Philips Sonicare DiamondClean 9000 User manual

DiamondClean
9000

4
3
5
6
8
12
14
13
11
10
7
9
1
2
1

English 6
Español 35
Français (Canada) 66

English
Introduction
Congratulations on your new Philips Sonicare power
toothbrush! Superior plaque removal, whiter teeth and healthier
gums are at your fingertips. Using Sonicare’s combination of
gentle sonic technology and clinically developed and proven
features, you can be confident that you’re getting the very best
clean, every time. Further support and product registration are
available to you at: http://www.philips.com/welcome.
Welcome to the Philips Sonicare family!
Intended Use
DiamondClean series power toothbrushes are intended to
remove adherent plaque and food debris from the teeth to
reduce tooth decay and improve and maintain oral health.
DiamondClean series power toothbrushes are intended for
consumer home use. Use by children should be with adult
supervision.
IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USE
When using electrical products, especially when children are
present, basic safety precautions should always be followed,
including the following:
6English

DANGERS
To reduce the risk of electrocution:
-Do not place or store product where it can fall or be pulled
into a tub or sink.
-Do not place in or drop into water or other liquid.
-Do not use while bathing.
-Do not immerse the charger in water or any other liquid.
-After cleaning, make sure the charger is completely dry
before you connect it to a power outlet.
-Do not reach for a product that has fallen into water. Unplug
immediately.
WARNINGS
To reduce the risk of burns, electrocution, fire or physical injury:
-Do not clean the brush head, the handle or the charger in the
dishwasher.
-Do not use attachments other than those recommended by
Philips Sonicare.
-Never use a charger with a damaged cord or plug.
-Always replace the charger with one of the original type in
order to avoid a hazard.
-Do not plug into an outlet with a voltage other than specified
on the bottom of the product. This product is designed to
operate within a range of 100 to 240 volts. Voltage converters
do not warrant voltage compatibility.
-Never force the plug into an outlet; if the plug does not easily
fit into the outlet, discontinue use.
-Discontinue use if the product appears damaged in any way
(brush head, handle or charger, etc.).
7
English

-The power cord cannot be replaced. If the power cord is
damaged, discard the charger.
-Keep the power cord away from heated surfaces.
-This product contains no user-serviceable parts. Refer to
‘Warranty and support’ if the product no longer works
properly or needs repair.
-Do not use the charger outdoors.
-Do not use the charger if dropped into water
-This product is designed to clean your teeth, gums and
tongue only. Use this product only for its intended use as
described in this booklet. Discontinue use of this product and
contact a physician/dentist if discomfort or pain is
experienced.
-This product is not intended for use by persons (including
children) with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
-Children should be supervised to ensure that they do not
play with the product.
-Philips Sonicare is a personal care device and is not intended
for use on multiple patients in a dental office or institution.
-This appliance contains no serviceable parts. If the appliance
is damaged, contact the Consumer Care Center in your
country (see chapter 'Warranty and support').
-For connection to a supply not in the U.S.A., use a charger of
the proper configuration for the power outlet.
-Use a UL-listed computer, USB Hub, or USB duplex
receptacle when charging the handle in the travel case.
-Avoid direct contact with products that contain essential oils
or coconut oil. Contact may result in bristle tufts dislodging.
8English

-If your toothpaste includes peroxide, baking soda or other
bicarbonate (common in whitening toothpastes), thoroughly
clean your brush head and handle with soap and water after
each use. Otherwise plastic cracking may occur.
MEDICAL WARNINGS
1Consult your dental professional before you use this product
if you have had oral or gum surgery in the previous 2 months.
2Contact your dental professional if excessive bleeding occurs
after using this product or bleeding continues to occur after 1
week of use.
3Discontinue use of this product and contact a
physician/dentist if discomfort or pain is experienced.
4This product complies with the safety standards for
electromagnetic devices. If you have a pacemaker or other
implanted device, contact your physician or the device
manufacturer prior to use.
5Consult your physician if you have other medical concerns.
SAVE THESE
INSTRUCTIONS
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Smart brush heads*
3 Handle
4 Power on/off button
5 Intensity light
6 Mode/intensity button
7 Modes
8 Brush head replacement reminder light
9 Battery indication
9
English

