Performance Tool W2007 User manual

OWNER’S MANUAL
Item Number W2007
WARNING
It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and
maintenance instructions contained on the product label and instruction manual prior to
operation of this product. The owner/operator shall retain product instructions for future
reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning
labels and while in use, maintaining the unit in good working order. If the owner and/or operator
are not fluent in English, the product warnings and instructions shall be read and discussed with
the operators’ native language by the purchaser/owner or his designee. Make sure that the
operator comprehends its contents. Safety information shall be emphasized and understood
prior to usage. The product shall be inspected per the operating instructions.
Users of this product must fully understand these instructions. Each person operating this
product must also be of sound mind and body and must not be under the influence of any
substance that might impair their vision, dexterity or judgment.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
45 PC THREADED INSERT RIVET KIT
On occasion, after printing of our literature is completed, our manufacturers may make changes
and/or modifications to merchandise which will not be reflected in this manual. Although we strive
to maintain complete and accurate information, it is possible in some instances, that the product
may differ slightly from printed specifications. Illustrations are intended for reference only. Actual
merchandise may vary. Wilmar is not responsible for typographical errors.
Please read these instructions carefully and retain them for future use.

WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in
electric shock, fire and/or serious personal injury.
Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
Do not operate power tools in potentially explosive environments, such as in the presence of flammable liquids,
gas or dust. Power tools create sparks that may ignite dust or fumes.
Keep bystanders, children and visitors away while operating the tool. Distractions can cause the operator
to lose control.
Stay alert, be aware of the surroundings, and use common sense when operating a power tool. Do not use a power
tool while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating a
power tool may result in serious personal injury.
Dress properly. Do not wear loose clothing or jewelry.
Contain long hair. Keep hair, clothing, and gloves away from moving parts. Loose clothing, jewellery, or long hair
can get caught in moving parts.
Avoid accidental start-ups. Verify that the switch is in the OFF position before plugging in the tool. Carrying a
power tool with a finger on the switch or plugging in a tool that has the switch in the ON position invites accidents.
Remove adjusting keys and wrenches before turning the tool ON. A wrench or key that is left attached to a rotating
part of the tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. Proper footing and balance allows the operator to
maintain better control of the tool in unexpected situations.
Use safety equipment. Always wear eye protection.
Use a dust mask, non-skid safety shoes, a hardhat, or hearing protection when appropriate.
GENERAL SAFETY RULES
PERSONAL SAFETY
2
This nut thread setter kit is a great way to add backless attachment points anywhere you need them with just
a single hole. This kit includes a rugged thread setting tool, along with various sized mandrels and nosepieces,
40 assorted thread nuts, a wrench, and a handy storage case.
1. Drill the recommended diameter hole for the chosen threaded insert into the workpiece.
2. Select the matching mandrel and nose piece from the kit.
3. While the wrench/handle lock is still on (keeping the handle together), screw the mandrel into the head.
Note this is left hand thread.
OPERATION INSTRUCTIONS

3
4. Remove the wrench and tighten the mandrel snug, wrench is designed to prevent over tightening.
5. Screw on the nose piece until snug, it may be easier if you hold the handle together in the closed position.
6. With the handle released screw on the threaded insert flange end first.
7. Set the depth screw to the desired length.
8. Pass the threaded insert threw the hole until flange is flush with work piece.
9. Squeeze the tool handles until the threaded insert is installed firmly by forming a bulge against the back of the
workpiece. You may need to set the depth adjustment screw to achieve this bulge.
10. Release the tool handles fully and turn the mandrel adjusting knob counter clockwise to remove the mandrel
from the threaded insert.
NOTE: A pilot test is always recommended before installing threaded inserts into the workpiece. This is done for
the proper stop position providing the desired bulge in the insert.
11. Fasten your object by screwing a bolt or machine screw to the threaded insert you just installed.
OPERATION INSTRUCTIONS CONT.
LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These
warranties give specific legal rights. Except where prohibited by local law, the law of the State of Washington
governs all warranties and all exclusions and limitations of warranties and remedies. There may be other rights
which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal
use and service. A defective product may be returned for a free replacement within 90 days from the date of
purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90
days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which
our examination shall disclose to be defective and under warranty. These warranties shall be valid only when a sales
receipt showing the date of purchase accompanies the defective product or defective part (s) being returned.
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be
replaced under normal use and service. These warranties shall not apply to any product or part which is used for a
purpose for which it is not designed, or which has been repaired or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to misuse,
neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in
connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no
express or implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes
no implied warranty of merchantability and no implied warranty of fitness for any particular purpose, except that for
goods purchased primarily for personal, family or household use and not for commercial or business use,
PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied
warranty of fitness for a particular purpose), but only for the particular qualities or characteristics, and for the
duration, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations may not apply in
all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any
manner related to any product, or to the design, use, or any inability to use the product. The sole and exclusive
remedy for a defective product or part shall be the repair, or replacement thereof as provided above. The laws on
limitation of remedies or on consequential, incidental or special damages may vary from state to state, so the above
limitations may not apply in all cases.
