PerfecTron OXY5362A User manual

Version 1.4
OXY5362A
3.5" SBC with Intel® Kabylake-U SoC
www.perfectron.com

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
1
Safety Information
Electrical safety
 To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the
system.
 When adding or removing devices to or from the system, ensure that the power cables for the devices are
unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing
system before you add a device.
 Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.
 Seek professional assistance before using an adapter or extension cord. These devices could interrupt the
grounding circuit.
 Make sure that your power supply is set to the correct voltage in your area.
 If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.
 If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your local
distributor.
Operation safety
 Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the
package.
 Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If
you detect any damage, contact your dealer immediately.
 To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.
 Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become
wet.
 Place the product on a stable surface.
 If you encounter any technical problems with the product, contact your local distributor
Statement
 All rights reserved. No part of this publication may be reproduced in any form or by any means, without prior
written permission from the publisher.
 All trademarks are the properties of the respective owners.
 All product specifications are subject to change without prior notice

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
2
Revision History
Revision
Date (dd.mm.yyyy)
Changes
Version
0
.
9
01.06
.201
7
Draft
Version
1.0
13.06
.201
7
Initial Release
Version
1.1
15.06
.201
7
Update latest product photo
Change JP13.JP14,JP15 default setting
Change LVDS and CN18 pin define.
Version
1.2
20.06.2017
Change LPC pin define
Version
1.3
02.12.2020
Add LVDS VDD JP24 pin define
Version
1.4
07
.
10
.2021
Add SATA Power J6 & ATX Power CN11 pin define
Packing list
□ OXY5362A 3.5” SBC
□ CD (Driver + user's manual)
□ Optional Accessories
 Cable kit
• SATA cable
• SATA power cable
• USB cable
• COM cable
 Thermal kit:
• Copper heat spreader
• Passive heatsink
If any of the above items is damaged or missing, please contact your local distributor.

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
3
Table of Contents
Safety Information ............................................................................................................................................................. 1
Electrical safety ............................................................................................................................................................... 1
Operation safety .............................................................................................................................................................. 1
Statement ........................................................................................................................................................................ 1
Revision History ................................................................................................................................................................ 2
Packing list ........................................................................................................................................................................ 2
Chapter 1: Product Information ....................................................................................................................................... 5
1.1 Block Diagram ........................................................................................................................................................... 5
1.2 Key Features ............................................................................................................................................................. 6
1.3 Board Placement ...................................................................................................................................................... 7
Chapter 2: Jumpers and Connectors .............................................................................................................................. 8
2.1 Onboard connector and jumper list........................................................................................................................... 8
2.2 Connector and jumper pin definition ......................................................................................................................... 9
2.2.1 Jumper ................................................................................................................................................................... 9
JP1: Clear CMOS ....................................................................................................................................................... 9
JP2: COM1 RI/+5V/+12V ........................................................................................................................................... 9
JP13: AT/ATX Mode ................................................................................................................................................... 9
JP14: mPCIe1 signal select........................................................................................................................................ 9
JP15: mPCIe2 signal select...................................................................................................................................... 10
JP24 LVDS Signal Power ......................................................................................................................................... 10
SW1: LVDS Resolution ............................................................................................................................................ 10
2.2.2 Connector ............................................................................................................................................................ 10
LVDS ........................................................................................................................................................................ 10
CN11: ATX Power .................................................................................................................................................... 11
CN18: LVDS Control connector .............................................................................................................................. 11
J1: DIO .......................................................................................................................................................................... 11
J6: SATA Power ............................................................................................................................................................ 12
J9: Front Panel .............................................................................................................................................................. 12
J10: LPC ....................................................................................................................................................................... 12
J11: Audio ..................................................................................................................................................................... 12
J12: COM2 RS232/422/485 .......................................................................................................................................... 12
J14: USB2.0 x2 ............................................................................................................................................................. 13
Chapter 3: Quick Installation Guide .............................................................................................................................. 14
Chapter 4: AMI BIOS UTILITY ........................................................................................................................................ 14
4.1 Starting .................................................................................................................................................................... 15
4.2 Navigation Keys ...................................................................................................................................................... 15
4.3 Main Menu .............................................................................................................................................................. 16
4.4 Advanced Menu ...................................................................................................................................................... 16

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
4
4.4.1 Trust Computing .................................................................................................................................................. 17
4.4.2 IT8786 Super IO Configuration ............................................................................................................................ 18
4.4.2.1 Serial Port 1 Configuration ........................................................................................................................... 18
4.4.2.2 Serial Port 2 Configuration ........................................................................................................................... 19
4.4.3 Hardware Monitor ................................................................................................................................................ 20
4.4.4 CPU Configuration ............................................................................................................................................... 20
4.4.5 SATA Configuration ............................................................................................................................................. 21
4.4.6 CMS Configuration .............................................................................................................................................. 22
4.4.7 USB Configuration ............................................................................................................................................... 22
4.5 Chipset .................................................................................................................................................................... 22
4.5.1 System Agent (SA) Configuration ........................................................................................................................ 23
4.5.1.1 Graphic Configuration .................................................................................................................................. 24
4.5.1.1.1 LCD Control ............................................................................................................................................... 24
4.5.1.2 Memory Configuration .................................................................................................................................. 25
4.5.2 PCH-IO Configuration .......................................................................................................................................... 25
4.6 Security ................................................................................................................................................................... 26
4.7 Boot Menu ............................................................................................................................................................... 27
4.8 Save & Exit ............................................................................................................................................................. 27

