LDS Series
DIE CAST ALUMINUM LED EXIT
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
Illumination: Illumination of
the stencil face is accomplished
with long-lasting, high-output
Light Emitting Diodes (LEDs).
Hot spots and striations are
eliminated by the internal “light
chamber” allowing for even
illumination in normal and
emergency situations.
Housing: Rugged die cast
aluminum housing, backplate,
faces and canopy. Exits are
painted with a durable powder
coat and available in a black
frame with brushed aluminum
stencil face, black frame with
black stencil face, or white
frame with white stencil face.
Operating Temperature
Range:
65°F (19°C) to 85°F (30°C)
Diagnostic Electronics
(standard): 120/277 VAC,
60 Hz, dual voltage input.
Solid state circuitry is surge-
protected and provides for
a reliable charging system.
Standard features include
low voltage disconnect, labor
saving AC lockout, brownout
protection and instantaneous
transfer.
Self-Testing Diagnostics
(optional): The diagnostics
routine is activated upon the
presence of AC power to
ensure proper installation
and initialization. Continuous
monitoring of the systems
critical components include:
battery disconnect/failure,
charger failure, LED failure,
AC line voltage monitoring
and transfer circuit failure.
Fault/service monitoring is
accomplished via a dual color
LED on the outside of the unit
so there is no need to open
the fixture if trouble shooting
is needed. The self-test
routine satisfies the exception
clause for periodic testing
requirements of NFPA 101 and
automatically tests the unit for
one minute every thirty days
and 90 minutes annually.
Electrical Specifications:
AC Only Red and Green:
0.026 A (120 VAC)
0.012 A (277 VAC)
Self-Powered Red and Green:
0.033 A (120 VAC)
0.017 A (277 VAC)
Code Compliance
UL 924 listed. NFPA 101,
NEC, BOCA, OSHA and IBC
illumination standards.
Warranty
Five year full warranty.
13.38"
(33.97 cm)
8.5"
(21.59 cm)
LDSNURW
9.125"
(23.18 cm)
12.75"
(32.38 cm)
2.0"
(5.08 cm)

LDS Series
DIE CAST ALUMINUM LED EXIT
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
LDS Series August 11, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
Ordering Information
Series
LDS = Die Cast
Aluminum LED Exit
SD = Self-Testing Diagnostics1
Factory Installed Options
A= AC Only
N= Self-Powered
Battery
A= Natural Brushed Aluminum
Face w/ Black Housing
B= Black Stencil Face w/ Black
Housing
W= White Stencil Face w/
White Housing
Stencil Face/Housing Color
LDS
U= Universal, 2 Faces
Backplate and Canopy
Stencil Faces
R= Red
G= Green
Letter Color
U
Note
1) SD available on nickel cadmium models only and only as universal.
2) Custom pendant lengths and colors available, consult factory.
Accessories (order as a separate item)
PKIT12W2= Pendant Kit, 12” White Finish
PKIT12B2= Pendant Kit, 12” Black Finish
