PG BISON BLUM FLATPAX Series User manual

GSPublisherVersion 183.1.8.100
BLUM FLATPAX KITCHEN RANGEASSEMBLY GUIDEWALL CABINET 300mmSys5 Quickfit TL2 Dowel 8 x 34Sys5 Cam 3000 15 x 14 mmScrew 4.0 x 30mmA - Visible Side LeftC - Wall BottomE - BackF - Adjustable ShelfB - Visible Side RightD - TopTOTAL NUMBER OF PANELS: 6HARDWAREPRODUCTQTYScrew 3.5 x 16mm81Wooden Dowel Titus 8 x 30 mm16Screw Nail in Anchor 8 x 80mm Yellow81482APC 1 Wall Cabinet Hanger KitCabinet Connecting Screw Kit4Shelf Support Flipper 14mm Kit4IMAGE

GSPublisherVersion 183.1.8.100
2TOOLS REQUIREDScrew Driver(Pozidriv Head)Cordless DrillPozi Bit (PZ2) 1. Confirm that all panels (6) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (A, B, C, D, E & F). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below.Rubber Mallet8mm Drill Bit2 O'ClockPosition230°PANEL CONNECTION AND FASTENINGGENERAL INSTRUCTIONSDet. 1Det. 2Det. 3IIIIIIIVI - Insert the Minifix (1), Dufix (1) and wooden dowels (2) in the shown positions.Gently knock in the wooden dowels using a rubber mallet where necessary.II - Confirm that the Minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the Minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for Minifix orientation when fastened. Reset the Minifixorientation to that shown in Det.1 to disconnect the panels.

GSPublisherVersion 183.1.8.100
3Dowel-Dufix-Dowel holes forpanel connectionDowel-Dufix-Dowel holes forpanel connectionCabinet connectionholes for CabinetConnecting Screws.Shelf adjustmentholes for flipper eurodowels.Hinge Plate HolesHinge Plate HolesCabinet connectionholes for CabinetConnecting Screws.PILOT HOLES KEY FOR SIDE PANELS

GSPublisherVersion 183.1.8.100
STEP 1STEP 2Connect panels C & D to panel A as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Connect panel B to panels C & D as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.4ADDCABC

GSPublisherVersion 183.1.8.100
5STEP 3STEP 4First, check the diagonal of the cabinet by measuring the two distances indicated by the red,broken lines. They should be equal. If not, twist the cabinet accordingly in the diagonal corners asshown until an equal value is achieved. After, place the APC 1 hangers in the shown positionsensuring that the shaded areas are flush with each other. Then, secure panel E to panel C usingScrew 3.5 X 16mm and to panel D, through the APC 1 hangers, using Screw 4 X 30mm. Reinforcethe APC 1 hangers in the shown positions using Screw 3.5 X 16mm.ACDABDESlide 3mm panel E through the grooves on panels A & B as shown. Refer to the holes and/orgrooves on the diagram to determine the panel orientation.EScrew 4 x 30mmX 2Screw 3.5 x 16mmX 4Screw 3.5 x 16mmX 4APC 1

GSPublisherVersion 183.1.8.100
STEP 5STEP 6I) Separate the yellow plug from the nail in anchor and, using a rubber mallet, gently knock in theplug into the holes drilled in Step 5.II) Place the APC 1 wall plates on the wall. Align the oval holes on the wall plate with the plugs.III) Screw the nail in anchor into the yellow plug.6The broken lines indicate the outer boundaries of the wall cabinet. Mark the drill points on the wallwith respect to the hanging position of the wall cabinet. Refer to Det. 5 for dimensions. Then, usingan 8mm Drill Bit, drill 80mm deep holes through the marked positions on the wall ensuring that thedrill bit is perpendicular to the wall surface.
32mm
IIIIIIDet. 6
38mm18mm38mm32mm
Det. 5
18mmWALLWALL

GSPublisherVersion 183.1.8.100
STEP 77Hang the wall cabinet on the wall by hooking the APC 1 Hangers onto the APC 1 wall plates. SeeDet. 7. Also see Det. 7 for adjustment details.Det. 7
WALL
In-depth AdjustmentVertical AdjustmentSTEP 8After mounting and levelling the cabinet, snap in the APC 1 cover caps to conceal the holes onpanel F. See Det. 8Det. 8
WALL

GSPublisherVersion 183.1.8.100
STEP 9STEP 108Euro DowelX 4Screw in the Euro Dowels for flipper in the shown positions. Their positions can be adjusted asshown in Det. 9 to change the level of the shelves or to slant the shelves.Insert the shelf supports for flipper in the shown positions. Confirm that the orientation is as shown inDet. 10 and Det. 11.ABCDEGDet. 10Det. 11Det. 9

GSPublisherVersion 183.1.8.100
STEP 1191. Slide in the shelf (Panel F) above the euro dowels as shown. Slide it in until it touches the back.2. Press down the shelf lightly such that the euro dowels snap into the shelf supports. See Fig. 1.See the Door Installation guide for further instructions.12Fig. 1FABCDE