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
5
Chapter 1: Product Information
1.1 Block Diagram

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
6
1.2 Key Features
Processor & System
CPU Type
Intel® Kabylake
-
U series, BGA type
Intel® Core™ i7-7600U Processor (4M Cache, up to 3.9GHz)
Intel® Core™ i5-7300U Processor (3M Cache, up to 3.5GHz)
Intel® Core™ i3-7100U Processor (3M Cache, 2.4GHz)
Memory Type
2
x SO
-
DIMM DDR
4
2133
MHz up to
32
GB
BIOS
AMI® UEFI BIOS
Super I/O
Fintek F8
786E
Watchdog
1
-
255 sec.
Expansion Slot
1 x
Full
-
size
mPCIe
/mSATA
1 x Half-size mPCIe/mSATA
Display
Chipset
Intel®
Integrated
DisplayPort
Max. resolution
4096
x
2304
LVDS
Dual channel 24
-
bit LVDS
Display Type
DisplayPort,
LVDS
Audio
Codec
Realtek ALC88
8
High De
fi
nition Audio Codec
Ethernet
Chipset
Intel®
I210
-
IT + I219
-
LM
WOL
Yes
Boot from LAN
Yes for PXE
Rear I/O
DisplayPort
2 x DisplayPort
Ethernet
2 x RJ45
USB
4
x USB 3.0
COM
1 x RS232
Internal I/O
SATA
1
x SATAIII (6 Gb/s)
USB
2
x USB 2.0
COM
1
x
RS232/422/485
Audio
Mic
-
in, Line
-
out
1 x 3W amplifier (Optional)
FAN
1 x CPU fan
LVDS
3
0
-
pin
connector
DIO
8
-
bit
Mechanical and Environment
Form Factor
3.5" SBC
Power Type
9~36
V DC
-
in, 4
-
pin ATX power connector, AT/ATX mode support
Dimension
146 x 101mm (5.7" x 4")
Operating Temp.
-
2
0
to
85
°C
Storage Temp
-
40
to 8
5
°C
Relative Humidity
10% to 90%, non
-
condensing
*All specifications and photos are subject to change without notice.

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
7
1.3 Board Placement
24
JP1
CN11

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
8
Chapter 2: Jumpers and Connectors
2.1 Onboard connector and jumper list
Label Function
COM1 (Rear) RS232, DB9 connector
DP1 (Rear) DisplayPort
DP2 (Rear) DisplayPort
LAN1 (Rear) RJ45 connector
LAN2 (Rear) RJ45 connector
USB1/2 (Rear) 2 x USB3.0
USB3/4 (Rear) 2 x USB3.0
MPCIE1 Full-size mPCIe/mSATA
MPCIE2 Half-size mPCIe/mSATA
LVDS LVDS
CN18 LVDS Control Connector
CN11 ATX Power
J1 DIO header
J5 SATAIII connector
J6 SATA power
J9 Front panel
J10 LPC header
J11 Audio
J12 COM2, RS232/422/485
J13 CPU fan
J14 2 x USB2.0, USB5/6
SW1 LVDS resolution Select
JP1 Clear CMOS
JP2 COM1 RI/+5V/+12V select
JP13 AT/ATX select
JP14 mPCIE1 SATA/PCIe select
JP15 mPCIE2 SATA/PCIe select
JP24 LVDS Signal Power

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
9
2.2 Connector and jumper pin definition
2.2.1 Jumper
JP1: Clear CMOS
Jumper
Function
description
Setting
1-2 Normal
2-3 Clear CMOS
Default
setting:
1
-
2
JP2: COM1 RI/+5V/+12V
JP13: AT/ATX Mode
Jumper
Function
description
Setting
1-2 ATX
2-3 AT
Default
setting:
2
-
3
JP14: mPCIe1 signal select
Jumper
Function
description
Setting
1-2 SATA
2-3 PCIe
Default
setting:
2
-
3
Jumper
Function
description
Setting
1-2 Ring
3-4 5V
5-6 12V
Default
setting:
1
-
2

