Phoenix Contact ILC 191 ME/AN Wiring diagram

User manual
Installing and operating the
ILC 191 ME/AN and
ILC 191 ME/INC Inline controllers

2014-06-16
PHOENIX CONTACT 8607_en_03
Installing and operating the ILC 191 ME/AN and ILC 191 ME/INC Inline
controllers
UM EN ILC 191 ME/X
03
—
Designation Version or later
(HW)
Version or later
(FW)
Order No.
ILC 191 ME/AN 01 4.0x 2700074
ILC 191 ME/INC 01 4.0x 2700075
User manual
Designation:
Revision:
Order No.:
This user manual is valid for:

PHOENIX CONTACT
Please observe the following notes
User group of this manual
The use of products described in this manual is oriented exclusively to:
– Qualified electricians or persons instructed by them, who are familiar with applicable
standards and other regulations regarding electrical engineering and, in particular, the
relevant safety concepts.
– Qualified application programmers and software engineers, who are familiar with the
safety concepts of automation technology and applicable standards.
Explanation of symbols used and signal words
How to contact us
Internet Up-to-date information on Phoenix Contact products and our Terms and Conditions can be
found on the Internet at:
phoenixcontact.com
Make sure you always use the latest documentation.
It can be downloaded at:
phoenixcontact.net/products
Subsidiaries If there are any problems that cannot be solved using the documentation, please contact
your Phoenix Contact subsidiary.
Subsidiary contact information is available at phoenixcontact.com.
Published by PHOENIX CONTACT GmbH & Co. KG
Flachsmarktstraße 8
32825 Blomberg
GERMANY
Should you have any suggestions or recommendations for improvement of the contents and
layout of our manuals, please send your comments to:
[e-mail]
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety measures that follow this symbol to avoid possible in-
jury or death.
There are three different categories of personal injury that are indicated with a
signal word.
DANGER This indicates a hazardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING This indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION This indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
This symbol together with the signal word NOTE and the accompanying text
alert the reader to a situation which may cause damage or malfunction to the
device, hardware/software, or surrounding property.
This symbol and the accompanying text provide the reader with additional in-
formation or refer to detailed sources of information.

Please observe the following notes
PHOENIX CONTACT
General terms and conditions of use for technical documentation
Phoenix Contact reserves the right to alter, correct, and/or improve the technical documen-
tation and the products described in the technical documentation at its own discretion and
without giving prior notice, insofar as this is reasonable for the user. The same applies to any
technical changes that serve the purpose of technical progress.
The receipt of technical documentation (in particular user documentation) does not consti-
tute any further duty on the part of Phoenix Contact to furnish information on modifications
to products and/or technical documentation. You are responsible to verify the suitability and
intended use of the products in your specific application, in particular with regard to observ-
ing the applicable standards and regulations. All information made available in the technical
data is supplied without any accompanying guarantee, whether expressly mentioned, im-
plied or tacitly assumed.
In general, the provisions of the current standard Terms and Conditions of Phoenix Contact
apply exclusively, in particular as concerns any warranty liability.
This manual, including all illustrations contained herein, is copyright protected. Any
changes to the contents or the publication of extracts of this document is prohibited.
Phoenix Contact reserves the right to register its own intellectual property rights for the
product identifications of Phoenix Contact products that are used here. Registration of such
intellectual property rights by third parties is prohibited.
Other product identifications may be afforded legal protection, even where they may not be
indicated as such.

