PerkinElmer Lambda 465 User manual

09931298C
PerkinElmer, 710 Bridgeport Avenue,
Shelton, CT 06484-4794, U.S.A
Produced in the USA.
Lambda 465 Advanced Transmission Holder
Installation Instructions
This instruction sheet describes the installation of this accessory which is used with the Lambda 465
Spectrophotometer.
NOTE:
Read these instructions before you install this accessory.
Contacting PerkinElmer
Supplies, replacement parts, and accessories can be ordered directly from PerkinElmer, using the part
numbers.
See our website:
http://perkinelmer.com
PerkinElmer's catalog service offers a full selection of high-quality supplies.
To place an order for supplies and many replacement parts, request a free catalog, or ask for information:
If you are located within the U.S., call toll free 1-800-762-4000, 8 a.m. to 8 p.m. EST. Your order will be
shipped promptly, usually within 24 hours.
If you are located outside of the U.S., call your local PerkinElmer sales or service office.
Features
•Use for measuring the transmittance of various features of film, glass, and plate, etc.
•User-convenient sampling
•Adjustable fixing arms for the samples with various thickness
•Height controller to meet sample features
•Internal magnet for fixing sample
Figure 1 Lambda 465 Advanced Transmission Holder [P/N: N4104005]

09931298C
2
Dimensions and Specifications
Type Specification
Dimension (mm) 100 (H) X 80 (W) X 150 (L)
Weight (kg) 1.0
Sample Size (mm) Max. Length : 300 x 300
Max. Thickness : 70
Description
Configuration of Advanced Transmission Holder
Figure 2 Lambda 465 Advanced Transmission Holder configuration

09931298C
3
Installation
1. Disassemble the existing cell holder.
Figure 3 Location of screws
2. Install the advanced transmission holder by fastening the knob bolts.
Figure 4 Fastening the bolts
3. Connect the communication cable and the power cord, and then turn on the power of the Lambda
465.

09931298C
4
Sampling
Proper Size Sample
1. Prepare a sample plate.
Figure 5 Preparing a sample plate
2. Open the fixing arm and insert the sample.
Figure 6 Opening the fixing arm

09931298C
5
3. Close the fixing arm to fix the sample.
Figure 7 Closing the fixing arm on the sample
4. Adjust the sample loading height using the height controller depending on the sample size.
Figure 8 Controlling the height
Measurement
NOTE
:
Start the sample measurement after warming up the system for at least 20 minutes.
1. Launch the UV Lab software. When the window below is appeared, select Experiment
Type and click OK.

09931298C
6
2. Select Transmittance mode (%T) in the Data Type and select OK.
3. Place the air or reference plate on the sampling port and click Blank to measure blank.
4. Insert sample in the advanced transmission holder and click Sample to measure sample.
