Philips HR2730 User manual
English
1 Important
Read these instructions for use carefully before using the appliance and save them for future
reference.
Danger
Do not immerse the motor unit in water nor rinse
it under the tap.
Do not connect the appliance to a timer switch.
Warning
Before you connect the appliance to the power,
make sure that the voltage indicated on the bottom
of the appliance corresponds to the local power
voltage.
If the power cord, the plug, or other parts are
damaged, do not use the appliance.
If the power cord is damaged, you must have it
replaced by Philips, a service center authorized by
hazard.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
For their safety, do not allow children to play with
the appliance.
Be very careful when you handle the cutter,
especially when you remove it from the worm shaft
and during cleaning.The cutting edges are very
sharp!
Before you remove any accessory, switch the
appliance off and unplug it.
to push ingredients into the hopper while the
appliance is running. Only the pushers are to be
used for this purpose.
the appliance is running.
Caution
The appliance is intended for household use only.
Before you connect the appliance to the mains,
make sure that the appliance is assembled correctly.
Never use any accessories or parts from other
recommend. If you use such accessories or parts,
your guarantee becomes invalid.
Always switch the appliance off by turning the
switch knob to .
Do not let the appliance run unattended.
Do not exceed the maximum operating time of
4 minutes under heavy load applications. Let the
appliance cool down to room temperature before
next operation.
Do not use the button with the plastic hopper.
Noise level: Lc = 87 dB [A]
Safety system (Fig. 9)
This appliance is equipped with overheat protection. If the appliance overheats, it switches
off automatically. Unplug the appliance and let it cool down until room temperature.Then,
put the mains plug back into the power outlet and switch on the appliance again. Please
contact your Philips dealer or an authorized Philips service center if the overheat protection
is activated too often.
HR2732, HR2733 HR2734 and HR2735 only
appliance is overloaded, it automatically activates the overload protection and switches off.
If this occurs, set the switch knob to , unplug the appliance and let it cool down for 15
minutes. Remove the residue inside the hopper and then press the overload reset button on
the bottom of the motor unit (Fig. 9).
handled properly and according to the instructions in this user manual, the appliance is safe
Recycling
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a product, it means the
Never dispose of your product with other household waste. Please inform yourself
about the local rules on the separate collection of electrical and electronic products.
The correct disposal of your old product helps prevent potentially negative
consequences on the environment and human health.
2 Introduction
that Philips offers, register your product at www.philips.com.
With this meat mincer, you can
mince meat
make sausages
Tip
For more recipes, go to www.kitchen.philips.com.
3 What’s in the box (Fig. 1)
a Hopper release button
Press and hold it when you remove the hopper.
b
c Switch knob for power and reverse modes / /
Switch off ( ) or on ( ) the meat mincer.
Switch to to reverse the motor.
d Power cord
e Pusher for the metal hopper
f
g Extra gear for the worm shaft (HR2730, HR2731, HR2733 and HR2735 only)
h Worm shaft
i Cutter/Knife
j Hygienic stainless steel grinding discs
A
B
C
only)
k Screw ring
l Sausage horns
A
B
m Sausage separator
n
A: Kebbe separator
B: Kebbe shaper
o Pusher for the plastic hopper (HR2731, HR2733 and HR2735 only)
p Plastic hopper (HR2731, HR2733 and HR2735 only)
q Shield (HR2731, HR2733 and HR2735 only)
r
B: Slicer drum
s Dust cover (HR2732, HR2733 HR2734 and HR2735 only)
t Accessories tray (HR2732, HR2733 HR2734 and HR2735 only)
u
v Innovative cleaning tool
Note
Never grind bones, nuts, or other hard items.
Do not overload the appliance by pushing too much meat into the hopper.
Depending on the granularity of minced meat, select the proper grinding disc.You can also
Tip
Remove bones, gristle, and sinews out of the meat as much as possible.
If the hopper is blocked, switch to to reverse the motor and clear the leftover meat.
Note
Do not block the air outlet grooves of the sausage horn.
Do not make the sausages too thick in case the sausage skin is overstretched.
Keep the sausage skin wet to prevent it from sticking on the sausage horn.
Recipe
Sausages
Ingredients:
4 m of pork sausage skin (wet)
Seasoning such as Salt, pepper, spices and herbs of your choice
Directions:
1
2 Grind the pork belly and shoulder together using the coarse screen.
3 Add seasoning and mix well (tip: fry a spoonful of the mixture to check the taste).
4 Apply the wet sausage skin to the sausage horn, and attach to the meat mincer (no
blade needed).
