Performance PL 102GG User manual

KLIX CAM INSTRUCTIONS
Please follow these instructions for easy assembly.
Thank you for purchasing the Performance Desk Shell.
Do not tighten screws/bolts until the unit is completely assembled.
Check to be sure that you have all parts and hardware.
Remove all wrapping materials, including staples & packing straps before you start to assemble.
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
Keep all hardware parts out of reach of children.
being scratched.
IMPORTANT :
Top Panel
A
Back Panel
B
21
Cam Lock
11 Pcs
Klix Cam
11 Pcs
543
Housing
Cap (Long)
4 Pcs
Housing
Cap (Short)
7 Pcs
Adjustable
Glide
4 Pcs
Right Side Panel
D
Left Side Panel
C
6
6 Hole
L-Bracket
5 Pcs
Screw
#6 x 58"
30 Pcs
DESK SHELL
M4 x 65
Allen-Key
1 Pc
7
PL 102GG,PL103GG,PL 105GG
Insert the cam with the arrow
pointing towards the hole in
the edge.
Line up Cam Lock,
turn clockwise.
1 2
Insert the Cam Lock into
Klix Cam. Turn Klix Cam to
lock.
3

Turn Top Panel (A) upside down and insert Cam Lock
pins (1) into top panel and into side panels (C,D).
Insert Klix Cams (2) in Side Panels (C,D) and back
panel (B). Attach Back Panel (B) to side panels (C,D)
and Top Panel (A). Turn Klix Cam to tighten.
X
D
XAAttach those
Back Panel(B)
and left right
Side
Panel(C,D) to
Top Panel as
same as Box 1.
X
2Attach L-Bracket(5) to Top
Panel(A), Back Panel(B) and
Side Panel(C,D) as shown by
tighten Screws(6) securely.
6
X
B
X
5
X
C
Attach Housing Cap(3) to each
Klix Cam(2) by pushing the
neck thought the center of the
Klix Cam.
1
B
TOP D
C
PL 102GG,PL103GG,PL 105GG
Screw Adjustable Glides(4)
into bottom of Side Panel.
4
3
DESK SHELL
4
3
