Phillips & Temro industries EVOCHARGE 40A EVSE Installation and operating instructions

EVOCHARGE®40A EVSE
CHARGING STATION
iEVSE®, iEVSE®Home
User Manual & Installation Guide

1Part No. 701052 | Rev C
EvoCharge Installation
Before Installation
Safety Check
• Check for transport damages.
• Before connecting the product to the power supply, check that
the power supply voltage and current rating corresponds with
the power supply details shown on the product rating label.
• The charge point must be installed only by a licensed electrician
in accordance with the provisions of the local electrical industry
construction and should comply with national electrical codes
and standards.
• Before installing the charge point, make sure you have read all
of these instructions in this manual and fully understand its
contents. Appropriate protection is required when connecting to
a main switchboard. The tools and parts used as outlined in the
section “Tools & parts required for installation”.
Disconnect the power supply before installing or repairing the
charge point. Failure to do so may result in physical injury or
damage to the power supply system and the charge point.
Avoid touching or pressing the OLED screen all times, as this
may result in damage to the OLED screen.
RISK OF SUFFOCATION: Keep any packing materials away from
children – these materials are a potential source of danger, e.g.
suffocation.
Grounding instructions
The charge point must be installed with an equipment grounding
conductor. Use a dedicated grounding wire with a ring terminal to
connect to the grounding terminal block.

2EVOCHARGE 40A EVSE User Manual & Installation Guide
Tools & parts required for installation
Tool Qty Size Supplier Remark
Mounting Bracket 1 194x09x9 mm Model
Accessories
Fasten charge point to the
wall
Holster ASSY 1 58x58x70 mm Model
Accessories
Hold EV charging plug
Screw 4 Tapping: #12 Model
Accessories
Fasten mounting bracket
and hook
Mechanical: M6 Commercially
Available
Wire, Copper 3 8 AWG Commercially
Available
UL1015 (recommended)
Heat Shrink Tube 3 For 8 AWG wire Commercially
Available
Protect wires and terminals
Terminal 3 For 8 AWG wire Commercially
Available
Connect input wires to the
terminal block
Conduit 1 1 inch Commercially
Available
Protect power cable
Torx Screwdriver 1 T20 Commercially
Available
Philips
Screwdriver
1 PH3 Commercially
Available
Hexagon Socket 1 5/16 Commercially
Available
Tighten #12 tapping screws
Torque Wrench 1 35 kgf-cm min Commercially
Available
Install the charge point
Disconnect power at the circuit breaker before installation.
Before mounting, determine the suitable mounting location.
The unit must be fixed to a wooden or masonry/concrete wall
using hardware that is appropriate for the surface. Do not
install on drywall, wall boards or thin plywood. The fixing point
must be capable of supporting the weight of the unit.
Secure the mounting bracket to the wall with appropriate screws.

3Part No. 701052 | Rev C
Follow applicable accessibility requirements for the mounting
position. The unit shall be stored or located at a sufficient height.
Follow local electric code and applicable standards.
For indoor use: The unit should be mounted between 18 inches
(450 mm) and 4 feet (1.2m) from the floor. Follow local electric
code and applicable standards.
For outdoor use: The unit should be mounted between 24 inch-
es (600 mm) and 4 feet (1.2m) from the floor. Follow local elec-
tric code and applicable standards. The mounting bracket has
ten screw holes. If only two screws are to be used to fasten the
mounting bracket, use the middle two screw holes of the mounting
bracket. The other screw holes are reserved for the user.
Screw suggestion:
• For masonry walls, use M6 mechanical screws. (Commercially
available)
• For finished walls supported by wood studs, locate the stud
and use 1/4” or M6 tapping screws. (Commercially available)
• Please use following torque force:
Screw Torque
M6 25 kgf.cm min 21.7 lb-in min
#12 25 kgf.cm min 21.7 ln-in min
Mount the charge point onto mounting bracket and lock the screw.
• Put the charge point on the mounting bracket.
• Fix charge point on mounting bracket with M4 screw and screw
washer.
• Please refer to the following torque:
Screw Torque
M4 16 kgf.cm 13.88 lb-in

4EVOCHARGE 40A EVSE User Manual & Installation Guide
Installing the mounting bracket
Charge point and mounting bracket Screw locking position
Screw holes of mounting bracket
Plug in the power cord (BC3/SC3 ONLY)
The outlet should be located at 20-26 inches from the ground.
Refer to the installation template to decide where to install the
charge point.

5Part No. 701052 | Rev C
Choose the appropriate conduit in accordance with all applicable
state, local and national electrical codes and standards.
Plug in the power cord
Conduit Right angle conduit
Clamp the copper sleeve terminal to connect the copper wire.
• Refer to the following wire specification. Use a hand tool to cut
the outer layer of the wire and leave around 12mm of length
for connecting the copper sleeve terminal.
Terminal Conductor Rating
L1, L2 6 AWG 90C copper wire
G 10 AWG 90C copper wire

6EVOCHARGE 40A EVSE User Manual & Installation Guide
Connect copper sleeve terminal to wire
Note:
• Please make sure there
is no copper wire out of
ferrule.
• The dimensions of ferrule
terminal after cramping is
4.8mm square MAX.
Electrical wiring to the charge point
• Disassemble top cover.
• Use Philips screwdriver to release terminal screws.
• Fold the wire end to pass through the conduit and insert into
the input hole.
• Fix the copper wire on the corresponding terminal block. The
wiring instruction is printed in front of the terminal block (L1/
L2/G).
• Use the following torque to connect the wire terminal to the
terminal block:
Torque
1.2 N-m 10.5 ln-in
• The recommended terminal specifications are as follows:
Terminal #6AWG Dimensions (mm) #10 AWG Dimensions (mm)
F 12 12
L 24 20
W 8.8 6.3
B 10 8.5
D 6.2 3.9
C 5.8 3.5

7Part No. 701052 | Rev C
Dimensions of terminal
Input wiring
Terminal Dimension (mm)
W ≤ 9.5
d2 4-6.4

8EVOCHARGE 40A EVSE User Manual & Installation Guide
CAUTION: To reduce the risk of fire, connect only to a circuit
provided with 40 amperes maximum branch circuit overcurrent
protection in accordance with the National Electrical Code, ANSI/
NFPA 70, and the Canadian Electrical Code, Part I, C22.1.
CAUTION: If this unit is installed outdoors, the outlet must be
rated for outdoor installation. The outlet must be installed properly
to maintain the proper NEMA rating of the enclosure.
Model Current rating
Intelligent Charger-40A 40A
Lock the conduit on the enclosure. Please refer to the following
torque:
Conduit Torque
1 “ 35 kgf.com 30.36 lb-in
Reassemble the top cover. Please refer to the following torque:
Screw Torque
M4 16 kgf.com 13.88 lb-in

9Part No. 701052 | Rev C
For additional products, field support and cable
management solutions visit evocharge.com or
contact us at 888-653-0160.
