PETKIT FRESH ELEMENT User manual

FRESH
ELEMENT
SMART PET FEEDER
INSTRUCTION BOOK
P
Read
instructions carfully before use,
please keep it well.
-01-

PARTS
FOOD
STORAGE BUCKET LID
• Open the bucket lid, put the dry
pet food
in
BUCKET RELEASE KEY
• Move finger left, push the
release key to open the bucket
Wi-Fl LIGHT
MANUAL FEED BUTTON
• Click to
start/finish feeding
process
STATUS INDICATOR LIGHT
• Rest food indicator
• Error indicator
MAIN MACHINE
FOOD
OUTLET DOOR
• The door opens
automaticalW
when feeding start
The door closes automatically
when feeding finishes
BASE
STAIN LESS STEEL BOWL
BASE REGISTRATION COLUMN
BATTERY
COVER
•Install 4 D -cell alkaline
batteries for
emergency
power outages

PARTS
MAIN
MACHINE LOCATE HOLES
DESICCANT BOX
-Fix the main machine on the base
'Place the
desiccant
ADAPTER SOCKET
'Connect adapter
OSCILLATING BAR
-Mix food, make it even, preventing
any blockages
CHECK -BOARD
-Cooperate
with impeller institutions,
apply to
different size of dry pet food,
to make sure feed as planned
IMPELLER
•Soft
materials, to prevent any
blockages
FOOD STORAGE BUCKET
• Holds dry pet food with
5.9L
capacity
Wi-Fi SETTING KEY
• Link to smart phone
after long press
BUCKET
RELEASE BUTTON
'Allows bucket to be removed.
Please keep
bucket empty
to
prevent food from
dropping
into machine
when
taking out

I INSTALL
13
CONNECT ADAPTOR
IA INSTALL
Take out the main machine, plug the
power
source adaptor into
the power input, found
under the main machine.
1. Place the base
on a level surface.
2.
Please make certain that the
main
machine
power input and base
connect
are correct.
Ii
INSTALL BACKUP BATTERY
1. Remove screws to open the battery cover.
2. Install 4 D -cell alkaline
batteries in battery compartment.
Make certain the bucket is empty and that
there is nofood
in the bucket when you install or
change the battery.
3. Upon battery
installation, please calibrate: Press and
hold
the manual feed button until the food
outlet door opens.
You will
hear a short beeping sound to indicate
that the
machine is ready for
calibration. (Attention: if there isfood
inside, empty
the container). Calibration is
complete when
you hear a long sound.
4. For every time install and remove
batteries,please repeat
steps 1, 2, and 3 to calibrate. Otherwise, the rest
food
indicator may affected.

I
HOW TO USE
OPEN THE LID
Move release
key to the left to open the lid
of the
food
storage bucket.
Othi
PUT DESICCANT IN
Open desiccant package
and flatten the desiccant evenly
inside the small orange box.
FILL WITH FOOD
Fill with dry pet food after completing
above steps.
MANUAL FEED
Click the manual feed button and the food outlet
door
will open and start to feed. Click the manual
feed button again and the
outlet door will close,
completing the feeding process.
SMART PLAN FEED
Download the
PETKIT app in the App
Store or Google Play. Once downloaded,
add and link your equipment and set up
your feeding plan.
Open up the
PETKIT app and click "+" to
add your equipment. Follow the prompt
to set up
feeding plan for your pets.
App Store
Gooslcplay

I BASIC
PARAMETERS I
NOTES
Name
PETKIT SMART FEEDER
Product model
P512
Size
Main machine: 221 x 217 x 423mm Base: 445 x 223 x 50mm
Dry cell
batteries 4 D -cell
alkaline batteries
Recommended pet type
small to medium size dogs/cats
Total
weight 5kg
Wireless Wi-Fi
enabled
Nominal voltage
6 VDC
Rated
power 6W
1000Ma
I
ERROR
DIAGNOSIS
Wi-Fl
indicator light flashing
Smart feeder offiine:
First check your network
connection. If network is stable, open the
PETKIT app and tap the top right corner
button to reset the Wi-Fl
Food storage
indicator light
keeps
flashing
System error: Ensure that lid is tightly closed.
Then reset the smart feeder.
Note.
To
manage other issues or perform daily maintenance,
please check the electronic directions.
Failure in complying
with these
instructions may lead to
equipment
malfunction
or pet' s safety concern
• For dry
pet food only.
• PLEASE place base on
a level surface.
•
DO NOT put
anything (except dry pet
food) into the bucket.
Foreign objects will
cause
equipment to malfunction
or lead to pet's safety
concern.
• It is
recommended to place
equipment in a corner or
against the wall. Please
place at
least 70mm distance
between the base and
the wall, however.
• DO
NOT allow pets to bite the
wire. It may cause an
electric shock or death
•
DO NOT allow children
under the age of 12
control or play with this
equipment.
• DO
NOT touch the food outlet
door once the food is out.
• DO
NOT put anything on
top of the machine.
Anything against the
machine may
affect the
machine's function.
• PLEASE
KEEP the bucket empty
if you wish to take it out.
• For dog and cat
use only. We DO NOT
recommend any pet
under the age of 3
months
use this equipment.
I
ELECTRONIC
DIRECTIONS
Scan to
downloaq u
onic directions
http://m
petkit
coneplouuchtiansfer.htruPproducteD1
We will improve
our product regularly to
offer you the better
product. May has
difference between the real
product and package photo.

I
PARTS
MAIN
MACHINE LOCATE
HOLES
•Fix the main
machine on the base
ADAPTER
SOCKET
-Connect adapter
OSCILLATING BAR
-Mix food, make
it even, preventing
any
blockages
CHECK -BOARD
•Cooperate with impeller institutions,
apply to
different size of dry pet
food,
to make
sure feed as planned
IMPELLER
-Soft materials, to prevent any
blockages
DESICCANT BOX
• Place the desiccant
FOOD STORAGE BUCKET
• Holds dry pet food with
5.9L capacity
Wi-Fl
SETTING KEY
• Link to smart phone
after long
press
BUCKET RELEASE BUTTON
-Allows
bucket to be removed
Please keep bucket empty
to
prevent food from
dropping into machine
when
taking out
