Philips Trilogy Evo Universal User manual

Instructions for Use | Introduction
Trilogy Evo Universal Instructions for Use
For Technical Support and Customer Service, contact Philips Customer Service:
USA
Respironics Inc.
1001 Murry Ridge Lane Murrysville, PA 15668
Email: [e-mail], [e-mail]
Web: www.philips.com\healthcare
Authorized European Representative:
Respironics Deutschland GmbH & Co. KG
Gewerbestrasse 17
D-82211 Herrsching Germany
[phone]
Copyright © 2018 Koninklijke Philips N.V. All rights reserved.
This work is protected under Title 17 of the United States copyright code and is the sole property of Philips Respironics. No part
of this document may be copied or otherwise reproduced, or stored in any electronic information retrieval system, except as
specifically permitted under United States copyright law, without the prior written consent of Philips Respironics.
Trilogy Evo Universal is the registered trademark of Respironics Inc.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
Philips Respironics is under license.
Dawn Ultra is a registered trademark of Procter & Gamble.
Other trademarks and trade names are those of their respective owners.
Illustrations and screen images in this document are representative depictions.

Instructions for Use | Introduction
Contents
1. Introduction ................................................................4
Intended Use...................................................................4
Environments of Use.......................................................4
Contraindications............................................................4
Package Contents............................................................5
Warnings.........................................................................5
Symbols Glossary ............................................................9
How to Contact Philips Respironics ..............................11
2. About Trilogy Evo Universal ......................................12
Parts of Trilogy Evo Universal...........................................12
Parts of the User Interface............................................14
Monitoring Window......................................................15
3. Therapy Modes and Controls....................................17
Overview.......................................................................17
Control Modes ..............................................................19
Spontaneous Modes .....................................................21
Mixed Modes ................................................................23
Therapy Features ..........................................................25
Therapy Actions ............................................................27
Therapy Control Settings ..............................................27
Dynamic Therapy Parameters.......................................29
4. Device Setup .............................................................31
Setup Overview.............................................................31
Placement .....................................................................31
Connecting AC Power ...................................................31
Installing Filters.............................................................31
Connecting a Circuit......................................................33
Adding Oxygen..............................................................35
Starting Trilogy Evo Universal .......................................36
5. Device Operation ......................................................37
Clinical Assessment.......................................................37
Entering New Patient Information................................37
About Prescriptions ......................................................37
Starting and Stopping Ventilation .................................39
Actions during Ventilation ............................................39
6. Alarms and System Messages .................................. 41
Overview ...................................................................... 41
About Alarms................................................................ 41
The Alarm List............................................................... 42
Setting and Changing Alarms........................................ 42
Setting the Alarm Volume ............................................ 43
Responding to an Alarm ............................................... 43
Resetting Alarms .......................................................... 43
Alarms and System Messages ...................................... 44
Prescription Alarm Availability by Therapy Mode ........ 60
Testing Alarms .............................................................. 60
Alarm and Event Log .................................................... 63
7. Device Options ......................................................... 65
Device Settings ............................................................. 65
Calibration .................................................................... 66
Data Transfer................................................................ 68
Information .................................................................. 70
8. Cleaning and Disinfection......................................... 71
Exterior Cleaning and Disinfection ............................... 71
Cleaning the Detachable Battery.................................. 72
Rinsing the Air-Inlet Foam Filter................................... 72
External Active Exhalation Valve Cleaning and
Disinfection .................................................................. 73
9. Service and Maintenance ......................................... 75
Service .......................................................................... 75
Disposal ........................................................................ 75
Routine Maintenance................................................... 75
Replacing the Air-Inlet Foam Filter............................... 75
Replacing the Particulate Filter .................................... 76
Preparing the Device for a Use by a Different Patient.. 76
10. Trilogy Evo Universal Accessories......................... 77
Power Accessories........................................................ 77
Patient Monitors .......................................................... 77
Filters............................................................................ 80
Patient Circuits ............................................................. 81
Circuit Accessories........................................................ 81
Dual Limb Active Exhalation Valve ............................... 82
Oxygen ......................................................................... 82
Portability and Travel Accessories................................ 83

