Philips GV-3/1F-RC-M433 User manual

Operation Instructions of Controller
1.Specifications:
Supply coltage: 3V Working temperature:-20-60℃Product size:L114*W64*H25mm
Net weight:100g Output:RGB Signle Max load current:15mA
2.Control Method:
Adopt IR remoter to control the LED controller, which has 24 buttons, the function of each
button as the table below:
Direction: A:When in“Static”mode,“Brightness+/Speed+”,“Brightness-/Speed-”means the
brightness is up/down.
B:When in “flsh”“fade”“smooth”or“strobe”mode,“Brightness+/Speed+”“
Brightness-/Speed”Means the speed of light change is up/down.
C.It can remember the lasted lasted state before power off.
3.Panel specification and connecting drawing as follows:
4.Warning: A: Replace battery with a matching set of new battery of the same model.
B:Lead wire should be connected correctly according to colors that connecting diagram
offers.
C.Warranty of this product is one year,but exclude the artificial situationg of damaged
or Overload working.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION
IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
The user manual for an intentional or unintentional radiator shall caution the user that changes or
modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
(SAMPLE)
Brightness+/Speed+
Brightness-/Speed-
OFF
ON
Red
Green
Blude
Static White
Orange
Pea green
Dark blue
7 colors jump
Dark yellow
Cyan
Brown
3 base colors fade change
Yellow
Light blue
Pink
7 colors fade change
Straw yellow
Sky blue
purple
3 base colors jump

NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR
MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Model No:GV-3/1F-RC-M433
FCC ID:2ACO2-GV-RC433
779852-101
Made In China
