PG BISON BLUM FLATPAX User manual

GSPublisherVersion 0.1.100.9
BLUM FLATPAX KITCHEN RANGEASSEMBLY GUIDEBASE CABINET 1000mmDufixMinifix Plinth Leg With Base H100mm Kit4A - Visible Side LeftC - Floor BottomF - BackB - Visible Side RightD - Cantenaria ProfileE - Back RailH - Adjustable ShelfG - BackTOTAL NUMBER OF PANELS: 8HARDWAREPRODUCTQTYScrew 3.5 x 16mm8Wooden Dowel162218Cabinet Connecting Screw Kit4H Profile Backer Connector1Shelf Support Flipper 14mm Kit4Cantenaria-profile_Silver1IMAGE

GSPublisherVersion 0.1.100.9
2TOOLS REQUIREDScrew Driver(Pozidriv Head)Cordless DrillPozi Bit (PZ2) 1. Confirm that all panels (6) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (A, B, C, E, F, G & H). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below.Rubber Mallet8mm Drill Bit2 O'ClockPosition230°PANEL CONNECTION AND FASTENINGGENERAL INSTRUCTIONSDet. 1Det. 2Det. 3IIIIIIIVI - Insert the minifix (1), Dufix (1) and wooden dowels (2) in the shown positions.Gently knock in the wooden dowels using a rubber mallet where necessary.II - Confirm that the minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for minifix orientation when fastened. Reset the minifixorientation to that shown in Det.1 to disconnect the panels.

GSPublisherVersion 0.1.100.9
STEP 1STEP 2Connect panels C & E to panel A as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Connect panel B to panels C & E as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.3AECCABE

GSPublisherVersion 0.1.100.9
STEP 3STEP 4First, check the diagonal of the cabinet by measuring the two distances indicated by the brokenlines. They should be equal. If not, twist the cabinet accordingly in the diagonal corners as shownuntil an equal value is achieved. After, secure panels F & G to panels E & C respectively as shownusing Screw 3.5 X 16mm.AF4Screw 3.5 x 16mmX 10BEACBFGGDet. 4IIIIIIFSlide 3mm panel G into the groove on panels A & B with the finished side facing inside thecabinet. After, insert the H Profile Backer Connector into panel G as shown (See Det. 4). To finishthis step, slide 3mm panel F through the groove on panels A & B and into the H Profile BackerConnector as shown in Det. 4.GC

GSPublisherVersion 0.1.100.9
STEP 5STEP 65Screw 3.5 x 16mmX 12 Plinth Leg With BaseH100mm KitX 4Flip the cabinet up-side down as shown. Place the four units of Leg Adjustable Base 100mm in theshown positions, aligning with the pre-drilled pilot holes on panel C. Ensure that the orientation is asshown in Det. 5. Using Screw 3.5 X 16mm, secure the legs onto panel C.Det. 5ABCEFABCFlip the cabinet upright, place it in the desired position and adjust its height by rotating the baseof the legs as shown to level.FGGE

GSPublisherVersion 0.1.100.9
STEP 7Fix the cantenaria profile as shown below.Step 1; Insert the end cap flush with the profile.(View Det.5). Step 2; Use the screw provided to securely fasten the end dowel to the profileand onto the panel A and panel E. (View Det.6). Step 3; Fix the cantenaria profile to the top usingthe special connecting plate.(View Det.7)Fixing plateCantenaria ProfileDet. 5Det. 6AECFHScrews for fixingclosingcap-dowel.Fixing plateCantenaria ProfileDet. 76

GSPublisherVersion 0.1.100.9
STEP 8STEP 97Euro DowelX 4Screw in the Euro Dowels for flipper in the shown positions. Their positions can be adjusted asshown in Det. 6 to change the level of the shelves or to slant the shelves.Insert the shelf supports for flipper in the shown positions. Confirm that the orientation is as shown inDet. 7 and Det. 8.ABCDEFGDet. 7Det. 8Det. 6

GSPublisherVersion 0.1.100.9
STEP 1081. Slide in the shelf (Panel H) above the euro dowels as shown. Slide it in until it touches the back.2. Press down the shelf lightly such that the euro dowels snap into the shelf supports. See Fig. 1.See the Door Installation guide for further instructions.12Fig. 1HABCEFG