8607_en_03 PHOENIX CONTACT 5
Table of contents
1 Foreword ....................................................................................................................................9
1.1 Purpose of this user manual .................................................................................. 9
1.2 Hardware and software requirements ............................................................... 9
2 Description of the Inline controller.............................................................................................11
2.1 General description of the Inline controller........................................................... 11
2.2 Possible fields of application of the Inline controller............................................. 13
2.2.1 Controller as a distributed controller of an Inline station ....................... 13
2.2.2 The Inline controller for position control ............................................... 14
2.2.3 The Inline controller as a PROFINET device in a PROFINET network . 15
2.2.4 Applicative system redundancy using the Inline controller ................... 16
2.3 Notes on using the Inline controller in potentially explosive areas ....................... 17
2.4 Unpacking the Inline controller ............................................................................ 18
2.5 Connection and operating elements .................................................................... 19
2.6 Diagnostics and status indicators ........................................................................ 21
2.7 Mode selector switch........................................................................................... 25
2.8 Reset button (concealed) .................................................................................... 26
2.9 Parameterization memory.................................................................................... 26
2.9.1 Inserting/removing the parameterization memory ................................ 27
2.9.2 Operating the Inline controller with or without plug-in
parameterization memory (SD card) .................................................... 28
2.10 Internal basic circuit diagram ............................................................................... 29
2.11 Mounting and removing the Inline controller ........................................................ 31
2.12 Communication paths.......................................................................................... 35
2.12.1 Ethernet ............................................................................................... 36
2.12.2 Serial PRG interface (mini-DIN socket) ................................................ 37
2.13 INTERBUS ................................................................................................. 39
2.13.1 Local bus ............................................................................................. 39
2.13.2 Remote bus ......................................................................................... 39
2.14 Power supply ....................................................................................................... 40
2.14.1 Sizing of the power supply ................................................................... 40
2.14.2 Connecting the power supplies ............................................................ 41
2.14.3 24 V segment supply/24 V main supply ............................................... 43
2.14.4 24 V segment supply ........................................................................... 43
2.14.5 24 V main voltage ............................................................................... 43
2.14.6 24 V ILC supply ................................................................................... 43
2.14.7 Jumpers .............................................................................................. 43
2.15 Digital outputs...................................................................................................... 44
2.16 Digital inputs........................................................................................................ 46
2.17 Pulse direction outputs and PWM function .......................................................... 47
2.18 RS-485/RS-422 communication interface ........................................................... 48

ILC 191 ME/X
6PHOENIX CONTACT 8607_en_03
2.19 Analog inputs....................................................................................................... 51
2.20 Analog outputs .................................................................................................... 53
2.21 Counter inputs ..................................................................................................... 54
2.22 Incremental encoder inputs ................................................................................. 56
3 The Inline controller under PC Worx/PC Worx Express ............................................................59
3.1 Software version.................................................................................................. 59
3.2 Assigning the IP address for the controller/BootP server..................................... 60
3.3 The Inline controller as a PROFINET device ....................................................... 63
3.4 Setting the realtime clock under PC Worx Express.............................................. 69
3.5 Download changes.............................................................................................. 69
3.6 Parameterization memory and Internet Explorer.................................................. 70
3.6.1 Internet Explorer FTP functionality ....................................................... 71
3.6.2 Activating/deactivating the FTP server ................................................. 71
3.6.3 Activating/deactivating the HTTP server .............................................. 72
3.7 Activating/deactivating the journaling function..................................................... 73
3.8 Activating/deactivating the MRP client function ................................................... 74
3.9 Function blocks for handling files on the parameterization memory..................... 75
3.10 Function blocks for Ethernet communication....................................................... 76
3.11 Function blocks for PCP communication ............................................................. 76
3.12 Function blocks for pulse width modulation ......................................................... 77
3.13 Function blocks for RS-232 communication ........................................................ 81
3.13.1 RS232_INIT function block .................................................................. 81
3.13.2 RS232_SEND function block ............................................................... 83
3.13.3 RS232_RECEIVE function block ......................................................... 85
3.14 Function blocks for RS-485/RS-422 communication ........................................... 87
3.14.1 RS485_422_INIT function block .......................................................... 87
3.14.2 RS485_422_SEND function block ....................................................... 89
3.14.3 RS485_422_RECEIVE function block ................................................. 91
3.15 Function blocks for counter inputs....................................................................... 93
3.15.1 Counter operating modes .................................................................... 96
3.16 Function blocks for incremental encoder inputs................................................... 98
3.16.1 Counter operating modes for incremental encoders .......................... 100
3.17 Alignment .......................................................................................................... 102
4 System variables and status information.................................................................................105
4.1 General notes .................................................................................................... 105
4.2 Status register for local digital inputs and outputs.............................................. 105
4.3 Status register for local analog inputs and outputs ............................................ 106
4.3.1 Representation of measured values for the local analog inputs ......... 107