10 Charging glass
11 Charging stand
12 Charging base
13 (Charging)Travel case*
14 USB wall adapter*
* Note: The content of the box may vary based on the model
purchased.
Sonicare app – Getting Started
The Sonicare app pairs with your toothbrush to provide you a
connected experience. By connecting your toothbrush to your
Sonicare app account, you will be able to:
-Easily review your progress report for ways to improve your
brushing routine
-Receive personalized tips and recommendations for
managing your oral health
To start using the Sonicare app:
1Download the Sonicare app to your phone
2Open the app and follow the guided steps
3Pair your toothbrush with the app
4Create your account
5Complete firmware update, if prompted, to access the latest
improvements and features.
6Brush regularly
You are ready to start your connected experience. Be sure to
brush regularly. You can receive updates to help improve your
oral healthcare.
Note: Make sure your phone’s Bluetooth is turned on when
using the app. Your toothbrush uses the Bluetooth connection
to transfer your brushing data to the app. If you have questions
about why your brushing data is collected, be sure to review the
10 English

Sonicare Privacy Statement, available throughout the app setup
process.
Sonicare app – Track and improve your oral health
care
Your Sonicare power toothbrush is equipped with smart sensors
to provide you with feedback about your brushing habits,
including:
-Daily brushing sessions
-Time spent during each brushing session
-Applied brushing pressure
-Brush head replacement reminder (based on actual use)
The Sonicare app collects the data provided by the smart
sensors and tracks your brushing habits over time.
Each of the features available in the app are designed to help
you understand your brushing habits and provide you with
simple recommendations for improving and maintaining your
oral health. You will receive personalized brushing information
in the Sonicare app.
Brush heads
To see what type of brush head you have, check the label at the
bottom of the brush head. The symbol at the bottom of the
brush head indicates that it is a smart brush head, equipped
with the BrushSync technology.
11
English

Brush head
name
Premium
Plaque
Control
Premium
White
Premium Gum
Care
Brush head
label
C3 W3 G3
Benefit Plaque
removal
Plaque and
stain removal
Healthier
gums
To explore our full range of brush heads, go to
www.philips.com/toothbrush-heads for more information.
Using your Philips Sonicare
Brushing instructions
1Push the brush head firmly onto the handle. Wet the bristles
and apply toothpaste.
Note: It is normal to see a slight gap between the brush head
and the handle. This allows the brush head to vibrate
properly.
2Place the toothbrush bristles against the teeth at a slight
angle (45 degrees), apply light pressure to make the bristles
reach the gumline or slightly beneath the gumline.
Note: Keep the center of the brush head in contact with the
teeth at all times.
12 English

3Press the power on/off button to turn on the Philips
Sonicare.
45°
4Apply light pressure to maximize Philips Sonicare’s
effectiveness and let the Philips Sonicare toothbrush do the
brushing for you. Gently move the brush head slowly across
the teeth in a small back and forth motion so the longer
bristles reach between your teeth. Continue this motion
throughout the brushing cycle.
Note: Different modes are available (see 'Brushing modes').
5To clean the inside surfaces of the front teeth, tilt the brush
handle semi-upright and make several vertical overlapping
brushing strokes on each tooth.
13
English

Note:
- A change in vibration from the handle alerts you when you
apply too much pressure (see 'Pressure sensor').
- Your Philips Sonicare toothbrush is safe to use on braces,
dental modifications and dental restorations (fillings, crowns,
veneers)
- Do not use your power toothbrush in the shower.
BrushSync technology
BrushSync technology enables your brush heads to
communicate with your handle using a microchip. The symbol at
the bottom of the brush head indicates that it is equipped with
the BrushSync technology. This enables the following features:
-Brush head mode pairing
-Brush head replacement reminder
Brushing modes
Your power toothbrush is equipped with 4 different modes:
clean, white+, gum health and deep clean+.
Based on the smart brush head you use, the optimal mode and
intensity will be selected automatically by the BrushSync
technology.
To manually change the mode, press the mode/intensity button
while the toothbrush is off with the brush head attached.
14 English

