Philips HR7772/00 User manual

ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Foodprocessor
HR7772/00
09/03
PRODUCT INFORMATION
Features
- Extra Large feeding tube The XL feeding tube takes whole fruits and vegetables so you don’t need to pre-cut them
anymore.
- Large 3.4L bowl The large 3.4 L bowl allows for maximum volumes to be processed in 1 go: capacity for 2 L
soup, 1.7 kg dough, 7 egg whites.
- 31 functions 7 tools for 31 different functions. They are: a SS blade for chopping, crumbling, cutting,
mashing, mincing; a reversible slicing disk; a shredding disk for medium or fine shredding
or grating; whisk accessory for whipping, whisking, emulsifying, stirring, mixing, creaming,
beating; a kneading tool for heavy mixing, kneading, folding in; a blender for blending,
crushing, foaming, grinding, (heavy) pureeing, homogenizing, liquidizing, milling, shaking,
stirring, measuring; a citrus press for pressing citrus fruits.
- 700 W motor + 3 speed With the powerful 700 W motor plus 3 speed button you can adjust speed precisely to get
desired results.
- Sturdy base The sturdy base comes with suction feet to ensure it does not move, even when you use it for
heavy applications like kneading dough.
Accessories
- Chopping knife Chopping, beating, creaming, crumbling, cutting, folding in, mashing, mincing
- Kneading tool For kneading, heavy kneading, mixing dough, batter
- Whisk Accessory Whisking, whipping, mixing and emulsifying
- Reversible shredding disk For medium and fine shredding
- Reversible slicing disk For medium and fine slicing
- Break resistant blender For blending, crushing, foaming, grinding, pureeing, homogenizing, liquidizing, milling,
shaking, stirring
- Citrus press For pressing of citrus fruits

HR7772/00
2-6
Safety
- Automatic resettable thermal cut off Protecting the motor against overheating.
- Built-in safety lock Detects whether lid & bowl are assembled.
- Brake system Stops the accessories within 1,5 seconds.
SPECIFICATIONS
General specifications Integrated cord storage, Non-slip feet
Technical Specifications
- Cord length 1,20 m
- Voltage 220 - 240 V
- Frequency 50 - 60 Hz
- Bowl volume capacity dry 3,4 l
- Bowl working capacity liquid 2 l
- Bowl working capacity dough 1700 g
- Bowl working capacity flour 1000 g
- Blender working capacity 1,5 l
- Safety Lid & bowl detection, mechanical 1,5 sec brake
- Speeds 3 speed
- Function buttons Pulse, rotary
Design specifications
- Housing, bottom, speed knob, pusher ABS
- Toolholder PA + 30 %
- Disks, chopping blade Stainless steel
- Kneading tool, citrus press PP
- Colours Bright white, citrus yellow, paprika red, capoeira grey
- Bowl + lid, blender, inner pusher SAN
- Knife protection PET
Product size:
Length : 230 mm
Width : 230 mm
Height : 170/400 mm (with food pusher)
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues.
REPAIR INSTRUCTION
- No specific issues.
TECHNICAL INFORMATION

HR7772/00
3-6
PARTS LIST
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
4203 035 87710
4203 035 87720
4203 035 87730
4203 035 88050
4203 035 88010
4203 035 87760
4203 035 87770
4203 035 88060
4203 035 88070
4203 035 87800
4203 035 88080
4203 035 88090
4203 035 87830
4203 035 87840
4203 035 87850
4203 035 82650
4203 035 87860
4203 035 87870
4203 035 87880
4203 035 87890
4203 035 87900
4203 035 87910
4203 035 88020
4203 035 88030
4203 035 87940
4203 035 87950
4203 035 87970
4203 035 87980
4203 035 87990
4203 035 88000
Housing
Bottom + airtunnel
Sucker Foot (1 pcs)
Motor - incl. wires + gearing
3 speed Switch knob assembly
PCBA HR7772
Holder safety switch I
Safety switch HR7772
Cordset WEu
Cordset Storage Box
Holder safety switch II
Safety switch lever
Measuring cap
Jar Lid
Jar
Sealing ring
Knife unit Jar
Inner pusher
Pusher
Bowl Lid
Toolholder
Bowl
Julienne disc
Shredding disc
Kneading tool
Chopping knife + protection
Press cone
CP Sieve
Gear Unit - Whisk Accessory
Whisk basket

HR7772/00
4-6
EXPLODED VIEW
1
10
2
9
8
5 12
6
11
4
7
3

HR7772/00
5-6
EXPLODED VIEW
14
15
16
17
13
19
20
21
22
18

HR7772/00
6-6
EXPLODED VIEW
23
25
24
26
29
30
27
28
