Philips HD2070 User manual

User manual
Register your product and get support at
www.philips.com/welcome
HD2070
HD2075

3EN
Contents
1 Important 4
Electromagnetic Fields (EMF) 6
Conformity with national standards 6
2 Introduction 7
3 What’s in the box 7
4 Overview 8
5 Cleaning before first use 9
6 Use the appliance 9
Make soymilk 9
Make five-grain soymilk 11
Make rice paste 12
Make juice 14
Make vegetable puree 15
Make corn juice (HD2075 only) 17
Keep warm 18
7 Cleaning 19
Easy clean 19
8 Product information 20
9 Recycling 21
10 Guarantee and service 21
11 Troubleshooting 22
12 Recipes 25
Soymilk 25
Five grain soymilk 25
Rice paste 28
Juice 30
Vegetable puree 30
Corn juice 30

4EN
• Never use the appliance for dry
heating.
• Never add contents (including
water) above 上水位 (the
maximum level indication) or
below 下水位 (the minimum
level indication).
• If the power cord, the plug, or
other parts are damaged, do
not use the appliance.
• If the power cord is damaged,
you must have it replaced
by Philips, a service centre
authorised by Philips or similarly
qualified persons to avoid a
hazard.
• Do not replace parts of the
appliance yourself.
• This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instructions concerning use
of the appliance by a person
responsible for their safety.
• For their safety, do not allow
children to play with the
appliance.
• Make sure that the water you
add into the soymilk maker is no
hotter than 70°C.
• This appliance is intended for
household use only.
1 Important
Read this user manual carefully
before you use the appliance, and
save the user manual for future
reference.
Before processing:
• Before you insert the plug into
the power outlet, make sure
that the appliance is assembled
correctly.
• Make sure that your hands are
dry before you insert the plug
into the power outlet.
• Before you connect the
appliance to the power, make
sure that the voltage indicated
on the bottom of the appliance
corresponds to the local power
voltage.
• This appliance can only be used
with an earthed plug. Make sure
that the plug is firmly inserted
into the power outlet.
• Never connect this appliance
to a timer switch, to avoid a
hazardous situation.
• Make sure that you clean the
appliance before use (see the
“Cleaning before first use”
section on Page 9).
• Do not use this appliance to
heat up other liquid foods.

5EN
After processing:
• Disconnect the power before
you continue other operations.
• Disconnect the power and
remove the power cord before
cleaning or disassembling this
appliance.
• To prevent steam scalding,
keep a certain distance from
the soymilk maker before you
lift the head unit.
• Install, remove, and clean the
perforated flow cup with care.
The blade on the head unit
is sharp. Be careful not to cut
yourself or others.
• To prevent a short circuit or an
electric shock,
• do not use water to rinse
the outside of the chamber
unit or head unit (including
the head unit handle,
control panel, upper plug,
upper plug connector, and
the power cord connector);
and keep them away from
drip or splash,
• do not place the head unit
in water, and
• do not place the base of the
soymilk maker in water.
• Use a microwave to heat up
cold soymilk. Do not use this
appliance to heat it, as the
contents will stick to the inner
side of the chamber.
During processing:
• Do not use this appliance on an
unstable or uneven surface.
• Keep the appliance and its
power cord out of the reach of
children.
• Never let the appliance run
unattended.
• Do not touch the steam or the
metal parts of the appliance, to
avoid burns or scalding.
• Do not disconnect the power
cord or remove the head unit
before processing is complete.
• If you have to stop processing,
disconnect the power cord
before you perform other
operations.
• If there is a power outage
during processing and this
lasts up to three minutes, do
not immediately restart the
soymilk maker. Empty the
contents in the soymilk maker,
and then put in new contents
before restarting. Otherwise,
the contents will stick to the
chamber or overflow, or the
appliance will set off a long
alarm.

6EN
Electromagnetic Fields (EMF)
This Philips soymilk maker
complies with all standards
regarding electromagnetic fields
(EMF). If handled properly and
according to the instructions in
this user manual, the appliance
is safe to use based on scientific
evidence available today.
Conformity with national
standards
• GB4706. 1-2005, “Safety of
household and similar electrical
appliances”, Part 1 General
requirements
• GB4706. 19-2008, “Safety
of household and similar
electrical appliances”, Particular
requirements for appliances for
heating liquids
• GB4706. 30-2008, “Safety
of household and similar
electrical appliances”, Particular
requirements for kitchen
machines
• Store the power cord in a cool
and dry place.
• To prevent an electric shock,
use the power cord to connect
other appliances.
• Food coloring can discolor
components. This is normal and
has no impact on use.

