Phanteks Glacier C399A User manual

Phanteks Glacier C399A
INSTALLATION GUIDE
PH-C399A_BK01/PH-C399A_CR01
PACKAGE CONTENTS
Glacier C399a
QTY: 1
RGB LED Cable
QTY: 1
DISCLAIMER - This product is intended for advanced users. Please consult
with a qualied technician for installation, improper installation may
result in damage to your equipment.While all eorts have been made to
provide the most comprehensive information possible, Phanteks assumes
no liability expressed or implied for any damage(s) occurring to your
components as a result of using Phanteks cooling products, either due to
mistake or omission on our part in the below instructions, or due to failure
or defect in the Phanteks cooling products.
WARNING -Turn o the power to your system and discharge your body’s static
electric charge by touching a grounded surface – for example, the metal surface of
the power supply or chassis – before performing any hardware procedure. Phanteks
assumes no liability for any damage, caused directly or indirectly, by improper
installation of any components. If you do not feel comfortable with performing the
installation procedure, consult a qualied computer technician.
Thermal Compound
(PH-NDC_01)
QTY: 1
TR4 Socket Screws
QTY: 4
Phanteks Manual
QTY: 1
Phanteks Motherboard RGB Adapter
QTY: 1
RGB Y-Splitter
QTY: 1
*Please do not disassemble the water block. Warranty will be voided.
*Always check our website for the latest installation guide.
STEP ONE: CONNECTING THE RGB LED LIGHTING
FOR INSTALLATION OF AMD TR4 SOCKET
Step 1: Plug in the connectors of the RGB LED Cable as illustrated.
After Installation: Two options to install the RGB lighting from the C399A block
A. Connect to a compatible Phanteks Case (see Phanteks.com for compatibility)
B. Connect to a compatible motherboard featuring a RGB header, using the RGB.
(see Phanteks.com for compatibility)
PHANTEKS CASE
RGB ADAPTER (PH-CB_RGB4P)
A. Connect to compatible Phanteks’case
B. Connect to compatible motherboard
STEP TWO: CLEANING THE CPU AND APPLYING THE THERMAL PASTE
Wipe the CPU’s contact surface (use non-abrasive cloth to clean the area).
Apply the thermal compound to the CPU heat spreader (Phanteks recommends
using PH-NDC that was provided).We recommend to use ve dots of thermal paste.
See illustration.
Please refer to AMD’s thermal paste recommendation on their website.
ver. 2

Use the male to male screws to tigthen until you reach the end of the thread.
STEP THREE: INSTALLING THE MALE TO MALE SCREWS
STEP FOUR: INSTALLING THE WATER BLOCK TO THE SOCKET SCREWS
Align the thumb screws to the socket screws and tighten the screws by hand. Do not use any
tools to tighten the thumb screws.
Phanteks recommends you follow the steps below before you start your water loop setup
1. Test all your hardware before you start your water loop setup to make sure it is in working condition.
2. Plan out your loop to save some time.
3. Flush and rinse your water blocks with distilled water prior to use to ensure a clean loop.
4. Make sure that everything is unpowered and unplugged, either at the power supply end or hardware’s end before you
start your leak test.
5. Use paper towels under ttings and joints to avoid damage if there are leaks.
6. With the ll port open, run the loop for approximately 24 hours to completely bleed the air out of the loop.
Do not use any tools to tighten the screws.
Tighten the thumb screws at a time in the cross pattern.
