PETKIT YUMSHARE DUAL-HOPPER WITH CAMERA SMART PET... User manual

USER MANUAL
V1.0-2023.08
PETKIT YUMSHARE DUAL-HOPPER WITH CAMERA
SMART PET FEEDER
Please read the User Manual carefully
before using the product and keep it
properly.

TABLE OF CONTENTS
PRODUCT LIST
PRODUCT DESCRIPTION
PRODUCT INSTALLATION
HOW TO USE
DESCRIPTION OF APP FUNCTIONS
CLEANING AND MAINTENANCE
VIDEO GUIDE
BASIC SPECIFICATIONS
A MESSAGE TO OUR VALUED CUSTOMERS
USER SAFETY GUIDE
3
4
6
8
13
26
27
28
29
29

PRODUCT LIST01
-3-
RETURN TO
CONTENTS
Main Unit
* Please confirm the following accessories are complete before installation
and use.
Desiccant Adapter
Stainless Steel
Food Bowl
User Manual
Hopper
（ Batteries or screwdriver are not equipped and need to be purchased separately ）

-4-
*Note: in order to provide a better user experience, we will be implementing periodic product
enhancements. Product images shown for illustration purpose only. Actual product may vary
from the image shown on the box. For any discrepancies, please refer to the actual product.
PRODUCT DESCRIPTION
02
Lid Release
Button
Hopper
Stainless Steel
Food Bowl
Microphone
Dispensing
Module
Camera
Lid
Partition
Window
Main Unit
Food Dispensing
Vanes
RETURN TO
CONTENTS

-5-
Indicator Light
Wi-Fi Setting
Button
PUSH Button
Hopper 01
Feeding Button
Hopper 02
Feeding Button
Speaker
Power Input
RETURN TO
CONTENTS

PRODUCT INSTALLATION
03
-6-
3.1 Installing the Main Unit
①Place the main unit on the level ground or desk.
②Lift the hopper, align the notches on both sides with the PUSH button on the main
unit, and place it vertically downwards.
③Press and hold the PUSH buttons until they are fully stuck into the notches.
④Place the stainless steel food bowl in the food bowl holder.
3.2 Connecting the Power Supply
Take out the power adapter cord and attach it to the power input on the back.
RETURN TO
CONTENTS

-7-
* Note: When the battery is low, please replace the batteries in time. Check
and replace the batteries before leaving the device unattended for an extended
period of time.
Bottom of the
main unit
Interior of the lid
① Take out the screw and remove the battery cover.
②Take four D batteries and place them in the battery compartment.
(Pay attention to the orientation of the positive and negative ends)
③ Put the battery cover back on and tighten down the screw.
Choose whether to install batteries based on personal actual usage needs.
(Batteries need to be purchased separately, and only alkaline batteries can be used)
3.3 Installing the Backup Batteries
Battery cover
D alkaline batteries *4
3.4 Installing the Desiccant
①Press and hold the lid release button
to the right and lift up to remove the lid.
② Open the desiccant compartment,
take the desiccant packet, and lay it down
evenly in the compartment, Then close
the desiccant.
DESICCANT
Desiccant
compartment
RETURN TO
CONTENTS

返回目录
HOW TO USE
04
-8-
* Note: Do not pull out the partition if there is food left inside.
4.1 Adding Pet Food
① Add pet food. (Do not exceed the MAX line) Two different pet foods can be placed
in hopper 01 and hopper 02 according to your feeding needs.
* Recommended kibble size of dry food ≤12mm (0.47in)
* Recommended kibble size of freeze-dried food ≤9mm (0.35in)
②Cover the lid: Insert the rear side of the lid into the two holes above the hopper.
RETURN TO
CONTENTS

