PG BISON KINETIC FLATPAX RANGE WALL CABINET User manual

GSPublisherVersion 90.2.13.100
KINETIC FLATPAX RANGEASSEMBLY GUIDEWALL CABINET 900mmScrew 4.0 x 50mmC - Back RailE - Visible Side LeftD - Wall BottomF - BackG - Adjustable ShelfA - Visible Side RightB - TopH - BackTOTAL NUMBER OF PANELS: 8HARDWARE1PRODUCTQTYScrew 3.5 x 16mm1610Shelf Studs4Screw 3.5 x 16mm2H Profile Backer Connector1Screw Cap Super White2IMAGE

GSPublisherVersion 90.2.13.100
GENERAL INSTRUCTIONS1. Confirm that all panels (8) are in the package before assembling.2. Check the white sticker on each panel for the labelling (A, B, C, D, E, F,G & H).3. Ensure that the panels are laid on a non-abrasive surface whenassembling.4. Countersink the holes on the side panels before inserting the screws.5. Ensure that the screw is perpendicular to the surface being drilled for aclean and strong joint.2TOOLS REQUIREDScrew Driver(Pozidriv Head)Cordless DrillPozi Bit (PZ2)Rubber Mallet8mm Drill Bit

GSPublisherVersion 90.2.13.100
STEP 1STEP 2ADBCABCDEConnect panels B, C & D to panel A using Screw 4.0 X 50mm in the pre-drilled pilot holes as shown.Refer to Det 1 - 3 below before fastening the screws.Connect panel E to panels B, C & D using Screw 4.0 X 50mm in the pre-drilled pilot holes as shown.Ensure that the symmetry between panel E and panel A is maintained. Refer to Det 1 - 3.
23mm
18.4mm
0.5mm
0.5mm
23mm
0.5mm0.5mm
1 mm
3Det. 1Det. 2Det. 3Screw 4 x 50mmX 8Screw 4 x 50mmX 8

GSPublisherVersion 90.2.13.100
STEP 3STEP 4BFirst, check the diagonal of the cabinet by measuring the two distances indicated by the red,broken lines. They should be equal. If not, twist the cabinet accordingly in the diagonal corners asshown until an equal value is achieved. After, secure panel F to panels B & D as shown using Screw3.5 X 16mm.BEF4Screw 3.5 x 16mmX 10CEDAFHSlide 3mm panel H into the groove on panels A & E with the finished side facing inside the cabinet.After, insert the H Profile Backer Connector into panel H as shown (See Det. 4). To finish this step,slide 3mm panel F into the groove on panels A & E and into the H Profile Backer Connector asshown in Det. 1.HDet. 4IIIIIIFHC

GSPublisherVersion 90.2.13.100
STEP 5STEP 6a) Raise the cabinet on the wall up to the desired level. Mark the drill points on the wall through the holes drilled in Step 4 ensuring that the cabinetis both upright and level.b) Lower the cabinet and using an 8mm drill bit, drill 80mm deep holes on the wall, through the marked points.c) Separate the yellow plug from the nail in anchor.d) Raise the cabinet and using a rubber mallet, gently knock in the plug through panels F & C and into the wall (See Det. 6).e) Screw the nail in anchor into the yellow plug ensuring that the screw head is flush with the surface of panel F (See Det. 6). f) Stick the Screw Caps onto the screw heads to conceal them (See Det. 6).5Using an 8mm Drill Bit, gently drill two holes through panels F & C in the positions shown in Det. 5. Countersink the holes such that the Screw Head willbe flush with the surface of panel F.
41 mm41 mm
50 mmØ8 mmFFDet. 550 mmCabinet Front ViewSection View of Cabinetwithout panels B & EIIIIIIFADADet. 6EABFH

GSPublisherVersion 90.2.13.100
STEP 7STEP 86With the cabinet hanged on the wall, insert the Shelf Studs in the shown positions.BEFDASlide in panel G as shown, such that it sits on the four shelf studs. The level of the shelf is adjustableby shifting the position of the shelf studs as shown in Det. 7. See Door Installation Guide for furtherinstructions.GDet. 7BEFDAHHShelf StudsX 4
