Phanteks GLACIER ONE D30 User manual

INSTALLATION GUIDE
VERSION 1.0
| www.phanteks.com 01
INSTRUCTIONS
Thank you for choosing Phanteks. Please take a moment to
carefully go through the manual. This manual will walk you
through all the installation steps of the Glacier One D30.
GLACIER ONE D30-240
1x 240 Radiator
2x D30-120mm Fans
GLACIER ONE D30-360
1x 360 Radiator
3x D30-120mm Fans
GLACIER ONE D30-420
1x 420 Radiator
3x D30-140mm Fans
This manual is for the following models:
GLACIER ONE 240 D30
GLACIER ONE 360 D30
GLACIER ONE 420 D30
GLACIER ONE D30
ACCESSORIES
Phanteks will not take responsibility for any damages incurred due to
incorrect installation or usage of this product.
MOUNTING HARDWARE
D30 ACCESSORIES
PH-NDC THERMAL
COMPOUND
1x
33mm RADIATOR
SCREWS
8x | 12x 6-32 UNC
35mm RADIATOR
SCREWS
8x | 12x 6-32 UNC
6mm RADIATOR
SCREWS
8x | 12x 6-32 UNC
THUMB NUTS
4x
3-PIN D-RGB MOTHERBOARD
ADAPTER
1x 600mm
SATA TO 2-PIN PUMP ADAPTER
1x
TUBE CLIPS
3x
INTEL 115X | 1200 | 1700
BACKPLATE
1X
AMD AM4 | AM5
BRACKET
(INTEL BRACKET IS PRE-INSTALLED)
1X
AMD TR4 BRACKET
(360 & 420 MODELS ONLY)
1X
INTEL 1700 STAND-OFF
4x
CORNER CLIP
3x
AM4 | AM5 STAND-OFF
4x
BRIDGE CLIP
1x | 2x
BRIDGE CLIP
CONNECTOR
1x | 2x
CORNER CLIP CABLE
1x
INTEL 115X | 1200
STAND-OFF
4x
SCREW COVER CORNER
2x each
SCREW COVER BRIDGE
2x | 4x
INTEL 2011 | 2066
STAND-OFF
4x
TR4 STAND-OFF
(360 MODELS ONLY)
4x
SILVER COLOR DARK COLOR

INSTALLATION GUIDE
02 | www.phanteks.com
Remove the stock mounting
brackets.
Secure the 4x TR4 Stand-offs to the motherboard.
Secure the 4x Intel 2011 | 2066 Stand-offs to the motherboard.
Insert the backplate through the motherboard. Secure the backplate with the
4x Stand-offs.
Make sure to use the correct
socket stand-off.
Securethe4xAM4/AM5Stand-
offs to the motherboard.
AMD AM4 |AM5
AMD TR4
INTEL 2011 |2066
INTEL 115X |1200 |1700
AMD BRACKET
SCREWS
REMOVE
4x AM4 |AM5
STAND-OFF
INSTALL
4x
TR4 STAND-OFF
INSTALL
4x
1700
115X |1200
1700 STAND-OFF
INSTALL
4x
115X |1200
STAND-OFF
INSTALL
4x
1. PREPARE MOTHERBOARD
Follow instructions for the corresponding socket.
ATTENTION
Check the stand-off texture to
make sure you got the correct
socket stand-off.
115X | 1200 1700
PROCEED TO STEP 2. >
PROCEED TO STEP 2. >
PROCEED TO STEP 2. >
PROCEED TO STEP 2. >
2011 |2066
STAND-OFF
INSTALL
4x
Attach the AM4/AM5 bracket
by sliding it on the cooling
module.
Remove the pre-installed Intel
bracket rst by sliding it off the
cooling module.
Remove the pre-installed Intel
bracket rst by sliding it off the
cooling module.
For the AMD TR4 socket, slide the
bracket on the cooling module.
DARK COLOR
SILVER COLOR

INSTALLATION GUIDE 03 | www.phanteks.com
INSTALLATION GUIDE
VERSION 1.0
INPUT CORNER
2
2
1
ATTENTION
Make sure to read and follow all the steps in the
D30-120 manual for correct installation.
Secure the CPU block to the stand-offs on the motherboard with
the 4x thumb nuts.
2. INSTALLING THE CPU BLOCK
THUMB NUT
INSTALL
4x
3. PREPARE D30 FANS
The thermal compound is pre-applied. More thermal
compound is included for future installations.
PRO TIP

| www.phanteks.com
INSTALLATION GUIDE
04
The D-RGB pump and fan lighting need a controller to function.
Connect to an ARGB-equipped motherboard with the included
D-RGB Motherboard adapter or use a Phanteks D-RGB Controller.
The Phanteks D-RGB Controller is sold separately (PH-CTHUB_DRGB_01)
Install the (3x) included Tube Clips for a tidy tube routing. Simply
snap the clips on the tubes.
More Phanteks D-RGB lighting products can be daisy-chained
easily with the JST-connector.
MOTHERBOARD CONTROL
PHANTEKS D-RGB CONTROLLER
CONNECT TO THE D-RGB CONTROLLER WITH
JST CONNECTOR.
*FOLLOW MOTHERBOARD MANUAL FOR INSTRUCTION ON D-RGB CONTROL
DAISY-CHAIN PHANTEKS D-RGB PRODUCTS TOGETHER
WITH THE JST-CONNECTOR.
EXPAND WITH MORE D-RGB PRODUCTS
D-RGB FAN
D-RGB FAN
MOTHERBOARD
D-RGB CONTROLLER
6. CONNECT D-RGB5. CONNECT PUMP CABLE
As a Phanteks customer, you are priority number one for us. We have a dedicated team across the globe to deliver the experience
you deserve. If you have any issues with the products, please don’t hesitate to contact out customer care team.
RMA and Technical Support Americas
Hours: Monday-Friday 9:00-5:00 PST
Phone number: [phone]
Email: [email protected]
Facebook: @Phanteks
RMA and Technical Support International
Email: [email protected]
Facebook: @Phanteks
For spare parts and optional upgrades please visit:
www.axpertec.com (EU) | www.phanteksusa.com (US)
SUPPORT & WARRANTY
D-RGB CONTROL
PUMP CABLE
D-RGB EXPANSION
7. INSTALL TUBE CLIPS
TUBE CLIPS
INSTALL
3x
Fan cables can be routed through
the middle of the Tube Clips.
PRO TIP
Connect the pump cable to an
available 3 or 4-pin header on the
motherboard (pump header if
available). Alternatively, you can use
the included Sata to pump adapter to
power the pump directly from the PSU.
3 or 4-pin pump cable
5
YEARS
WARRANTY
We recommend to install the fans to the radiator before mounting it into the chassis. Three types of screws are included to mount the
radiator and the fans in different options.
Use the 30mm radiator screws to mount fans to the radiator and
the 6mm screws to to mount the radiator directly to the chassis.
Use the 35mm radiator screws to mount the fan to the radiator
and chassis.
4. MOUNT THE RADIATOR AND FANS
33mm RADIATOR
SCREWS
8x | 12x 6-32 UNC
35mm RADIATOR
SCREWS
8x | 12x 6-32 UNC
6mm RADIATOR
SCREWS
8x | 12x 6-32 UNC
A B
