Philips ExpertClean Sonicare 7300 User manual

ExpertClean
7300, 7500

1
2
11
12
4
3
5
6
7
8
9
10
1

English 6
Deutsch 34
Español 65
Français 95
Italiano 126
Nederlands 155
Português 186
Ελληνικά 215

English
Introduction
Congratulations on your new Philips Sonicare power toothbrush!
Superior plaque removal, whiter teeth and healthier gums are at your
fingertips. Using Sonicare’s combination of gentle sonic technology
and clinically developed and proven features, you can be confident
that you’re getting the very best clean, every time. Further support
and product registration are available to you at:
http://www.philips.com/welcome.
Welcome to the Philips Sonicare family!
Intended Use
ExpertClean series power toothbrushes are intended to remove
adherent plaque and food debris from the teeth to reduce tooth
decay and improve and maintain oral health. ExpertClean series
power toothbrushes are intended for consumer home use. Use by
children should be with adult supervision.
Important safety information
Read this important information carefully before you use the
appliance and save it for future reference.
Note: The accessories and features of different models vary. For
example, some models come with a sanitizer or are equipped with
Bluetooth.
Danger
- Keep the charger and/or sanitizer away
from water. Do not place or store the
appliance where it can fall or be pulled into
a tub or sink.
- Do not immerse the charger and/or sanitizer
in water or any other liquid.
6English

- After cleaning, make sure the charger
and/or sanitizer is completely dry before
you connect it to the wall socket.
Warning
- This appliance can be used by children and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Cleaning and user
maintenance shall not be made by children
without supervision.
- Children shall not play with the appliance.
- Keep the sanitizer out of the reach of
children at all times.
- Stop using the sanitizer if the UV light bulb
remains on when the door is open. UV light
can be harmful to the human eye and skin.
- If the appliance is damaged in any way
(brush head, toothbrush handle, charger
and/or sanitizer), stop using it.
- The mains cord cannot be replaced. If the
mains cord is damaged, discard the charger
and/or sanitizer.
7
English

- Always replace the charger and/or sanitizer
with one of the original type in order to
avoid a hazard.
- This appliance contains no user-serviceable
parts. If the appliance is damaged, contact
the Consumer Care Center in your country
(see 'Warranty and support').
- Keep the cord away from heated surfaces.
- Do not use the charger and/or sanitizer
outdoors or near heated surfaces.
Caution
- Do not clean the brush head, handle,
charger, charger cover or sanitizer in the
dishwasher.
- If you have had oral or gum surgery in the
previous 2 months, consult your dentist
before you use this appliance.
- Consult your dentist if excessive bleeding
occurs after using this appliance or if
bleeding continues to occur after 1 week of
use. Also consult your dentist if you
experience discomfort or pain when you use
this appliance.
8English

- This Philips appliance complies with the
safety standards for electromagnetic
devices. If you have a pacemaker or other
implanted device, contact your doctor or the
appliance manufacturer of the implanted
appliance prior to use.
- If you have medical concerns, consult your
doctor before you use this appliance.
- This appliance has only been designed for
cleaning teeth, gums and tongue. Do not
use it for any other purpose. Stop using the
appliance and contact your doctor if you
experience any discomfort or pain.
- This appliance is a personal care device and
is not intended for use on multiple patients
in a dental practice or institution.
- Do not use other brush heads than the ones
recommended by Philips Sonicare.
- Stop using a brush head with crushed or
bent bristles. Replace the brush head every
3 months or sooner if signs of wear appear.
9
English

- If your toothpaste contains peroxide, baking
soda or bicarbonate (common in whitening
toothpastes), thoroughly clean the brush
head with soap and water after each use.
This prevents possible cracking of the
plastic.
- Avoid direct contact with products that
contain essential oils or coconut oil. Contact
may result in bristle tufts dislodging.
- The UV light bulb of the sanitizer is hot
during and immediately after the sanitizing
cycle. Do not touch the UV light bulb when it
is hot.
- Do not operate the sanitizer without the
protective screen in place to avoid contact
with a hot UV light bulb.
- If you have used the sanitizer for 3 UV clean
cycles in a row, switch it off for at least 30
minutes before you start another UV clean
cycle.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
10 English