Indicator light
4.2 Indicator Light
The indicator light can be turned on/off in the App.
The indicator light is not on in battery mode.
Indicator light Status
Device is not connected to
Wi-Fi
White light is
flashing slowly
White light is
flashing quickly
White light is
constantly on
Device is connecting to Wi-Fi
Device is connected to Wi-Fi
(Camera is not working)
Green light is
constantly on Device is connected to Wi-Fi (Camera is working)
-9-
4.3 Manual Feeding
Select 01 or 02 hopper button.
Press the button to start dispensing;
Release the button to end dispensing.
Hopper 01
feeding button
Hopper 02
feeding button
RETURN TO
CONTENTS

-10-
4.4 App Binding and Activation
① Download and install PETKIT App:
② Add a device
Open the PETKIT App and enter its homepage; click “+” on the top right corner of the
page to select and add the “PETKIT YUMSHARE DUAL-HOPPER WITH CAMERA”.
Download the PETKIT App in an
App Store or Android Stores
Available on
Android stores
TM
Download on the
App Store
* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
Device
电量：100%
0h 8h 16h 24h
小佩智能猫牌
进食次数
5
下次出粮时间：19:30
智能双子星喂食
器
0h 8h 16h 24h
9:41
Hello, PETKIT
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-11-
③Start connection
In the startup state, long press the Wi-Fi setup button for 5 seconds until the indicator
light on the device flashes rapidly; click Next to configure Wi-Fi and the App will start
to connect to the device. Please wait until the App displays configuration succeeds.
*This product supports 2.4GHz Wi-Fi, but not 5GHz. Please make sure you have turned on the
2.4 band when connecting the device to the Internet.
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-12-
④ Read usage guidelines
After the device successfully connects to the PETKIT App for the first time, to ensure
pet safety and proper use of the product, please carefully read the usage guidelines
and appropriately use the product according to the instructions.
RETURN TO
CONTENTS

DESCRIPTION OF APP
FUNCTIONS
05
* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-13-
5.1 Device Homepage
① Real-time video：
View your pet's status in real-time.
② VLOG：
Click “ ”, and the system will
automatically generate vlogs of your pet.
This section displays up to the last 7
days of video.
③ YUMSHARE today (Timeline)：
Clips captured are categorized as visit,
eat, and feed through AI algorithm.
You can click any of them for more
details.
* Only pictures can be viewed when PETKIT
Care+ Cloud Service is not subscribed. Please
subscribe the Service if you want such
functions as playing back full clips, moments
and speedup playback. For specific rules,
please refer to PETKIT Care+ Service
Agreement.
④ Function keys
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-14-
④ Description of function keys
Click it to dispense food for your pets
instantly.
(Remote control is supported.)
Extra feeding
Long press “Intercom”, and the feeder will
broadcast what you said simultaneously,
so as to have dialogues with your pets in
real time.
Intercom
Your voice is only heard when playing
back videos. (You need to turn on the
microphone first via the App.)
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-15-
Set up the feeding time and portions to
make sure your pet is fed on time.
Feeding plans
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-16-
①Highlight playback
5.2 Play Videos
After subscribing the PETKIT Care+ Cloud Service, click the Timeline on the
homepage of the device to play back full clips, highlight with speedup options.
You can preview 4-second videos that are sped up by clicking them in the Timeline.
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-17-
② Full clips playback
Switch the tag to “Playback” to watch complete video clips.
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-18-
③ Speedup playback
When playing full video clips, click “ ” on the top right corner to choose the speed
as needed, or long press the center of video frame to directly switch to 2x play.
RETURN TO
CONTENTS

* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
-19-
5.3 Delete Video Clips
You are entitled to delete any video.
① Method 1:
Delete videos in the Timeline;
② Method 2:
Delete videos in VLOG. Click the
video you want to remove, turn its
play tag to “Full” and click the “ ”
on the top right corner to delete the
video.
RETURN TO
CONTENTS

-20-
5.4 Privacy Protection
① Camera permissions
You are entitled to turn the camera on or off as needed.
If it is turned off, any video footage fails to be captured.
RETURN TO
CONTENTS
* Note: To provide the best possible user experience
and functional optimization, the product firmware will
be irregularly upgraded. Please refer to actual situations
and promptly upgrade the firmware via PETKIT App.
