Phanteks GIGABYTE XTREME GLACIER G2080Ti User manual

INSTALLATION GUIDE V1.1
GIGABYTE XTREME
GLAC IER G2080Ti
PH-GB2080TiGB_BK01/CR01
PACKAGE CONTENTS
WARNING - This product is intended for advanced users. Improper installation may result in damage to your equipment.While all eorts have
been made to provide the most comprehensive information possible, Phanteks assumes no liability expressed or implied for any damage(s) occurring to your
components as a result of using Phanteks cooling products, either due to mistake or omission on our part in the below instructions, or due to failure or defect in
the Phanteks cooling products. Do not disassemble the water block.Warranty will be voided.
Turn o the power to your system and discharge your body’s static electric charge before proceeding with the installation procedure. If you do not feel comfortable
with performing the installation procedure, consult a qualied computer technician.
For latest version check www.Phanteks.com
Clean o the original thermal compound.
We recommend using isopropanol alcohol.
Apply a drop of the Phanteks Thermal
Compound to the center of the GPU chip
STEP 1. REMOVING STOCK COOLER
GLACIER GB2080TiGB
QTY: 1
GLACIER Stop Fitting
QTY: 2
Thermal Pads
QTY: 3
M2.5x5 Screws/Washers
QTY: 10/10
Thermal Compound
PH-NDC-01
QTY: 1
Phanteks D-RGB Cable
QTY: 1
Unscrew all highlighted screws to remove
the stock cooler.
STEP 2. APPLYING THERMAL PASTE & PADS
Remove the protective lm and place the
the thermal pads on correct position on
the PCB.
Make sure to unplug the LED and Fan
cables when you remove the stock cooler.
No need to remove the backplate.
Make sure to remove the protective lm on
both sides of the thermal pads.
Take the EVA-Foam from the box to use
as a base for your installation process.
5
2
3 3 3 3 3 3 3 3
1
3 3 3 3
4
RTX 2080
RTX 2080Ti
5
1
4
2
3
3
3
3
3 3 3
3 3 3 3
12
3
3
3 3 3 3
3
3
2
3 3 3 3 3 3 3 3
1
3 3 3 3

STEP 3. MOUNT THE WATER BLOCK
Carefully position the water block onto the
graphics card. Align the mounting holes on
the PCB with the holes on the water block.
Secure the water block with 9 M2.5x5mm
screws and 5 washers to the PCB.
STEP 4. CONNECT D-RGB LIGHTING
Connect the D-RGB cable to the D-RGB strip
in the water block.
STEP 5. INSTALLING FITTINGS
Install G1/4 threaded male ttings and
close the remaining ports with the two
included Stop Fittings.
9x
5x
Connect to
Phanteks Case / Motherboard Cable
Always perform a leak test before providing
power to any system components.
You can connect the D-RGB cable to a
compatible motherboard with the cable
that is included with the motherboard.
Make sure to lay the GPU with the water
block at down without resting on the
PCI bracket.
All Phanteks D-RGB products can be
daisy-chained together.
5x screws + washer
4x screws only
+
