Philips VOX150 User manual

Wireless Bluetooth Headset VOX 150
Instructions for use
English 1
Gebrauchsanleitung
Deutsch 17
Mode d'emploi
Français 33
Instrucciones de uso
Español 49

Helpline
www.p4c.philips.com

1 2
3
4
5
6
7 8

2 ENGLISH
Important information
Please read this guide carefully before using the Bluetooth headset.
Please keep it for future reference.
•Do not open the device or the power supply.
•Do not use the device in rain, or in damp or wet environments.
•Clean the device and the power supply only with a dry cloth.
•Do not use other power supplies for your Bluetooth headset.
•Caution: risk of electric shock. Do not use power supply near water.
•Hearing safety! Continuous use at high volume may permanently
damage your hearing.
•The socket outlet shall be installed near the equipment and shall be
easily accessible
Hereby, Koninklijke Philips Electronics N.V., declares that this VOX 150
is in compliance with the essential requirements and other
relevant provisions of Directive1999/5/EC.

ENGLISH 3
Contents
Setting up your Bluetooth headset ...................................................... 3
Using your Bluetooth headset ................................................................. 6
Handling your phone calls.......................................................................... 9
Using the dialling features of your Bluetooth headset............ 12
Problem solving ............................................................................................. 14
Technical specifications ............................................................................. 16
Setting up your Bluetooth headset
Charging the battery for the first time
Four hours’ charging time is required the first time you charge your
Bluetooth headset’s battery. For detailed information please read the
charging instructions in the chapter “Using your Bluetooth headset”.

4 ENGLISH
Pairing your Bluetooth headset to your mobile phone
Your Bluetooth headset must be paired to your mobile phone
before they are able to communicate. Please make sure your mobile
phone supports Bluetooth technology and is in range (e.g. within 5
meters). Read your mobile phone instructions how to connect to
Bluetooth devices (Bluetooth headsets or audio devices)
Your Bluetooth headset enters easy pairing mode automatically at
the first time of use. In any other cases follow the instructions below.
1Press the ON/OFF&SEND/END button for 10 seconds.
>The STATUS light indicates pairing mode by flashing fast green.
Pairing mode is now active for 30 seconds.
2Follow the instructions of your mobile phone to start the pairing
process.
The Bluetooth equipment search process can take a few seconds.
>Your mobile phone finds the Bluetooth headset as
PHILIPS BVOX.

ENGLISH 5
If a pairing PIN-CODE is requested, the default code for your
Bluetooth headset is: 0000.
Once the Bluetooth headset is paired to your mobile phone it will
reconnect automatically when:
•it is switched on;
•it tries to reconnect for 20 seconds after a link loss;
•STATUS light blinks fast green by pressing a button;
•STATUS light blinks fast green by request from your mobile phone.
Resetting your Bluetooth headset
To pair the Bluetooth headset again or to pair it to another mobile
phone you have to reset the Bluetooth headset.
1Press the ON/OFF&SEND/END button for 10 seconds.
Now you can pair your Bluetooth headset to a mobile phone.

6 ENGLISH
Using your Bluetooth headset
Turning On/Off the Bluetooth headset
ON: Press the ON/OFF&SEND/END button for 3 seconds.
>You will hear the ON tone and the STATUS light flashes green.
The Bluetooth headset is now in search mode (green fast
blinking).
OFF: Press the ON/OFF&SEND/END button for 3 seconds.
>The STATUS light indicates OFF by a green flash and a red flash.
Low Battery Status
STATUS light will slowly blink red and a signal tone is played when
the battery needs recharging. During an ongoing call the signal tone
indicates less than 5 minutes’ speaking time.

ENGLISH 7
Charging the battery
1Plug the USB power adapter to your computer’s USB port or to
the power supply.
If you are using the power supply, plug it into the mains supply.
2Plug the USB power adapter into the power supply socket.
>STATUS light blinks fast red during charging.
Charging time is approximately 2 hours.
21

8 ENGLISH
>STATUS light stays permanently on green when the battery is fully
charged.
During charging you can use your Bluetooth headset.
Adjusting the ear hook
1Adjust the ear hook to the most comfortable position by selecting
one of the three possible earhook positions.
1
1
2
3
2 3

ENGLISH 9
2To change the side it is worn on, pull off the ear hook.
3Attach the ear hook to the other side of the hole.
Handling your phone calls
Your Bluetooth headset enables you to accept and reject calls, mute
the microphone and end calls.
Accepting a call
>An incoming call will be indicated by your ring tone.
Some mobile phone provide a separate ringtone for Bluetooth
headsets.
1To accept the call, briefly press the ON/OFF&SEND/END button
once.