Table of contents
8607_en_03 PHOENIX CONTACT 7
4.3.2 Representation of output values for the local analog outputs ............. 108
4.4 Status register for counter inputs....................................................................... 109
4.5 Status register for incremental encoder inputs................................................... 109
4.6 Diagnostic status register .................................................................................. 110
4.7 Diagnostic parameter register............................................................................ 111
4.8 PROFINET register............................................................................................ 112
4.9 IEC 61131 runtime system................................................................................. 113
4.10 Control processor .............................................................................................. 114
4.11 Power storage, realtime clock............................................................................ 114
4.12 Power supplies .................................................................................................. 114
4.13 Mode selector switch......................................................................................... 115
4.14 System time....................................................................................................... 115
5 Easy Motion function block library ..........................................................................................117
5.1 Characteristics of one-dimensional positioning axes......................................... 119
5.2 Homing (dynamic homing)................................................................................. 121
5.3 Starting up the Easy Motion function block library ............................................. 124
5.4 Function blocks of the Easy Motion function block library.................................. 125
5.4.1 M191_DRV1 and M191_DRV2 function blocks ................................. 126
5.4.2 M191_Power function block ............................................................... 129
5.4.3 M191_HomePARA function block ..................................................... 131
5.4.4 M191_Home function block ............................................................... 133
5.4.5 M191_MoveAbsolute function block .................................................. 135
5.4.6 M191_MoveRelative function block ................................................... 137
5.4.7 M191_MoveVelocity function block ................................................... 139
5.4.8 M191_Reset function block ............................................................... 141
5.4.9 M191_Stop function block ................................................................ 142
5.5 Simple application example............................................................................... 144
6 Technical data and ordering data ...........................................................................................145
6.1 Technical Data .................................................................................................. 145
6.1.1 Tolerance values for the analog inputs ............................................... 152
6.1.2 Tolerance values for the analog outputs ............................................ 153
6.2 Ordering data .................................................................................................... 154
6.2.1 Modules ............................................................................................. 154
6.2.2 Accessories ....................................................................................... 154
6.2.3 Software ............................................................................................. 154
6.2.4 Documentation ................................................................................... 154
A Appendix: Service and maintenance ......................................................................................155
A 1 Error causes and remedies............................................................................... 155

ILC 191 ME/X
8PHOENIX CONTACT 8607_en_03
A 2 Updating the Inline controller firmware ............................................................. 155
A 3 Connecting unshielded cables ......................................................................... 156
A 4 Connecting the shield....................................................................................... 157
B Appendix for document lists....................................................................................................159
B 1 List of figures .................................................................................................... 159
B 2 List of tables ..................................................................................................... 163
B 3 Index................................................................................................................. 167

Foreword
8607_en_03 PHOENIX CONTACT 9
1 Foreword
1.1 Purpose of this user manual
This user manual is intended to help you start up and operate the ILC 191 ME/AN and
ILC 191 ME/INC Inline controllers.
1.2 Hardware and software requirements
HW/SW Description
Inline controller ILC 191 ME/AN ILC 191 ME/INC
Parameterization
memory, plug-in
For ordering data, see Section
“Accessories” on page 154
For ordering data, see Section
“Accessories” on page 154
Ethernet cable Ethernet cable for connecting the Inline controller to a PC
Connecting cable Connecting cable for connecting the Inline controller to a PC (RS-
232, optional)
Automation software versions (Service Pack = SP)
PC Worx ≥6.30 *
PC Worx Express ≥6.30 *
* Part of the AUTOMATIONWORX Software Suite 2013 1.80
For the ordering data for hardware, software, and additional documentation, please refer
to Section “Technical data and ordering data” on page 145.
PROFINET device function
The PROFINET device function of the controllers is not supported by the
PC Worx Express software.

