Introduction
Congratulations on your purchase and welcome to Philips!To fully
benet from the support that Philips offers, register your product at
www.philips.com/welcome.
Important
READ ALL INSTRUCTIONS BEFORE USE
Danger
- Do not immerse, place or store the charger over or near water. Do
not reach for a charger that has fallen into water. Unplug immediately.
After cleaning, make sure the charger is completely dry before you
connect it to the mains.
Warning
- The mains cord cannot be replaced. If the mains cord is damaged,
discard the charger. Always have the charger replaced with one of the
original type in order to avoid a hazard.
- Discontinue use if this product appears damaged in any way (brush
head, charger, toothbrush handle). Cord, plugs and batteries cannot
be replaced. This appliance contains no user-serviceable parts.
- Do not use the charger outdoors or near heated surfaces.
- This appliance is not intended for use by children or persons with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless supervised or instructed in use by a person
responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
Electromagnetic elds (EMF)
This appliance complies with current standards regarding electromagnetic
elds (EMF). If used as directed this appliance is safe.
ENGLISH

The Sonicare (Fig. 1)
1 Replaceable brush head
2 Power on/off button
3 Handle
4 Hygienic travel cap
5 Charger
Getting started
Attaching the brush head
1 Align the front of the brush head with the front of the toothbrush
handle.
2 Push the brush head onto the metal shaft. (Fig. 2)
Note:When the brush head is attached, it is normal that there is a small gap
between the brush head and the handle.
Charging the Sonicare
1 Put the plug of the charger in the wall socket.
2 Place the handle on the charger.
Note:To keep the batteries fully charged at all times, you may keep your
toothbrush on the charger when not in use. It takes approximately 30 hours
to fully charge the batteries.When the toothbrush is used in clinical studies,
the handle should be fully charged.
Using the Sonicare
1 Wet the bristles of the toothbrush and apply a small amount of
toothpaste (Fig. 3).
2 To avoid splattering, place the brush head in your mouth before
switching the toothbrush on.
3 Press the power on/off button to switch on the toothbrush
ENGLISH 5

4 Brush like you normally would do. (Fig. 4)
Note:To achieve optimal results, thoroughly brush your entire mouth. Brush
the outside, the inside and chewing surfaces of your teeth, as well as your
gums.
5 Apply light pressure to maximise the toothbrush’s effectiveness. Do
not press too hard.
6 The toothbrush will automatically turn off after two minutes.
7 You may also brush your tongue, with the toothbrush turned on or
off, as you prefer.
The toothbrush is safe to use on:
- Braces (brush heads wear out sooner when used on braces)
- Dental restorations (llings, crowns, veneers)
Notes
- Consult your dentist if you have had oral surgery in the previous 2
months, if excessive bleeding occurs right after using this appliance or
if bleeding continues to occur after 1 week of use.
- This appliance has only been designed for cleaning teeth, gums and
tongue. Do not use it for any other purpose. Stop using the appliance
and contact your doctor if you experience any discomfort or pain.
- The toothbrush is a personal care device and is not intended for use
on multiple patients in a dental practice or institution.
Features
2 minute-timer
- After 2 minutes, the timer automatically switches off the toothbrush.
Cleaning
Do not clean brush heads, the handle or the charger in the dishwasher.
1 Rinse the brush head and bristles after each use. Let the brush
head air-dry only (Fig. 3).
ENGLISH6

2 Remove the brush head from the handle and rinse the brush head
connection at least once a week with warm water. (Fig. 5)
3 Periodically wipe the surface of the handle with a damp cloth and
mild soap (Fig. 6).
4 Unplug the charger and periodically wipe its surface with a damp
cloth.
Note: If your toothpaste contains peroxide, baking soda or other bicarbonate
(common in whitening toothpastes), thoroughly clean the brush head and the
handle with soap and water after each use. Otherwise the plastic may crack.
Storage
If you are not going to use the toothbrush for a long time (a month or
longer), unplug the charger, clean the appliance and store it in a cool and
dry place away from direct sunlight.
Replacement
Brush head
- Replace Sonicare brush heads every 3 months to achieve optimal
results.
- Do not use a brush head with crushed or bent bristles. Replace the
brush head every 3 months or sooner if signs of wear appear.
- Use only Philips Sonicare brush heads.
Note: Use of Sonicare for Kids brush heads are not recommended with this
toothbrush.
Environment
- Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the environment (Fig. 7).
ENGLISH 7

