BLUM FLATPAX KITCHEN RANGEASSEMBLY GUIDETANDEM WOODEN DRAWER BOX HEIGHT 3Sys5 Quickfit TL2 Dowel 8 x 34Sys5 Cam 3000 15 x 14 mmScrew 4.0 x 30mmTandem Blumotion Single Extension For18mm 500mm Left&RightTandem Locking Device Left & RightFront Adjustment Bracket Knock InDome Screw M4 x 25G - Left Box SideJ - Drawer Box Sub FrontK - Drawer Box BottomH - Right Box SideI - Drawer Box BackTOTAL NUMBER OF PANELS: 5HARDWAREPRODUCTQTYScrew 3.5 x 16mm8121821222Wooden Dowel4IMAGE

GSPublisherVersion 183.1.8.100
2TOOLS REQUIREDScrew Driver(Pozidriv Head)Cordless DrillPozi Bit (PZ2) 1. Confirm that all panels (5) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (G, H, I, J & K). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below.Rubber Mallet8mm Drill Bit2 O'ClockPosition230°PANEL CONNECTION AND FASTENINGGENERAL INSTRUCTIONSDet. 1Det. 2Det. 3IIIIIIIVI - Insert the Minifix (2), Dufix (2) and wooden dowels (1) in the shown positions.Gently knock in the wooden dowel using a rubber mallet where necessary.II - Confirm that the Minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the Minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for Minifix orientation when fastened. Reset the Minifixorientation to that shown in Det.1 to disconnect the panels.

GSPublisherVersion 183.1.8.100
STEP 1STEP 2Connect panel I to panel H as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Connect panel G to panel I as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.3HIGIH

GSPublisherVersion 183.1.8.100
STEP 3STEP 4Connect panels H & G to panel J as shown. Refer to the holes and/or grooves on the diagram todetermine the panel orientation.Slide 3mm panel K through the grooves on panels H & G and into the groove on panel J as shown.Refer to the holes and/or grooves on the diagram to determine the panel orientation.4HIGIHGJJK

GSPublisherVersion 183.1.8.100
STEP 5STEP 6Secure the 3mm panel K onto panel I using Screw 3.5 x 16mm. Refer to the holes and/or grooveson the diagram to determine the panel orientation.Place the Tandem Locking Devices in the shown positions, aligning them with the pre-drilled pilotholes. Secure the locking devices onto panel J using Screw 3.5 x 16mm. Refer to the Base CabinetDraw Assembly Guides for further instructions.5HIIHKKScrew 3.5 x 16mmX 6Screw 3.5 x 16mmX 4Locking DeviceLeft & Right
