PerfecTron OXY5741A User manual

Version 1.3
OXY5741A
Rugged Open-Standard EBX SBC Expansion,
Extend Temperture -40°C~85°C
www.perfectron.com

www.perfectron.com
1
Safety Information
Electrical safety
 To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before
relocating the system.
 When adding or removing devices to or from the system, ensure that the power cables for the
devices are unplugged before the signal cables are connected. If possible, disconnect all power
cables
from the existing system before you add a device.

Before connecting or removing signal cables from the motherboard, ensure that all power cables
are
unplugged.

Seek professional assistance before using an adapter or extension cord. These devices could
interrupt the grounding circuit.
 Make sure that your power supply is set to the correct voltage in your area.
 If you are not sure about the voltage of the electrical outlet you are using, contact your local
power company.
 If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your local distributor.
Operation safety
 Before installing the motherboard and adding devices on it, carefully read all the manuals that
came with the package.
 Before using the product, make sure all cables are correctly connected and the power cables are not
damaged. If you detect any damage, contact your dealer immediately.

To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets
and
circuitry.
 Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may
become wet.
 Place the product on a stable surface.
 If you encounter any technical problems with the product, contact your local distributor
Statement
 All rights reserved. No part of this publication may be reproduced in any form or by any means,
without prior written permission from the publisher.
 All trademarks are the properties of the respective owners.
 All product specifications are subject to change without prior notice

www.perfectron.com
2
RoHS Compliance
Perfectron RoHS Environmental Policy and Status Update
Perfectron is a global citizen for building the digital infrastructure. We are committed to
providing green products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive
2011/65/EU, to be your trusted green partner and to protect our environment.
In order to meet the RoHS compliant directives, Perfectron has established an engineering and
manufacturing task force to implement the introduction of green products. The task force will ensure that
we follow the standard Perfectron development procedure and that all the new RoHS components and new
manufacturing processes maintain the highest industry quality levels for which Perfectron are renowned.
The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all
designed components will be RoHS compliant

www.perfectron.com
3
Revision History
Revision Date (yyyy/mm/dd) Changes
V1.0 2021/04/22 First release
V1.1 2021/05/27 Add Mechanical Dimensions
V1.2 2021/9/10 Modify DIO Pin Define
V1.3 2021/12/7 Typesetting modification
Packing List
Item Description Q’ty
1 OXY5741A EBX SBC 1
2 CD(Drivier + User’s manual) 1
If any of the above items is damaged or missing, please contact your
local distributor.

www.perfectron.com
4
Table of Contents
Safety Information .............................................................................................................................................................. 1
Electrical safety ................................................................................................................................................................. 1
Operation safety ............................................................................................................................................................... 1
Statement ........................................................................................................................................................................ 1
RoHS Compliance ................................................................................................................................................................ 2
Revision History .................................................................................................................................................................. 3
Packing List ......................................................................................................................................................................... 3
Chapter 1 : Product Introduction ........................................................................................................................................ 6
1.1 Specifications .............................................................................................................................................................. 6
1.2 Block Diagram ............................................................................................................................................................. 9
1.3 Board Placement ....................................................................................................................................................... 10
1.4 Mechanical Dimensions ............................................................................................................................................. 11
Chapter 2 : Jumpers and Connectors Loacation ................................................................................................................ 12
2.1 Jumpers and connectors list ....................................................................................................................................... 12
2.2 Jumper Settings ........................................................................................................................................................ 13
Chapter 3: AMI BIOS UTILITY ............................................................................................................................................. 22
3.1 Starting ..................................................................................................................................................................... 22
3.2 Navigation Keys ......................................................................................................................................................... 23
3.3 Main Menu ................................................................................................................................................................ 24
3.4 Advanced Menu ........................................................................................................................................................ 25
3.4.1 CPU Configuration .................................................................................................................................................. 25
3.4.2 Power & Performance .............................................................................................................................................. 26
3.4.3 PCH-FW Configuration ............................................................................................................................................ 26
3.4.4 Trusted Computing ................................................................................................................................................. 27
3.4.5 ACPI Setting............................................................................................................................................................ 27
3.4.6 IT8786 Super IO Configuration ................................................................................................................................. 28
3.4.7 HardwareMonitor ................................................................................................................................................... 29
3.4.8 USB configuation .................................................................................................................................................... 30
3.4.9 CSM Configuration .................................................................................................................................................. 30
3.4.10 NVMe Configuration.............................................................................................................................................. 31
3.4.11 Network Stack Configuration ................................................................................................................................. 31
3.5 Chipset ..................................................................................................................................................................... 32
3.5.1 SA Configuration..................................................................................................................................................... 32