- The built-in rechargeable batteries contain substances that may
pollute the environment. Always remove the batteries before you
discard and hand in the appliance at an ofcial collection point.
Dispose of the batteries at an ofcial collection point for batteries. If
you have trouble removing the batteries, you can also take the
appliance to a Philips service centre. The staff of this centre will
remove the batteries for you and will dispose of them in an
environmentally safe way (Fig. 8).
Removing the rechargeable batteries
1 To deplete the rechargeable batteries of any charge, remove the
handle from the charger, switch on the toothbrush and
let it operate until it stops. Repeat this step until you can no longer
switch on the toothbrush.
2 Insertaat-head(standard)screwdriverintotheslotlocatedat
the bottom of the handle.Turn the screwdriver anti-clockwise to
release the bottom cap (Fig. 9).
3 Hold the handle upside down and push down on the shaft to
release the internal components of the handle (Fig. 10).
4 Cut the wires to disconnect the batteries from the housing.
5 Placeaat-head(standard)screwdriverontoeachofthethree
snaps and tap with a hammer to break the snaps. (Fig. 11)
6 Separate the bottom cap from the housing and remove the
rechargeable batteries.
7 The rechargeable batteries can now be recycled and the rest of the
appliance discarded appropriately.
Guarantee and service
If you need information or if you have a problem, please visit the Philips
website at www.philips.com/support or contact the Philips Customer
Care Centre in your country. You nd its phone number in the worldwide
guarantee leaet. If there is no Customer Care Centre in your country, go
to your local Philips dealer.
ENGLISH8

Guarantee restrictions
The terms of the guarantee do not cover the following:
- Brush heads
- Damage caused by misuse, abuse, neglect, alterations or unauthorized
repair.
- Normal wear and tear, including chips, scratches, abrasions,
discolouration or fading.
ENGLISH 9

10
Pendahuluan
Selamat atas pembelian Anda dan selamat datang di Philips! Untuk
memanfaatkan sepenuhnya dukungan yang ditawarkan Philips, daftarkan
produk Anda di www.philips.com/welcome.
Penting
BACA SEMUA PETUNJUK SEBELUM MENGGUNAKAN
Bahaya
- Jangan merendam, meletakkan atau menyimpan pengisi daya di atas
atau di dekat air. Jangan mengambil pengisi daya yang jatuh ke dalam
air. Segera cabut stekernya. Setelah membersihkan, pastikan pengisi
daya benar-benar kering sebelum Anda menghubungkannya ke arus
listrik.
Peringatan
- Kabel listrik tidak bisa diganti. Jika kabel listrik rusak, buang pengisi
daya. Selalu ganti pengisi daya dengan tipe yang asli untuk menghindari
bahaya.
- Hentikan penggunaan jika tampak kerusakan pada produk (kepala
sikat, pengisi daya, gagang sikat gigi). Kabel, colokan dan baterai tidak
bisa diganti. Alat ini tidak memiliki bagian yang bisa diperbaiki
pengguna.
- Jangan gunakan pengisi daya di luar ruangan atau dekat permukaan
panas.
- Alat ini bukan untuk digunakan oleh anak-anak atau orang dengan
cacat sik, indera atau kecakapan mental yang kurang, atau kurang
pengalaman dan pengetahuan, kecuali diawasi atau diarahkan oleh
orang yang bertanggung jawab atas keselamatan mereka.
- Anak kecil harus diawasi untuk memastikan mereka tidak bermain-
main dengan alat ini.
Medan elektromagnet (EMF)
Alat ini mematuhi standar yang berkenaan dengan medan elektromagnetik
(EMF). Jika digunakan sesuai petunjuk, alat ini aman.
INDONESIA

