PerkinElmer S20 Series User manual

S20 Series Autosampler Installation Guide
Unpack and place the autosampler on the bench, as close as
possible to the analytical instrument. To lift, place one hand
under the back of the autosampler. Place the other hand along
the front of the top cover to steady the autosampler. Do not
lift by the removable tray.
Gently tug the front of the removable tray upward to verify
that it is firmly attached to the base of the autosampler.
(Optional) If you need to re-seat the removable tray, lower it
straight down then push it straight back.
Insert the dual rinse station in the holder at the back left
corner of the tray. Press straight down until it is fully seated.
1
2
5
TIP: If you find it difficult
to get a good connection
to the rinse station,
remove the rinse station
and press the tubing firmly
so that it completely covers
the barb of the fitting. It
helps to use your other
hand to apply counter-
pressure.
Connect the RINSE IN
tubing to channels 2 and 3
of the peristaltic pump on
the autosampler (2 mm I.D.
pump tubing).
Connect the WASTE tubing
to channel 1, closest to the
back of the autosampler
(3.2 mm I.D. pump tubing).
Ensure that the drain tubing
is not submerged in the
waste liquid.
A dual-rinse, pumped-drain tubing arrangement is shown. Your application may need a different arrangement—see the User’s Guide .
Carefully press the tubing straight on to the fittings as shown below.
3
4

Install the sample probe: Route the sample tubing through the loop on the Z-drive. Raise the slider on the Z-drive to its highest position
and guide the probe straight down until the tip of the probe is level with the bottom of the Y arm. Tighten the two thumbscrews.
Connect the power supply to the back of the autosampler.
Connect the USB cable between the PC and autosampler.
For ICP-MS with HTS, use a serial cable—see the User’s Guide.
Turn on the autosampler.
Turn the PC off then on to initialize communication.
The autosampler is now ready to use.
See the S20 Autosampler User’s Guide (on the included flash
drive) for safety information, maintenance information, and
detailed instructions.
Consultez le « S20 Autosampler User’s Guide » (présent sur
la clé USB fournie) pour les informations de sécurité, les
informations d’entretien et des instructions détaillées.
S23 autosampler after assembly.
Standard Tubes
Y Arm
Z Drive
Sample Tubing
Sample Probe
Sample Probe Holder
Dual Rinse Station
Sample Tubes
Removable Sample Racks
Removable Tray
Z
Y
X
7
8
9
Part Number 09931598
Release A, February 2020
32-0775-048
Printed in USA
10
Sample Tubing Loop
6