7EN
3 What’s in the box
2 Introduction
Congratulations on your purchase
and welcome to Philips! To fully benefit
from the support that Philips offers,
register your product at
www.philips.com/welcome.
• Philips soymilk maker HD2070 can
be used to make beverages and food
such as soymilk, five-grain soymilk,
rice paste, juice, and puree. It comes
with keep warm and easy clean
functions and an anti-overflow and
anti-splash protective device. It is
fully automated, easy to use, healthy,
attractive, and durable.
• Philips soymilk maker HD2075 can
be used to make beverages and food
such as soymilk, five-grain soymilk,
rice paste, juice, puree, and corn juice.
It comes with keep warm and easy
clean functions and an anti-overflow
and anti-splash protective device. It is
fully automated, easy to use, healthy,
attractive, and durable.
Warranty card
Power cord
Head unit
Perforated
flow cup
Measuring cup
Soymilk cup
Chamber unit
Filter
Cleaning pad
User manual
Tip
• Do not change the filter direction.
The convex filter is a special design
from Philips, which makes filtering
much more efficient.

8EN
aHandle of the head unit
bControl panel
• Function buttons:
选择 (Select)
开始 (Start)
易清洗 (Easy clean)
• Indicators:
干/湿豆豆浆 (Soymilk)
五谷豆浆 (Five-grain soymilk)
营养米糊 (Rice paste)
果蔬冷饮 (Juice)
蔬菜浓汤 (Puree)
玉米汁 (Corn juice - only for
HD2075)
工作中 (Working)
保温 (Keep warm)
易清洗 (Easy clean)
cOverflow sensor
• Monitor soymilk and prevent
overflowing
dBlade
eLower part of the head unit
fUpper plug
gPerforated flow cup
• Increase the flow rate and make
soymilk well balanced
hChamber unit
iBase
jProtective cover of the power cord
connector
kPower cord connector
lChamber handle
mWaterproof cover
• Prevent drip or splash
nUpper plug connector
4 Overview
f
e
g
n
m
l
k
j
a
b
c
d
h
i

9EN
6 Use the
appliance
Warning
• If you wish to cancel a function once
it is selected, do not lift the head unit
to prevent the facial scald. You can
unplug the power cord, re-plug it, and
then select another function.
Make soymilk
• Measure ingredients as instructed.
You can adjust the quantity a bit as
per your personal taste.
• For 2-4 people.
Note
• Make sure that the perforated flow
cup is installed correctly before use.
1Take a cup of dry soybeans with the
supplied measuring cup and wash
them clean.
• To increase the life of the blade,
soak the soybeans (8-9 hours
in fall and spring, 6-7 hours in
summer, and 9-10 hours in
winter) and wash them clean
before processing.
5 Cleaning before
first use
Method 1:
1Pour boiling water into the chamber,
put the head unit into the chamber,
and soak for 10 minutes.
2Clean the appliance (see the
"Cleaning" section on Page 19).
Method 2:
1Make soymilk following the
instructions in the “Make soymilk”
section.
2After soymilk is made, pour it away
and then clean the appliance (see the
“Cleaning” section on Page 19).

10 EN
6Open the protective cover, insert the
power cord, and connect the power.
»The indicators flash in a circle,
indicating that the power is
connected.
7Press 选择 (Select) to select 干/湿
豆豆浆 (Soymilk).
»The 干/湿豆豆浆 (Soymilk)
indicator lights up.
8Press 启动 (Start).
»The 工作中 (Working) indicator
flashes and 1 beep occurs,
indicating that processing starts.
After about 24 minutes, 6 beeps
occur and the 保温 (Keep warm)
indicator lights up, indicating
that soymilk is ready. If no other
operations are performed,
the appliance starts the keep
warm function. The keep warm
function lasts for 1 hour, and then
automatically stops (see the "Keep
warm" section on Page 18).
2Install the perforated flow cup and
rotate it to the correct position, as
shown in the illustration.
»Make sure that it cannot be pulled
off.
3Put the soybeans evenly at the
bottom of the chamber to prevent
them from touching the perforated
flow cup.
4Pour water into the chamber.
Make sure that the water level is
between 上水位 (the maximum
level indication) and 下水位 (the
minimum level indication).
ഌට໎
ഌට໎
༳ට໎
༳ට໎
ഌට໎
༳ට໎
5Put the head unit into the chamber.
Make sure that the upper plug is
correctly inserted into the connector.