* Note:
- All brush heads work with each mode.
- When the Philips Sonicare toothbrush is used in clinical
studies, it must be used at high intensity, with the EasyStart
feature turned off.
Brush head mode pairing
Brush heads with BrushSync technology are equipped with a
microchip which communicates to the handle and automatically
pairs it with the recommended mode and intensity.
Note:If you change modes/intensity, the brush head will
remember the last used setting. If you wish to brush with the
recommended setting, you can find the recommended
mode/intensity in ‘Brushing Modes’.
Brush head mode pairing
Brush heads with BrushSync technology are equipped with a
microchip which communicates to the handle and automatically
pairs it with the recommended mode and intensity.
Note:If you change modes/intensity, the brush head will
remember the last used setting. If you wish to brush with the
recommended setting, you can find the recommended
mode/intensity in the following table.
15
English

clean and
deep clean+
white+ gum health
Benefit Plaque
removal
Plaque and
surface stains
removal
Plaque
removal and
gum massage
Recommend
ed
brush head
Premium
Plaque
Control (C3)
Premium
White (W3)
Premium Gum
Care (G3)
Recommend
ed
intensity level
3 3 3
Total
brushing time
clean: 2
minutes
deep clean+:
3 minutes*
2 minutes and
40 seconds
3 minutes and
20 seconds
16 English

clean and
deep clean+
white+ gum health
How to brush clean: Brush
each segment
for 20
seconds
1
2
3
4
5
6
deep clean+:
Brush each
segment for
30 seconds*
1
2
3
4
5
6
Brush each
segment for
20 seconds,
1
2
3
4
5
6
then brush
segments 7
and 8 for 20
seconds each.
7
8
Brush each
segment for
20 seconds,
1
2
3
4
5
6
then brush
segments 7, 8,
9 and 10 for
20 seconds
each.
7
8
10
9
*Note: When brushing with the Sonicare app in 'deep clean+'
mode, the brushing time will be 2 minutes.
Intensity settings
Your power toothbrush comes with 3 different intensity settings:
-low intensity (one bar)
17
English

-medium intensity (two bars)
-high intensity (three bars)
When attached to the handle, the smart brush head will
automatically select the recommended intensity. To manually
change the intensity, turn on the handle and press the
mode/intensity button.
While toothbrush
is ON, press this
button to change
the intensity
setting
Features
-BrushPacer
-Pressure sensor
-Brush head replacement reminder
-EasyStart
BrushPacer
The BrushPacer features indicates when you have to move to
the next section of your teeth with a brief change in vibration.
The toothbrush turns off automatically at the end of the
brushing session.
Pressure sensor
Your Philips Sonicare measures the pressure you apply while
brushing to protect your gums and teeth from damage.
If you apply too much pressure, the handle will change its
vibration until you reduce the pressure.
18 English

Note: The Pressure Sensor comes activated with your product.
To deactivate this feature, see 'Activating or deactivating
features'.
Brush head replacement reminder
Over time, the handle will track the wear of your smart brush
head by measuring:
-The overall pressure you apply while brushing
-The total time you have brushed with your brush head
Once your brush head is no longer effective, the brush head
replacement reminder will blink amber and the handle will make
a series of beeps and tones.
Note: The brush head replacement reminder comes activated
with your product. To deactivate this feature, see 'Activating or
deactivating features'.
EasyStart
The EasyStart feature gently increases the power of the handle
over the first 14 brushings to help you get used to the brushing
power of the Philips Sonicare.
The EasyStart feature works with all modes.
19
English

Note: The EasyStart feature comes deactivated with your
product. To activate EasyStart, see 'Activating or deactivating
features'.
Charging and battery status
Charging on charger base
1Plug the cord of the charging base into an electrical outlet.
2Place the charging stand or the charging glass on the
charging base.
3Place the handle on the charging stand or in the charging
glass.
4The charger will charge your toothbrush until it is fully
charged.
20 English
