Philips SmartSleep The Snoring Relief Band SN3710/60 User manual

Instructions for use
Snoring Relief Band
SmartSleep

2
3
1
15
1312
16
11
10
9
17 18
14
4
5
7
8
6

English 6
Español 38
Français (Canada) 73

English
Introduction
Congratulations on your purchase and
welcome to Philips! To fully benefit from the
support that Philips offers, register your
product at www.philips.com/welcome.
The first Philips solution designed to alert you
before your snoring starts. Using clinically-
proven2 technology the positional monitor
detects when you’re moving onto your back
and delivers adaptive vibrations that prompt
you to sleep on your side – leading to quieter
nights for you and your partner1.
1This product is for position-dependent back
snorers where snoring ceases when sleeping
on their side.
2Clinically proven. Philips Snoring Relief Band’s
design is based on clinical research. Five
clinical studies have shown a reduction in
supine sleep time when study participants use
a sleep position solution. (van Maanen 2014,
Deiltjens 2015, Eijsvogel 2015, Benoist 2018,
Ruiter 2018).
Tip: Watch the how-to video of the Snoring
Relief Band at
www.usa.philips.com/c-p/SN3710_60/
smartsleep-snoring-relief-band
6

General description
1 Sensor
2 Activation button
3 Display
4 Adaptation phase
indicator
5 Battery status
indicator
6 Response rate
7 Hours in bed
8 Hours on your
back
9 Socket for small
plug
10 Clip
11 Window for
display
12 Window for
activation button
13 Pouch for sensor
14 Insertion slit for
sensor
15 Strap
16 Strap adjuster
17 Adapter
18 USB cable
Intended use
The Philips SmartSleep Snoring Relief Band is
intended to reduce snoring disruptions,
leading to an improved sleep experience. This
product is not a medical device and is not
intended for use in the mitigation and
treatment of disease or conditions including
POSA (Positional Obstructive Sleep Apnea).
When not to use
-The Snoring Relief Band must not be used if
your breathing repeatedly stops and starts
during sleep while snoring. You might have
obstructive sleep apnea which is potentially
a serious sleep disorder. Consult a doctor
for diagnosis.
-Do not use the Snoring Relief Band if you
are younger than 18 year.
7

- The Snoring Relief Band should not be used
by a person who has a medical implant (e.g.
pacemaker, insulin pump) that can be
affected by mild vibrational stimuli on the
chest, without consulting a doctor first.
- During pregnancy, consult a doctor before
use.
- The Snoring Relief Band is not
recommended for persons who are
supposed to sleep on their back due to a
physical condition (e.g. because of shoulder
or back problems).
- The Snoring Relief Band cannot be used by
persons who sleep in an upright position or
require more than 2 pillows during sleep.
- Do not use the Snoring Relief Band if you
are not able to switch sleeping positions
independently due to physical limitations.
- Do not use the Snoring Relief Band in case
of existing allergies to Polyester, Nylon or
Spandex.
Important safety information
Read this important information carefully
before you use the product and save it for
future reference.
DANGER
To reduce the risk of electric shock:
-The Snoring Relief Band is for indoor use only.
-Keep the adapter and the sensor dry and away from liquids
and moisture (running tap, bathroom etc.).
8

-Never immerse the adapter and sensor in water nor rinse it
under the tap.
WARNING
To reduce the risk of burns, fire, electric shock, or injury to
persons:
-Only use this product for its intended purpose as shown in
this user manual.
-Do not place the strap on damaged skin.
-This device is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the device by a person responsible for their safety.
-Do not let children play with the Snoring Relief Band, the
strap, the adapter or the USB cable as these may present a
strangulation hazard.
-Always check the Snoring Relief Band before you use it. Do
not use the Snoring Relief Band or adapter if it is damaged,
became wet or hot as this may cause injury.
-Be aware of the kinetic energy stored in elastic strap when
stretched and released suddenly, it may cause bruises.
-Only use the adapter WA1001 which is provided with the
Snoring Relief Band for charging the battery. Using another
adapter may jeopardize system safety.
-If the adapter and/or USB cord is damaged or defective,
always seek a replacement from Philips in order to avoid a
hazard (see 'Accessories').
-The sensor contains a non-replaceable Lithium battery.
-Do not open the sensor, there are no serviceable parts inside.
It will void warranty and may induce a battery related hazard.
9