11EN
winter) and wash them clean
before processing.
2Install the perforated flow cup and
rotate it to the correct position, as
shown in the illustration.
»Make sure that it cannot be
pulled off.
3Put rice and the soybeans evenly
at the bottom of the chamber to
prevent them from touching the
perforated flow cup.
4Pour water into the chamber.
Make sure that the water level is
between 上水位 (the maximum
level indication) and 下水位 (the
minimum level indication).
• To shorten the processing time,
you can add warm water no hotter
than 70℃.
ഌට໎
ഌට໎
༳ට໎
༳ට໎
ഌට໎
༳ට໎
5Put the head unit into the chamber.
Make sure that the upper plug is
correctly inserted into the connector.
9After processing, disconnect the
power. Hold the handle of the
chamber tightly with one hand and
lift the head unit with the other hand.
10 Filtrate soymilk with the filter, and it
is ready to serve. You can add some
sugar before serving.
• Soymilk can also be served
without being filtrated.
Make five-grain soymilk
• Measure ingredients as instructed.
You can adjust the quantity a bit as
per your personal taste.
• Example recipe: rice and soy bean
milk, for 2-4 people.
Note
• Make sure that the perforated flow
cup is installed correctly before use.
1Take 30 g of soybeans (around
1/2 cup) and 50 g of rice (around
1/2 cup) with the supplied measuring
cup and wash them clean.
• To increase the life of the blade,
soak the soybeans (8-9 hours
in fall and spring, 6-7 hours in
summer, and 9-10 hours in

12 EN
6Open the protective cover, insert the
power cord, and connect the power.
»The indicators flash in a circle,
indicating that the power is
connected.
7Press 选择 (Select) to select 五谷豆
浆(Five-grain soymilk).
»The 五谷豆浆 (Five-grain
soymilk) indicator lights up.
8Press 启动 (Start).
»The 工作中 (Working) indicator
flashes and 1 beep occurs,
indicating that processing starts.
After about 25 minutes, 6 beeps
occur and the 保温 (Keep warm)
indicator lights up, indicating
that soymilk is ready. If no other
operations are performed,
the appliance starts the keep
warm function. The keep warm
function lasts for 1 hour, and then
automatically stops (see the “Keep
warm” section on Page 18).
9After processing, disconnect the
power. Hold the handle of the
chamber tightly with one hand and
lift the head unit with the other hand.
10 Pour five-grain soymilk into the
soymilk cup, and it is ready to serve.
You can also add some sugar before
serving.
Make rice paste
• Measure ingredients as instructed.
You can adjust the quantity a bit as
per your personal taste.
• Example recipe: lily bulb and
Job’s-tears rice paste, for 2-4 people.
Note
• Make sure that the perforated flow
cup is installed correctly before use.
1Take 35 g of Job’s-tears and 35 g of
rice (around 2/5 cup each) with the
supplied measuring cup, take 20 g of
fresh lily bulbs (around 7-8 pieces),
and wash them clean.

13EN
2Install the perforated flow cup and
rotate it to the correct position, as
shown in the illustration.
»Make sure that it cannot be
pulled off.
3Put the lily bulbs, Job’s-tears, and rice
evenly at the bottom of the chamber
to prevent them from touching the
perforated flow cup.
4Pour water into the chamber.
Make sure that the water level is
between 上水位 (the maximum
level indication) and 下水位 (the
minimum level indication).
• To shorten the processing time,
you can add warm water no hotter
than 70℃.
ഌට໎
ഌට໎
༳ට໎
༳ට໎
ഌට໎
༳ට໎
5Put the head unit into the chamber.
Make sure that the upper plug is
correctly inserted into the connector.
6Open the protective cover, insert the
power cord, and connect the power.
»The indicators flash in a circle,
indicating that the power is
connected.
7Press 选择 (Select) to select
营养米糊 (Rice paste).
»The 营养米糊 (Rice paste)
indicator lights up.
8Press 启动 (Start).
»The 工作中 (Working) indicator
flashes and 1 beep occurs,
indicating that processing starts.
After about 25 minutes, 6 beeps
occur and the 保温 (Keep warm)
indicator lights up, indicating
that soymilk is ready. If no other
operations are performed,
the appliance starts the keep
warm function. The keep warm
function lasts for 1 hour, and then
automatically stops (see the “Keep
warm” section on Page 18).