5 Leave adequate sausage skin at the beginning before turning on the meat mincer.
HR2732, HR2733 HR2734 and HR2735
only)
Recipe
Kebbe
Yield: 5-8 servings
Ingredients:
Outer casing
1 small onion and cooked
Filling
15 ml oil
salt and pepper
Directions:
Outer casing
1)
2) Thoroughly mix the minced ingredients, and then mince the mixture twice again.
3) Use the kebbe maker to shape the mixture into kebbe casing.
Filling
1)
2) Fry the onion chops until they turn golden brown.
3)
4)
Cooking
1)
2)
3)
7 Cut vegetables (HR2731, HR2733 and
HR2735 only)
contact with food.
Fig. 7 indicates the foods that each drum is applicable to and the cutting shapes.
Note
Only use the plastic hopper in combination with the metal drums and the pusher for plastic
hopper.
Do not press the button during use of the plastic hopper.
Cut vegetables
1 Switch on the appliance.
2 Push the vegetables into the hopper.
Tip
You can also grate cheese.
8 Cleaning and maintenance (Fig. 4, Fig. 5 and
Fig. 6)
Note
contact with food.
Before you remove accessories or clean the motor unit, switch off and unplug the appliance.
Do not immerse the motor unit in water nor rinse it under the tap.
Do not clean the metal parts in a dishwasher.
Pass pieces of bread through the cutter housing to remove any meat left.
Wash removable parts with a soft brush in soapy water, rinse them with clear water, and then
dry them with soft cloth or tissues immediately.
Lightly brush the metal parts with fat or oil to prevent rusting.
Tip
Use the innovative cleaning tool to remove the remains stuck in the grinding discs. rinse them
with clear water, and then dry them with soft cloth or tissues immediately.
9 Replace the gear (Fig. 8) (HR2730, HR2731,
HR2733 and HR2735 only)
When you mince sticky or fatty meat, use the supplied plastic coupling. For instructions on
Register your product and get support at
User manual
KK
UK
RU
Specifications are subject to change without notice
© 2014 Koninklijke Philips Electronics N.V.
All rights reserved.
3-1
3-2
3-4
3
2
2-1
2-2
1
8
9
7
6
5
2-4
2-3 3-3
(HR2732, HR2733,
HR2734, HR2735)
(HR2730, HR2731)
(HR2732, HR2733, HR2734, HR2735)
r
o
p
q
A
BA
B
v
b
a
e
khg
c
d
A
B
C
ji
l
B
A
A
B
m n t
s
u
f
4
(HR2732, HR2733
HR2734, HR2735)
(HR2731, HR2733, HR2735)
(HR2732, HR2733
HR2734, HR2735)
(HR2732, HR2733 HR2734,
HR2735)
(HR2730_MEA, HR2732,
HR2733 HR2734, HR2735)
(HR2730, HR2731)
(HR2731, HR2733, HR2735)
a
b
c / /
).
d
e
f
g
h
i
j
A
B
C
k
l
A
B
m
n
HR2735)
o
p
q
r
s
t
u
v
5
1)
2)
3)
1)
2)
3)
4)
1)
2)
3)
.
1
2
.
a
b
c / /
d
e
f
g
HR2735)
h
i
j
A
B
C
k
l
A
B
m
n
o
p
q
r
s
t
u
v
1
2
3
4
5
HR2735);
1
2
.
Philips.
a
b
c / /
d
e
f
g
h
i
j
A
B
C
k
l
A
B
m
n
o
p
q
r
s
t
u
v
1
2
3
4
1
2
3
4
5
1)
1)
4)
1)
.
1
2
HR2735)
Импортер на территорию России и Таможенного
Союза: ООО «Филипс», Россия, Москва, ул. Сергея
Макеева, 13, тел. +7 495 961 1111
Изготовитель: “Филипс Консьюмер Лайфстайл Б.В.",
Туссендиепен 4, 9206 АД, Драхтен, Нидерланды
Для бытовых нужд
Мясорубка
Ет тартқыш
HR2730/90 / HR2731/90 / HR2732/00
HR2733/00 / HR2735/00
220 - 240V~ 50Hz 800 W
Ресей және Кедендік Одақ территориясына импорттаушы: «Филипс»
ЖШҚ, Ресей, Мәскеу қаласы, Сергей Макеев көшесі, 13-үй,
тел. +7 495 961 1111
Өндіруші: “Филипс Консьюмер Лайфстайл Б.В.", Туссендиепен 4, 9206
АД, Драхтен, Нидерланды
Тұрмыстық қажеттіліктерге арналған