Instructions for Use | Introduction
Intended Use 3
11. Power Management .............................................84
Power Sources ..............................................................84
Battery Power Indicator................................................84
Battery Status Indicator ................................................84
AC Power........................................................................84
External Battery ............................................................85
Detachable Battery .......................................................85
Internal Battery .............................................................86
Power Loss ....................................................................86
Power Indicator Icons ...................................................86
12. Technical Specifications ........................................88
Specifications ............................................................... 88
Standards Compliance.................................................. 91
Pneumatic Diagram ...................................................... 92
EMC Information .......................................................... 92
13. Wireless Connectivity ........................................... 96
Bluetooth Actions......................................................... 96
NFC Actions .................................................................. 97
Troubleshooting ........................................................... 97
14. Glossary ................................................................ 98
15. Warranty ............................................................ 100

Instructions for Use | Introduction
1. Introduction
The Trilogy Evo Universal ventilator is a medical device intended for use by qualified, trained personnel under the direction of a
physician according to its technical specifications.
Intended Use
The Trilogy Evo Universal ventilator provides invasive and non-invasive positive pressure ventilation for the care of patients
≥2.5 kg through adults. The ventilator can measure, display, record, and alarm SpO2, FiO2, CO2, respiratory rate, and pulse rate
data when integrated with the appropriate accessories. The ventilator is suitable for use in institutional and hospital settings
and non-emergency transport settings; for example, wheelchair, personal vehicle, or ambulance.
Environments of Use
The Trilogy Evo Universal ventilator is intended to be used:
•In institutional environments.
•While attached to a wheelchair, bedrail, gurney, roll stand, or sitting on a flat surface such as a table or nightstand.
•While transporting patients within and between facilities such as automobile or commercial aircraft.
Contraindications
If the patient has any of the following conditions, consult the patient’s health care professional before using noninvasive
ventilation:
•An inability to maintain a patent airway or adequately clear secretions
•At risk to aspirate gastric contents
•Acute sinusitis or otitis media
•Epistaxis, causing pulmonary aspiration of blood
•Hypotension

Instructions for Use | Introduction
Warnings 5
Package Contents
Warnings
Environmental
•You should not operate Trilogy Evo Universal in the presence of flammable gasses.
•Do not cover the ventilator or place in a position that affects proper operation.
•Do not block the cooling and intake air vents.
•Do not operate Trilogy Evo Universal in an environment that is outside the specified ranges. Using the ventilator outside
of this temperature range or above this altitude can affect the ventilator performance.
•The blower warms the temperature of the airflow. Use of the device at room temperatures warmer than 40˚C may cause
thermal irritation.
•Do not expose the device or detachable battery to temperatures above 60˚ C (140˚ F) during use or above 70˚ C (158˚ F)
during storage. This will reduce battery life and may increase the risk of fire or damage the battery.
•The Trilogy Evo Universal is not intended for MRI or anesthesia applications, and is not intended to be permanently
mounted in EMS vehicles.
•When disposing of this device or any accessories, ensure you comply with your local regulations. Dispose of any
potentially biohazardous waste according to your local regulations.