ILC 191 ME/X
10 PHOENIX CONTACT 8607_en_03

Description of the Inline controller
8607_en_03 PHOENIX CONTACT 11
2 Description of the Inline controller
2.1 General description of the Inline controller
The Inline controller is a modular small-scale controller with integrated Ethernet and
INTERBUS connections.
IEC 61131 control perfor-
mance
The Inline controller is consistently configured and programmed in accordance with
IEC 61131 using the PC Worx automation software. PC Worx can be operated via the net-
work (Ethernet). The powerful processor can be programmed in all five IEC 61131 program-
ming languages and ensures quick control task processing.
Integrated Ethernet con-
nection
The integrated Ethernet connection (via twisted pair cable) ensures Ethernet connectivity.
Throughout the Ethernet network, the Inline controller can be accessed via TCP/IP or
UDP/IP. The Inline controller has two fully implemented Ethernet connections, which are
switched inside the device.
Integrated communication functions enable direct and effective data exchange via Ether-
net. The Ethernet network provides universal options for communicating with the Inline con-
troller. Using the IP_USEND and IP_URCV communication blocks, information, e.g., nec-
essary coupling variables, can be exchanged between Inline controllers via Ethernet. This
enables distributed, modular automation solutions to be configured.
The existing IEC 61131-5 blocks have therefore been extended to include a transparent
TCP/IP mode and a transparent UDP/IP mode.
When using the AX OPC server provided in the AUTOMATIONWORX Software Suite Ver-
sion 1.30 or later, Inline controller data is available in the Ethernet network in a standardized
format and can be used for the different visualization packages.
PROFINET device
functionality
The PROFINET protocol can be used via the Ethernet interfaces of the Inline controller. In
this case, the Inline controller can be used as a PROFINET device.
Modbus functionality The Modbus TCP/UDP communication protocol can be used via the Ethernet interfaces of
the Inline controller. In this case, the Inline controller can be used as a Modbus client. For
additional information, please refer to the AH EN MODBUS TCP application note.
MRP The Media Redundancy Protocol (MRP) can be used via the Ethernet interfaces of the Inline
controller. The controller supports the MRP client function, which can be enabled or dis-
abled via PC Worx as an option. This function is disabled by default. If the function is en-
The ILC 191 ME/AN and ILC 191 ME/INC Inline controllers have the same appearance
and numerous identical functions.
The main differences between the Inline controllers are connectors 6 (ILC 191 ME/AN:
analog inputs, ILC 191 ME/INC: counter inputs) and 7 (ILC 191 ME/AN: analog outputs,
ILC 191 ME/INC: incremental encoder inputs), see from page 51 onwards.
In the following, the term Inline controller is used in general. Differences between the con-
trollers are particularly mentioned where necessary.
For information on how to configure the Inline controller as a PROFINET device in the
PC Worx software, please refer to Section “The Inline controller as a PROFINET device”
on page 63.

ILC 191 ME/X
12 PHOENIX CONTACT 8607_en_03
abled, it remains enabled after the supply voltage is switched off and on. If the controller has
been reset to the delivery state, the MRP client function will also be disabled again. In a ring
with Media Redundancy Protocol, maximum switch-over times of up to 200 ms can be ex-
pected.
Integrated INTERBUS
connection
An Inline local bus as well as an INTERBUS remote bus can be connected via the
INTERBUS connection. In this way you can create a complete INTERBUS system (maxi-
mum of 4 remote bus levels) using the Inline controller as a distributed controller.
The I/O level is connected to the Inline controller via INTERBUS.
RS-232 interface This interface can be used to either assign the IP address of the Inline controller and to ac-
cess the controller using the Diag+ diagnostic tool or to communicate with serial I/O devices
via function blocks.
RS-485/RS-422 interface An RS-485 network with several I/O devices can be created via the RS-485/RS-422 inter-
face. The interface is operated in PC Worx via the RS485_422_INIT,
RS485_422_RECEIVE, and RS485_422_SEND function blocks, see Section “Function
blocks for RS-485/RS-422 communication” on page 87.
Parameterization
memory/SD card
The Inline controller can be operated using a plug-in parameterization memory in the form
of an SD card. This memory can be used to save programs and configurations which belong
to your project, e.g., the visualization project.
The plug-in parameterization memory is optional and is not required in order to operate the
Inline controller.
The Inline controller cannot be programmed via the RS-232 interface.
The parameterization memory is not supplied as standard with the Inline controller.
Only use a parameterization memory provided by Phoenix Contact (for ordering data, see
Section “Accessories” on page 154).
NOTE: Parameterization memory (SD card) – formatting note
The SD card is already formatted and is intended for use with Phoenix Contact devices.
Make sure that the SD card is not reformatted.