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
10
JP15: mPCIe2 signal select
Jumper
Function
description
Setting
1-2 SATA
2-3 PCIe
Default
setting:
2
-
3
JP24 LVDS Signal Power
1-2 5V
2-3 3V3
SW1: LVDS Resolution
Resolution Color
depth Channel
Setting
Drawing
Switch
1
Switch2
Switch
3
Switch
4
800 x 600 18-bit Single On On On On
Off On
1024 x 768 18-bit Single Off On On On
1024 x 768 24-bit Single On Off On On
1280 x 800 18-bit Single Off Off On On
1280 x 1024 24-bit Dual On On Off On
1366 x 768 24-bit Single Off On Off On
1440 x 900 24-bit Dual On Off Off On
1920 x 1080 24-bit Dual Off Off Off On
2.2.2 Connector
LVDS
Pin
Definition
Pin
Definition
2 30
1 29
1
LVDS_CLK+
2
GND
3
LVDS_CLK
-
4
LVDSA3+
5
GND
6
LVDSA3
-
7
LVDSB3+
8
GND
9
LVDSB3
-
10
LVDSA_CLK+
11
LVDSB2+
12
LVDSA_CLK
-
13
LVDSB2
-
14
GND
15
LVDSB1+
16
LVDSA2+
17
LVDSB1
-
18
LVDSA2
-
19
LVDSB0+
20
LVDSA1+
21
LVDSB0
-
22
LVDSA1
-
23
GND
24
LVDSA0+

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
11
25
LVDS_SCLK
26
LVDSA0
-
27
LVDS_SDATA
28
GND
29
VDD
30
VDD
CN11: ATX Power
PIN DEFINITION
1 GND
2 GND
3 DC in
4 DC in
CN18: LVDS Control connector
PIN DEFINITION
1 +12V
2 +12V
3 +12V
4 5V
5 5V
6 GND
7 GND
8 Backlight Enable
9 Backlight control
10 GND
J1: DIO
PIN DEFINITION
1 DIO0
2 DIO1
3 DIO2
4 DIO3
5 DIO4
6 DIO5
7 DIO6
8 DIO7
9 3.3V
10 GND

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
12
J6: SATA Power
PIN DEFINITION
1 12V
2 GND
3 GND
4 5V
J9: Front Panel
PIN DEFINITION PIN DEFINITION
1 FP_HDLED+ 2 FP_PLED+
3 SATALED# 4 GND
5 GND 6 EC_PWR_BTN
7 RESET- 8 GND
9
J10: LPC
PIN DEFINITION
1 GND
2 GND
3 +3.3VSB
4 LPC_AD0
5 LPC_AD1
6 LPC_AD2
7 LPC_AD3
8 LPC_FRAME#
9 PLTRST#_BUF1
10 LPC_CLK_1
J11: Audio
PIN DEFINITION
1 GND
2 MIC1_JD
3 MIC1_R
4 MIC1_L
5 FRONT_JD
6 FRONT_R
7 FRONT_L
8 LINE1_JD
9 LINE1_R
10 LINE1_L
J12: COM2 RS232/422/485
Note: RS232/422/485 can be set by BIOS.

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
13
Pin
RS232 mode (Default)
RS422 mode
RS485 mode
1
1
5V
2
GND
GND
GND
3
RI
4
DTR
RX
-
5
CTS
6
TXD
RX+
7
RTS
8
RXD
TX+
DATA
-
9
DSR
10
DCD
TX
-
DATA+
J14: USB2.0 x2
PIN DEFINITION
1 +5V
2 USB5-
3 USB5+
4 GND
5 GND
6 +5V
7 USB6-
8 USB6+
9 GND
10 GND

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
14
Chapter 3: Quick Installation Guide
Chapter 4: AMI BIOS UTILITY
This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI
BIOS setup utility.

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
15
4.1 Starting
To enter the setup screens, perform the following steps:
 Turn on the computer and press the <Del> key immediately.
 After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be accessed from the
main BIOS setup menu, such as the Chipset and Power menus.
4.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be
used at any time during the setup navigation process.
Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys.
Some of the navigation keys may differ from one screen to another.
Left/Right
The Left and Right <Arrow> keys moves the cursor to
select a menu.
Up/Down
The Up and Down <Arrow> keys moves the cursor to select a setup screen
or sub-screen.
+− Plus/Minus
The Plus and Minus <Arrow> keys changes the field value of a particular
setup setting.
F1
The <
F1
> key
offer general help
.
F2
The
<F
3
> key
load previous values.
F
3
The <F
3
> key
load optimized defaults.
F
4
The <F
4
> key saves any changes made and exits the BIOS setup utility.
Esc
The <Esc> key discards any changes made and exits the BIOS setup utility.
Enter
The <Enter> key
displays a sub
-
screen or changes a selected or
highlighted option in each menu.

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
16
4.3 Main Menu
The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.
4.4 Advanced Menu
The Advanced Menu allows you to configure your system for basic operation. Some entries are defaults required by the
system board, while others, if enabled, will improve the performance of your system or let you set some features
according to your preference. Setting incorrect field values may cause the system to malfunction.

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
17
4.4.1 Trust Computing

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
18
4.4.2 IT8786 Super IO Configuration
4.4.2.1 Serial Port 1 Configuration

OXY536
2
A
3.5"
SBC
User’s
Manual
V1.
4
www.perfectron.com
19
4.4.2.2 Serial Port 2 Configuration