Instructions for Use | Introduction
Warnings 6
•This device is intended for use in the electromagnetic environment specified in the “EMC Information” chapter. Ensure
the environment is compatible. Portable and mobile RF communications equipment, including cables, should be no closer
to any part of the device than the recommended separation distance indicated in the “EMC Information” chapter.
•This device is not made with natural rubber latex.
•Do not use the ventilator in a hyperbaric chamber.
•Do not use the ventilator in the presence of nitric or nitrous oxide.
•Do not use the ventilator with helium or in the presence of mixtures in combination with helium.
•Route all cables in a manner to prevent injury, such as tripping or strangulation, to the patient and caregiver.
Clinical
•Before placing a patient on the ventilator, perform a clinical assessment. Considerations should include:
-Choosing alarm settings
-Whether alternative ventilation equipment is required
-Whether alternative monitors are required, such as Vte monitoring for Active PAP circuit, pulse oximeter or
respiratory monitor with alarm
•Trilogy Evo Universal is a restricted medical device. It is designed for use by respiratory therapists or other trained and
qualified caregivers under the supervision of a physician. Only the supervising physician’s orders authorize changes to the
prescription and other device settings. Before using Trilogy Evo Universal, you must read and understand this manual.
•When using the ActivePAP circuit, CO2monitoring is required to measure exhaled carbon dioxide, in accordance with ISO
80601-2-55.
•Unintentional leaks cause exhaled volume and expired CO2values to differ from actual patient values.
•The caregiver or health care professional is responsible for verifying any changes to the device, prescription, or other
settings before applying changes. The caregiver or health care professional is responsible for ensuring settings are correct
and compatible with the patient. Using the wrong prescription for a patient may result in improper therapy, lack of
appropriate safety monitoring, or risk of death or injury to the patient.
Alternate Ventilation
•To avoid patient death or serious injury, ventilator-dependent patients require immediate access to alternate ventilation
equipment, such as a back-up ventilator or manual resuscitator.
•Qualified personnel should monitor ventilator-dependent patients continuously. Personnel should be prepared to provide
alternate therapy in the event of ventilator failure or inoperative equipment.
Alarms
•Do not rely on any single alarm to detect a disconnected circuit.
•Respond immediately to any high priority alarm. It may indicate a potentially life-threatening condition.
•Visually monitor the patient and ventilator at all times during an Alarm Silence period.Allowing alarms to continue
without intervention may result in harm to the patient.
•If the high-priority Low Battery alarm occurs, immediately connect the ventilator to an alternate power source. If no
alternate power source is available, immediately place the patient on an alternate source of ventilation.
•When using a remote alarm, make sure you fully test the remote alarm connector and cable by verifying that:
-You can hear the ventilator’s audible alarms on the remote alarm.
-The remote alarm signals when you disconnect the remote alarm cable from the ventilator or from the
remote alarm
•Test the operation of the circuit disconnect function daily and whenever the patient circuit is changed. An increase in
circuit resistance can prevent proper operation of some alarms.

Instructions for Use | Introduction
Warnings 7
•Speaking valves, heat moisture exchangers (HMEs), humidifiers, and filters create additional circuit resistance and may
affect the performance of alarms chosen for circuit disconnect protection.
•Do not set the Low Peak Inspiratory Pressure alarm too low, or the system may not detect large circuit leaks or a patient
disconnect.
Accessories
•Use Trilogy Evo Universal only with accessories intended for use with this device. Otherwise, adverse performance
including increased electromagnetic emissions or decreased electromagnetic immunity of this equipment can occur. For a
list of accessories, such as patient interfaces, circuits, exhalation ports, and cables, see the Trilogy Evo Universal
accessories guide. Ensure accessories and parts are compatible before you connect a patient to the device. Consult the
accessory’s instructions before use.
•The air-inlet foam filter is required to protect the ventilator from dirt and dust. See the “Service and Maintenance”
chapter for maintenance instructions.
•Be certain that any breathing system filter used with this device complies with ISO 23328-1 and ISO 23328-2. · To prevent
patient or ventilator contamination, we recommend you use a Respironics-approved main flow bacteria filter (Part
Number 342077) on the patient gas outlet port. Filters not approved by Respironics may degrade system performance.
•When adding any components (such as humidifiers, speaking valves, heat moisture exchangers, and filters) to the
breathing system, consider the flow resistance and dead space in relation to the potential for adverse effects on the
patient’s ventilator management and device alarms.
•Nebulization or humidification can increase the resistance of breathing system filters. Monitor the breathing system
frequently for increased resistance and blockage.
•Gas added by the use of a pneumatic nebulizer can adversely affect ventilator accuracy.
•When using a passive circuit an exhalation port is required. At low expiratory pressures, the flow through the exhalation
port may be inadequate to clear all exhaled gas from the tubing – some rebreathing may occur.
•Do not use antistatic or conductive hoses or conductive patient tubing with the device.
•The ventilator system (used with patient circuit accessories, such as patient interface devices, humidifiers, water traps, and
circuit tubing) may contain small parts that could result in a choking hazard.
•Be certain that any humidifier in use, including any heated breathing tube, complies with ISO 8185.
Oxygen
•This device is equipped with an oxygen blender that can deliver oxygen to the patient within a range of 21-100%
concentration.
•To ensure accuracy of oxygen administration when using the oxygen blender, use the internal FiO2accessory or an
external oxygen monitor that complies with ISO 80601-2-55 to verify the oxygen concentration in the delivered gas.
•Substantial leaks may reduce the inspired oxygen concentration to less than the expected value. Use appropriate patient
monitoring, as medically indicated, such as an alarming pulse oximeter.
•Do not connect the device to an unregulated oxygen source.
•Do not use oxygen while smoking or in the presence of an open flame.
•Turn off the oxygen flow when the device is not in use.
Cleaning and Maintenance
•To avoid electric shock, do not remove the enclosure cover. Only service personnel should remove the enclosure.
•Do not immerse the device or allow liquids into any of the controls or the interior of the enclosure as the device may be
damaged. If this occurs, contact your equipment provider for assistance. Use only the agents and methods described in

