PETKIT Fresh Element Mini Pro User manual
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
TABLE OF CONTENTS
Quick Setup (Device setup) 3
Quick Setup (opening lid and adding food) 4
List of parts 5
Product Summary 6,7,8
Product Usage 9
Indication Light Instructions 10
Cleaning guide 11
FAQ 12,13
Troubleshooting 12
A Message to our Valued Customers 13
How to Use Safely 14
Basic Specifications 15
Bottom of the device
1. Remove the screws and slide off the battery cover on the
bottom of the device.
2. Install 5 AA batteries in the battery compartment. (make
sure they are installed with the correct orientation)
3. Slide the cover back into place and tighten down screws.
*We strongly recommend replacing the batteries before
leaving on a trip for an extended period of time. Make
sure to replace batteries when they are low on power.
(Use alkaline batteries only)
1. Please set the device on a flat, even surface.
2. Place the food bowl on the bottom section
of the device. The magnetic sensors will allow
it to snap it into place once it is in the correct
position. (Please see the illustration below)
Take the power adapter out of the food storage
container, and plug it into the power adapter port
on the bottom of the main device.
QUICK SETUP (DEVICE SETUP)
3
Setting up the main device
3
Installing the batteries (batteries sold separately)
(*Before installing batteries, make sure there is
no food in the food storage container.)
1
Connect power adapter
2
Please read the User Manual carefully before using the product and keep it properly.
FRESH ELEMENT Mini
INSTRUCTION MANUAL
INDICATION LIGHT STATUS
The device has lost its connection to the
internet or is unable to connect to the router.
Wifi indication light
is blinking slowly
Wifi indication light
is blinking quickly
Wifi indication
light is on (constant)
Wifi indication light
is off
Food level indication
light is on (constant)
Food level indication
light is blinking
Food level indication
light is off
①The device is searching for a wi-fi signal.
②The device is undergoing an update
(Please refer to the notifications in your
App)
The device is connected to the internet.
The device is not connected to the internet,
or the indication light has been switched off.
The food level is low.
The device is not functioning properly.
The food level is adequate.
INDICATION LIGHT INSTRUCTIONS
10
Wi-fi Indication Light
Food Level
Indication
Light
11
1. Open the top lid, remove the food storage container. Pull out the food bowl set and separate
the stainless steel food bowl from the food bowl support.
2. One by one, clean the food storage container (including the propeller blades), the stainless
steel food bowl, and the bowl support. We recommend using an appropriate cleaning agent
and rinsing clean.
*Be aware that the exterior of the main device should not get wet.
3. Once washing is complete and the parts have air dried, install them back into the main
device one at a time.
*When putting the food storage container back in, lightly screw the food mixer back into
the food storage container until the container is fully secured in the main device.
Top Lid Food storage
container Stainless steel food bowl
Food bowl support
CLEANING GUIDE
Food mixer
PRODUCT USAGE
9
Manual feeding
1
Hold down the manual feeding button. The food
outlet door will open and dispense food. Let go of
the button, and the food outlet door will close and
cease dispensing food.
Feeding remotely using the APP
2
You can dispense food in real time or set times
for food to be dispensed via remote control of
Petkit App.
1
Scan the QR code to
view a video on how to
connect to your device
using wifi.
12
Friendly reminder: If there is a problem with the indication light (it doesn’t turn on), or if you
iare unable to dispense food manually, please first check the App settings, or try unplug and
plug back the device again.
Note: For troubleshooting for other problems, as well as everyday maintenance information, please refer to
the prompts in the App.
The food level
indication light is
on constantly.
Wi-fi indication light
is not blinking
properly.
①The device has lost its connection to the internet. Please
check the internet in your area.
②If the internet is functioning properly, please open the
“Device” page in the App, click the “setting” in the upper
right corner, and reconfigure your device’s wi-fi connection.
The food level is low. Please add food now.