Sonicare (Gbr. 1)
1 Kepala sikat yang dapat diganti
2 Tombol daya
3 Gagang
4 Tutup yang higienis
5 Pengisi daya
Persiapan awal
Memasang kepala sikat
1 Sejajarkan bagian depan kepala sikat dengan bagian depan gagang
sikat gigi.
2 Tekan kepala sikat ke poros logam. (Gbr. 2)
Catatan: Saat kepala sikat terpasang, sedikit celah antara kepala sikat dan
gagang adalah hal yang normal.
Mengisi daya Sonicare
1 Masukkan colokan pengisi daya ke stopkontak dinding.
2 Pasang gagang ke pengisi daya.
Catatan:Agar baterai tetap terisi penuh,Anda dapat memasang sikat gigi
pada pengisi daya saat tidak digunakan. Mengisi daya baterai hingga penuh
memerlukan waktu sekitar 30 jam. Saat sikat gigi digunakan dalam studi
klinis, gagangnya harus terisi daya penuh.
Menggunakan Sonicare
1 Basahi bulu sikat gigi dan beri sedikit pasta gigi (Gbr. 3).
2 Agar tidak tumpah, masukkan kepala sikat ke dalam mulut sebelum
menghidupkan sikat gigi.
3 Tekan tombol on/off untuk menghidupkan sikat gigi
4 Sikat gigi seperti biasa. (Gbr. 4)
INDONESIA 11

Catatan: Untuk hasil optimal, sikat seluruh bagian mulut Anda. Sikat bagian
luar, dalam dan permukaan atas gigi Anda, serta gusi Anda.
5 Tekan sedikit untuk memaksimalkan kerja sikat gigi. Jangan tekan
terlalu keras.
6 Sikat gigi akan otomatis mati setelah dua menit.
7 Anda juga bisa menyikat lidah Anda saat sikat gigi dalam keadaan
hidup atau mati, sesuai keinginan Anda.
Sikat gigi aman digunakan pada:
- Kawat gigi (kepala sikat lebih cepat rusak bila digunakan pada kawat
gigi)
- Restorasi gigi (tambalan, mahkota, veneer)
Catatan
- Konsultasilah pada dokter gigi jika Anda baru mengalami operasi
mulut dalam 2 bulan terakhir, jika timbul pendarahan berlebihan
setelah menggunakan alat atau jika pendarahan berlanjut setelah 1
minggu penggunaan.
- Alat ini hanya dirancang untuk membersihkan gigi, gusi dan lidah.
Jangan gunakan untuk keperluan lain. Hentikan penggunaan alat dan
hubungi dokter Anda jika mengalami rasa tidak nyaman atau sakit.
- Sikat gigi adalah perangkat perawatan pribadi dan bukan untuk
digunakan oleh beberapa orang pasien pada praktik atau institusi gigi.
Fitur
Timer 2 menit
- Setelah 2 menit, timer secara otomatis mematikan sikat gigi.
Membersihkan
Jangan membersihkan kepala sikat, gagang atau pengisi daya dalam mesin
pencuci piring.
1 Bilas kepala sikat dan bulu sikat setelah setiap penggunaan. Biarkan
kepala penyikat kering dengan sendirinya (Gbr. 3).
INDONESIA12