Instructions for Use | Introduction
Warnings 8
this manual to clean and disinfect the device.After cleaning and disinfecting, ensure the device is completely dry before
reattaching accessories and connectors and before reconnecting it to a power source. Do not use solvents, polishes, or
any oily substances on the device, as they are flammable.
•If the device has been exposed to rain or dampness, dry the device including the area around the power cord connection
with the power cord disconnected from the device before applying ACpower.
•Repairs andadjustments must beperformed by service personnel only. Unauthorized service could cause death or injury,
invalidate the warranty, orresult incostly device damage.
•If you notice any unexplained changes in the performance of the device, ifitismaking unusual sounds, ifthe device or
detachable battery is dropped, ifwater isspilled into the enclosure, orifthe enclosure is cracked or broken, discontinue
use and contact Philips Respironics.
•To avoid electrical shock, always unplug the power cord from the wall outlet before cleaning the ventilator.
•Periodically inspect electrical cords, cables, and the detachable battery pack for damage orsigns of wear. Discontinue use
and replace ifdamaged.
•No modification of this equipment isallowed. Any changes or modifications made to the device that are not expressly
approved by Respironics may void the user’s authority to operate the equipment.
Power
•Do not connect the ventilator to thebattery ofa battery-powered wheelchair as this can affect the ventilator performance,
which can result in patient death.
•An external battery should only be connected to the ventilator using the Philips Respironics approved External Battery
Cable. This cable is fused, pre-wired, and properly terminated toensure safe connection

Instructions for Use | Introduction
Symbols Glossary 9
Symbols Glossary
This glossary contains the symbols on the model label and on the device exterior. Software symbol explanations appear
throughout this book. For a complete explanation of symbols appearing on the device and associated labels, go to the
following web address:
http://www.symbols.philips.com
Symbol
Definition
Symbols on the Model and Warning Label
Refer to instruction manual
Prescription device
Not made with natural rubber latex
For airline use. Complies with RTCA D0160
section 21, category M
Bluetooth symbol
This equipment includes RF transmitters.
IP22: protection against finger-sized objects
and protected against dripping water when
tilted up to 15 degrees.
Catalog number
Batch code
Serial number
Manufacturer
Date of manufacture
Class II equipment
BF applied part
LI-ion recycling
Waste electrical & electronic equipment
Humidity limit
Temperature limit
Symbols on the Device
On/Off (Standby) button
Alarm Silence button
USB connection
Nurse call connection
DC power (direct current)
AC power (alternating current)
Symbol
Definition
Oxygen inlet
Low flow oxygen inlet
Flow sensor cable connection
Proximal pressure out
AEV control line
Patient in
Patient out
Symbols on the Screen - General
Prescription settings
Home screen
Options
Help
Manual breath
Deliver 100% oxygen
Delete prescription
Patient type indicators
Touch screen lock
Edit
Wi-Fi
Symbols on the Screen - Alarms
Alarms tab
Alarm Silence
High priority alarm

Instructions for Use | Introduction
Symbols Glossary 10
Medium or low priority alarm
System message
Alarm reset
Symbols on the Screen – Monitoring Views
See chapter 2, “About Trilogy Evo.”
Symbols on the Screen - Power
See the Power Management chapter.
Symbols on the Screen –Connectivity
Bluetooth enabled
Bluetooth connected
USB is exporting data