Radio Equipment Directive
Hereby, Philips declares that electric toothbrushes with radio
frequency interface (Bluetooth) are in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address: www.philips.com/support
The radio frequency interface in this product operates at 13.56MHz.
The maximum RF power transmitted by the appliance is 30.16dBm.
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Smart brush head(s)*
3 Handle
4 Power on/off button
5 Intensity light
6 Mode/intensity button
7 Modes
8 Brush head replacement reminder light
9 Battery indication
10 Charger
11 Travel case
12 UV Sanitizer*
*Note: The content of the box may vary based on the model
purchased.
Using your Philips Sonicare
Brushing instructions
1Push the brush head firmly onto the handle. Wet bristles and apply
toothpaste.
11
English

Note: It is normal to see a slight gap between the brush head and
the handle. This allows the brush head to vibrate properly.
2Place the toothbrush bristles against the teeth at a slight angle (45
degrees), pressing firmly to make the bristles reach the gumline or
slightly beneath the gumline.
Note: Keep the center of the brush in contact with the teeth at all
times.
3Press the power on/off button to turn on the Philips Sonicare.
45°
4Apply light pressure to maximize Philips Sonicare’s effectiveness
and let the Philips Sonicare toothbrush do the brushing for you.
Gently move the brush head slowly across the teeth in a small
back and forth motion so the longer bristles reach between your
teeth. Continue this motion throughout the brushing cycle.
12 English

Note: To learn how to brush with specific modes, see ‘Modes’.
5To clean the inside surfaces of the front teeth, tilt the brush handle
semi-upright and make several vertical overlapping brushing
strokes on each tooth.
Note:
- A change in vibration from the handle alerts you when you apply
too much pressure (see Pressure sensor)
- Your Philips Sonicare toothbrush is safe to use on braces ,dental
moderations and dental restorations (fillings, crowns, veneers)
- Do not use your power toothbrush in the shower.
Brush heads
To see what type of brush head you have, check the label at the
bottom of the brush head. The symbol at the bottom of the brush
head indicates that it is a smart brush head, equipped with the
BrushSync technology.
13
English

Brush head
name
Premium
Plaque Control Premium White Premium Gum Care
Brush head
label
C3 W3 G3
Benefit Plaque removal Plaque and
stain removal Healthier Gums
To explore our full range of brush heads, go to
www.philips.com/toothbrush-heads for more information.
Note: The type of brush heads vary based on the model purchased.
BrushSync Technology
BrushSync technology enables your brush heads to communicate
with your handle using a microchip. The symbol at the bottom of the
brush head indicates that it is equipped with the BrushSync
technology. This enables the following features:
- Brush Head Mode Pairing
- Brush Head Replacement Reminder
Brushing modes
Your power toothbrush is equipped with 4 different modes*: Clean,
Deep Clean+, White+* and Gum health*.
Based on the smart brush head you use, the mode will be selected
automatically.
To manually change the mode, press the mode/intensity button while
the toothbrush is off.
14 English

* Note:
- The modes vary based on the model purchased.
- All brush heads work with each mode.
- When the Philips Sonicare toothbrush is used in clinical studies, it
must be used at high intensity, with the EasyStart feature turned off.
Brush head mode pairing
Brush heads with BrushSync technology are equipped with a
microchip chip which communicates to the handle and automatically
pairs it with the recommended mode and intensity.
Note: If you change modes/intensity, the handle will remember the
last used setting. If you wish to brush with the recommended setting,
you can find the recommended mode/intensity in ‘Brushing Modes’.
Clean and
Deep Clean +
White+ Gum Health
Benefit Plaque removal Plaque and
surface stains
removal
Plaque removal
and gum
massage
Recommended
brush head
Premium
Plaque Control*
(C3)
Premium
White* (W3) Optimal Gum Care* (G3)
Recommended
intensity level
3 3 3
15
English

Clean and
Deep Clean +
White+ Gum Health
Total brushing
time
Clean: 2
minutes
Deep Clean: 3
minutes
2 minutes and
40 seconds 3 minutes and 20 seconds
How to brush Clean: Brush
each segment
for 20 seconds
1
2
3
4
5
6
Deep Clean:
Brush each
segment for 30
seconds
1
2
3
4
5
6
Brush each
segment for 20
seconds,
1
2
3
4
5
6
then brush
segments 1 and
2 for 20
seconds each.
1
2
Brush each
segment for 30
seconds,
1
2
3
4
5
6
then brush
segments 1, 2, 3
and 4 for 20
seconds each.
1
2
4
3
*Note: The modes and type brush head vary based on the model
purchased.
Intensity settings
Your power toothbrush comes with 3 different intensity settings: low,
medium and high. When attached to the handle, the smart brush
16 English