2 Lepaskan kepala sikat dari gagang dan bilas sambungan kepala
penyikat dengan air hangat setidaknya seminggu sekali. (Gbr. 5)
3 Secara teratur, seka permukaan gagang dengan kain lembap dan
sabun lembut (Gbr. 6).
4 Cabut colokan pengisi daya dan secara teratur seka permukaannya
dengan kain lembap.
Catatan: Jika pasta gigi mengandung peroksida, baking soda atau bikarbonat
lainnya (umumnya terdapat dalam pasta gigi pemutih), bersihkan kepala
sikat dan gagang secara menyeluruh dengan air dan sabun setelah setiap
penggunaan. Jika tidak, plastiknya bisa retak.
Penyimpanan
Jika Anda tidak akan menggunakan sikat gigi untuk waktu yang lama (satu
bulan atau lebih), cabut colokan pengisi daya, bersihkan alat dan simpan
di tempat yang sejuk dan jauh dari sinar matahari langsung.
Penggantian
Kepala sikat
- Ganti kepala sikat Sonicare setiap 3 bulan untuk memperoleh hasil
yang optimal.
- Jangan gunakan kepala sikat dengan bulu sikat yang hancur atau
bengkok. Ganti kepala sikat setiap 3 bulan atau kurang jika ada tanda
keausan.
- Gunakan hanya kepala sikat Philips Sonicare.
Catatan: Penggunaan kepala sikat Sonicare untuk Anak tidak disarankan
untuk sikat gigi ini.
Lingkungan
- Jangan membuang alat bersama limbah rumah tangga biasa jika alat
sudah tidak dapat dipakai lagi, tetapi serahkan ke tempat pengumpulan
barang bekas yang resmi untuk didaur ulang. Dengan melakukan hal
ini, Anda ikut membantu melestarikan lingkungan (Gbr. 7).
INDONESIA 13

- Baterai isi-ulang yang terpasang mengandung bahan yang dapat
mencemari lingkungan. Selalu keluarkan baterai sebelum membuang
alat atau serahkan alat ke tempat pengumpulan resmi. Buang baterai
di tempat pengumpulan resmi untuk baterai. Jika Anda kesulitan
mengeluarkan baterai, Anda juga dapat membawa alat tersebut ke
pusat servis Philips. Staf di sana akan membantu mengeluarkan baterai
dan membuangnya dengan cara yang aman bagi lingkungan (Gbr. 8).
Melepas baterai isi-ulang
1 Untuk menghabiskan daya baterai isi-ulang, lepaskan gagang dari
pengisi daya, hidupkan sikat gigi dan biarkan beroperasi hingga
berhenti. Ulangi langkah ini hingga Anda tidak bisa menghidupkan
sikat gigi.
2 Masukkan obeng datar (standar) ke dalam slot di bagian bawah
gagang. Putar obeng berlawanan arah jarum jam untuk melepaskan
tutup bawah (Gbr. 9).
3 Pegang gagang secara terbalik dan tekan poros ke bawah untuk
melepaskan komponen internal gagang (Gbr. 10).
4 Gunting kabel untuk melepaskan baterai dari rangka.
5 Pasang obeng datar (standar) ke masing-masing dari tiga pengunci
dan ketuk dengan palu untuk membuka pengunci. (Gbr. 11)
6 Pisahkan tutup bawah dari rangka dan lepaskan baterai isi-ulang.
7 Baterai isi-ulang kini bisa didaur ulang dan bagian alat lainnya bisa
dibuang dengan cara yang sesuai.
Garansi dan layanan
Jika Anda perlu informasi atau jika Anda memiliki masalah, silakan kunjungi
situs web Philips di www.philips.com/support atau hubungi Pusat Layanan
Konsumen Philips di negara Anda. Anda bisa menemukan nomor
teleponnya di kartu garansi internasional. Jika tidak ada Pusat Layanan
Konsumen di negara Anda, kunjungi dealer Philips setempat.
INDONESIA14

Batasan garansi
Ketentuan garansi tidak mencakup yang berikut:
- Kepala sikat
- Kerusakan akibat kesalahan penggunaan, penyalahgunaan, kelalaian,
perubahan, atau perbaikan tidak resmi.
- Kerusakan dan keausan normal, seperti pecahan kecil, goresan, lecet,
perubahan warna atau memudar.
INDONESIA 15