Instructions for Use | Introduction
How to Contact Philips Respironics 11
How to Contact Philips Respironics
If you need help setting up, using or maintaining Trilogy Evo Universal, or if this device does not perform as expected, contact Philips Respironics.
Call Philips Respironics Customer Service at:
•1-724-387-4000
•1-800-345-6443 (toll-free)
•[phone] (international)

Instructions for Use | About Trilogy Evo Universal
Parts of Trilogy Evo Universal 12
2. About Trilogy Evo Universal
Parts of Trilogy Evo Universal
Front Panel
1. On/off (standby) button
2. AC power indicator
3. Alarm indicator/alarm silence
4. Alarm bar
5. Touch screen
6. Ambient light sensor
Back Panel
1. Carrying handle
2. FiO2sensor access panel
3. Power cord retention clip
4. Air inlet
5. Oxygen blender
6. High pressure oxygen inlet
7. Air vents

Instructions for Use | About Trilogy Evo Universal
Parts of Trilogy Evo Universal 13
Patient Panel
1. Accessory USB port
(pulse oximeter, CO2monitor)
2. Inspiratory port (to patient)
3. Proximal pressure port
4. Active exhalation valve line connection for
ActivePAP and Active Flow circuits
5. Dual limb active exhalation valve connection (from
patient)
6. Flow sensor cable connector
Utility Panel
1. AC power connector
2. Air vents
3. Low flow oxygen inlet
4. Detachable battery access door
5. Micro USB Port for device service
6. Accessory USB Port (USB external storage
device, communication cables)
7. Remote alarm or nurse call connector (RJ9)
8. DC power connector

Instructions for Use | About Trilogy Evo Universal
Parts of the User Interface 14
Parts of the User Interface
Standard Screen Elements
1. Menu bar
2. Main window
3. Monitored parameters pane
4. Status bar
Menu Bar
Use the menu bar to navigate, manage alarms, and see the active prescription at a glance.
1. Home: view the main window
2. Prescriptions: manage patient prescriptions
3. Options:
-Device Settings
-Calibration
-Data Transfer
-Information
-Alarm & Event Log
4. Patient type indicator

Instructions for Use | About Trilogy Evo Universal
Monitoring Window 15
Main Window
The main window contents vary depending on the action you are performing. The main window can show the standby window, prescription
window, monitoring window, and others.
Monitored Parameters Pane
Use the monitored parameters pane to see measured and calculated
values while delivering therapy. These values vary based on the circuit,
therapy mode, and accessory type.
Depending on the accessories you use, values such as SpO2appear
during active ventilation and during standby.
Parameters that may appear are:
-PIP: peak inspiratory pressure
-Vte: exhaled tidal volume
-RR: respiratory rate
-MinVent: minute ventilation
-SpO2: saturation of peripheral oxygen
-Pulse Rate
-etCO2: end tidal carbon dioxide
Status Bar
Use the status bar to monitor device status and the availability of manual therapeutic actions.
1
Manual breath
8
Wi-Fi
2
Deliver 100% Oxygen
9
Alarm silence
3
100% Oxygen timer
10
Power sources and their status
4
CMD
11
5
USB data transfer
12
6
Bluetooth
13
Device Actions Menu
7
Bluetooth data transfer
14
System time
Monitoring Window
During ventilation, a monitoring window, or home screen, contains information such as measured parameters and battery status. You can select
the type of information you want to see.
Selecting a Monitoring View
To select a monitoring view during ventilation:
1. In the Menu Bar, tap the Home button.
2. In the monitoring window, tap the Views button
3. In the Views menu, tap the type of view you want to use.