Description of the Inline controller
8607_en_03 PHOENIX CONTACT 13
2.2 Possible fields of application of the Inline control-
ler
2.2.1 Controller as a distributed controller of an Inline station
The Inline controller can be used as a distributed controller of an Inline station which is con-
nected to an Ethernet system. A single Inline local bus (Figure 2-1) as well as a complete
INTERBUS system with a maximum of 4 remote bus levels (Figure 2-2) can be connected
to the Inline controller.
Inline local bus
Figure 2-1 Connected Inline local bus
Remote bus levels
Figure 2-2 Remote bus levels
FR
UL
FF
UM
SF
US
BF
E
Q3
Q4
Q1
Q2
I1 I2
I3 I4
I7 I8
I5 I6
RDY
D1 D2
P1
P2
FAIL
TxD
RxD
UA
BSA
O1
O2
PF
RS485/422
PWR
X2.1
LNK
PRG
X1
RUN/PROG
MRESET
D-32825Blomberg
ILC 191 ME/AN
Order-No.: 2700074
HW/FW: 00/100
MAC Addr. 8Block:
xx. xx. xx. xx
AUTOMATIONWORX
RESET
STOP
ACT
LNK
ACT
X2.2
Slot
PWR
DO
DI
PWM
AI
A0
Voltage
PWR 24 V
DO 24 V
DI 24 V
PWM 5 V
RS485/422
AI 0 - 10 V
A0 0 - 10 V
Ethernet
FR
UL FF
UM SF
US
BF
E
Q3 Q4
Q1 Q2
I1 I2
I3 I4
I7 I8
I5 I6
RDY
D1 D2
P1 P2
FAIL
TxD RxD
UA
BSA
O1 O2
PF
RS485/422
PWR
X2.1
LNK
PRG
X1
RUN/PROG
MRESET
D-32825Blomberg
ILC191 ME/AN
Order-No.:2700074
HW/FW:00/100
MACAddr. 8Block:
xx.xx. xx. xx
AUTOMATIONWORX
RESET
STOP
ACT
LNK
ACT
X2.2
Slot
PWR
DO
DI
PWM
AI
A0
Voltage
PWR 24V
DO 24 V
DI 24V
PWM 5 V
RS485/422
AI 0 - 10 V
A0 0- 10 V
1.
2.
3.
4.
Remote bus levels
Inline local bus
INTERBUS
INTERBUS
INTERBUS

ILC 191 ME/X
14 PHOENIX CONTACT 8607_en_03
2.2.2 The Inline controller for position control
The Inline controller offers Ethernet, RS-485, and pulse direction interfaces. This means
that electric motors can be driven via frequency inverters or other power electronics. Axis
limit switches and home position switches are connected directly to the Inline controller.
Analog inputs (ILC 191 ME/AN) are available for the position detection of a tool using a laser
measuring system, for example. The ILC 191 ME/INC has digital inputs for incremental en-
coders.
Figure 2-3 The Inline controller for position control
TR
DR1
ESC Enter
X10 X11
24V GND DI0 DI1 DI2 DI3 DI4 AO AI COM NC NO
D
R
1
X20 IN X21 OUT
PHOENIXCONTACT
GmbHCo. KG
Flachsmarktstrasse8
D-32825Blomberg
[email protected]
X2.2
LNK
ACT
X2.1
LNK
ACT
ILC191 ME/AN
Order-No.:2700074
HW/FW:00/100
MACAddr. 8Block:
xx.xx. xx. xx
AUTOMATIONWORX
MRESET RESET
X1
PRG
PWR
STOP
RUN/PROG
FR E
FF
SF
SF
UL
US
UM
Q2
Q4
Q1
Q3
I6
I8
I5
I7
P2
RDY FAIL BSA
D2
P1
D1 RxDTxD
S5S1
PF
O2O1I2
I4
I1
I3
Nr.
X1
X2
X3
X4
X5
X6
X7
Function
Power In
dig.Out
dig.In
PWM/ PTO
RS485/422
analogIn
analogOut
Voltage
24V
24V
24V
5V
0- 10 V
0- 10 V
X2.2
LNK
ACT
X2.1
LNK
ACT
ILC191 ME/AN
Order-No.:2700074
HW/FW:00/100
MACAddr. 8Block:
xx.xx. xx. xx
AUTOMATIONWORX
MRESET RESET
X1
PRG
PWR
STOP
RUN/PROG
FR E
FF
SF
SF
UL
US
UM
Q2
Q4
Q1
Q3
I6
I8
I5
I7
P2
RDY FAIL BSA
D2
P1
D1 RxDTxD
S5S1
PF
O2O1I2
I4
I1
I3
Nr.
X1
X2
X3
X4
X5
X6
X7
Function
Power In
dig.Out
dig.In
PWM/ PTO
RS485/422
analogIn
analogOut
Voltage
24V
24V
24V
5V
0- 10 V
0- 10 V
0 102030405060