14 EN
3Put the banana cubes evenly at the
bottom of the chamber to prevent
them from touching the perforated
flow cup.
4Pour 200 ml of milk and some water
into the chamber. Make sure that the
water level is between 上水位 (the
maximum level indication) and 下水
位(the minimum level indication).
ഌට໎
ഌට໎
༳ට໎
༳ට໎
ഌට໎
༳ට໎
5Put the head unit into the chamber.
Make sure that the upper plug is
correctly inserted into the connector.
6Open the protective cover, insert the
power cord, and connect the power.
9After processing, disconnect the
power. Hold the handle of the
chamber tightly with one hand and
lift the head unit with the other hand.
10 Pour rice paste into the soymilk cup,
and it is ready to serve. You can add
some sugar before serving.
Make juice
• Measure ingredients as instructed.
You can adjust the quantity a bit as
per your personal taste.
• Example recipe: banana juice, for 2-4
people.
Note
• Make sure that the perforated flow
cup is installed correctly before use.
1Cut 3 bananas (about 400 g) into
1.3-mm cubes.
2Install the perforated flow cup and
rotate it to the correct position, as
shown in the illustration.
»Make sure that it cannot be
pulled off.

15EN
Tip
• After banana juice is ready, serve at
once to avoid oxidization.
• If you want to make juice multiple
times, wait about 10 minutes until the
appliance cools down before the next
use. This makes the appliance more
durable.
Make vegetable puree
• Measure ingredients as instructed.
You can adjust the quantity a bit as
per your personal taste.
• Example recipe: tremella, lotus seed,
and mung bean soup, for 2-4 people.
Note
• Make sure that the perforated flow
cup is installed correctly before use.
1Take a cup of dry lotus seeds with
the supplied measuring cup, take
one piece of tremella, wash them
clean and soak. Cut the soaked
tremella into pieces the size of soaked
soybeans.
2Install the perforated flow cup and
rotate it to the correct position, as
shown in the illustration.
»Make sure that it cannot be
pulled off.
»The indicators flash in a circle,
indicating that the power is
connected.
7Press 选择 (Select) to select
果蔬冷饮 (Juice).
»The 果蔬冷饮 (Juice) indicator
lights up.
8Press 启动 (Start).
»The 工作中 (Working) indicator
flashes and 1 beep occurs,
indicating that processing starts.
After about 4 minutes, 6 beeps
occur, indicating that juice is
ready.
9After processing, disconnect the
power. Hold the handle of the
chamber tightly with one hand and
lift the head unit with the other hand.
10 Pour banana juice into the soymilk
cup, and it is ready to serve. You can
add some sugar before serving.

16 EN
»The indicators flash in a circle,
indicating that the power is
connected.
7Press 选择 (Select) to select 蔬菜浓
汤(Puree).
»The 蔬菜浓汤 (Puree) indicator
lights up.
8Press the 启动 (Start) button.
»The 工作中 (Working) indicator
flashes and 1 beep occurs,
indicating that processing starts.
After about 25 minutes, 6 beeps
occur and the 保温 (Keep warm)
indicator lights up, indicating that
vegetable puree is ready. If no
other operations are performed,
the appliance starts the keep
warm function. The keep warm
function lasts for 1 hour, and then
automatically stops (see the “Keep
warm” section on Page 18).
9After processing, disconnect the
power. Hold the handle of the
chamber tightly with one hand and
lift the head unit with the other hand.
3Take 1/2 cup of mung beans with
the supplied measuring cup and
wash them clean. Put the cleaned
ingredients evenly at the bottom of
the chamber to prevent them from
touching the perforated flow cup.
4Pour water into the chamber.
Make sure that the water level is
between 上水位 (the maximum
level indication) and 下水位 (the
minimum level indication).
• To shorten the processing time,
add warm water no hotter than
70°C.
ഌට໎
ഌට໎
༳ට໎
༳ට໎
ഌට໎
༳ට໎
5Put the head unit into the chamber.
Make sure that the upper plug is
correctly inserted into the connector.
6Open the protective cover, insert the
power cord, and connect the power.

17EN
4Pour water into the chamber.
Make sure that the water level is
between 上水位 (the maximum
level indication) and 下水位 (the
minimum level indication).
• To shorten the processing time,
add warm water no hotter than
70°C.
ഌට໎
ഌට໎
༳ට໎
༳ට໎
ഌට໎
༳ට໎
5Put the head unit into the chamber.
Make sure that the upper plug is
correctly inserted into the connector.
6Open the protective cover, insert the
power cord, and connect the power.
»The indicators flash in a circle,
indicating that the power is
connected.
10 Pour puree into the soymilk cup,
and it is ready to serve. You can add
some sugar before serving.
Make corn juice (HD2075 only)
• Measure ingredients as instructed.
You can adjust the quantity a bit as
per your personal taste.
• For 2-4 people.
Note
• Make sure that the perforated flow
cup is installed correctly before use.
1Take 300-350 g of fresh corns
(around 5-6 cups) with the supplied
measuring cup and wash them clean.
2Install the perforated flow cup and
rotate it to the correct position, as
shown in the illustration.
»Make sure that it cannot be
pulled off.
3Put the fresh corns evenly at the
bottom of the chamber to prevent
them from touching the perforated
flow cup.