head will automatically select the recommended intensity. To
manually change the intensity, turn on the handle and press the
mode/intensity button.
While toothbrush is
ON, press this
button to change
intensity setting
Features
- EasyStart
- Connected Brush experience
- Brush head replacement reminder
- Pressure sensor
- BrushPacer
Easy-Start
The EasyStart feature gently increases the power of the handle over
the first 14 brushings to help you get used to the brushing power of
the Philips Sonicare.
The EasyStart feature works with all modes.
Note: The EasyStart feature comes deactivated with your product. To
activate EasyStart, see 'Activating or deactivating features'.
Sonicare App - Connected brushing experience
The Sonicare app pairs with your toothbrush to provide you with
interactive brushing features. By brushing with your Sonicare app
account, you will be able to:
17
English

- Receive brushing suggestions and personalized feedback
- Track your brushing progress over time
To start using the connected brushing features:
1Download the Sonicare app to your phone
2Follow the steps in the app setup
3Pair your toothbrush with the app
4Create your account
5Personalize your app by answering questions about your brushing
habits and interests
6Start your connected brushing experience
Note: Make sure your phone’s Bluetooth is turned on when using the
connected brushing features.
Note: If you have any questions while setting up your account, be
sure to review the Sonicare Privacy Statement, available throughout
the app setup process.
How to Brush with the App
1Go to the Brushing Screen in the app and select Start Brushing.
2First brushing starts on the upper right molar. You can customize
your starting location in Settings.
3Follow the brushing guidance.
Tip: To ensure the best performance of the brushing sensors, keep
your head looking forward.
4Gently begin brushing. The app will highlight the correct segment.
The timer will help you keep track.
5Move your brush head when the highlighted segment changes.
6Repeat, until you finish brushing all segments.
7When done brushing, review and touch up any missed areas.
Follow the in-app instructions on how to use the touch-up feature.
Brush Head Replacement Reminder
The handle will track the wear of your smart brush head. Over time,
the handle will track the wear of your smart brush head by measuring:
- The overall pressure you apply while brushing
- The total time you’ve brushed with your brush head
18 English

Once your brush head is no longer effective, the Brush Head
Replacement Reminder will blink amber. This indicates that it is
recommended to change your brush head.
Note: The Brush Head Replacement Reminder comes activated with
your product. To deactivate this feature, see 'Activating or
deactivating features'.
Pressure sensor
Your Philips Sonicare measures the pressure you apply while
brushing to protect your gums and teeth from damage.
If you apply too much pressure, the handle will change its vibration
until you reduce the pressure.
Note: The Pressure Sensor comes activated with your product. To
deactivate this feature, see 'Activating or deactivating features'.
Brush Pacer
The BrushPacer features indicates when you are supposed to move
onto the next section of your teeth via a brief change in vibration.
The toothbrush will automatically turn off at the end of the brushing
session.
Charging and battery status
Charging
1Plug the charger into an electrical outlet.
2Place the handle on the charger.
3The charging indicator will flash green until your toothbrush is fully
charged.
19
English

Note: Your handle comes pre-charged for first use. After first use,
charge for at least 24 hours.
Charging on stand or Sanitizer
1Plug the charger or sanitizer into an electrical outlet.
2Place the handle on the charger or sanitizer.
3The charger will charge your toothbrush until it is fully charged.
Charging with the travel case
Note: Only the following ExpertClean handles can be charged in the
charging travel case: HX972G, HX972K, HX972V, HX972P.
The HX number can be found on the bottom of your handle.
Note: The charging travel case requires a USB adapter to charge the
handle. The USB adapter is not included.
1Connect the charging travel case to 5V DC input power either from:
-a UL-listed or certified to ANSI/UL 60950-1 personal
computer's standard USB connector or,
-a UL-listed or certified to ANSI/UL 60950-1 LPS power supply
with USB output port or,
-a UL-listed or certified 1310 Class 2 power supply.
2The travel case will charge your toothbrush until your toothbrush is
fully charged.
Note: Charging the handle with the charging travel case may take
longer than on the charger.
Battery Status (handle on plugged in charger)
When the handle is placed on the charger, sanitizer or travel case ,
the battery light will flash green based on the current battery level.
Number of Flashing LEDs Battery charging status
1 Low
2 Medium
3 High
20 English