-Do not dispose of batteries in fire or extreme heat. Batteries
may explode or leak.
CAUTION
-The sensor is not washable. Never immerse the sensor in
water or rinse it under the tap.
-Never use compressed air, scouring pads, abrasive cleaning
agents or aggressive liquids such as petrol or acetone to
clean the Snoring Relief Band.
-Check if the voltage indicated on the adapter corresponds to
the local mains voltage before you connect the adapter.
-Do not use the adapter in or near wall sockets that contain or
have contained an electric air freshener to prevent
irreparable damage to the adapter.
-Use and store the product under the right environmental
conditions as indicated in this user manual (see
'Specifications '). If not, this could affect the performance and
lifetime of the product.
-The strap should feel snug but comfortable below your chest.
-Reset the sensor if you intend to change the user as the
sensor has a self-learning algorithm which is optimized to
your personal sleep behavior.
General
-For hygienic reasons, the strap can be
washed and air-dried. Tumble dry and/or
excessive washing will deteriorate the
aesthetic appearance of the strap.
-For optimal battery performance of the
product life time, charge the battery when
the battery low indicator blinks orange.
10

-Do not store the sensor when the battery is
empty. Charge the sensor for two hours and
then store it at room temperature to ensure
optimal optimal battery performance over
the product life time.
-After charging, remove the adapter from the
wall socket to preserve energy.
-After the product has reached end-of-life,
dispose the sensor battery as described in
chapter ‘recycling’ to preserve our
environment.
SAVE THESE
INSTRUCTIONS
Electromagnetic fields (EMF)
This Philips product complies with all
applicable standards and regulations
regarding exposure to electromagnetic fields.
Preparing for use
The Snoring Relief Band consists of a sensor
and a strap.
Wear the Snoring Relief Band when you sleep
to reduce snoring caused by sleeping on your
back. The sensor will gently vibrate to
encourage you to turn from your back to your
side.
11

Charging
Charge the sensor before you use it for the
first time and when the battery low indicator
blinks orange.
Charging takes up to 8 hours. A fully charged
sensor has an operating time of up to 8 sleep
sessions.
Charging with the adapter
Tip: Charge the sensor when it is in the pouch
of the strap.
1
2
3
1Insert the small plug of the USB cable into
the socket on the back of the sensor.
2Insert the large plug of the USB cable into
the socket of the adapter.
3Insert the adapter into the wall socket.
Note: You cannot use the sensor while
charging.
Note: Put the sensor on a flat surface while
charging.
Note: The USB socket on the sensor can only
be used for charging.
12
Note: During charging, the battery indicator
blinks slowly white.

Battery fully charged
When the battery is fully charged, the battery
indicator lights up white continuously and
switches off automatically after 30 minutes.
Quick charge
When the battery is low or empty, you can
quickly charge the sensor for 1 hour. This
allows you to use the sensor during one
sleeping session.
Battery low
When the battery is almost empty, the battery
indicator blinks orange. Charge the sensor
when the battery low indication lights up
before using it.
Battery empty
When the battery is empty, the battery
indicator blinks orange quickly.
13

2Insert the sensor into the pouch.
Note: Make sure that the sensor is
completely inserted into the pouch.
3The display and the activation button of the
sensor should be visible through the pouch
windows.
Wearing the Snoring Relief Band during the night
1Center the pouch with the sensor in front of
your torso, just below the chest.
2Do not wear the strap too high or too low.
3Fully push the clip into the loop to securely
fasten the strap.
14
Inserting the sensor into the pouch
1Push open the slit on the back of the pouch.

Note: Make sure that the activation button
is pointing towards your chin and the
display is visible through the window of the
pouch.
Note: For best results, wear the Snoring
Relief Band on bare skin. In case you use
body lotions make sure that these are
absorbed by the skin before assembling the
strap.
4Adjust the length of the strap with the strap
adjuster. The strap should feel snug but
comfortable below your chest.
The Snoring Relief Band should stay in the
same position during the night.
Sensor data
The display shows three types of sensor data.
Response rate:
How many times (in percentage) you turned from your
back to your side after the sensor vibrates.
Hours in bed:
How many hours you spent in bed.
Hours on your back:
How many hours you spent on your back.
15

Display
1 sec. 1Press the activation button briefly to switch
on the sensor.
2The sensor switches on and quickly shows
an animation of the sensor data and battery
indicator.
1 sec. 3The display first shows the response rate.
This indicates how many times (in
percentage) you turned from your back to
your side after the sensor vibrates.
Press the activation button briefly again to
see the number of hours spent in bed.
1 sec. 4The display shows how many number of
hours you spent in bed.
Press the activation button briefly again to
see the hours spent on your back.
5The display shows the number of hours you
have spent on your back.
Note: The sensor will only save the data of
your last sleep session. If you use the sensor
for the first time the display shows '-.-' to
indicate that there is no data available yet.
16
Note: When the sensor shows one of the data
screens, the sensor switches off
automatically after eight seconds of
inactivity.