10 ENGLISH
Rejecting a call
>An incoming call will be indicated by your ring tone.
Your ring tone will be played by your Bluetooth headset and your
mobile phone.
1To reject the call, press the ON/OFF&SEND/END button twice.
Muting the microphone during an ongoing call.
This function disables the microphone so that your partner cannot
hear you. Muting the microphone is only available during ongoing
calls.
1To mute the microphone press the VOLUME UP and VOLUME
DOWN button simultaneously.
Your microphone is disabled.

ENGLISH 11
2To reactivate the microphone press the VOLUME UP and
VOLUME DOWN button simultaneously again.
Your microphone is now activated to finish your call in normal mode.
Ending a call
To end a call you can choose to use your Bluetooth headset or to
use your mobile phone’s keypad.
1To end the call, briefly press the ON/OFF&SEND/END button
once.
Controlling the Volume
To control the volume and sounds (ring tone and signals) use the
VOLUME UP and VOLUME DOWN button.

12 ENGLISH
Using the dialling features of your Bluetooth headset
Activate voice dialling
The voice dialling function is a feature of your mobile phone. The
Bluetooth headset just activates this feature. Please make sure your
mobile phone supports voice dialling to use this feature through your
Bluetooth headset. Read your mobile phone instructions on how to
establish connections with voice dialling.
Voice dialling cannot be activated during an incoming call.
1To activate the voice dialling function press the
ON/OFF&SEND/END button twice.
Follow your mobile-phone instructions to establish a phone call using
the voice dialling function.

ENGLISH 13
Redial the last number
The redial function establishes a phone call to the last number you
dialled on your mobile phone. Your mobile phone must support this
feature. The Bluetooth headset just activates this function.
1To redial the last number press the ON/OFF&SEND/END button
short.
>Redialling starts.

14 ENGLISH
Problem solving
Problem Possible cause Solution
Bluetooth headset
does not switch
on.
Battery is very low. Charge your BluetoothB
headset.
Bluetooth disabled. Enable Bluetooth on
your mobile phone.
Too long out of range
(more than 40 seconds). Ensure you are within range, press any button.
No connection to
mobile phone.
Pairings may have been
reset. Start the pairing process.

ENGLISH 15
Problem Possible cause Solution
Red and green
STATUS light
during charging.
Charging error. Unplug Bluetooth
headset and restart
charging.
Redialling does not
work; the error
tone is played.
Your mobile phone
does not support
redialling.
Voice dialling does
not work; the
error tone is
played.
Your mobile phone
does not support voice
dialling.

16 ENGLISH
Technical specifications
•Talking time: up to 6 hours
•Standby time: up to160 hours
•Rechargeable lithium-ion battery
•Frequency according Bluetooth
specification
•Bluetooth profile HFP 1.0,
HSP 1.1 compliant
Disposal Instructions
This device uses a rechargeable lithium-ion battery which should last
for the lifetime of the device.
Caution: The used lithium-ion battery entails a risk of fire or chemical
burns if it is mistreated. Do not disassemble the battery for disposal.
Do not place the device with normal waste. Please dispose the
device according to your local recycling laws.

LGNE HSI
FCC Notice - VOX 150
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: 1. This device may
not cause harmful interference; and 2. This
device must accept any interference
received, including interference that may
cause undesired operation. This equipment
has been tested and found to comply with
the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed and
used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures: Reorient or relocate
the receiving antenna. Increase the
separation between the equipment and
receiver. Connect the equipment into an
outlet on a circuit different from that to
which the receiver is connected. Consult the
dealer or an experienced radio/TV
technician for help. NOTE: FCC Radiation
Exposure Statement: This equipment
complies with FCC radiation exposure limits
set forth for an uncontrolled environment.
This transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.

18
EN
Health and safety
Do not allow the product to come into contact with liquid. Do not open it.
Electric, Magnetic and Electromagnetic Fields ("EMF")
1. Philips Royal Electronics manufactures and sells many products targeted at consumers, which,
like any electronic apparatus, in general have the ability to emit and receive electro magnetic
signals.
2. One of Philips' leading Business Principles is to take all necessary health and safety measures
for our products, to comply with all applicable legal requirements and to stay well within the
EMF standards applicable at the time of producing the products.
3. Philips is committed to develop, produce and market products that cause no adverse health
effects.
4. Philips confirms that if its products are handled properly for their intended use, they are safe
to use according to scientific evidence available today.
5. Philips plays an active role in the development of international EMF and safety standards,
enabling Philips to anticipate further developments in standardization for early integration in
its products.
Conformity
The Declaration of conformity is available on www.p4c.philips.com.
Maintenance and service
On line help: www.p4c.philips.com
Information
