Performance Tool W54198 User manual

Capacity:................................................................................................. Bulk - 3 oz. (88.7ml)
........................................................................................................ Cartridge - 3 oz. (88.7ml)
Load Type..................................................................................................................... 2 Way
Develops up to:......................................................................................................10,000 PSI
Delivers:........................................................................................ 1 oz. / 28 Strokes (29.5ml)
Hose / Length: ..................................................................5 in. Rigid / 12 in. Flex 1/8 in. NPT
Capacity:................................................................................................. Bulk - 3 oz. (88.7ml)
........................................................................................................ Cartridge - 3 oz. (88.7ml)
Load Type..................................................................................................................... 2 Way
Develops up to:......................................................................................................10,000 PSI
Delivers:........................................................................................ 1 oz. / 28 Strokes (29.5ml)
Hose / Length: ................................................................................... 5 in. Rigid / 1/8 in. NPT
Capacity:................................................................................................. Bulk - 3 oz. (88.7ml)
........................................................................................................ Cartridge - 3 oz. (88.7ml)
Load Type..................................................................................................................... 2 Way
Develops up to:......................................................................................................10,000 PSI
Delivers:........................................................................................ 1 oz. / 28 Strokes (29.5ml)
Hose / Length: ..........................................................................5 in. Rigid / 12 in. 1/8 in. NPT
NOTE: This is a basic instruction manual which covers various models of grease guns. The illustrations
below may not depict your specic gun exactly.
1. Rotating counter clockwise, unscrew
Head Cap from gun Barrel. (Fig. 1)
NOTE: Because they lack lubrication
on the rubber plunger, new grease
guns may be difcult to load with
grease cartridges the rst time. Apply
a liberal coating of grease to plunger
when using gun for the rst time.
This grease gun requires a 3 oz.
grease cartridge.
2. Draw handle back fully so that the
plunger rod catches and locks into
place. (Fig. 2)
CAUTION: Depressing the lock release when empty causes the handle to snap back quickly.
3. After removing the plastic cap from the grease cartridge,
apply a small amount of grease to the inside edge of the
cartridge. This will make insertion of the plunger easier. (Fig. 3)
4. Push grease cartridge into gun barrel completely, until
metal edge tightly seals on top of the grease gun barrel.
 Detachip-topsealfromcartridge.(Fig.4)
5. Screw on head cap approximately two turns, being sure
not to tighten. Release plunger rod from its locked position
and push in. Push on plunger rod handle to force plunger
into cartridge. At the same time, pump the lever or handle
to release trapped air. When grease comes through vents
and the head of the gun, fully tighten the head cap to the barrel.
6. As soon as the gun is pumping grease, carefully depress the lock release and push plunger rod back
into gun.
Head Cap/
Tapa de
Cabeza
Barrel/Barril
Fig. 1
Plunger
Handle /
Piston
de
Mango
Fig. 2
NOTE: Used cartridges must be removed prior to suction lling.
1. Remove the gun head cap from the barrel.
2. Submerge open end of the barrel into grease bucket. Be sure the plunger handle is depressed
 completely.Graspthebarrelrmlyandpullbackslowlyontheplungerhandle.Besurethemouth
of the barrel is always under the surface so that air is not transferred into the barrel. (Figure 5)
3. Loading is complete when plunger rod is fully extended.
4. Reattach the gun head cap to the barrel. Depress lock release and push the plunger rod back
into the gun.
NOTE: Grease guns may lose their prime on occasion, because of air pockets in the grease. If this
occurs, remove the trapped air by bleeding the head cap and resume pumping.
NOTA: Los cartuchos usados se deben remover antes de llenar a succión.
1. Remueva la tapa de la cabeza de la pistola del barril.
2. Sumerja la parte abierta del barril en el cubo de grasa. Aserurese que el
 mangodelpistonestacompletamentesuelto.Sujeteelbarrilrmemente
y jale despacio el mango del piston. Asegurese que la boca del barril
este siempre sumergida en el cubo para que no pase aire a el barril. (Fig. 5)
3. El relleno se termina cuando la barra del piston esta completamente
extendida.
4. Ponga de nuevo la tapa de la cabeza de la pistola a el barril. Quite el
sujetador del seguro y ponga la barra del piston de nuevo en la pistola.
NOTA: En ocasiones las pistolas de grasa pueden perder su fuerza
debido a bolsas de aire en la grasa, si esto ocurre, remueva el aire
atrapado purgando la tapa de la cabeza y sigua bombeando.