16
소개
필립스 제품을 구입해 주셔서 감사합니다! 필립스가 드리는 지원 혜택을
받으실 수 있도록 www.philips.co.kr에서 제품을 등록하십시오.
중요 사항
본 제품을 사용하기 전에 이 사용 설명서를 주의 깊게 읽고 나중
에 참조할 수 있도록 잘 보관하십시오.
위험
-충전기를 물에 담그거나 물이 가까이 있는 곳에 보관하거나
두지 마십시오. 물에 떨어진 충전기를 만지지 마십시오. 물에
떨어뜨린 경우 즉시 플러그를 뽑으십시오. 청소한 후에는 충
전기가 완전히 건조된 다음 본체에 연결하십시오.
경고
-전원 코드는 교체할 수 없습니다. 전원 코드가 손상된 경우 충
전기를 폐기하십시오. 손상된 충전기는 위험한 상황을 방지하
기 위해 정품으로 교체하여 사용하십시오.
-제품에 손상된 부분(칫솔모, 충전기, 핸들)이 나타나면 사용을
중단하십시오. 코드, 플러그, 배터리는 교체할 수 없습니다.
이 제품에는 서비스되는 부품이 없습니다.
-충전기를 실외 또는 발열되는 표면 근처에서 사용하지 마십시오.
-신체적인 감각 및 정신적인 능력이 떨어지거나 경험과 지식이
풍부하지 않은 성인 및 어린이는 혼자 제품을 사용하지 말고
제품 사용과 관련하여 안전에 책임질 수 있도록 지시사항을
충분히 숙지한 사람의 도움을 받으십시오.
-어린이가 제품을 가지고 놀지 못하도록 지도해 주십시오.
EMF(전자기장)
이 제품은 EMF(전자기장)와 관련된 현재 기준을 준수합니다. 지
침대로 사용하는 경우 본 제품은 안전합니다.
소닉케어 (그림 1)
1 교체형 칫솔모
2 전원 버튼
3 손잡이
4 여행용 위생 칫솔모 뚜껑
한국어

5 충전기
시작하기
칫솔모 부착 방법
1 칫솔손잡이및칫솔모를앞면으로조정하십시오.
2 칫솔모를금속샤프트쪽으로미십시오.(그림2)
참고:칫솔모부착시칫솔모와핸들사이가약간벌어지는것은
정상입니다.
소닉케어 충전
1 충전기플러그를벽면콘센트에꽂으십시오.
2 충전기에손잡이를꽂으십시오.
참고:배터리를항상완전히충전된상태로유지하려면칫솔을
사용하지않을때에도충전기에꽂아두십시오.배터리를완전히
충전하려면약30시간이걸립니다.임상연구에사용할때는핸
들을완전히충전해야합니다.
소닉케어 사용 방법
1 칫솔모를물로적신후소량의치약을바르십시오(그림3).
2 칫솔모를입안에넣은상태에서전원을켜면치약이튀지않
습니다.
3전원버튼을눌러소닉케어를켜십시오.
4 평상시대로이를닦으십시오.(그림4)
참고:최적의결과를얻으려면입안전체를완벽히닦으십시오.
어금니와잇몸안쪽및바깥쪽을모두닦으십시오.
5 소닉케어를효과적으로사용하려면칫솔모로약하게문지르
십시오.너무세게문지르지마십시오.
6 칫솔은2분후에자동으로꺼집니다.
7 혀를닦을때는칫솔을켜거나끈상태중선호하시는방법을
선택하십시오.
한국어 17

