PG BISON BLUM FLATPAX 367779 User manual

GSPublisherVersion 241.1.7.100
BLUM FLATPAX OFFICE FURNITURE RANGEASSEMBLY GUIDE3 - DRAW PEDESTAL1TOTAL NUMBER OF PANELS: 23

GSPublisherVersion 241.1.7.100
DufixMinifixHandle J9913 260mm2TOOLS REQUIREDScrew Driver(Pozidriv Head)Cordless DrillPozi Bit (PZ2)Rubber Mallet8mm Drill BitPRODUCTQTYScrew 3.5 x 16mm32Wooden Dowel205432Tandem Single Extension Runners 270mmLeft & Right3 pairsScrew 4 x 30mm6Front Adjusters6Dome Screws6Locking Devices Left & Right3 pairsGlides43HARDWAREIMAGE

GSPublisherVersion 241.1.7.100
CARCASS ASSEMBLYB - Visible Side RightE - BackC - Floor BottomD - TopA - Visible Side Left3NUMBER OF PANELS: 5

GSPublisherVersion 241.1.7.100
42 O'ClockPosition230°PANEL CONNECTION AND FASTENINGDet. 1Det. 2Det. 3IIIIIIIVI - Insert the Minifix (1), Dufix (1) and wooden dowels (2) in the shown positions.Gently knock in the wooden dowels using a rubber mallet where necessary.II - Confirm that the Minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the Minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for Minifix orientation when fastened. Reset the Minifixorientation to that shown in Det.1 to disconnect the panels. 1. Confirm that all panels (5) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (A - E). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below unless otherwise stated.GENERAL INSTRUCTIONS

GSPublisherVersion 241.1.7.100
5STEP 1STEP 2Using a rubber mallet, knock in the Plastic Glides in the shown positions on panel C. Refer to theindicated dimensions for positioning. Note that the glides go on the face without holes.C10 mm50 mmWith panel C sitting on the glides, connect panels A & B to panel C as shown. Refer to the holesand/or grooves on the diagram to determine the panel orientation.A50 mm50 mm50 mm10 mm10 mm10 mmCB

GSPublisherVersion 241.1.7.100
6STEP 3Slide panel E through the grooves on panels A and B and into the groove on panel C.BACESTEP 4Connect panel D to panels A & B as shown. Note that the groove on panel D goes into therevealed edge on panel E (See Det. 9). Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Det. 9BACDEEDA

GSPublisherVersion 241.1.7.100
7STEP 5STEP 6Screw in the Left Tandem Runner in the shown positions on panel A. See Det. 10.Screw in the Right Tandem Runners in the shown positions on panel B. See Det. 11.First, use these screwsto align the runnerholes with thepredrilled pilot holes.Then, reinforce therunners by addingscrews in the shownpositions.Right RunnerDet. 11BCBACABDCEFirst, use these screwsto align the runnerholes with thepredrilled pilot holes.Then, reinforce therunners by addingscrews in the shownpositions.Left RunnerDet. 10ACED

GSPublisherVersion 241.1.7.100
DRAWER BOX ASSEMBLY 1P - Left Box SideS - Drawer Box Sub FrontT - Drawer Box BottomQ - Right Box Side)R - Drawer Box BackTOTAL NUMBER OF PANELS: 58 1. Confirm that all panels (5) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (P, Q, R, S & T). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below.GENERAL INSTRUCTIONS2 O'ClockPosition230°PANEL CONNECTION AND FASTENINGDet. 1Det. 2Det. 3IIIIIIIVI - Insert the Minifix (2), Dufix (2) and wooden dowels (1) in the shown positions.Gently knock in the wooden dowel using a rubber mallet where necessary.II - Confirm that the Minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the Minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for Minifix orientation when fastened. Reset the Minifixorientation to that shown in Det.1 to disconnect the panels.