Description of the Inline controller
8607_en_03 PHOENIX CONTACT 15
2.2.3 The Inline controller as a PROFINET device in a PROFINET
network
The following figure shows the example of an ILC 191 ME/AN as a PROFINET device in a
PROFINET network.
Figure 2-4 PROFINET device using the ILC 191 ME/AN as an example
Key:
APROFINET controller (in the example: RFC 470 PN 3TX Remote Field Controller)
BManaged Switch
CPROFINET device (in the example: ILC 191 ME/AN)
For additional information on how to integrate the Inline controller into a PROFINET net-
work as a PROFINET device, please refer to Section “The Inline controller as a PROFI-
NET device” on page 63.
FR
UL
FF
UM
SF
US
BF
E
Q3
Q4
Q1
Q2
I1 I2
I3 I4
I7 I8
I5 I6
RDY
D1 D2
P1
P2
FAIL
TxD
RxD
UA
BSA
O1
O2
PF
RS485/422
PWR
X2.1
LNK
PRG
X1
RUN/PROG
MRESET
D-32825 Blomberg
ILC 191 ME/AN
Order-No.: 2700074
HW/FW: 00/100
MAC Addr. 8Block:
xx. xx. xx. xx
AUTOMATIONWORX
RESET
STOP
ACT
LNK
ACT
X2.2
Slot
PWR
DO
DI
PWM
AI
A0
Voltage
PWR 24 V
DO 24 V
DI 24 V
PWM 5 V
RS485/422
AI 0 - 10 V
A0 0 - 10 V
PROFINET
A
B
PROFINET C
RUN/PROG
STP
MRESET
DISPLAY
RFC 470 PN 3TX
Ord.No.2916600
+
-
LNKLNK
LNK
USB
ACTACT
REMOTE
LAN1.1 LAN1.2
LAN2
I/O
24VDC

ILC 191 ME/X
16 PHOENIX CONTACT 8607_en_03
2.2.4 Applicative system redundancy using the Inline controller
The following figure shows an example of applicative system redundancy. The example
shows a PROFINET device with control function (ILC 191 ME/AN) that is connected to a
PROFINET network by means of a switch. Identical application programs run on both
higher-level PROFINET controllers. To achieve synchronization, both PROFINET control-
lers are connected via an Ethernet connection by means of a switch. PROFINET controller
A operates as primary controller, PROFINET controller B operates as backup controller.
Figure 2-5 Applicative system redundancy – example
APrimary controller (in the example: RFC 470 PN 3TX Remote Field Controller)
BBackup controller (in the example: RFC 470 PN 3TX Remote Field Controller)
CManaged Switches
DPROFINET device with control function (in the example: ILC 191 ME/AN with
PROFINET device function and Phoenix Redundancy Layer)
FR
UL
FF
UM
SF
US
DF
E
Q3
Q4
Q1
Q2
I1 I2
I3 I4
I7 I8
I5 I6
RDY
D1 D2
P1
P2
FAIL
TxD
RxD
UA
BSA
O1
O2
PF
RS485/422
PWR
X2.1
LNK
PRG
X1
RUN/PROG
MRESET
D-32825 Blomberg
ILC 191 ME/AN
Order-No.: 2700074
HW/FW: 00/100
MAC Addr. 8Block:
xx. xx. xx. xx
AUTOMATIONWORX
RESET
STOP
ACT
LNK
ACT
X2.2
Slot
PWR
DO
DI
PWM
AI
A0
Voltage
PWR 24 V
DO 24 V
DI 24 V
PWM 5 V
RS485/422
AI 0 - 10 V
A0 0 - 10 V
RUN/PROG
STP
MRESET
DISPLAY
RFC 470 PN 3TX
Ord.No.2916600
+
-
LNKLNK
LNK
USB
ACTACT
REMOTE
LAN1.1 LAN1.2
LAN2
I/O
24VDC
RUN/PROG
STP
MRESET
DISPLAY
RFC 470 PN 3TX
Ord.No.2916600
+
-
LNKLNK
LNK
USB
ACTACT
REMOTE
LAN1.1 LAN1.2
LAN2
I/O
24VDC
PROFINET
AB
CC
C
PROFINET
D
ETHERNETETHERNET
ETHERNET
Controllers with applicative
(programmed) redundancy
Network redundancy with
Media Redundancy Protocol
(MRP)
PROFINET devices with
Phoenix Redundancy Layer
For additional information on applicative system redundancy, please refer to the
AH EN APPLICATIVE SYSTEM REDUNDANCY application note. This application note
can be downloaded at phoenixcontact.net/products.