TROUBLESHOOTING
FAQ
That the Feeder loses connection to your home’s router will cause the device get offline. Possible causes for this
problem include:
1. Electricity has gone out in your home. If it happens, your router will not work and your Feeder will switch to
battery power. If there are no batteries installed, then your device will cease working until power is restored.
Before the batteries die, the Feeder will operate normally. However, the App will be unable to connect to your
device. Records of feeding during this time will be labeled as “unknown”. (Note: once the internet connection is
restored, you will only be able to update a maximum of 10 feeding records, and during this time you will be
unable to adjust the feeding schedule.)
Ⅰ. The Feeder Mini has lost its internet connection:
QUICK SETUP(OPENING LID AND ADDING FOOD)
4
DEDICCANT
Open the lid
1
Hold down the “Open Lid” button and lift it up
the lid.(You can scan the QR code below for
further instructions on how to open the lid)
Add cat food
3
1. Add dry cat food. (Please do not exceed the
MAX line)
2. Close the lid. *Sizes for cat food should be
between 5mm and 12mm.
Connect using the APP
*
Insert a desiccant packet
2
Lay the cover flat and open the compartment for
the moisture-absorbent material. Stir the bag of
moisture-absorbent material until it is spread
evenly in the compartment, then close the
compartment cover.
Download the “PETKIT” app from App Store or
Play Store。Enter Home Page of the App- Click”+”
on the right of “Device Lists” and add a device
correspondingly. Follow the prompts to connect
your device.
Scan QR Code to
download the
“PETKIT” App
How to open
the lid
1 - 16
English
Deutsch
En français
Português
Español
日本語
繁体
한국어
Italiano
17 - 32
33 - 48
49 - 64
65 - 80
81 - 96
97 - 112
113 - 128
129 - 144
Русский 145 - 160
PRODUCT SUMMARY
7
Works together with the
propeller. Can be used with
different sized pebbles of
dry food.
Stopper gate
Mixes food Used to
ensure an even distribution
Prevents blockages
Silicone food
mixer paddles
Propeller
Soft material, prevents blockages
*Note: In order to provide the best product,
we will be implementing periodic product
enhancements. If the illustrations do not
match what you see on the device, please
refer to the device as standard.
Hold down to dispense food
Let go to stop dispensing food
Food level indication light
Stainless steel food bowl
Supports for
the food bowl
PRODUCT SUMMARY
6
Button to dispense food manually
After opening, pour in dry pet food
Lid
Hold down the “Open Lid” button
“Open Lid” button
Adequate (no light)
Low (constant light)
Unknown problem (blinking)
Food outlet door
The food outlet door will open
automatically when dispensing food
The opening will close automatically
when finished dispensing food
Wifi indication light
Connecting to internet (quick blinking)
Not connected to the internet (slow blinking)
Connected to internet (constant light)
5
LIST OF PARTS
Food bowl
supports *1
Stainless steel
food bowl *1
Adapter *1 Moisture-absorbent
material *1
Main device *1
*Before setting up your device, please make sure you have all the necessary parts. (This
product does not come with batteries or a screwdriver. You will need to purchase these
separately.)
DEDICCANT
User’s Manual *1
INSTRUCTION MANUAL
PRODUCT SUMMARY
8
Battery cover
Top of the
devicea
Bottom of
the device
Power adapter port
Desiccant compartment
Food storage container
Wi-fi setup button
You can install 5 AA batteries
The batteries can provide
emergency power when electricity
has been cut
Attach the power adapter
Insert a desiccant packet
Press the button for 5 seconds. When
the light begins blinking quickly, you can
connect the device to your phone.
Capacity: 2.8 L
Can hold up to 1.5 KG of pet food
16
HOW TO USE SAFELY
* Not respecting or abiding by the following guidelines may result in device malfunction or
other unexpected accidents.
·Only install and use the device as instructed in the User Manual.
·This device is not recommended for pets younger than 3 months.
·Please only use indoors.
·This device operates under low voltage, however it may still lose power if pets chew on the
power cable. Please make sure pets do not chew on the cord.
·Only use the original power adapter. Otherwise, you may damage the device or cause a risk
to safety.