www.perfectron.com
5
3.5.2 PCH-IO Configuration .............................................................................................................................................. 34
3.6 Security ..................................................................................................................................................................... 34
3.7 Boot .......................................................................................................................................................................... 35
3.8 Save & Exit ................................................................................................................................................................. 36

www.perfectron.com
6
Chapter 1 : Product Introduction
1.1 Specifications
System
CPU
Intel® Core™ i7-9850HE (6 Cores/12 Threads, 9M Cache, up to 4.40 GHz),45W
Intel® Core i7-9850HL (6 Cores/12 Threads, 9M Cache, up to 4.10 GHz), 25W
XEON E-2276ME (6 Cores/12 Threads, 12M Cache, up to 4.50 GHz), 45W
XEON E-2276ML (6 Cores/12 Threads, 12M Cache, up to 4.20 GHz), 25W
Intel® Core™ i5-8400H (6 Cores/12 Threads, 8M Cache, up to 4.20 GHz) TDP: 45W
Memory type 4 x 260 Pin DDR4 2400MHz SO-DIMM (up to 128GB, XEON SKU support ECC)
Chipset CM246
BIOS Code AMI UEFI BIOS
BIOS Flash SPI Flash
Super I/O ITE 8786
TPM TPM2.0(SLB9665)
iAMT iAMT12.0
WatchDog 1-255 sec. or 1-255 min. software programmable and can be generate system
reset
Display
Chipset Intel® UHD Graphics 630
LVDS Dual channel 24-bit LVDS, max resolution up to 1920 x 1080@ 60Hz
Display Port Up to 4096x2304 @ 60Hz
Multi-
Display Triple simultaneous displays with 48-bit LVDS + DP
Audio
Codec ALC888S
Expansion
M.2 1 x M.2(M-key,Type : 2280, SATA/PCIe 3.0x4 NVMe)
mPCIe 2 x Full size (USB / PCIe and 1 x micro SIM Card)
PCIe/104 1 x TYPE2
FPE 1
Ethernet
Chipset Intel®I210 & I219LM GbE LAN(10/100/1000 Mbps support)
WOL Yes
Boot from LAN Yes for PXE

www.perfectron.com
7
Rear I/O
Display Port 2
USB 3.0 4 x USB3.0
LAN 2
Front I/O
LED 6 (HDD, 2 x LAN ACT+LINK) RED/GREEN LED
PW Button 1
USB 2 x USB 3.0
Internal I/O
USB2.0 4
GPIO 1(4in/4out)
SATA 4 (SATAIII (RAID 0,1,5)
SATA Power 4
DP 1
Audio 1 (Line-out /Mic-in)
Serial 2 (RS-232/422/485 autoflow control)
DC connector 1
LVDS Inverter 1
LVDS connector 1
LPC 1
CPU FAN 1
Front Panel Control Power LED, HD LED, Reset, Power Switch, Buzzer
Mechanical and environmental
Form Factor EBX
Dimension 146mm x 243mm
Power Type 12V DC-IN
Power Consumption 180W
Operation
Temperture -40 to 85°C
Storage Temperture -40 to 85°C
Relative Humidity 10% to 90%, non-condensing

www.perfectron.com
8
Standard Compliance
Standart Compliance CE / FCC
Modular Architecture
PCIe/104 Bus PCIe/104 (PCIe v3.0, Type 2) bus – Two Gen3.0 x4 lanes plus quard Gen 3.0x1 lanes Supports integration with stackable PCIe/104 and/or PCI/104-Express I/O cards
PCI-PCIe bridge adapter required to support PCI-104 and/or PC/104-Plus IO cards
FPE
FPE B2B connector to support PCIe Gen3.0 x16 lanes
Use this feature configures the PCI-E port Bifuraction setting for a PCI-E port
Specified by the user. The options are x8x4x4, x8x8 and x16 (SK229)
3 card slots available for PCIe/104 or PCIe adapter cards example :
(1) FPE/PCIe104 to 4 mini SAS connectors (SK229)
(2) Mini SAS to PCIe x16 slot (x8 signal (SK228)
(3) Mini SAS to PCIe x16 slot (x16 signal (SK226/SK230)
(4) Mini SAS to MXM adapter board (SK224)
Mini PCI/e
2 x Full size mini PCIE slot
(1) 1 x slot dedicated for Mini-PCIe card I/O module (i.e. MIL-STD-1553,
ARINC 429, serial, Ethernet, GPS, etc.)
(2) 1 x slot auto-detectable mSATA storage or Mini-PCIe card I/O
(3) 60+ pins available on DTL-38999 for Mini-PCIe I/O signals
M.2 M.2 2280 slot to support PCIe Gen3.0 x4 or NVME SSD storage device by jumper
setting.
Expansion I/O
Support
5 to 6 card slots available for PCIe/104 or PCI/104-Express cards example :
(1) HDSDI/PAL/NTSC H.264 frame grabber (mPCIe by SK401)
(2) H.264 video recorder/network streaming card, (mPCIe by SK401)
(3) MIL-STD-1553 /ARINC429 (mPCIe by SK401)
(4) CAN data-bus module (mPCIe by SK401)
(5) Ethernet NIC / 10GbE LAN switch (SK506 ; SK502 )
Data Storage
4 x SATA controllers for SATA 3.0 and 1 x NVME SSD can support Data Storage
function
(1) SATA LAN 0
(2) SATA LAN 1
(3) SATA LAN 2
(4) SATA LAN 3
(5) M.2 2280 NVME SSD