Description of the Inline controller
8607_en_03 PHOENIX CONTACT 17
2.3 Notes on using the Inline controller in potentially
explosive areas
Approval according to directive 94/9/EC
II 3G Ex nA IIC T4 Gc X
Installation notes
1. The Inline controller conforms to the requirements of protection type “n” and can be in-
stalled in a zone 2 potentially explosive area. The Inline controller is a category 3G item
of electrical equipment.
The Inline controller meets the requirements of EN 60079-0:2009 and
EN 60079-15:2012.
2. The Inline controller must only be installed, started up, and maintained by qualified spe-
cialist personnel.
3. Please follow the installation instructions given in the user manual and the package slip.
4. When installing and operating the device, the applicable safety directives (including na-
tional safety directives), accident prevention regulations, as well as general technical
regulations, must be observed.
5. For the safety data, please refer to the corresponding documentation (user manual,
package slip) and the certificates (declaration of conformity and other approvals, if ap-
plicable).
6. Access to the circuits inside the Inline controller is not permitted. Do not repair the Inline
controller yourself but replace it by an approved controller of the same type.
Repairs may only be performed by the manufacturer. The manufacturer is not liable for
harm resulting from noncompliance.
7. The IP20 (EN 60529) degree of protection for the device is designed for a clean and dry
environment.
8. Do not subject the Inline controller to mechanical strain and/or thermal loads, which ex-
ceed the limits specified in the product documentation.
9. The Inline controller is not designed for use in potentially dust-explosive atmospheres.
If dust is present, install the device in suitable, approved housing. Please note the sur-
face temperature of the housing.
Installation in zone 2
1. Observe the specified conditions for use in potentially explosive areas!
2. Install the device in a suitable approved housing (with at least IP54 protection according
to EN 60529) that meets the requirements of EN 60079-15.
3. In potentially explosive areas, only snap the device onto the DIN rail and remove it from
the DIN rail and connect and disconnect the cables when the power is disconnected.
4. Connect the DIN rail to protective earth ground.
5. Only connect devices to the supply and signal circuits in zone 2 that are suitable for op-
eration in potentially explosive areas of zone 2 and for the conditions at the installation
location.
6. For reliable operation, the RJ45 connector needs to have a fully functioning locking clip.
Repair any damaged connectors immediately.
WARNING: Explosion hazard
Make sure that the following notes and instructions are observed.

ILC 191 ME/X
18 PHOENIX CONTACT 8607_en_03
7. For safe operation with the plug-in parameterization memory, it must be completely
plugged and snapped in.
8. The programming interface may only be used if there is no potentially explosive atmo-
sphere.
Restrictions/limit values
1. Only Inline terminals that are approved for use in potentially explosive areas
may be snapped next to the Inline controller.
Before using the Inline terminal in a zone 2 potentially explosive area, check whether
this Inline terminal has been approved for installation within this area.
For a list of terminals that are approved for zone 2 potentially explosive areas, please
refer to the AH EN IL EX ZONE 2 application note.
2. Please make sure that the maximum permissible current of 4 A flowing through poten-
tial jumpers UMand US(total current) is not exceeded when using the Inline controller
in potentially explosive areas.
3. Also make sure that the maximum permissible current of 2 A flowing through potential
jumper ULis not exceeded.
4. The maximum permissible current for each spring-cage contact is 2 A.
2.4 Unpacking the Inline controller
The Inline controller is supplied in an ESD bag together with a package slip with installation
instructions. Read the complete package slip carefully before unpacking the Inline control-
ler.
NOTE: Electrostatic discharge
The Inline controller contains components that can be damaged or destroyed by electro-
static discharge. When handling the Inline controller, observe the necessary safety pre-
cautions against electrostatic discharge (ESD) according to EN 61340-5-1 and
IEC 61340-5-1.
NOTE:
To avoid possible damage to the Inline controller, unpack and pack the controller in ac-
cordance with the ESD regulations.

