Philips RSAT 2 Reference guide

RSAT 2
Remote Control Panel
Customer‘s Manual

BTS Media Solutions GmbH
Brunnenweg 9
D-64331 Weiterstadt, Germany
P.O. Box 1165
Tel: [phone]
Fax: [phone]
Web Sites
Internet: www.thomsonbroadcast.com
www.imagingsystems.de
Intranet: www.weiterstadt.thmulti.com
Information in this document is subject to change without notice.
This document and any updates and/or supplemental information, including any copies thereof, cannot be reproduced, neither
communicated to a third party, without written authorization from THOMSON multimedia Broadcast Solutions.
Please notify THOMSON multimedia Broadcast Solutions of any errors in this document. We also would appreciate any comments
you have to improve this manual.
 BTS Media Solutions GmbH 2002. All rights reserved.
Copyrights
Published by
All product names mentioned in this manual are the trademarks of their respective owners.
Trademarks

Before reading the entire
manual, please check for any
supplements at the end
of the manual.
Item Rev Date Serial
No Pages affected Volume/Contents Remarks
1 0 07.2000 100 All Customer‘s Manual First Issue
2 1 11.2001 chapter 6 Oberating Instructions Macros
Remote Panel RSAT 2
Revision Report
Documentation Order Number Customer’s Manual RU 0065, 000 351 763 000

Remote Panel RSAT2 Contents
I
Operating Instructions - Rev. 1 / 11.2001
CONTENTS Page
Revision Report
1. General 1
1.1 Application examples 1
1.2 Control and display elements 1
2. Technical Data 3
3. Installation and Start-up 5
3.1 Safety Instructions 5
3.2 Mounting the Remote Control Panel RSAT2 6
3.3 Rack Mounting 8
3.4 Connecting to the DD35 control panel 10
3.5 Port re-configuration RS-422 / RS-232 11
4. Operation 13
4.1 How to start the Satellite Panel 13
4.2 How to learn a new function 14
4.3 What can be learned 15
4.4 Loading and saving setups 16
4.5 RSAT2 Makros and Control Panel M/E Delegation 19
5. Setup / Tests 22
6. Annex 24
6.2 Default Macros 25

Remote Panel RSAT2
Contents
II Operating Instructions - Rev. 1 / 11.2001

Remote Control Panel RSAT2 1. General
Operating Instructions - Rev. 1 / 11.2001 1
1. GENERAL
The remote control panel RSAT2 is used for copying button functions of the DD35
main operation panels for control of mixer functions from another workplace.
Connected to DD35 main panel via RS-422 cable which can be ordered optionally.
When the learn mode is applied single button functions also the built in Digipots and
the Fader can be trained with functions of the DD35 main panel –
Standard predefined settings for single M/E operation are also availlable.
1.1 APPLICATION EXAMPLES
Remote control on source selection, effects register recall, transitions, macros,
Shot-Box, Keyer adjust ...., specifically in conjunction with the use of an additional
sidepanel control PC.
Fig. 1: RSAT2 Remote Control Panel
1.2 CONTROL AND DISPLAY ELEMENTS
3 x16 button source selection busses with 4 digit displays
Transition control field with fader
4x Digipots
4x Delegation buttons
Learn mode buttons with Display
2x Menu control buttons (Step up/down)
22 additionally programmable buttons
In learn mode only one function per button or digipot is programmable. Delegation
functions are not available. Also, functions of the display panel RPV are not recor-
dable.

Remote Control Panel RSAT11. General
2Operating Instructions - Rev. 1 / 11.2001
The programmable memory of the RSAT2 is part of the DD35. Thus the program-
med function set for the RSAT2 buttons can be switched from application to appli-
cation. More complex button sequences can be achieved by programmed recall of
macro buttons of the DD35 main panel.
The standard unit is equipped with 1x reconfigurable 9 Pin D-Sub interface for con-
nection to a host processor. Without further options the factory configuration is a
RS-422/485 port for direct connection to DD35’s panel controller.

Remote Control Panel RSAT2 2. Technical Data
Operating Instructions - Rev. 1 / 11.2001 3
2. TECHNICAL DATA
Mechanics Width: 240 mm, Length: 464 mm, Depth: 115 mm
Weight: 5 kg
Desk cut out: 441 x 217 mm
Optional 19”Mounting frame
Voltage supply Line voltage: 100 V –240 V $10 %, autosense
Line current: 0.8 A
Line frequency: 50 Hz to 60 Hz
Wide AC range power supply block
Power consumption: < 50 W
Environmental Operating temperature: +0°C ... 40°C
requirements Storage/transport temp: –40°C ... 85°C
Humidity: v95%, DIN IEC 68-2-14
non-condensing
Electromagnetic EMA: EN 55103-1, EN 55 022, Class B,
compability ESD: EN 61000-4-2
EMI: EN 61000-4-3
Burst: EN 61000-4-4 , IEC 1000-4-4
RF immunity: EN 61000-4-6
Safety VDE 0805, EN 60 950
Interface RS-422/485 port for direct connection to the DD35 panel controller.
9pin D-sub, female. Port re-configurable for RS-232.
Communication is asynchron with 38.4 kbaud, 1 start, 8 data, no parity, 1 stop bit.-
A factory re-configuration is recommended for use of an RSAT2 with a PC.
Standard Accessories Accessory pack with tools fuses and button spare parts.
Options 19”Mounting frame für rack mounting.
Order no.: RC 2326, 000 351 762 600