Using the product
Starting a sleep session
When you are ready to go to sleep, put the
strap with the sensor around your chest (see
'Wearing the Snoring Relief Band during the
night').
Start a sleep session by pressing the activation
button for two seconds when the sensor is off
or when it shows one of the sensor data
screens.
The sensor will vibrate briefly and show '--' to
indicate that the sleep session has started.
2 sec.
Note: The sensor allows you to fall asleep in
any position. 30 minutes after a sleep session
has started, the vibrations will start when you
are sleeping on your back.
17

Pause mode
In case you need to get up during the night
(e.g. going to the toilet), the sensor will pause
automatically until you are in a sleeping
position again. The vibrations will start after 5
minutes to give you some time to fall asleep
again.
Note: If you wake up during the night and want
to check if the sensor is still active, press the
activation button briefly. The display lights up
and shows '--' to indicate that the sensor is
still active. The display will fade out
automatically.
Note: A sleep session can last up to 12 hours,
after which the sensor automatically stops the
sleep session and switches off.
Note: If a sleep session has been stopped and
started again within 2 hours, both sessions are
counted as 1 full sleep session.
Stopping a sleep session
You need to manually stop the sleep session
when you wake up and get out of bed.
Press and hold the button for two seconds to
stop the sleep session. If you do not stop the
sleep session, the sensor keeps vibrating when
the Snoring Relief Band is taken off and the
sensor is placed on a horizontal surface.
18

After the sleep session has ended, the sensor
will vibrate briefly and show the data of your
last sleep session.
2 sec.
Learning more about your Snoring Relief
Band
Adaptation phase
You may need time to get used to the Snoring
Relief Band. To help you get used to the
vibrations, the sensor starts with an adaptation
phase that consists of 7 sleep sessions. During
this period, the percentage of time the Snoring
Relief Band vibrates increases gradually. From
the 8th sleep session onwards, the sensor
vibrates every time when you are lying on your
back (normal phase).
1 2 3 4 5 6 7
20% 25% 33% 50% 66% 75% 80% 100%
19

The sensor shows a small dot on the left side
of the display to indicate that the adaptation
phase is active.
Switching off the adaptation phase
You can manually switch off the adaptation
phase. Press and hold the activation button for
five seconds when the sensor shows one of
the data screens. The sensor vibrates after two
seconds, but keep the button pressed until the
sensor has counted down from three to one
and you feel another vibration. The final
vibration indicates that switching off the
adaptation phase was successful.
5 sec.
3 sec. 2 sec.
The data of your last sleep session has been
removed and the display shows '- -'.
20

Switching on the adaptation phase
At any time after the adaptation phase, you
can manually switch on the adaptation phase
again. Use the same 5-second long press as
described in ‘Switching off the adaptation
phase’.
The small dot on the display of the sensor
indicates that the adaptation phase is active
again during 7 sleep sessions. With this re-
activation of the adaptation phase, the data of
your last sleep session has been removed.
Vibration level
The sensor is smart and has a self-learning
algorithm. The sensor optimizes the vibration
level based on your reaction time (response
rate).
Vibration patterns
Every five days, the vibration pattern changes
to make sure that you do not get used to the
vibrations and that you will keep responding
to them.
Resetting the sensor
Reset the sensor if you want to remove your
data and reset the adaptation phase (e.g.
other user, a long period of disuse).
5 sec.
To reset the sensor, press and hold the
activation button for five seconds when the
sensor shows one of the data screens.
The sensor vibrates after two seconds, but
keep the button pressed until the sensor has
21

counted down from three to one and you feel
another vibration.
The final vibration indicates that the reset was
successful and that the data has been
removed.
5 sec.
3 sec. 2 sec.
After the reset, the adaptation phase is also
active again (see 'Adaptation phase'), as
indicated by the small dot on the display of
the sensor.
Cleaning
Cleaning the sensor
Warning: Do not immerse the sensor in
water and do not rinse it under the tap.
Warning: Never clean the sensor with
abrasive cleansing products or (aggressive)
liquids.
22
1Clean the sensor with a dry cloth after use,
if needed.
