BLUM FLATPAX OFFICE FURNITURE RANGEASSEMBLY GUIDEDESK 1800mm X 600mm X 760mmDufixMinifixCable Management Black24Plastic Glide BrownF - TopE - PartitionA - Visible Side LeftB - Visible Panel RightD - Fixed ShelfC - Back PanelTOTAL NUMBER OF PANELS: 6HARDWAREPRODUCTQTY21Wooden Dowel42121IMAGE

GSPublisherVersion 241.1.7.100
2TOOLS REQUIREDScrew Driver(Pozidriv Head)Cordless DrillPozi Bit (PZ2) 1. Confirm that all panels (6) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (A, B, C, D, E & F). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below.Rubber Mallet8mm Drill Bit2 O'ClockPosition230°PANEL CONNECTION AND FASTENINGGENERAL INSTRUCTIONSDet. 1Det. 2Det. 3IIIIIIIVI - Insert the Minifix (1), Dufix (1) and wooden dowels (2) in the shown positions.Gently knock in the wooden dowels using a rubber mallet where necessary.II - Confirm that the Minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the Minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for Minifix orientation when fastened. Reset the Minifixorientation to that shown in Det.1 to disconnect the panels.

GSPublisherVersion 241.1.7.100
STEP 1STEP 2Connect panel E to panel D as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Connect panel D to panel C as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.3DEDC

GSPublisherVersion 241.1.7.100
STEP 3STEP 4Connect panels C & D to panel B as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Connect panel A to panels C & D as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.4ADCCEBE

GSPublisherVersion 241.1.7.100
STEP 5STEP 6Flip the base up-side-down and using a rubber mallet, knock in the Plastic Glides in the shownpositions on panels A & B. Refer to Det. 4 and Det. 5.5ABACDFBD50 mm50 mmDet. 4Det. 5CEConnect panel F to panel A, B & E as shown. Refer to the holes on the diagram to determine thepanel orientation.

GSPublisherVersion 241.1.7.100
STEP 7Insert the Cable Management in the shown positions on panel F. Refer to Det. 4 and Det. 5. If tootight, gently knock them in using a rubber mallet.6ADFDet. 6Det. 7