Remote Control Panel RSAT22. Technical Data
4Operating Instructions - Rev. 1 / 11.2001

Remote Control Panel RSAT2 3. Installation and Startup
Operating Instructions - Rev. 1 / 11.2001 5
3. INSTALLATION AND STARTUP
3.1 SAFETY INSTRUCTIONS
Caution!
These instructions are for use by qualified personnel only. To reduce the risk
of electric shock, do not perform any installation other than that contained in
the Operating Instructions unless you are qualified to do so.
Refer all servicing to qualified service personnel.
Attention!
Electrostatic sensitive devices on the p. c. boards. Observe the following
precaution for handling:
Handling or mounting the RSAT2 unit call for special attention to personal
safety. Personnel should be connected to ground potential via a wristlet (e.g.
3M Wristlet Serial 2200).
Do not touch the p. c. boards during mounting.
Repair the p. c. boards only at static-safe work stations.
Use antistatical protective bags when carrying the p.c. boards.

Remote Control Panel RSAT23. Installation and Startup
6Operating Instructions - Rev. 1 / 11.2001
3.2 DESK MOUNTING
Cut-out dimensions: 441 x 217 mm
Fig. 2: Panel cut out
Unpack the RSAT2 panel and remove the panel module from the mounting box.
The locking mechanism can be removed by the two release tools delivered in
the accessory pack. Therefore the module can be removed very simply.
Disconnect the cables.
Cut-out the openings in the desk.
Put in the mounting box of the panel. For fastening, bores are provided in the
frame. The housing can be fastened with countersunk wood screws with a di-
ameter of 4 mm. The length of the screw depends on the plate thickness of the
desk. A set with mounting parts is included in the delivery of the panel.
Connect the cables into the corresponding plugs of the modules.
Put in the panel module in in the mounting box. By pressing, the modules enga-
ges independently. After mounting the panels please close all locking holes
witch the plastic caps delivered in the accessory pack.


Remote Control Panel RSAT2 3. Installation and Startup
Operating Instructions - Rev. 1 / 11.2001 7
19”Mounting Frame
All dimensions are [ mm ]
482.6
465.1
190.5
265.9
6 Rack units
439
464
240
58 25.8
7
114.5
12.5 215
176.7
Fig. 3: Mechanicak dimensions

Remote Control Panel RSAT23. Installation and Startup
8Operating Instructions - Rev. 1 / 11.2001
3.3 RACK MOUNTING
Caution:
Mounting the RSAT panel has only be done by qualified service personnel
being informed about the dangers involved!
Fig. 4: 19”mounting frame for RSAT2 remote control panel with mounting accessories
Mounting the 19”frame:
Mount the 19”frame into the rack by useing the deliverd accessories
Demount the RSAT2 module by useing the two release tools
(see figures below).
Fig. 5: Release tools
Disconnect control, DC and the ground cable.

Remote Control Panel RSAT2 3. Installation and Startup
Operating Instructions - Rev. 1 / 11.2001 9
Fig. 6: Mounting the RSAT2 case
Put in the RSAT2 case into the 19”frame and fasten it with 6 screws (see acces-
sories).
Connect the cable and put in the RSAT2 module in the case. By pressing, the
module engages independently.
After mounting, please secure the modules with the two locking screws (see
figure below).
Locking mechanism
Fig. 7: Locking the RSAT2 module

PE
Remote Control Panel RSAT23. Installation and Startup
10 Operating Instructions - Rev. 1 / 11.2001
3.4 CONNECTING TO THE DD35 CONTROL PANEL
Attention:
The EMC regulations require the use of properly shielded cables in the instal-
lation of the device or the system. Suitable cables can be ordered from
Philips Broadcast.
MODEM J5B
WIPE SELECTION AUX SELECTION
J6 J7
J5AGPI/GPOPORT 1
PORT 4
J2A
J2B PORT 2
PORT 3
REMOTE
REMOTE 50
PORT 1
PORT 2
J3A
J3B
J4A
J4B
J1
RS 422 CONTROLPANELRS 232 INTERFACE
Re Ω
J2A
Part of the DD35
control panel rear
RS-422 Cable
(Option)
RS-422
Ports
AC INFuses
Befor mounting the Satellite
Panel, switch to ON
Protective Earth
Fig. 8: Power and control connectors
The panel have a PE terminal as protective earth on rear.

