Philips HR2743 User manual
English
1 Important
Read these instructions for use carefully before using the appliance and save them for future
reference.
Danger
Do not immerse the motor unit in water nor rinse
it under the tap.
Do not connect the appliance to a timer switch.
Warning
Before you connect the appliance to the power,
make sure that the voltage indicated on the bottom
of the appliance corresponds to the local power
voltage.
If the power cord, the plug, or other parts are
damaged, do not use the appliance.
If the power cord is damaged, you must have it
replaced by Philips, a service center authorized by
hazard.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
For their safety, do not allow children to play with
the appliance.
Be very careful when you handle the cutter,
especially when you remove it from the worm shaft
and during cleaning.The cutting edges are very
sharp!
Before you remove any accessory, switch the
appliance off and unplug it.
to push ingredients into the hopper while the
appliance is running. Only the pushers are to be
used for this purpose.
the appliance is running.
Make sure you fully assemble and lock the hopper
before putting in the worm shaft, blade and screen
into the hopper.
Caution
The appliance is intended for household use only.
Before you connect the appliance to the mains,
make sure that the appliance is assembled correctly.
Never use any accessories or parts from other
recommend. If you use such accessories or parts,
your guarantee becomes invalid.
Always switch the appliance off by turning the
switch knob to .
Do not let the appliance run unattended.
Do not exceed the maximum operating time of
4 minutes under heavy load applications. Let the
appliance cool down to room temperature before
next operation.
Do not use the button with the plastic hopper.
Noise level: Lc = 87 dB [A]
Safety system (Fig. 9)
This appliance is equipped with overheat protection. If the appliance overheats, it switches
off automatically. Unplug the appliance and let it cool down until room temperature.Then,
put the mains plug back into the power outlet and switch on the appliance again. Please
contact your Philips dealer or an authorized Philips service center if the overheat protection
is activated too often.
appliance is overloaded, it automatically activates the overload protection and switches off.
If this occurs, set the switch knob to , unplug the appliance and let it cool down for
15 minutes. Remove the residue inside the hopper and then press the overload reset button
on the bottom of the motor unit (Fig. 9).
handled properly and according to the instructions in this user manual, the appliance is safe
Recycling
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a product, it means the
Never dispose of your product with other household waste. Please inform yourself
about the local rules on the separate collection of electrical and electronic products.
The correct disposal of your old product helps prevent potentially negative
consequences on the environment and human health.
that Philips offers, register your product at www.philips.com.
With this meat mincer, you can
mince meat
make sausages
make kebbe
cut vegetables
Tip
For more recipes, go to www.kitchen.philips.com.
3 What’s in the box (Fig. 1)
a Hopper release button
Press and hold it when you remove the hopper.
b
c / /
Switch off ( ) or on ( ) the meat mincer.
Switch to to reverse the motor.
d
e Pusher for the IntraClean hopper
f IntraClean hopper
g Extra gear for the worm shaft
h Worm shaft
i Cutter/Knife
j
A
B: Medium grinding disc (diameter of 5 mm)
C: Fine grinding disc (diameter of 3 mm)
k Screw ring
l Sausage horns
A
B
m Sausage separator
n Kebbe maker
A: Kebbe separator
B: Kebbe shaper
o Pusher for the plastic hopper
p Plastic hopper
q
r
B: Slicer drum
s Accessories tray (HR2745 only)
t
u
4 Before first use
Clean the IntraClean hopper (Fig. 5)
metal hopper, so that you can fully and easily clean it even from inside.
For disassembly, refer to Fig. 3-1.
Note
Never grind bones, nuts, or other hard items.
Do not overload the appliance by pushing too much meat into the hopper.
Depending on the granularity of minced meat, select the proper grinding disc.You can also
Tip
Remove bones, gristle, and sinews out of the meat as much as possible.
If the hopper is blocked, switch to to reverse the motor and clear the leftover meat.
Note
Do not block the air outlet grooves of the sausage horn.
Do not make the sausages too thick in case the sausage skin is overstretched.
Keep the sausage skin wet to prevent it from sticking on the sausage horn.
