8 Relevant Standards for UHF
European radio standards: EN 300220 and EN 302208
Usage recommendations for RFID type labels, information about recycling, installation of
readers and antennae: ISO/IEC TR 24729 parts 1-4
Installation and commissioning of UHF-RFID systems: ETSI TR 102436
Description of air interface: EPC Gen 2 (ISO/IEC 18000-63)
Channel
0.1
2.0
920 925920.625 924.375 MHz
Werp
012345678910111213141516171819
0.2
4.0
902.75 927.25MHz
Channel
W
eirp
10 15 2051 30354025 45 50

IUH-F190-V1-*
Product Description
2014-11
17
4.3 Countries of Use
The country identifier also defines the frequency access method used.
Frequency Access Method
■A frequency hopping spread spectrum is used in the United States and China. See
chapter 4.2.7. The number and position of the frequencies is fixed and cannot be
changed by the user. All channels are used.
■A programmable frequency list is used in other countries, including the European Union,
Singapore, Vietnam, and India. You can compile this frequency list from a specified set of
channels. Four channels are specified in the European Union as appropriate for dense
reader mode in accordance with EN 302208. See chapter 4.2.6. When selecting this
country identifier, you can configure one or more channels, or all four channels.
4.3.1 European Union
In the European Union, the use of RFID in the UHF range is regulated by EN 302208.
■UHF wavelength: 865 MHz …868 MHz
■Radiated power: 30 mW …300 mWERP; Default = 50 mWERP (IUH-F190-V1-FR1)
Radiated power: 20 mW …200 mWERP; Default = 50 mWERP (IUH-F190-V1-EU)
■Channel bandwidth: 200 kHz
■Channel spacing: 600 kHz
■Frequency access method: programmable frequency list
■Number of predefined channels: 4
Programmable channels: 4, 7, 10, 13
Center frequencies: 865.7 MHz, 866.3 MHz, 866.9 MHz, 867.5 MHz
Up to 4 channels can be parameterized and used in sequence.
Default: dense reader mode on channel 4, 10, 7, 13. See chapter 4.2.6.
4.3.2 Argentina
The regulations for the UHF frequency range in Argentina are the same as the regulations for
the UHF frequency range in the USA. See chapter 4.3.18.
4.3.3 Australia
In Australia, the use of RFID in the UHF range is regulated as follows:
■UHF wavelength: 920 MHz ... 926 MHz
■Radiated power: 50 mW …500 mWEIRP; Default = 125 mWEIRP (IUH-F190-V1-FR2)
■Channel bandwidth: 500 kHz
■Channel spacing: 500 kHz
■Frequency access method: frequency hopping spread spectrum. See chapter 4.2.7.
Note!
Country Identifier
All IUH-F190-V1-* read/write heads operate within their maximum frequency range with the
appropriate settings for the relevant country. You must set the correct country identifier when
commissioning for the first time. See chapter 6.2.
Note!
If you wish to use the IUH-F190-V1-* read/write head in a country not included in this chapter,
make sure the relevant values for the read/write head are consistent with the local conditions
before use.

2014-11
18
IUH-F190-V1-*
Product Description
■Number of channels: 12
Channels used: 1, 2, 3, ... 12
Center frequencies: 919.75 MHz + (M x 0.5) MHz
All 12 channels are always used.
4.3.4 Brazil
In Brazil, the use of RFID in the UHF range is regulated as follows:
■UHF wavelength: 915 MHz …928 MHz
■Radiated power: 50 mW …500 mWEIRP; Default = 125 mWEIRP (IUH-F190-V1-FR2)
■Channel bandwidth: 250 kHz
■Channel spacing: 250 kHz
■Frequency access method: frequency hopping spread spectrum. See chapter 4.2.7.
■Number of channels: 52
Channels used: 1, 2, 3, ... 52
Center frequencies: 914.825 MHz + (M x 0.25) MHz
All 52 channels are always used.
4.3.5 Canada
The regulations for the UHF frequency range in Canada meet the requirements for the UHF
frequency range in the U.S.. See chapter 4.3.18.
4.3.6 China
In China, the use of RFID in the UHF range is regulated by the provisions of the China Ministry
of Industry and Information Technology (CMIIT).
■UHF wavelength: 920 MHz ... 925 MHz
■Radiated power: 30 mW …300 mWERP; Default = 80 mWERP (IUH-F190-V1-FR2)
■Channel bandwidth: 250 kHz
■Channel spacing: 250 kHz
■Frequency access method: frequency hopping spread spectrum (China). See chapter
4.2.7.
■Number of channels: 16
Channels used: 2, 3, 4, ... 17
Center frequencies: 920.125 MHz + (M x 0.25) MHz
All 16 channels are always used.
4.3.7 Hong Kong
The regulations for the UHF frequency range of 865 MHz to 868 MHz in Hong Kong are the
same as the regulations for the UHF frequency range in the European Union. See chapter
4.3.1.
The regulations for the UHF frequency range of 920 MHz to 925 MHz in Hong Kong are the
same as the regulations for the UHF frequency range in Thailand. See chapter 4.3.17.

