1. Technical Specifications and Connection Facilities
1. Technical Specifications and Connection Facilities
1.1 Read / Write Speed
Type of Disc (Function) Disc Rotation Speed
Read Speed CD 7X CAV
Read Speed DVD 4X CAV
Write Speed DVD+R/+RW 2.4X ZCAV
Write Speed DVD-R/-RW 2X
1.2 General:
Mains voltage : 220V – 240V
Mains frequency : 50 Hz
Standby Power Consumption : < 3 W
1.3 RF Tuner
Test equipment: Fluke 54200 TV Signal generator
Test streams: PAL BG Philips Standard test pattern
1.3.1 System
PAL B/G, PAL D/K, SECAM L/L’, PAL I
1.3.2 RF - Loop Through:
Frequency range : 43 MHz – 860 MHz
Gain: (ANT IN - ANT OUT) : -4dB ± 2dB
1.3.3 Receiver:
PLL tuning with AFC for optimum reception
Frequency range : 45.25 MHz – 857 MHz
Sensitivity at 40dB S/N
(video unweighted) : ≤40dBμV at 75 Ω
(high end)
≤60dBμV at 75 Ω
(low end)
1.3.4 Video Performance:
Channel 25 / 503,25 MHz,
Test pattern: PAL BG PHILIPS standard test pattern,
RF Level 74dBV, Measured on SCART 1
Frequency response : 0.1 MHz – 4 MHz ± 3dB
Group delay (0.1 MHz - 4.4 MHz) : 0 nsec ± 150 nsec
1.3.5 Audio Performance:
Audio Performance Analogue - HiFi:
Frequency response at SCART 1
(L+R) output : 100 Hz – 12 kHz / 0 ±
3dB
S/N Ratio (20Hz – 20kHz)
unweighted : ≥40dB
Harmonic distortion (1 kHz, ± 25
kHz deviation) : ≤1.5%
Audio Performance NICAM:
Frequency response at SCART 1
(L+R) output : 40 Hz – 15 kHz / 0 ±
3dB
S/N according to DIN 45405,7,1967
and PHILIPS standard test pattern
video signal : ≥40dB
Harmonic distortion (1kHz) : ≤1.5%
1.3.6 Tuning
Automatic Search Tuning
Scanning time without antenna : 3min. typical
Stop level (vision carrier) : ≥37dBμV
Maximum tuning error (drift) during
operation : ± 100 kHz
Tuning Principle:
Automatic B, G, I, DK and L/L’ detection
Manual selection in “STORE” mode
1.4 Analogue Inputs / Outputs
1.4.1 SCART 1 (Connected to TV)
Pin Signals:
1 Audio-out R 1.8V RMS
2 Audio-in R
3 Audio-out L 1.8V RMS
4 Audio GND
5 Blue / Chroma GND
6 Audio-in L
7 Blue-out 0.7Vpp ± 0.1V into 75W
8 Function switch < 2V = TV
> 4.5V / < 7V = asp. Ratio 16:9 DVD
> 9.5V / < 12V = asp. Ratio 4:3 DVD
9 Green GND
10 P50 control not use
11 Green out 0.7Vpp ± 0.1V into 75W (*)
12 NC
13 Red / Chroma GND
14 Fast switch GND
15 Red-out / 0.7Vpp ± 0.1V into 75Ω
Chroma-out 300mVpp ± 3dB
16 Fast switch
RGB / CVBS
or Y out < 0.4V into 75W = CVBS
>1V / < 3V into 75W = RGB
17 Y/CVBS GND OUT
18 CVBS GND IN
19 CVBS-out 1Vpp ± 0.1V into 75W(*)
20 CVBS-in
21 Shield
1.4.2 SCART 2 (Connected to AUX)
Pin Signals:
1 Audio-out R 1.8V RMS
2 Audio-in R
3 Audio-out L 1.8V RMS
4 Audio GND
5 Blue / Chroma GND
6 Audio-in L
7 Blue-in
8 Function switch
9 Green GND
10 P50 control
11 Green-in
12 NC
13 Red / Chroma GND
14 Fast switch GND
15 Red-in /
Chroma-in
16 Fast switch
RGB / CVBS or Y in
17 CVBS-OUT GND
18 Y/CVBS in GND
19 CVBS out sync 1Vpp ± 0.1V into 75Ω
20 CVBS-in / Y-in
21 Shield