18 EN
Keep warm
After soymilk, rice paste, puree, or corn
juice is made, 6 beeps occur and the
保温 (Keep warm) indicator lights up. If
no other operations are performed, the
appliance starts the keep warm function.
The keep warm function lasts for 1 hour,
and then automatically stops.
Tip
• If you lift the head unit as soon as
processing is complete, the appliance
does not start the keep warm
function.
• The appliance does not start the keep
warm function at the completion of
juice making.
7Press 选择 (Select) to select 玉米汁
(Corn juice).
»The 玉米汁 (Corn juice) indicator
lights up.
8Press 启动 (Start).
»The 工作中 (Working) indicator
flashes and 1 beep occurs,
indicating that processing starts.
After about 25 minutes, 6 beeps
occur and the 保温 (Keep warm)
indicator lights up, indicating
that corn juice is ready. If no
other operations are performed,
the appliance starts the keep
warm function. The keep warm
function lasts for 1 hour, and then
automatically stops (see the “Keep
warm” section on Page 18).
9After processing, disconnect the
power. Hold the handle of the
chamber tightly with one hand and
lift the head unit with the other hand.
10 Pour corn juice into the soymilk cup,
and it is ready to serve. You can also
add some sugar before serving.

19EN
3Use a cleaning pad to remove the
residue from the lower part of the
head unit, overflow sensor, and the
blade.
4Use a dry cloth to clean the head
unit handle, control panel, upper
plug, upper plug connector, base, and
power cord connector.
5The outside of the chamber can be
cleaned with a damp cloth.
Easy clean
• After processing is complete, if you
cannot promptly clean the residue on
the appliance, the residue will dry up
and stick on the appliance, difficult to
remove. As this happens, you can use
the easy clean function to heat and
soak the inner side of the chamber
and clean the appliance easier.
• To prevent the residue from smelling,
clean the appliance within 10 hours
after use.
7 Cleaning
Note
• Disconnect the power and remove
the power cord before cleaning or
disassembling this appliance.
• Do not put the head unit in water.
• To prevent scalding, do not touch the
head unit, perforated flow cup, or the
inner side of the chamber before they
cool down.
1After disconnecting the power, lift
the head unit, rinse the lower part of
the head unit, overflow sensor, blade,
perforated flow cup, and inner side of
the chamber.
2After the head unit cools down,
remove the perforated flow cup.
Rotate the perforated flow cup and
remove it, as shown in the illustration.
Take care of the sharp blade.

20 EN
8 Product
information
Note
• Product information is subject to
change without prior notice.
• Rated voltage: 220 V-
• Rated frequency: 50 Hz
• Motor power: 180 W
• Heating power: 900 W
• Dimensions (L x W x H)
• Soymilk maker:
239. 1 x 176. 2 x 310. 3 mm
• Packaging: 230 x 230 x 345 mm
• Weight
• Net weight: 2. 64 kg
• Gross weight: 3. 26 kg
• Capacity: 1000-1300 ml (for 2-4 people)
1Make sure that the perforated flow
cup is correctly installed before use.
2Pour water into the chamber.
Make sure that the water level is
between 上水位 (the maximum
level indication) and 下水位 (the
minimum level indication).
3Put the head unit into the chamber.
Make sure that the upper plug is
correctly inserted into the connector.
4Open the protective cover, insert the
power cord, and connect the power.
»The indicators flash in a circle,
indicating that the power is
connected.
5Press 易清洗 (Easy clean).
»The 易清洗 (Easy clean) indicator
lights up and 1 beep occurs,
indicating that the easy clean
function starts. After about 8
minutes, 6 beeps occur and the
工作中 (Working) indicator lights
up, indicating that the eay clean
function is complete.
6Clean the appliance as instructed in
the “Cleaning” section.

21EN
10 Guarantee and
service
If you have a problem, need service or
need information, see
www.philips.com/support or contact the
Philips Consumer Care Centre in your
country. The phone number is
4008 800 008.
9 Recycling
Do not throw away the appliance
with the normal household waste
at the end of its life, but hand it in
at an official collection point for recycling.
By doing this, you help to preserve the
environment.