Recipe
Sausages
4 m of pork sausage skin (wet)
Seasoning such as Salt, pepper, spices and herbs of your choice
1
2 Grind the pork belly and shoulder together using the coarse screen.
3 Add seasoning and mix well (tip: fry a spoonful of the mixture to check the taste).
4 Apply the wet sausage skin to the sausage horn, and attach to the meat mincer (no
blade needed).
5 Leave adequate sausage skin at the beginning before turning on the meat mincer.
For disassembly, refer to Fig. 3-3.
Recipe
Kebbe
: 5-8 servings
Outer casing
1 small onion and cooked
Filling
15 ml oil
salt and pepper
Outer casing
1)
2) Thoroughly mix the minced ingredients, and then mince the mixture twice again.
3) Use the kebbe maker to shape the mixture into kebbe casing.
Filling
1) Mince the meat with the medium grinding disc.
2) Fry the onion chops until they turn golden brown.
3)
4)
Cooking
1)
2)
3) Deep fry the kebbe for 3-4 minutes, or until it turns golden brown.
contact with food.
For disassembly, refer to Fig. 3-4.
Fig. 7 indicates the foods that each drum is applicable to and the cutting shapes.
Note
Only use the plastic hopper in combination with the metal drums and the pusher for plastic
hopper.
Do not press the button during use of the plastic hopper.
1 Switch on the appliance.
2 Push the vegetables into the hopper.
Tip
You can also grate cheese.
Fig. 6)
Note
Before you remove accessories or clean the motor unit, switch off and unplug the appliance.
Do not immerse the motor unit in water nor rinse it under the tap.
Do not clean the metal parts in a dishwasher.
Wash removable parts with a soft brush in soapy water, rinse them with clear water, and then
dry them with soft cloth or tissues immediately.
Lightly brush the metal parts with fat or oil to prevent rusting.
Tip
Use the innovative cleaning tool to remove the remains stuck in the grinding discs. Rinse them
with clear water, and then dry them with soft cloth or tissues immediately.
10 Replace the gear (Fig. 8)
When you mince sticky or fatty meat, use the supplied plastic coupling. For instructions on
how to replace the coupling, see Fig 8.
User manual
KK
RU
UK
Specifications are subject to change without notice
© 2014 Koninklijke Philips N.V.
3-1
3-2
3-4
3
2
2-1
2-2
1
8
9
6
5
7
2-4
2-3 3-3
A
B
A
B
C
i
B
A
A
B
lp
q
o
u
t
m
kjhg
e
d
c
b
a
s
f
r
n
(HR2745)
4
(HR2745)
a
b
c / /
).
d
e
f
g
h
i
j
A
B
C
k
l
A
B
m
n
o
p
q
r
s
t
u
Always there to help you
www.philips.com/welcome
1
2
3
4
5
1
2
.
www.philips.com.
a
b
c / /
d
e
f
g
h
i
j
A:
B:
C:
k
l
A
B
m
n
o
p
q
r
s
t
u
1
2
3
4
5
1)
3)
.
1
2
.
www.philips.com.
a
b
c / /
d
e
f
g
h
i
j
A
B
C
k
l
A
B
m
n
o
p
q
r
s
t
u
1
2
3
4
5
.
1
2
Импортер на территорию России и Таможенного
Союза: ООО «Филипс», Россия, Москва, ул. Сергея
Макеева, 13, тел. +7 495 961 1111
Изготовитель: “Филипс Консьюмер Лайфстайл Б.В.",
Туссендиепен 4, 9206 АД, Драхтен, Нидерланды
Для бытовых нужд
Мясорубка
Ет тартқыш
HR2743/00 / HR2745/00
220 - 240V~ 50Hz 800 W
Ресей және Кедендік Одақ территориясына
импорттаушы: «Филипс» ЖШҚ, Ресей, Мәскеу
қаласы, Сергей Макеев көшесі, 13-үй,
тел. +7 495 961 1111
Өндіруші: “Филипс Консьюмер Лайфстайл Б.В.",
Туссендиепен 4, 9206 АД, Драхтен, Нидерланды
Тұрмыстық қажеттіліктерге арналған