칫솔은 다음과 같은 경우에 사용해도 안전합니다.
-치아 교정기(교정기에 사용하는 경우 칫솔모가 보다 빨리 마
모될 수 있습니다.)
-치아 보철물(신경치료, 크라운, 라미네이트)
메모
-최근 2개월 내에 구강 수술을 받았거나 제품 사용 후 출혈이
심하거나 1주일이 지나도 증상이 호전되지 않는다면 치과 전
문의와 상의하십시오.
-본 제품은 치아와 잇몸, 그리고 혀만 세정할 수 있도록 만들어졌으므로
다른 용도에는 사용하지 마십시오. 사용 중 불편함이나 통증이
느껴지면 제품 사용을 중단하고 의사와 상의하십시오.
-칫솔은 개인 용품이므로 치과나 기타 의료 시설에서 공용으로
이용하지 마십시오.
기능
2분 타이머
-2분이 지나면 타이머 기능이 자동으로 작동을 멈춥니다.
청소
칫솔모,핸들또는충전기를식기세척기로세척하지마십시오.
1 매번사용후에브러시헤드및칫솔모를물로헹구십시오.
브러시헤드는자연건조하십시오(그림3).
2 핸들에서칫솔모를제거하고매주1회칫솔모와핸들사이연
결부분을따뜻한물로닦아줍니다.(그림5)
3젖은천과중성비누로핸들부분을정기적으로닦으십시
오(그림6).
4 충전기의전원코드를뽑은다음젖은천을사용하여정기적
으로표면을닦으십시오.
참고:사용하는치약성분에과산화수소,탄산수소나트륨,기타
중탄산염(미백치약주성분)이포함된경우이용후에칫솔모및
손잡이를비누로닦고물로깨끗이씻어내십시오.그렇지않으면
플라스틱에금이갈수도있습니다.
한국어18

보관
장기간(한 달 이상) 칫솔을 사용하지 않을 경우, 충전기의 전원
코드를 뽑은 다음 제품을 청소하고 직사광선이 없는 건냉한 장소
에 보관하십시오.
교체
칫솔모
-최적의 결과를 얻으려면 3개월에 한 번씩 소닉케어 칫솔모로
교체하십시오.
-눕거나 휘어진 칫솔모는 사용을 중단하십시오. 마모 증상이 나타나면
칫솔모를 교체하거나 3개월마다 정기적으로 교체하십시오.
-필립스 소닉케어 칫솔모만 사용하십시오.
참고:본칫솔에소닉케어어린이용칫솔모사용은권장하지않
습니다.
환경
-수명이 다 된 제품은 일반 가정용 쓰레기와 함께 버리지 마시
고 지정된 재활용 수거 장소에 버리십시오. 이런 방법으로 환
경 보호에 동참하실 수 있습니다 (그림 7).
-내장형 충전식 배터리는 환경 오염 물질을 포함하고
있습니다. 제품을 폐기하기 전에 항상 배터리를 분리하고
지정된 수거 장소에 버리십시오. 배터리는 반드시 지정된
배터리 수거함에 버리십시오. 배터리를 분리하기 어려울 경우
필립스 서비스 센터로 제품을 가져오시면 배터리를 분리하여
환경에 안전한 방법으로 폐기해 드립니다 (그림 8).
충전식 배터리 분리
1 충전식배터리를제거하려면충전기에서핸들을제거하고소
닉케어를켠다음멈출때까지작동합니다.더이상소닉케어
를켤수없을때까지이단계를반복합니다.
2 일자형(표준)드라이버를핸들아래쪽의슬롯에넣습니다.드라이버를
반시계반대방향으로돌려아래쪽뚜껑을풉니다(그림9).
한국어 19

3손잡이를뒤집은채로샤프트를아래로눌러손잡이내부
부품을분리합니다(그림10).
4 전선을잘라본체에서배터리를분리합니다.
5 일자형(표준)드라이버를세개스냅위에올려놓고해머로
눌러스냅을제거합니다.(그림11)
6 본체에서아래쪽뚜껑을분리하고충전식배터리를꺼냅니다.
7 충전식배터리는재활용할수있으며제품의나머지부분은
적절하게폐기하십시오.
품질 보증 및 서비스
보다 자세한 정보가 필요하시거나, 사용상의 문제가 있을 경우에
는 필립스전자 홈페이지(www.philips.com/support))를 방문하시
거나 필립스 고객 상담실로 문의하십시오. 전국 서비스센터 안내
는 제품 보증서를 참조하십시오. *(주)필립스전자: (02)709-
1200 *고객 상담실: [phone](수신자부담)
보증 제한
보증 약관에서 제외되는 항목은 다음과 같습니다.
-칫솔모
-오용, 남용, 부주의, 개조 또는 무단 수리로 인한 손상
-쪼개짐, 긁힘, 마멸, 변색, 탈색 등, 일반적인 마모 또는 손상
한국어20