www.perfectron.com
9
1.2 Block Diagram

www.perfectron.com
10
1.3 Board Placement

www.perfectron.com
11
1.4 Mechanical Dimensions

www.perfectron.com
12
Chapter 2 : Jumpers and Connectors Loacation
2.1 Jumpers and connectors list
Label Function
BAT1 BATTERY connector
CN1 Inverter connector
CN10/CN12/CN14/CN16 SATA Power
CN17 LPC connector (Update BIOS)
CN19 SMBUS
CN2 LVDS Connector
CN6/CN7 USB2.0 (Total 4 Port)
CN8 M.2 M KEY Connector
CN9/CN11/CN13/CN15 Serial SATA Connectors
DC_JACK1 ATX12V DC connector
DIMM0 DDR4 SO DIMM Socket
DIMM1 DDR4 SO DIMM Socket
DIMM2 DDR4 SO DIMM Socket
DIMM3 DDR4 SO DIMM Socket
DP3 DISPLAY PORT HEADER
FP1 Front Panel
FPE1 FPE Top connector
J1 Front side MIC-In/ Line-Out Connector
J2 Digital I/O Box Head
J3 RS232/422/485 with 5V/12V selectable
J4 RS232/422/485 with 5V/12V selectable
J5 System Fan connector
JCMOS1 ME Flash Security
JCMOS2 RTC Reset
JM2 M.2 Signal select
JP1 LVDS_VDD select
JP3 COM1 +12/+5V selection
JP4 COM2 +12/+5V selection
JP5 AT/ATX Mode
LED2 LAN1 LED STATUS
LED3 LAN2 LED STATUS
LED4 Power/HDD LED
MCARD1 Mini PCIE Card Slot<Full size Co-lay mSATA>
MCARD2 Mini PCIE Card Slot<Full size Co-lay mSATA>
SIM_CARD1 SIM card socket

www.perfectron.com
13
STACKPC1 PCIe/104 connector
SW1 LVDS Resolution selection
SW2 Power Button
SW3 PCIE CFG[5:6]
2.2 Jumper Settings
CN1: Inverter connector
PIN
DEFINITION
1
12V
2
12V
3
12V
4
5VS
5
5VS
6
GND
7
GND
8
BL
_
EN
9
LVDS_BKL_CTRL
10
GND
CN2: LVDS Connector
PIN
DEFINITION
PIN
DEFINITION
1
LVDS_BCLK
2
GND
3
LVDS_BCLK#
4
LVDS_A3
5
GND
6
LVDS_A3#
7
LVDS_B3
8
GND
9
LVDS_B3#
10
LVDS_ACLK
11
LVDS_B2
12
LVDS_ ACLK #
13
LVDS_B2#
14
GND
15
LVDS_B1
16
LVDS_A2
17
LVDS_B1#
18
LVDS_A2#
19
LVDS_B0
20
LVDS_A1
21
LVDS_B0#
22
LVDS_A1#
23
GND
24
LVDS_A0
25
LVDS_DCC_SC
26
LVDS_A0#
27
LVDS_DCC_SD
28
GND
29
+VDD_LVDS
30
+VDD_LVDS
CN7: USB2.0 Pin Header
PIN
DEFINITION
1
+USB2_VCC7
2
USB2_N7_C
3
USB2_P7_C
4
GND
5
GND
6
+USB2_VCC8
7
USB2_N8_C
8
USB2_P8_C
9
GND
10
GND

