Philips HP4648/37 User manual

SalonStraight ION
HP4648

2

3
1

4

HP4648
ENGLISH 6
 13
 20
 26
 33
 39
 46
 54
 61
 67
 74
 81
 89
 96
 102
 108

6
Introduction
This new Philips SalonStraight ION straightener provides ultra-fast and
super-smooth straightening results.The ioniser generates streams of ions
which surround and condition your hair. Ions reduce frizz and static
electricity and leave your hair looking soft, smooth and shiny.The
adjustable temperature enables you to personalise the straightener to
obtain optimal results for your hair.
General description (Fig. 1)
APilot light
green: selected temperature has been reached
red: selected temperature has not yet been reached
BDisplay: shows the selected temperature and the usage time
CSelected temperature
DUsage time
E+ button to increase the temperature
F- button to decrease the temperature
GOn/off button
HHanging loop
IClosing lock
JIon output holes
KCeramic-coated plates
LRubber strips
Important
Read these instructions for use carefully before using the appliance and
save them for future reference.
Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
Check the condition of the mains cord regularly. Do not use the
appliance if the plug, the cord or the appliance itself is damaged.
If the mains cord is damaged, it must be replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in
order to avoid a hazard.
,
,
,
ENGLISH

Keep this appliance away from water! Do not use this product near
or over water contained in baths, washbasins, sinks etc.When used
in a bathroom, unplug the appliance after use since the proximity of
water presents a risk, even when the appliance is switched off.
For additional protection, we advise you to install a residual current
device (RCD) with a rated residual operating current not
exceeding 30mA in the electrical circuit supplying the bathroom.
Ask your installer for advice.
Keep the appliance out of the reach of children.
Only use the appliance on dry or damp hair.
The plates and the surrounding plastic parts of this appliance will
become hot during use! Prevent contact with the skin.
For safety reasons, the straightener automatically switches off after
having been on for 1 hour.
Always unplug the appliance after use.
Do not wind the mains cord round the appliance.
Wait until the appliance has cooled down before storing it.
Keep the straightening plates clean and free of dust, dirt, styling
spray and gel. Never use the appliance in combination with styling
mousse, styling spray, gel etc.
Always return the appliance to a service centre authorised by
Philips for examination or repair. Do not attempt to repair the
appliance yourself, otherwise your guarantee will become invalid.
When using this appliance you may notice a characteristic smell.
This is caused by the ions that are generated and it is not harmful
to the human body.
The plates have a ceramic coating.This coating will wear in the
course of time.When this happens, the appliance will still function
normally.
Do not probe the ioniser with metal objects.
Styling your hair
Step 1: washing your hair
Everybody wants shiny and beautiful hair. A good hair-washing routine can
help to achieve this.
,
,
,
,
,
,
,
,
,
,
,
,
,
,
ENGLISH 7

When washing your hair, wet your hair thoroughly for 30-60
seconds.
Pour some shampoo into the palm of your hand. Spread it between
your hands and distribute it evenly through the hair.
Gently massage your hair and scalp. Do not rough up the hair or
pull long hair up onto the scalp, as this may cause tangles.
Massage your scalp with your ngertips. This stimulates blood
circulation and is gentler to the hair cuticles.
Rinse your hair thoroughly, as poor rinsing can result in dull hair.
Finish with a cold rinse for extra shine.
Step 2: drying your hair
To get super-smooth results, it is essential to prepare your hair for
straightening. Dry you hair properly with a hairdryer to ensure a
professional, smooth nish.
After washing, squeeze excess water out of the hair with your
hands and then towel-dry the hair. Use a comb to disentangle hair
gently from the roots to the tips.
Divide the hair into sections by means of clips, starting at the back.
Dry each section by pulling a straightening brush down the hair
length while following the brush with the hairdryer, with its nozzle
pointing towards the hair ends.
When you have nished drying each section, set the hairdryer to
the cold setting for a nal cold shot. This closes the cuticles and
leaves your hair glossier.
Note:Tip: Philips Protect hairdryers have a lower drying temperature and a
stronger airow than regular dryers. Thanks to this combination, they dry just
as quickly as regular hairdryers but in a gentler way.
Step 3: straightening your hair
Straighteners are powerful styling tools and should always be used with
care.
If you use the straightener incorrectly or if you use it at the wrong
temperature, you could overdry your hair or even burn it.Always
follow the four steps below to select the right temperature for you
hair type! (Fig. 2)
,
,
,
,
,
,
,
,
,
,
ENGLISH8

Always select a low heat setting when you start using the straightener
for the rst time.
For coarse, curly or hard-to-straighten hair, selected a medium
(120 cC) to high heat setting (160 cC).
For ne, medium-textured or soft waved hair, select a medium
(120 cC) to low heat setting (100 cC)
Take extra care with pale, blonde, bleached or colour-treated hair,
since it will be susceptible to damage at high temperatures.
The display shows the selected temperature and the remaining
time of the straightening session.
Look at the display to see the temperature you have selected.
The bars on the display show the remaining usage time of the
straightener.The total usage time is 60 minutes. Every ten minutes
one of the six bars will disappear.
1 Insert the plug into the wall socket.
2 Press the on/off button.
The pilot light burns red to indicate that the straightener is heating up.
Ions are generated as soon as the straightener is switched on and are
released through the ion output holes.
3 Let the appliance heat up.The default heat setting is 100 °C.
Never leave the appliance unattended when it is plugged in. Never put
the appliance on a surface that is not heat-resistant when it is heating
up and when it is hot.
4 When the pilot light turns green the default temperature of 100 cC
has been reached.When the appliance has reached this
temperature, you can adjust the temperature to your preference.
(Fig. 2)
Press the + button to increase the temperature or press the - button
to decrease the temperature.The display tells you which temperature
you have selected.The pilot light turns red to indicate that the
appliance is adjusting the temperature.
The pilot light turns green when the selected temperature has been
reached.
-
-
-
-
,
-
-
-
-
ENGLISH 9

5 Comb or brush your hair so that it is disentangled and smooth.
(Fig. 3)
Use a comb to divide the hair into sections. Do not put too much hair in
one section.
Note: it is better to section off the crown area and to straighten the hair
underneath rst. Then straighten the top area.
6 Take a section that is not wider than 5 cm. Place it between the
straightening plates and press the handles of the appliance rmly
together.
7 Slide the straightener down the length of the hair in 5 seconds,
from root to hair end, without stopping to prevent overheating.
(Fig. 4)
8 Repeat this process after 20 seconds until you have achieved the
desired look.
9 Allow your hair to cool down. Do not comb or brush it before it
has cooled down, as this would ruin the hairstyle you have just
created.
Reducing frizz and static electricity
The ioniser inside the hairstyler generates streams of ions that surround
and condition your hair. Ions reduce frizz and static electricity and leave
your hair looking soft, smooth and shiny.
The ioniser starts working as soon as the appliance is switched on.
Cleaning
1 Make sure the appliance is switched off and unplugged.
2 Let the appliance cool down completely on a heat-resistant surface.
3 Clean the appliance with a damp cloth.
ENGLISH10