GSPublisherVersion 241.1.7.100
STEP 1STEP 2Connect panel R to panel Q as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Connect panel P to panel R as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.9QRPRQ

GSPublisherVersion 241.1.7.100
STEP 3STEP 4Connect panels P & Q to panel S as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Slide 3mm panel T through the grooves on panels Q & P and into the groove on panel S as shown.Refer to the holes and/or grooves on the diagram to determine the panel orientation.10QRPRQPSST

GSPublisherVersion 241.1.7.100
STEP 5STEP 6Secure the 3mm panel T onto panel R using Screw 3.5 x 16mm. Refer to the holes and/or grooveson the diagram to determine the panel orientation.Place the Tandem Locking Devices in the shown positions, aligning them with the pre-drilled pilotholes. Secure the locking devices onto panel S using Screw 3.5 x 16mm.11QRRQTTScrew 3.5 x 16mmX 6Screw 3.5 x 16mmX 4Locking DeviceLeft & Right

GSPublisherVersion 241.1.7.100
STEP 7STEP 8Using a rubber mallet, gently knock in the Front Adjustment Brackets into panels W in the shownpositions. Confirm that they go all the way in such that no part appears above the surface of thepanel.Place the drawer box on panels W as shown. In each, connect panel S to panel W using DomeScrew M4 x 25, through the 5mm through hole and into the Front Adjustment Brackets. See Det. 4.12RSFront AdjustmentBracketX 2PTQDome Screw M4x 25X 2WWQSDet. 4

GSPublisherVersion 241.1.7.100
13STEP 9STEP 10Using Screw 3.5 x 16mm, screw in the handles onto panel W in the shown position. Confirm that theholes on the handles align with the pilot holes on panel W.X 2
W
SRQPTScrew 3.5 x 16mmInsert the Drawer Box as shown. Push the drawer all-in ensuring that the locking devices snap intothe Tandem Single Extension runners and that the hook at the rear end of the runners enters theholes at the back of panel R. If the holes are too small for the hook, expand them using a 6mm drillbit.DWABCE

GSPublisherVersion 241.1.7.100
STEP 1114Adjust panels W to achieve the clearance shown in Det.6. This is done by knocking the drawerface (Panels W) in the desired direction until the clearances in Det.6 are attained. When done,reinforce the panel S - panel W connection by adding Screws 4.0 x 30mm in the remaining holeson panel S. See Fig. 1.Det. 62.5 mmFig. 1
W
SRQPTScrew 4.0 x 30mmX 2ADBW2.5 mmBC

GSPublisherVersion 241.1.7.100
DRAWER BOX ASSEMBLY 2DL - Left Box Side (2)DF - Drawer Box Sub Front (2)DP - Drawer Box Bottom (2)DR - Right Box Side (2)DB - Drawer Box Back (2)15NUMBER OF PANELS: 10 1. Confirm that all panels (10) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (DF(2), DL(2), DR(2), DB(2) & DP(2)). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below.GENERAL INSTRUCTIONS2 O'ClockPosition230°PANEL CONNECTION AND FASTENINGDet. 1Det. 2Det. 3IIIIIIIVI - Insert the Minifix (2) and Dufix (2) in the shown positions.II - Confirm that the Minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the Minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for Minifix orientation when fastened. Reset the Minifixorientation to that shown in Det.1 to disconnect the panels.

GSPublisherVersion 241.1.7.100
16STEP 1STEP 2Connect panel DB to panel DL as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Connect panel DR to panel DB as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.DLDBDRDBDL

GSPublisherVersion 241.1.7.100
17STEP 3STEP 4Connect panels DL & DR to panel DF as shown. Refer to the holes and/or grooves on the diagramto determine the panel orientation.Slide 3mm panel DP through the grooves on panels DL & DR and into the groove on panel DF asshown. Refer to the holes and/or grooves on the diagram to determine the panel orientation.DRDBDLDBDRDLDFDFDP

GSPublisherVersion 241.1.7.100
18STEP 5STEP 6Secure the 3mm panel DP onto panel DB using Screw 3.5 x 16mm. Refer to the holes and/orgrooves on the diagram to determine the panel orientation.Place the Tandem Locking Devices in the shown positions, aligning them with the pre-drilled pilotholes. Secure the locking devices onto panel DF using Screw 3.5 x 16mm.DRDBDBDRDPDPScrew 3.5 x 16mmX 6Screw 3.5 x 16mmX 4Locking DeviceLeft & Right

GSPublisherVersion 241.1.7.100
STEP 7STEP 8Using a rubber mallet, gently knock in the Front Adjustment Brackets into panels U & V in the shownpositions. Confirm that they go all the way in, such that no part appears above the surface of thepanel.Place the two drawer boxes on panels U & V as shown. In each, connect panels DF to panels U & Vusing Dome Screw M4 x 25, through the 5mm through hole and into the Front Adjustment Brackets.See Det. 4.DBDFFront AdjustmentBracketX 2DLDPDRDome Screw M4x 25X 2U,Vu,vDRDFDet. 419

GSPublisherVersion 241.1.7.100
20STEP 9STEP 10X 2
U,V