www.perfectron.com
14
CN7: USB2.0 Pin Header
PIN
DEFINITION
1
+USB2_VCC9
2
USB2_N9_C
3
USB2_P9_C
4
GND
5
GND
6
+USB2_VCC10
7
USB2_N10_C
8
USB2_P10_C
9
GND
10
GND
CN9/CN11/CN13/CN15: Serial SATA Connectors
PIN
DEFINITION
1
GND
2
TXP
3
TXN
4
GND
5
RXN
6
RXP
7
GND
CN10/CN12/CN14/CN16: SATA POWER Connector
PIN
DEFINITION
1
12V
2
GND
3
GND
4
5VS
DC_JACK1: DC-IN
PIN DEFINITION PIN DEFINITION
1 GND 2 GND
3 GND 4 GND
5 +12VSB 6 +12VSB
7 +12VSB 8 +12VSB
CN17: LPC connector
PIN
DEFINITION
1
GND
2
INT_SERIRQ
3
3V3
4
LPC_AD0
5
LPC_AD1
6
LPC_AD2
7
LPC_AD3
8
LPC_FRAME#
9
CHIP_PLTRST#
10 C_LPC_CLK_SIO

www.perfectron.com
15
DP3: DISPLAY PORT HEADER
PIN
DEFINITION
PIN
DEFINITION
1
GND
2
GND
3
DDI3_TXP0_DP_C
4
NC
5
DDI3_TXN0_DP_C
6
NC
7
DDI3_TXP1_DP_C
8
NC
9
DDI3_TXN1_DP_C
10
NC
11
DDI3_TXP2_DP_C
12
NC
13
DDI3_TXN2_DP_C
14
NC
15
DDI3_TXP3_DP_C
16
NC
17
DDI3_TXN3_DP_C
18
NC
19
DDI3_AUX_P_C
20
NC
21
DDI3_AUX_N_C
22
NC
23
GND
24
GND
25
DDI3_DDC_AUX_SEL
26
NC
27
DP3_DET
28
NC
29
DP3_PWR
30
NC
31
GND
32
GND
FP1:Front Panel
PIN
DEFINITION
PIN
DEFINITION
1
FP_HDLED+
2
FP_PLED+
3
HDLED
-
4
GND
5
GND
6
PANSWIN#
7
EXT_RESET#
8
GND
9
NC
10
NC

www.perfectron.com
16
FPE1: FPE Top Connector
PIN DEFINITION PIN DEFINITION PIN DEFINITION PIN DEFINITION PIN DEFINITION
1 NC 2 NC 3 GND 4 3V3 5 GND
11 GND 12 NC 13 GND 14 NC 15 GND
21 NC 22 NC 23 NC 24 GND 25 NC
31 NC 32 NC 33 NC 34 NC 35 NC
41 GND 42 NC 43 GND 44 NC 45 GND
51 NC 52 GND 53 NC 54 GND 55 NC
61 NC 62 NC 63 NC 64 NC 65 NC
71 GND 72 NC 73 GND 74 NC 75 GND
81 PEG_TXP0 82 NC 83 PEG_TXP2 84 GND 85 PEG_TXP4
91 PEG_TXN0 92 PEG_TXP1 93 PEG_TXN2 94 PEG_TXP3 95 PEG_TXN4
101 GND 102 PEG_TXN1 103 GND 104 PEG_TXN3 105 GND
111 PEG_RXP_0 112 GND 113 PEG_RXP_2 114 GND 115 PEG_RXP_4
121 PEG_RXN_0 122 PEG_RXP_1 123 PEG_RXN_2 124 PEG_RXP_3 125 PEG_RXN_4
131 GND 132 PEG_RXN_1 133 GND 134 PEG_RXN_3 135 GND
141 PEG_TXP8 142 GND 143 PEG_TXP10 144 GND 145 PEG_TXP12
151 PEG_TXN8 152 PEG_TXP9 153 PEG_TXN10 154 PEG_TXP11 155 PEG_TXN12
161 GND 162 PEG_TXN9 163 GND 164 PEG_TXN11 165 GND
171 PEG_RXP_8 172 GND 173 PEG_RXP_10 174 GND 175 PEG_RXP_12
181 PEG_RXN_8 182 PEG_RXP_9 183 PEG_RXN_10 184 PEG_RXP_11 185 PEG_RXN_12
191 GND 192 PEG_RXN_9 193 GND 194 PEG_RXN_11 195 GND
PIN NAME PIN NAME PIN NAME PIN NAME PIN NAME
6 3V3SB 7 GND 8 5VSB 9 5V 10 +12V
16 NC 17 GND 18 NC 19 5V 20 +12V
26 GND 27 NC 28 GND 29 5V 30 +12V
36 NC 37 NC 38 NC 39 NC 40 +12V
46 NC 47 GND 48 NC 49 GND 50 +12V
56 GND 57 NC 58 GND 59 GND 60 +12V
66 NC 67 NC 68 NC 69 GND 70 +12V
76 NC 77 GND 78 NC 79 GND 80 +12V
86 GND 87 PEG_TXP6 88 GND 89 GND 90 +12V
96 PEG_TXP5 97 PEG_TXN6 98 PEG_TXP7 99 GND 100 NC
106 PEG_TXN5 107 GND 108 PEG_TXN7 109 GND 110 IO_PLTRST#
116 GND 117 PEG_RXP_6 118 GND 119 PEG_A_CLK_P5 120 GND
126 PEG_RXP_5 127 PEG_RXN_6 128 PEG_RXP_7 129 PEG_A_CLK_N5 130 FPE_BUS_ERR#
136 PEG_RXN_5 137 GND 138 PEG_RXN_7 139 GND 140 3V3SB
146 GND 147 PEG_TXP14 148 GND 149 PEG_B_CLK_P6 150 GND
156 PEG_TXP13 157 PEG_TXN14 158 PEG_TXP15 159 PEG_B_CLK_N6 160 GND
166 PEG_TXN13 167 GND 168 PEG_TXN15 169 GND 170 NC
176 GND 177 PEG_RXP_14 178 GND 179 NC 180 +12V
186 PEG_RXP_13 187 PEG_RXN_14 188 PEG_RXP_15 189 3V3 190 +12V
196 PEG_RXN_13 197 GND 198 PEG_RXN_15 199 3V3 200 +12V