Instructions for Use | About Trilogy Evo Universal
Monitoring Window 16
Types of monitoring windows
Monitoring windows may vary based on your model.
Views menu icon
Monitoring window contents
Small manometer
-Manometer pressure indicator
-Set parameters
Measured and
calculated
parameters
-Set parameters
-Measured and calculated parameters
-Additional parameters based on the prescription (including
accessories)
-This is the default view.
An explanation of dynamic parameters is in chapter 3, “Therapy
Modes.”
Large manometer
-Large manometer pressure indicator
-Six measured and calculated parameters
Waveform graphs
-Customizable scalar waveform graphs
To customize the graphs, use the buttons in the window as follows:
Button
Description
Select the waveforms to graph. On
the Select Waveforms dialog box,
select data for the top and bottom
graphs.
Pause graphing.
Automatically size the vertical scale
to fit the data.
Tap to change the time scale, and
then select a new time scale from
the list.

Instructions for Use | Therapy Modes and Controls
Overview 17
3. Therapy Modes and Controls
Overview
Trilogy Evo Universal therapy modes can be used for invasive and noninvasive ventilation with all circuit types, including mouthpiece ventilation.
Breath Types
Trilogy Evo Universal can deliver the following breath types:
oMandatory: Ventilator-initiated, time-cycled
oAssist-Control: Patient-initiated, time-cycled
oSpontaneous: Patient-initiated, patient-cycled
Triggering and Cycling
Patient triggers
Auto-Trak is a flow trigger with rules that make patient-triggering and cycling more comfortable for the patient. The system uses multiple
algorithms to detect the start and end of the breath. Also, it automatically adjusts the trigger and cycle sensitivity to optimize synchronization
between the patient and the ventilator.
Sensitive Auto-Trak is a more sensitive version of Auto-Trak
Flow trigger initiates a breath when the patient’s inspiratory effort creates a flow equal to or greater than the flow trigger sensitivity setting. A
lower number is more sensitive. As inspiratory flow begins to decrease, the device cycles to expiration when the patient flow is less than the
percentage of peak flow, based on the flow-cycle sensitivity setting.
Ventilator trigger
Time Trigger is time-based, defined by the Breath Rate setting.
Flow patterns
Ramp wave pattern: airflow starts high and decreases throughout inspiration of the breath.
Square wave pattern: airflow is generally constant throughout inspiration of the breath.
Therapy Modes Overview
Control Modes: breaths are assist-control or mandatory.
•A/C-PC: Assist control – assist-control and mandatory breaths with pressure control
•A/C-VC: Assist control – assist control and mandatory breaths with volume control
Spontaneous modes: the patient initiates all breaths.
•CPAP: Continuous positive airway pressure
•PSV: Pressure support ventilation

Instructions for Use | Therapy Modes and Controls
Overview 18
Mixed modes: breaths are spontaneous, assist-control, or mandatory.
•S/T: Spontaneous/timed ventilation – spontaneous breaths with pressure support and mandatory breaths with pressure control
•SIMV-PC: Synchronized intermittent mandatory ventilation (pressure control) – spontaneous breaths with pressure support, assist—
control breaths and mandatory breaths with pressure control
•SIMV-VC: Synchronized intermittent mandatory ventilation (volume control) – spontaneous breaths with pressure support, assist—
control breaths and mandatory breaths with volume control
Low Tidal Volume Therapy
For low tidal volume therapy, use the infant/pediatric external flow sensor. See the instructions included with the sensor.
When setting volumes greater than or equal to 50ml, use any circuit type.
When setting volumes greater than or equal to 35ml, use either the active flow or dual limb circuits.
The following pressure modes are available for patients who require a tidal volume less than 35ml:
•A/C-PC
•PSV
•S/T
•SIMV-PC
Therapy Mode Comparison Table
For all modes, the breath type varies based on time of patient inspiration. The breath type is always ventilator-initiated and mandatory when the
Trigger Type is set to Off.
Mode
Breath Types
Trigger Source
Inspiration
Cycle
Exhalation
Control Modes
A/C-PC
Assist-Control
Patient
Pressure Control +PEEP Inspiratory
Time PEEP
Mandatory Ventilator
(Breath Rate)
A/C-VC
Assist-Control
Patient
Tidal Volume Inspiratory
Time PEEP
Mandatory Ventilator
(Breath Rate)
Spontaneous Modes
CPAP
Spontaneous
Patient
CPAP
Patient
CPAP
PSV Spontaneous Patient Pressure Support + PEEP Patient PEEP
Mixed Modes
S/T
Spontaneous
Patient
IPAP
Patient
EPAP
Mandatory Ventilator
(Breath Rate)
Inspiratory
Time
SIMV-PC
Spontaneous Patient
Pressure Support + PEEP
Patient PEEP
Assist-Control
Patient
Pressure Control + PEEP Inspiratory
Time PEEP
Mandatory Ventilator
(Breath Rate)
SIMV-VC
Spontaneous Patient
Pressure Support + PEEP
Patient PEEP
Assist-Control
Patient
Tidal Volume Inspiratory
Time PEEP
Mandatory Ventilator
(Breath Rate)