·Please make sure the device is placed on a level surface. Do not overturn the device, or it
may not function properly.
·Only put dry pet food into the food storage container, or the device will not function
properly, and it may even endanger the safety of the pet.
·In order to prevent your pet from overturning this device, we recommend placing it in a
corner or against a wall.
·When dispensing food, please do not obstruct the dispenser opening.
·The main body of the device should not get wet.
·If you plan on leaving this device unused and unmoved for long periods of time, please
remove any batteries and unplug the power cable.
·Children should only be allowed to operate this device under the supervision of an adult.
·In order to avoid unnecessary damage or injury, only repair technicians should be allowed
to repair this device.
·If you plan on being away from the device for an extended period of time, please make
sure that the batteries installed in the device have sufficient charge (this device only used
alkaline batteries).
·If you encounter any problems operating this device, please contact customer service.
14 15
Product name PETKIT FRESH ELEMENT Mini
P530Product code
Product dimensions (mm)
Recommended for
Total weight of product
Wireless Connection
Rated voltage
Rated power
315mm*319mm*170mm
Cats
2.8kg
Wi-Fi
6VDC
6W/1000 mA
BASIC SPECIFICATIONS
MESSAGE TO OUR VALUED CUSTOMERS
· Thank you for choosing to purchase the PETKIT Smart Feeder Mini. PETKIT works hard to
make a better life for you and your pets through the implementation of science and technology.
·Before using, please carefully read the User Manual for this device. Installing and using this
device means you have read and accepted the safety guidelines listed below.
·PETKIT is not responsible, nor does it accept any legal responsibility,���� for any accidents
or losses caused by improper use of this device.
·PETKIT reserves the rights to interpret and modify this notice.
13
FAQ
2. The internet connection has been interrupted in your home (this could be due to reasons such as your
internet provider cutting internet service to your home). During this time, the Feeder will continue to operate
normally, however, the App will be unable to connect to your device. Records of feeding during this time will
be labeled as “unknown”. (Note: once the internet connection is restored, you will only be able to update a
maximum of 10 feeding records, and during this time you will be unable to adjust the feeding schedule.)
Ⅱ. The Feeder Mini is not dispensing food properly:
In order to dispense food on a specific schedule, the feeder dispenses a set amount of food each serving. Each
serving is approximately 5g. The actual weight of each serving may vary depending on the type of food, the size
of each pebble, and the density of the food. When the food storage container is full, each serving is relatively
consistent in weight. In most cases, you can adjust the amount dispensed in your settings. When the food level
is low, the portion size may shrink. Please make sure there is always enough food in the food storage container.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and ；(2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: -Reorient or relocate the receiving antenna.-Increase the
separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IC warning
- English:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre le fonctionnement.
English
Table of contents
Other PETKIT Pet Care Product manuals
PETKIT
PETKIT T3 User manual
PETKIT
PETKIT YUMSHARE SOLO WITH CAMERA SMART PET FEEDER User manual
PETKIT
PETKIT PURA X User manual
PETKIT
PETKIT T4 User manual
PETKIT
PETKIT F1 User manual
PETKIT
PETKIT AIRSALON MAX User manual
PETKIT
PETKIT Fresh Element Solo User manual
PETKIT
PETKIT W2S User manual
PETKIT
PETKIT YUMSHARE DUAL-HOPPER WITH CAMERA SMART PET... User manual
PETKIT
PETKIT PURA MAX User manual
PETKIT
PETKIT Eversweet Solo 2 User manual
PETKIT
PETKIT Fresh Element Solo User manual
PETKIT
PETKIT Fresh Element 3 NEW User manual
PETKIT
PETKIT SUS304 User manual
PETKIT
PETKIT Eversweet Solo User manual
PETKIT
PETKIT FRESH ELEMENT User manual
PETKIT
PETKIT VACUBE User manual
PETKIT
PETKIT PURA MAX User manual
PETKIT
PETKIT 490SPCIGY User manual
PETKIT
PETKIT Fresh Element Gemini User manual
