Phanteks GLACIER C350ip User manual

GLACIER C350ip MANUAL V1.0
STEP 1. PREPARING THE BACKPLATE
PH-C350ip_BK01
INSTALLATION for socket 115x/1366/775, for socket 2011/2066 see next page.
PACKAGE CONTENTS
C350ip Block Backplate
Socket Screws for:
- 115x
- 1366
- 775
Acetal Stando
Socket Screws for:
- 2011-3
- 2066
Thermal Compound
(PH-NDC_01)
4x
4x
4x
STEP 2. INSTALLING THE BACKPLATE
Place the back plate on the rear side of the motherboard so
that the socket screws will stick through the socket mounting holes.
Please seee image for reference.
Make sure the orientation of the
backplate is correct:
Choose the correct position for the Socket Screws.
Insert the four (4) screws into the correct position
indicated on the backplate.
DISCLAIMER - This product is intended for advanced users.
Please consult with a qualied technician for installation. Phanteks
assumes no liability for any damages occurring as a result of using
Phanteks cooling products.
WARNING - Power down the system before installation.
- Do not disassemble the waterblock. Warranty will be voided.
- Perform a leak test before turning on the system.
- Check our website for the latest installation guide.
Make sure the CPU is clean and clear of any residual
traces of thermal paste . Apply a dot (4-5mm size) of
Phanteks thermal compound on the center of the
CPU surface.
STEP 4. APPLYING THERMAL COMPOUND
Please verify that all four scres are inserted
correctly:
Socket positions:
Position 1: 1366
Position 2: 115x
Position 3: 775
STEP 3. INSTALLING THE ACETAL STANDOFFS
Place the four (4) included Acetal Standos onto the
socket screws.

GLACIER C350ip MANUAL V1.0
STEP 5. INSTALLING THE C350ip Block
FINAL STEP. POWER ON
Please check the following:
- Make sure the block is seated properly on the CPU.
- Always perform a leak test before turning on the system.
- Use paper towels under ttings and joints to avoid damage.
- Make sure all hardware has been tested before starting your
water loop.
Remove the protective lm on the copper base rst.
Place the C350ip block on the CPU and tighten the thumb-screws by hand.
Let the pump run for multiple hours. Tilting the system
can help to release air bubbles.
Thanks to the C350ip’s symmetrical design. Both ports can be used as
an inlet or outlet for the water loop.
By securing the screws in a diagonal sequence, the mounting pressure
will be distributed evenly. This optimizes the cooling performance.
Do not use force to overturn the thumb-screws. Please stop when
the screws are at a natural stop.
INSTALLATION for socket 2011-3/2066
STEP 1. INSTALLING THE SOCKET SCREWS
STEP 3. INSTALLING THE C350ip Block
Remove the protective lm on the copper base rst.
Place the C350ip block on the CPU and tighten the thumb-screws by hand.
Place and tighten the four (4) included socket screws by hand on the
Intel 2011-3/2066 socket.
Thanks to the C350ip’s symmetrical design. Both ports can be used as
an inlet or outlet for the water loop.
By securing the screws in a diagonal sequence, the mounting pressure
will be distributed evenly. This optimizes the cooling performance.
Do not use force to overturn the thumb-screws. Please stop when
the screws are at a natural stop.
STEP 2. APPLYING THERMAL COMPOUND
Make sure the CPU is clean and clear of any residual traces of thermal paste .
Apply a dot (4-5mm size) of Phanteks thermal compound on the center
of the CPU surface.