www.perfectron.com
17
J1 : Audio Box Head
PIN
DEFINITION
1
GND
2
MIC1_JD
3
MIC1_R
4
MIC1_L
5
FRONT_JD
6
FRONT_R
7
FRONT_L
8
NC
9
NC
10 NC
J2: Digital I/O Box Head
PIN
DEFINITION
1
DIO0(Input)
2
DIO1(Input)
3
DIO2(Input)
4 DIO3(Input)
5
DIO4(Output)
6
DIO5(Output)
7
DIO6(Output)
8
DIO7(Output)
9
3V3
10 GND
J3: RS232/422/485 Box Head
PIN
DEFINITION
1
5V
2
GND
3
COM1P9SEL
4 COM1_DTR-
5
COM1_CTS
-
6
COM1_TXD
-
7
COM1_RTS
-
8
COM1_RXD
-
9
COM1_DSR
-
10 COM1_DCD-

www.perfectron.com
18
J4: RS232/422/485 Box Head
PIN
DEFINITION
1
5V
2 GND
3
COM2P9SEL
4 COM2_DTR-
5
COM2_CTS
-
6
COM2_TXD
-
7
COM2_RTS
-
8
COM2_RXD
-
9
COM2_DSR
-
10 COM2_DCD-
J5: SYSTEM FAN Connector
PIN
DEFINITION
1 SYSTEMFAN_PWN
2 SYSTEMFAN_IO
3
+12V
4
GND
JCMOS1: ME Flash Security
Jumper
Function description
Setting
1-2 ME Lock
2-3 ME Unlock
Default setting: 1
-
2
JCMOS2: RTC Reset
Jumper
Function description
Setting
1-2 Default
2-3 Clear CMOS
Default setting:1
-
2

www.perfectron.com
19
JM2: M.2 Signal select
Jumper
Function description
Setting
1-2 PCIe
2-3 SATA
Default setting:Non
-
Put
JP1: LVDS_VDD select
Jumper
Function description
Setting
1-2 3.3V
2-3 5V
Default setting: 2
-
3
JP3: COM1 5V/12V selection
PIN
DEFINITION
PIN
DEFINITION
1
RI1#_OPTO
2
COM1P9SEL
3
5V
4
COM1P9SEL
5
+12V
6
COM1P9SEL
Default :1-2 short
JP4: COM2 5V/12V selection
PIN
DEFINITION
PIN
DEFINITION
1
RI1#_OPTO
2
COM2P9SEL
3
5V
4
COM2P9SEL
5
12V
6
COM2P9SEL
Default :1-2 short
JP5 : AT/ATX Mode Selection(Default ATX
Jumper
Function description
Setting
Non-Put ATX
1-2 AT
Default
setting: Non
-
Put