Fig. 5
GREASE CARTRIDGE LOADING
SUCTION FILLING / LLENADO DE SUCCIÓN
SPECIFICATIONS - W54198 CARGA DE CARTUCHO DE GRASA
NOTA: Este es un manual de instruciones basico que cubre varios modelos de pistolas de grasa. Lasi-
lustraciones de abajo puenden no ser exactamente iguales que su pistola especica.
1. Desatornille la tapa del barril de la pistola girando en dirección opuesta a las manecillas del reloj. (Fig. 1)
NOTA: Debido a la escasa lubricacion del piston de goma, puede ser dicil llenar la primera vez de
grasa los cartuchos. Aplique una capa suciente de grasa a el piston cuandose usa la pistola por prim-
era vez. Esta pistola de grasa requiere un cartucho de grasa de 85 g.
2. Jale completamente el mango hacia atras para que la cabeza del piston se asegure en su lugar. (Fig. 2)
PRECAUCÍON: Si se jala el sujetador del seguro al estar vacio, causa que el mango haga repentina-
mente para atras.
3. Despues de remover la tapa de plastico del cartucho de grasa, aplique una pequeña cantidad de
grasa al borde interior del cartucho. (Fig. 3)
4. Empuje el cartucho de grasa hacia el barril completamente, hasta que el metal selle con la parte
superior de la pistola de grasa. Retire le sello de arriba del cartucho. (Fig. 4)
5. Atornille la cabeza de la tapa aproximadamente dos vueltas, asegurandose que no apriete. Saque el
piston de su posición asegurada. Empuje el mango para forzar la cabeza del piston contra el cartucho.
Al mismo tiempo, bombee el mango para liberar el aire. Cuando la grasa salga de los extremos de la
pistola, Apriete la cabeza de la tapa contra al barril.
6. Al momento que la pistola bombee grasa, cuidadosamente jale el sujetador del seguro y empuje la
cabeza del piston de vuelta en la pistola.
Grease Cartridge Plastic Cap/Tapa de plástico
Cartucho de grasa Barrel/Barril
Fig. 3
Flip-top Tab/Tapa Quita-pon
Fig. 4
SPECIFICATIONS - W54200
SPECIFICATIONS - W54205

LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These
warranties give specific legal rights. Except where prohibited by local law, the law of the State of Washington
governs all warranties and all exclusions and limitations of warranties and remedies. There may be other rights
which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal
use and service. A defective product may be returned for a free replacement within 90 days from the date of
purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90
days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which
our examination shall disclose to be defective and under warranty. These warranties shall be valid only when a
sales receipt showing the date of purchase accompanies the defective product or defective part (s) being returned.
For part (s) after 90 days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be
replaced under normal use and service. These warranties shall not apply to any product or part which is used for a
purpose for which it is not designed, or which has been repaired or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to
misuse, neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in
connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no
express or implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes
no implied warranty of merchantability and no implied warranty of fitness for any particular purpose, except that for
goods purchased primarily for personal, family or household use and not for commercial or business use,
PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied
warranty of fitness for a particular purpose), but only for the particular qualities or characteristics, and for the
duration, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations may not apply in
all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any
manner related to any product, or to the design, use, or any inability to use the product. The sole and exclusive
remedy for a defective product or part shall be the repair, or replacement thereof as provided above. The laws on
limitation of remedies or on consequential, incidental or special damages may vary from state to state, so the above
limitations may not apply in all cases.
© Copyright 2021 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
MINI GREASE GUN
Item Number(s): W54198 / W54200 / W54205
This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting
steps described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest
product information available at the time of publication. The manufacturer reserves the right to make product changes at any time
without notice.
SAFETY GUIDELINES / DEFINITIONS
WARNING: Read and understand this entire instruction manual before attempting to assemble, install, operate or maintain
this product. Failure to comply with the instructions may result in serious personal injury and/or property damage!
The following signal words are used to emphasize safety warnings that must be followed when using this product:
DANGER: Indicates an imminently hazardous situation
that, if not avoided, WILL result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
that, if not avoided, COULD result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation
that, if not avoided, MAY result in minor or moderate injury.
NOTICE Indicates important information, which if not
followed, MAY cause damage to equipment.
WARNING!
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO
MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND
WILL VOID WARRANTY.
OWNER’S MANUAL / INSTRUCTIVO