Remote Control Panel RSAT2 3. Installation and Startup
Operating Instructions - Rev. 1 / 11.2001 11
3.5 PORT RE-CONFIGURATION RS-422 / RS-232
In case the RSAT2 panel shall be used in connection with a PC, the port can be
configurated as RS-232. For this a RS-232 cable is nesseccary.
Demount the panel module.
Change the flat cable from RS-422/485 connector (right) to the RS-232 con-
nector (left).
Switch the port selection switch to the left position.
RS-422/485 connector
Port selection switch:
Left position: RS-232
Right position: RS-422/485.
RS-232 connector
Fig. 9: Changing the seriall part standard

Remote Control Panel RSAT23. Installation and Startup
12 Operating Instructions - Rev. 1 / 11.2001

Remote Control Panel RSAT2 4. Operation
Operating Instructions - Rev. 1 / 11.2001 13
4. OPERATION
4.1 HOW TO START THE REMOTE PANEL
To start the protocol for the panel use the sidepanel menu. Step into the Install /
Panel / Satpanel menu and select the port number and the type of the protocol.
Fig. 10: DD35 install menu
After that the signal light of the remote panel has to be out. If it so, the panel is alive.
But if you do not have a macro file in your appli_cp.ini file the satellite panel will
be without any function. To add now the filename into the appli_cp.ini use the file
transfer program FTP to get the current appli_cp.ini and insert at the
[SAT_PANEL] under
filename = ”....”
the filename of the macro including the whole path.
E.g. filename = ”/flash/satpanel/me3_crs.sat”.
After the modification of the appli_cp.ini copy the file via FTP back into the mixer.
Now you should see the new function on the satellite panel.
After each new boot the file will be started automatically.

Remote Control Panel RSAT24. Operation
14 Operating Instructions - Rev. 1 / 11.2001
4.2 HOW TO LEARN A NEW FUNCTION
The learn mode is activated by pressing the two buttons left and right of the big (16
character) display simultaneously.
Press the buttons simulaneously
Fig. 11: Learn mode buttons
The message L e a r n i n g . . . will appear in the display. The
learn mode is deactivated the same way as it is activated (by pressing the two but-
tons).
The message “Learning ...”will disappear then.
Es ist sinnvoll erst ein vorhandenes Macro zu laden und dann dieses mit Learn ab-
zuändern! Im Learn–Mode ohne vorhandenes Macro steht die Delegation nicht zu
Verfügung. Delegation kann nicht gelernt werden!!Der Learn–Mode wird für die je-
weils aktive Gruppe (Delegation) aufgerufen.Bei Learn–Mode in der Present–Tas-
tenreihe wird die Program–Tastenreihe nicht automatisch mitgezogen, sondern
mußseperat gelernt werden!
4.2.1 Learning buttons
Alle Kreuzschienennamen wurden übernommen.
Wenn man Buttons ohne Display auf Buttons mit Display legt bleibt das Display
dunkel.
Ensure that you are in learn mode.
Press the desired button on the panel and hold it down.
Press the desired button on the DD35 control panel and then release it.
Release the button on the control panel.
The successful learning will be indicated by a beep (not yet implemented on
the Satellite Panel).

Remote Control Panel RSAT2 4. Operation
Operating Instructions - Rev. 1 / 11.2001 15
4.2.2 Learning digipots
Turn simultaneously two digipots, one on the panel, the other one on the control
panel.
Keep in mind that the space between the digipots on the panel is very narrow
so you probably might have turned more than one digipot (“fat fingers”problem)
and the result of the learning is not what you have expected (the last digipots
“wins”).
Die Diaplays der Digipots werden auch umgelegt.
4.2.3 Learning faders
Move simultaneously two faders, the one and only on the panel and one of the
5 faders of the control panel.
4.3 WHAT CAN BE LEARNED
Interactively all faders and digipots can be learned. As for the buttons, the delega-
tion buttons (the key1, key2 .. buttons in the keyers groups, the second/third but-
tons in the xbars, the Me1Wipe1,.. DVE2 buttons in the wipe group, the 2nd/rot/
user buttons (also wipe group), the arrow buttons in mask and matte group and all
that kind of buttons can NOT be learned).
All other buttons can be.
Displays and underfloor lamps can only be learned by using a setup file.
Note:
Due to the fact that all the functions of the RSAT2 panel can be learned no button
inlays are supplied. They can be easily be made in a do-i-you-self fashion. Printing
on foil e.g. with a laser printer. Foil thickness max. 200 mm.