IUH-F190-V1-*
Product Description
2014-11
19
4.3.8 India
In India, the use of RFID in the UHF range is regulated in accordance with EN 302208.
■UHF wavelength: 865 MHz …867 MHz
■Radiated power: 30 mW …300 mWERP; Default = 50 mWERP (IUH-F190-V1-FR1)
Radiated power: 20 mW …200 mWERP; Default = 50 mWERP (IUH-F190-V1-EU)
■Channel bandwidth: 200 kHz
■Channel spacing: 200 kHz
■Frequency access method: programmable frequency list
■Number of predefined channels: 10
Programmable channels: 1, 2, 3, ... 10
Center frequencies: 865.1 MHz, 865.3 MHz, 865.5 MHz, 865.7 MHz, 865.9 MHz, 866.1
MHz, 866.3 MHz, 866.5 MHz, 866.7 MHz, 866.9 MHz
Up to 10 channels can be parameterized and used in sequence.
Default: dense reader mode on channel 1, 7, 4, 10. See chapter 4.2.6.
4.3.9 Japan
In Japan, the use of RFID in the UHF range is regulated as follows:
■UHF wavelength: 916.7 MHz …920.5 MHz
■Radiated power: 50 mW …500 mWEIRP; Default = 125 mWEIRP (IUH-F190-V1-FR2)
■Channel bandwidth: 200 kHz
■Channel spacing: 1200 kHz
■Frequency access method: programmable frequency list.
■Number of predefined channels: 4
Programmable channels: 5, 11, 17, 23
Center frequencies: 916.8 MHz, 918.0 MHz, 919.2 MHz, 920.4 MHz
Up to 4 channels can be parameterized and used in sequence.
Default: dense reader mode on channel 5, 17, 11, 23. See chapter 4.2.6.
4.3.10 Colombia
The regulations for the UHF frequency range in Colombia are the same as the regulations for
the UHF frequency range in the USA. See chapter 4.3.18.
4.3.11 Malaysia
In Malaysia, the use of RFID in the UHF range is regulated as follows:
■UHF wavelength: 919 MHz …923 MHz
■Radiated power: 30 mW …300 mWERP; Default = 80 mWERP (IUH-F190-V1-FR2)
■Channel bandwidth: 500 kHz
■Channel spacing: 500 kHz
■Frequency access method: frequency hopping spread spectrum. See chapter 4.2.7.

2014-11
20
IUH-F190-V1-*
Product Description
■Number of channels: 8
Channels used: 1, 2, 3, ... 8
Center frequencies: 918.75 MHz + (M x 0.5) MHz
All 8 channels are always used.
4.3.12 Mexico
The regulations for the UHF frequency range in Mexico meet the requirements for the UHF
frequency range in the U.S.. See chapter 4.3.18.
4.3.13 New Zealand
In New Zealand, the use of RFID in the UHF range is regulated as follows:
■UHF wavelength: 921.5 MHz …928 MHz
■Radiated power: 50 mW …500 mWEIRP; Default = 125 mWEIRP (IUH-F190-V1-FR2)
■Channel bandwidth: 500 kHz
■Channel spacing: 500 kHz
■Frequency access method: frequency hopping spread spectrum. See chapter 4.2.7.
■Number of channels: 13
Channels used: 1, 2, 3, ... 13
Center frequencies: 921.25 MHz + (M x 0.5) MHz
All 13 channels are always used.
4.3.14 Russia
In Russia, the use of RFID in the UHF range is regulated in accordance with EN 302208:
■UHF wavelength: 866 MHz …867.6 MHz
■Radiated power: 30 mW …300 mWERP; Default = 50 mWERP (IUH-F190-V1-FR1)
Radiated power: 20 mW …200 mWERP; Default = 50 mWERP (IUH-F190-V1-EU)
■Channel bandwidth: 200 kHz
■Channel spacing: 200 kHz
■Frequency access method: programmable frequency list.
■Number of predefined channels: 8
Programmable channels: 1, 2, 3, ... 8
Center frequencies: 866.1 MHz, 866.3 MHz, 866.5 MHz, 866.7 MHz, 866.9 MHz,
867.1 MHz, 867.3 MHz, 867.5 MHz
Up to 8 channels can be parameterized and used in sequence.
Default: dense reader mode on channel 1, 7, 4. See chapter 4.2.6.
4.3.15 Singapore
In Singapore, the use of RFID in the UHF range of 866 MHz to 868 MHz is regulated in
accordance with EN 302208.
■UHF wavelength: 866 MHz …868 MHz
■Radiated power: 30 mW …300 mWERP; Default = 50 mWERP (IUH-F190-V1-FR1)
Radiated power: 20 mW …200 mWERP; Default = 50 mWERP (IUH-F190-V1-EU)
■Channel bandwidth: 200 kHz