Description of the Inline controller
8607_en_03 PHOENIX CONTACT 19
2.5 Connection and operating elements
ILC 191 ME/AN
Figure 2-6 Structure of the ILC 191 ME/AN Inline controller
The Inline controller consists of the following components:
1Electronics base
2Slot for the parameterization memory/card holder (SD card)
3Reset button
4Mode selector switch
5RS-232 interface
6Ethernet connection
7Connector 1: power connector
8Connector 2: connector for digital outputs
9Connector 3: connector for digital inputs
10 Connector 4: connector for PWM outputs
11 Connector 5: connector for RS-485/RS-422 communication
12 Connector 6: connector for analog inputs
13 Connector 7: connector for analog outputs
14 Diagnostic and status indicators
15 End plate
The SD card is not supplied as standard with the Inline controller.
Please refer to the ordering data in Section “Accessories” on page 154.
FR
UL
FF
UM
SF
US
BF
E
Q3
Q4
Q1
Q2
I1 I2
I3 I4
I7 I8
I5 I6
RDY
D1
D2
P1
P2
FAIL
TxD
RxD
UA
BSA
O1
O2
PF
PWR
Slot Voltage
PWR 24 V
DO 24 V
DI 24 V
PWM 5 V
RS485/422
AI 0 - 10 V
A0 0 - 10 V
RS485/422
PWR
DO
DI
PWM
AI
A0
D-32825Blomberg
ILC 191 ME/AN
Order-No.: 2700074
HW/FW: 00/100
MAC Addr. 8Block:
xx. xx. xx. xx
AUTOMATIONWORX
X1
MRESET
STOP
RESET
RUN/PROG
ACT
LNK
ACT
LNK
PRG
1
2
3
4
5
6
78910 111213
14
15

ILC 191 ME/X
20 PHOENIX CONTACT 8607_en_03
ILC 191 ME/INC
Figure 2-7 Structure of the ILC 191 ME/INC Inline controller
The Inline controller consists of the following components:
1Electronics base
2Slot for the parameterization memory/card holder (SD card).
3Reset button
4Mode selector switch
5RS-232 interface
6Ethernet interfaces
7Connector 1: power connector
8Connector 2: connector for digital outputs
9Connector 3: connector for digital inputs
10 Connector 4: connector for PWM outputs
11 Connector 5: connector for RS-485/RS-422 communication
12 Plug 6: plug for counter inputs
13 Connector 7: connector for incremental encoder inputs (asymmetric; channels A, B,
and Z)
14 Diagnostic and status indicators
15 End plate
The SD card is not supplied as standard with the Inline controller.
Please refer to the ordering data in Section “Accessories” on page 154.
FR
UL
FF
UM
SF
US
BF
E
Q3
Q4
Q1
Q2
I1
C11
C12
C13
C14
A1
B1
Z1
I2
C21
C22
C23
C24
A2
B2
Z2
I3 I4
I7 I8
I5 I6
RDY
D1
D2
P1
P2
FAIL
TxD
RxD
BSA
PF
PWR
Slot Voltage
PWR24 V
DO 24 V
DI 24 V
PWM 5 V
RS485/422
CNT 5 - 24 V
Encoder 5 - 24 V
RS485/422
PWR
DO
DI
PWM
CNT
Encoder
D-32825Blomberg
ILC 191 ME/INC
Order-No.: 2700075
HW/FW: xx/xxx
MAC Addr. 8Block:
xx. xx. xx. xx
AUTOMATIONWORX
X1
MRESET
STOP
RESET
RUN/PROG
ACT
LNK
ACT
LNK
PRG
1
2
3
4
5
6
78910 111213
14
15