Instructions for Use | Therapy Modes and Controls
Control Modes 19
Control Modes
A/C-PC: Assisted/Control-Pressure Control
DESCRIPTION:
The A/C-PC mode provides pressure-controlled mandatory or assist-control breaths. When the Trigger Type is set to Off, the ventilator triggers and
cycles all breaths. When the Trigger Type is not set to Off, then the ventilator or the patient can trigger a breath, and the ventilator cycles all
breaths.
SETTINGS:
Setting Name
Description
Pressure Control
Inspiratory pressure above PEEP
PEEP
Positive end expiratory pressure
Rise Time
Time required for the ventilator to change from the expiratory pressure setting to the inspiratory
pressure setting when the breath is triggered.
Breath Rate
Minimum rate of breaths per minute
Inspiratory Time
Length of the inspiratory phase
Trigger Type
•Auto-Trak (passive circuits only)
•Sensitive Auto-Trak (passive circuits only)
•Flow Trigger (Passive, Active PAP, Active Flow, or Dual Limb circuits)
•Off
Flow Trigger
Sensitivity
This control is available when the trigger type is Flow Trigger. The flow trigger initiates when the
patient’s inspiratory effort creates a flow equal to or greater than the flow trigger sensitivity setting.
Flow Cycle
Sensitivity
This control is available when the trigger type is Flow Trigger.
As flow begins to decrease during inspiration, if the patient flow is less than the flow cycle set point, the
device cycles to expiration.
FiO
2
(optional)
Requires model with oxygen blender
SETTABLE ALARMS:
•Circuit disconnect
•High tidal volume
•Low tidal volume
•High minute ventilation
•Low minute ventilation
•High respiratory rate
•Low respiratory rate
ILLUSTRATION
1. EPAP
2. Pressure control

Instructions for Use | Therapy Modes and Controls
Control Modes 20
A/C-VC: Assisted/Control-Volume Control
DESCRIPTION:
The A/C-VC mode provides volume-controlled mandatory and assist breaths. When the Trigger Type is set to Off, both triggering and cycling are
performed by the ventilator. When the Trigger Type is not Off, then the trigger can be performed by the vent or patient and the cycle is always
performed by the ventilator. To deliver the set volume in the set time, the ventilator alters the flow rate. The flow pattern setting defines the shape
of the flow delivery pattern.
SETTINGS:
Setting Name
Description
Tidal Volume
Set inspiratory volume
PEEP
Positive end expiratory pressure
Inspiratory Time
Length of the inspiratory phase
Breath Rate
Minimum rate of mandatory breaths per minute
Flow Pattern
Sets the shape of the waveform as a ramp or square
Trigger Type
•Auto-Trak
•Sensitive Auto-Trak (passive circuits only)
•Flow Trigger (Passive, Active PAP, Active Flow, or Dual Limb circuits)
•Off
Flow Trigger
Sensitivity
This control is available when the trigger type is Flow Trigger. The flow trigger initiates when the
patient’s inspiratory effort creates a flow equal to or greater than the flow trigger sensitivity setting.
Flow Cycle
Sensitivity
This control is available when the trigger type is Flow Trigger.
As flow begins to decrease during inspiration, if the patient flow is less than the flow cycle set point, the
device cycles to expiration.
SETTABLE ALARMS:
•Circuit disconnected
•High tidal volume
•Low tidal volume
•High minute ventilation
•Low minute ventilation
•High respiratory rate
•Low respiratory rate
•High inspiratory pressure
•Low inspiratory pressure
ILLUSTRATION
